To improve commutation accuracy and effectively suppress torque ripple in brushless DC motors (BLDCMs), this paper presents a novel commutation correction strategy integrated into an enhanced direct torque control (DTC) framework. The proposed method estimates the commutation angle error in real time by analyzing the integral difference in phase currents across adjacent 30° conduction intervals, enabling dynamic and accurate commutation correction. This correction mechanism is seamlessly embedded into a modified DTC algorithm that employs a three-level torque hysteresis comparator and introduces a novel zero-voltage vector selection strategy to minimize torque ripple. Compared with conventional DTC approaches employing dual-loop control and standard zero vectors, the proposed method achieves up to a 58% reduction in torque ripple along with improved commutation precision, as demonstrated through both simulation and experimental validation. These results confirm the method’s effectiveness and its potential for application in high-performance BLDCMs drive systems. Full article

To address the issue of control inaccuracy caused by the zero-offset fault in current sensors within the multiphase brushless DC motor (BLDCM) drive system, this paper proposes a fault diagnosis and fault-tolerant control method based on current signals. Different from traditional solutions that rely on hardware redundancy or precise modeling, this method constructs a dual-channel fault diagnosis framework by integrating the steady-state amplitude offset of the phase current after the fault and the abnormal characteristics of dynamic sector switching. Firstly, sliding time window monitoring is used to identify steady-state amplitude anomalies and locate faulty sectors. Subsequently, an algorithm for detecting the difference in current changes during sector switching is designed, and a logic interlocking verification mechanism is combined to eliminate false triggering and accurately locate single or multiple fault phases. Furthermore, based on the diagnostic information, a repeated iterative online correction method is adopted to restore the accuracy of the current measurement. This method only relies on phase current signals and rotor position information, does not require additional hardware support or accurate system models, and is not affected by the nonlinear characteristics of the motor. Finally, the experimental verification was carried out on a nine-phase BLDCM drive system. Experimental results indicate that the torque fluctuation of the system can be controlled within 5% through the fault-tolerant control strategy. Full article

This work focuses on the small Bearingless Brushless DC Motor (BL-BLDCM), to solve the problems, such as larger commutation torque ripple and difficult solution of air-gap magnetic field, a novel BL-BLDCM structure with like-tangential parallel-magnetization interpolar magnetic poles (LTPMIMPs) is proposed, which is abbreviated as BL-BLDCM-LTPMIMP in this work, and the analytical calculation model of its air-gap magnetic field has been investigated. First, inserting a like-tangential parallel magnetizing auxiliary magnetic pole between every two adjacent single-radial-magnetizing main poles, and forming several combination magnetic poles, each of which is composed of a radial-magnetizing main magnetic pole and two semi-auxiliary-magnetic-poles (with different magnetization directions) located on both sides. Then, by solving the Laplace equation and Poisson equation in every subdomain, and combining the relative permeability function, the analytical expressions of the air-gap magnetic fields for the BL-BLDCM-LTPMIMP was obtained. The armature reaction magnetic fields of the torque windings and suspension windings are also analyzed. Finally, through the finite element method (FEM), the correctness and computational accuracy of the analytical calculation model for the air-gap magnetic field is proven. Additionally, the comparison of electromagnetic characteristics with ordinary BL-BLDCM shows that the BL-BLDCM-LTPMIMP can not only effectively improve the amplitude and stability of electromagnetic torque on the basis of obtaining a shoulder-shrugged trapezoidal wave air-gap magnetic field but also has stable radial magnetic levitation force control characteristics. Full article

This work presents a sensorless brushless DC motor (BLDCM) drive control, optimized for solar photovoltaic (PV)- and battery-fed light electric vehicles (LEVs). A back-electromotive force (EMF) observer integrated with an enhanced quadrature-phase-locked-loop (QPLL) structure is proposed for accurate rotor position estimation, addressing limitations of existing control methods at low speeds and under dynamic conditions. The study replaces the conventional arc-tangent technique with a QPLL-based approach, eliminating low-pass filters to enhance system adaptability and reduce delays. The experimental results demonstrate a significant reduction in commutation error, with a nearly flat value at 0 degrees during steady-state and less than 8 degrees under dynamic conditions. Furthermore, the performance of a modified single-ended primary-inductor converter (SEPIC) for maximum power point tracking (MPPT) in solar-powered LEVs is verified, minimizing current ripple and ensuring smooth motor operation. The system also incorporates a regenerative braking mechanism, extending the vehicle’s range by efficiently recovering kinetic energy through the battery with 30.60% efficiency. The improved performance of the proposed method and system over conventional approaches contributes to the advancement of efficient and sustainable solar-powered BLDC motor-based EV technologies. Full article

This paper presents the design of a robust speed controller for brushless DC motors (BLDCMs) under field-oriented control (FOC). The proposed robust controller integrates extension theory (ET) and sliding mode theory (SMT) to achieve robustness. First, the speed difference between the speed command and the actual speed of the BLDCM, along with the rate of change of the speed difference, are divided into 20 interval categories. Then, the feedback speed difference and the rate of change of the speed difference are calculated for their extension correlation with each of the 20 interval categories. The interval category with the highest correlation is used to determine the appropriate control gain for the sliding mode speed controller. This gain adjustment tunes the parameters of the sliding surface in the SMT, thereby suppressing the overshoot of the motor’s speed. Because a sliding surface reaching law of the sliding mode controller (SMC) adopts the exponential approach law (EAL), the system’s speed response can quickly follow the speed command in any state and exhibit an excellent load regulation response. The simplicity of this robust control method, which requires minimal training data, facilitates its easy implementation. Finally, the speed control of the BLDCM is simulated using Matlab/Simulink software (2023b version), and the results are compared with those of the SMC using the constant-speed approach law (CSAL). The simulation and experimental results demonstrate that the proposed robust controller exhibits superior speed command tracking and load regulation responses compared to the traditional SMC. Full article

Torque ripple in a brushless DC motor (BLDCM) seriously restricts its application in high-performance fields. This paper proposes a commutation torque ripple suppression strategy based on a Zeta converter. The expected output voltage of a Zeta converter that suppresses the commutation torque ripple is obtained, according to the effect of the duty ratio of the Zeta converter on the turn-off phase freewheeling duration and the turn-on phase rising duration, during commutation. Based on the analysis of the dynamic response of the Zeta converter, the Zeta converter is adjusted to ensure that the Zeta converter reaches stability in sufficient time. During the commutation, the output voltage of the Zeta converter is connected to the main circuit to reduce the torque ripple during commutation, and the expected regulated duty cycle of the Zeta converter during the next commutation is calculated to adjust the output voltage of the Zeta converter. Based on this analysis, the experimental results verify the effectiveness of the proposed method. Full article

Single-phase input rectifier brushless DC motor drives with a small film capacitor have many advantages, such as high power density and high reliability. However, when the motor system operates in regenerative braking mode, the dc-link capacitor with reduced capacitance may suffer from overvoltage without adding additional hardware circuits. At the same time, the braking torque control of the motor will be affected by speed variations. In order to ensure smooth and reliable operation of the motor system, an anti-overvoltage braking torque control method is proposed in this article. The relationship among the dc-link capacitance, the dc-link capacitor voltage, and the speed during regenerative braking is analyzed quantitatively, and the speed at which the regenerative braking is switched to the plug braking is obtained, which in turn consumes the capacitor energy to avoid dc-link overvoltage. Additionally, based on the relationship between the controllability of the braking torque and the speed, a reference value of the braking current that matches the speed is designed. The proposed method makes use of the capacitor’s energy storage during regenerative braking. Meanwhile, it mitigates the impact of motor speed on braking torque. Finally, the effectiveness of the proposed method is verified on a motor platform equipped with the dc-link film capacitor. Full article

Accurate knowledge of the rotor position is essential for the control of brushless DC motors (BLDCM). Any deviation in this identification can cause fluctuations in motor current and torque, increase noise, and lead to reduced motor efficiency. This paper focused on a BLDCM equipped with a three-phase binary Hall sensor. Based on the principle of minimum deviation, this paper estimated the relative installation offset between the Hall sensors. It also provided a clear method for ideal phase commutation position recognition and eliminated the Hall sensor installation position deviation. The proposed pre-calibration method identified and eliminated the offset of the permanent magnet poles, the delay time caused by the Hall signal conditioning circuit, and the offset of the sensor signal identification due to armature response under different loads. Based on the pre-calibration results, a correction strategy for correcting the rotor position information of BLDCMs was proposed. This paper presented a self-adaptive position information prediction algorithm based on the Sage–Husa method. This filters out rotor position information deviations that are not eliminated in pre-calibration. Experimental results on a hydrogen circulation pump motor showed that, after the pre-calibration method was adopted, the Mean Square Error (MSE) of motor speed fluctuations decreased by 92.0%, motor vibration was significantly reduced, average phase current decreased by 62.8%, and the efficiency of the hydrogen circulation pump system was significantly improved. Compared to the traditional KF prediction algorithm, the Sage–Husa adaptive position information prediction algorithm reduced the speed fluctuation during the uniform speed operation stage and speed adjustment stage, the speed curve overshoot, and the commutation time deviation throughout the process by 44.8%, 56.0%, 54.9%, and 14.7%, respectively. This indicates a higher disturbance rejection ability and a more accurate and stable prediction of the commutation moment. Full article

The permanent magnet brushless DC motor (BLDCM) is typically controlled using the six-step commutation method, and the flux-weakening method is employed to enable the motor to operate at speeds higher than the base speed. Currently, it is considered that the weak magnetic angle range is 0-pi/3, while the range for deep weakening is pi/3-pi/2. In field-weakening control, a forward shift of the commutation point results in a circulating current flowing in the three-phase bridge of the inverter and the stator winding of the motor. This paper analyses the principle of the circulating current formed by the inverter. Through magnetic potential analysis and Simulink simulation, it is concluded that flux-weakening control generates a circulating current in the inverter and motor stator windings. The inverter’s circulating current affects the motor’s magnetic potential, causing it to shift towards the rotating direction of the motor rotor. When the forward shift angle of the inverter commutation point is within the range of 0-pi/6 electrical angle, the phase shift of the inverter circulating current remains below pi/6. This configuration weakens the magnetic field and provides the driving effect. However, when the forward shift angle falls within the range of pi/6-pi/3, the phase shift of the inverter circulating current exceeds pi/6, resulting in magnetic weakening and braking. During the braking effect, a reverse torque is generated, leading to a decrease in motor torque and efficiency. Therefore, the range of the weak magnetic angle should be between 0-pi/6. Full article

This article presents a brushless DC motor (BLDCM) drive for a maritime electric vehicle (MEV) application. The presented BLDCM drive uses a bridgeless Cuk-buckboost (BL-Cuk-BB) converter for input-side power factor (PF) improvement. The BL-Cuk-BB converter uses the buckboost converter for the negative half-cycles of the input AC voltages and the Cuk converter for the positive half-cycles. In the case of MEVs, the drive systems are generally fed by diesel engine generators (DEGs). The asymmetric BL-Cuk-BB converter is operated in a discontinuous inductor current mode (DICM) in the present work to attain better power quality. The usage of a second-order buckboost converter with a fourth-order Cuk converter results in a decrement in the net order of the system. Additionally, the input inductor of the Cuk converter also participates as the filter component along with capacitor C₂ during buckboost converter operation to enhance the power quality. The total component count reduction in the BL-Cuk-BB converter is also achieved by eliminating the usage of extra/external back-feeding diodes, which are generally used in bridgeless schemes. The present scheme uses the inbuilt anti-parallel diodes for the same purpose. The lesser components requirement in the BL-Cuk-BB-converter-based BLDCM drive implies lesser cost and volume, along with greater reliability, lower conduction losses, and lower weight of the BLDCM drive, which adds to the merits of the model. The paper includes a detailed mathematical model and stability analysis using pole-zero maps and bode plots of the BL-Cuk-BB converter for each half-supply AC voltage cycle. The BL-Cuk-BB-converter-based BLDCM drive for an EV application has been developed on the MATLAB/Simulink platform for a DICM operation, and the MATLAB simulation results have been presented for validation of the BL-Cuk-BB-converter-based BLDCM drive. Full article

This paper presents a new position sensorless control strategy for a brushless DC motor (BLDCM) driven by a four-switch three-phase inverter (FSTPI). This strategy introduces a flux-linkage function, which changes obviously at the time of the extremum jump. In the proposed strategy, the extremum jump edge determines the six commutation points needed for motor commutation. Then the high-precision and reliable commutation of the BLDCM is realized. This strategy can be used on BLDCM driven by FSTPI. Compared with other position sensorless control methods for BLDCM driven by FSTPI, the proposed method does not need to set a threshold value to detect the commutation point. It can obtain six commutation points required for motor commutation without interpolation. This avoids commutation errors caused by threshold value setting and interpolation. In addition, this strategy adopts a three-phase current control method for BLDCM driven by FSTPI. It can effectively restrain the current distortion of the capacitor middle point connection phase. And the terminal voltage is calculated. It can avoid the error caused by hardware sampling and improve the accuracy of the position sensorless control strategy. The experimental results verify the correctness of the theory and the effectiveness of the method. Full article

Although brushless direct current motor (BLDCM) drives are becoming more popular in industrial and commercial applications, there are still significant difficulties and unresolved research issues that must be addressed. In BLDCM drives, commutation current ripple (CCR) and diode freewheeling during non-commutation zone (NCZ) are the major challenges. To overcome these limitations, this paper proposes a novel PWM-Model Antiseptic Control (PWM-MAC) technique to alleviate the freewheeling of the diode. The proposed PWM technique is used to alleviate the diode freewheeling in the NCZ, whereas the DCLV circuit is utilized to obtain variable DC-link voltage to address the CCR in the CZ. The MATLAB/Simulink results are included along with experimental results obtained from a laboratory prototype of 325 W. The proposed module reduces the current ripple by 31.7% and corresponding torque ripples are suppressed by approximately 32.5%. This evidences the performance of the proposed control technique. Full article

In recent decades, there has been a growing interest in the design and development of power loss reduction in electric drive systems. To realize the full potential of the Brushless DC motor (BLDCM), the design methodology of an effective intelligent controller is vital. On the other hand, the Landsman converter is used in a bridgeless configuration to enhance the power factor and minimize the power loss of the BLDCM. In addition, BLDCM utilizes the different intelligent controllers that are used to decrease power loss. The performance of the Landsman converter and CSC converter is analyzed concerning various configurations/stages, and the numerical MATLAB 2016a simulation results are discussed to arrive at the suitable intelligent controller for the BLDC motor, and comparison results are presented. The proposed converter is designed and validated using hardware implementation by minimizing power loss. Effectiveness can be tested and valued for the proposed controller for the various intelligent controllers of BLDCM. Full article

With the wide application of permanent magnet brushless DC motors (BLDCMs) in home appliances and electric vehicles, there is increasing demand for BLDCMs with low vibration and noise. This paper aims to study the dynamic characteristics of a type of BLDCM with a rolling rotor. Firstly, a dynamic model of a BLDCM with eighteen degrees of freedom (18 DOFs) is built, for which the electromagnetic force and the oil-film force of the sliding bearing are considered. Then, the system responses are solved by Runge–Kutta numerical method, and the effects of the rotational speed, bearing backlash and eccentric distance of the rolling rotor on the dynamic response are analyzed in detail. The time history, frequency plot, axis trajectory diagram and phase portrait are introduced to discuss the dynamic behavior of the motor system. Analysis results show that eccentric force increases obviously with increasing rotational speed or eccentric distance, which can change the dynamic response through suppressing the electromagnetic force. The effect of bearing clearance on the rotor and stator is negatively correlated. Therefore, system parameters should be determined properly to improve the running performance of the motor system. Numerical results can provide a useful guide for the design and vibration control of such motor systems. Full article

This study examines the dynamics in a brushless DC motor (BLDCM) and methods used to control potentially chaotic behavior or behavior similar to chaotic processes in these systems. Bifurcation diagrams revealed complex nonlinear behaviors over a range of parameter values. In the resulting bifurcation diagram, period-doubling bifurcation, period-three bifurcation, and chaotic behavior can clearly be seen. We used Lyapunov exponents and Lyapunov dimensions to show the occurrence of chaos in a BLDCM. We then used the state feedback method to control chaos behaviors in the same BLDCM. Numerical simulations show the feasibility of the suggested means. Analysis of robustness against parametric perturbation in a BLDCM was performed from the perspective of Lyapunov stability theory and by using numerical simulations. We believe that studying the nonlinear dynamics and controlling chaos in BLDCMs will help to advance the development of high-performance electric vehicles. Full article
