Dynamic Characteristic Analysis of Permanent Magnet Brushless DC Motor System with Rolling Rotor
Abstract
:1. Introduction
2. Dynamic Model of the Rotor–Bearing–Stator System for the BLDCM
2.1. Model of the BLDCM
2.2. Oil-Film Force of Sliding Bearing
2.3. Electric Magnetization Analysis of the BLDCM
2.4. Equations of Motion
3. Dynamic Response of the BLDCM System
3.1. Analysis of the Effects of Rotational Speed
3.2. Analysis of the Effects of the Eccentric Distance
3.3. Analysis of the Effects of the Bearing Clearance
4. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
Appendix A. Matrixes M, C and K
Appendix B. 3D Dynamic Response Curves
References
