As an evolutionary advancement to conventional synthetic aperture radar (SAR), passive bistatic SAR (PBSAR) utilizing geostationary orbit (GEO) satellite signals demonstrates significant potential for high-resolution imaging. However, PBSAR faces dual challenges in computational efficiency and phase error compensation. Traditional accelerated back-projection (BP) variants developed from monostatic SAR are incompatible with PBSAR’s geometry, and autofocus BP (AFBP) methods exhibit prohibitive computational costs and inadequate space-variant phase error handling. This study first develops a bistatic ground Cartesian back-projection (BGCBP) algorithm through subimage wavenumber spectrum correction, specifically adapted to GEO-satellite-based PBSAR. Compared to conventional BP, the BGCBP achieves an order-of-magnitude complexity reduction without resolution degradation. Building upon this foundation, we propose a subimage autofocus BGCBP (SIAF-BGCBP) methodology, synergistically integrating autofocus processing with BGCBP’s accelerated framework. SIAF-BGCBP reduces phase estimation’s complexity by 90% through subimage pixel density optimization while maintaining estimation accuracy. Further enhancement of SIAF-BGCBP via geometric inversion would enable the precise compensation of space-variant phase errors while remaining efficient. Simulations and real-environment experiments verify the effectiveness of the proposed methods. Full article

This paper describes a flexible and seamless processor for Unmanned Aerial Vehicle (UAV)-borne Synthetic Aperture Radar (SAR) imagery. When designing a focusing algorithm for large-scale and high-resolution SAR images, efficiency and accuracy are two mandatory aspects to consider. The proposed processing scheme is based on a modified version of Fast Factorized Back-Projection (FFBP), in which the factorization procedure is interrupted on the basis of a computational cost analysis to reduce the number of complex operations at its minimum. The algorithm gains efficiency in the case of low-altitude platforms, where there are significant variations in azimuth resolution, but not in the case of conventional airborne missions, where the azimuth resolution can be considered constant in the swath. The algorithm’s performance is derived by assessing the number of complex operations required to focus an SAR image. Two scenarios are tackled in a numerical simulation: a UAV-borne SAR with a short synthetic aperture and a wide field of view, referred to as the ground-based-like (GBL) scenario, and a classical stripmap scenario. In both cases, we consider mono-static and bi-static radar configurations. The results of the numerical simulations show that the proposed algorithm outperforms FFBP in the stripmap scenario while achieving the same performance as FFBP in the GBL scenario. In addition, the algorithm is validated thanks to an experimental UAV-borne SAR campaign in the X-band. Full article

Tomographic synthetic aperture radar (TomoSAR) is an advanced three-dimensional (3D) synthetic aperture radar (SAR) imaging technology that can obtain multiple SAR images through multi-track observations, thereby reconstructing the 3D spatial structure of targets. However, due to system limitations, the multi-baseline (MB) monostatic SAR (MonoSAR) encounters temporal decorrelation issues when observing the scene such as forests, affecting the accuracy of the 3D reconstruction. Additionally, during TomoSAR observations, the platform jitter and inaccurate position measurement will contaminate the MB SAR data, which may result in the multiplicative noise with phase errors, thereby leading to the decrease in the imaging quality. To address the above issues, this paper proposes a MB bistatic SAR (BiSAR) 3D imaging method based on the phase error calibration that combines the phase gradient autofocus (PGA) and energy balance intensity-squared optimization autofocus (EB-ISOA). Firstly, the signal model of the MB one-stationary (OS) BiSAR is established and the 3D imaging principle is presented, and then the phase error caused by platform jitter and inaccurate position measurement is analyzed. Moreover, combining the PGA and EB-ISOA methods, a 3D imaging method based on the phase error calibration is proposed. This method can improve the accuracy of phase error calibration, avoid the vertical displacement, and has the noise robustness, which can obtain the high-precision 3D BiSAR imaging results. The experimental results are shown to verify the effectiveness and practicality of the proposed MB BiSAR 3D imaging method. Full article

Spotlight/sliding spotlight modes can achieve higher resolution than the other imaging modes and are widely used in object detection and recognition applications. This paper reviews the progress of the spaceborne spotlight/sliding spotlight SAR imaging field. The three steps of the current spaceborne spotlight/sliding spotlight SAR imaging algorithm framework are discussed in this paper. These include the following: eliminating the azimuth spectral aliasing by azimuth deramp preprocessing; implementing imaging processing using imaging kernels (RD, CS, RMA, etc.); and degrading the back-folded phenomenon in the final focused image domain by reference function multiplication post-processing. The different imaging kernels, consisting of RD, CS, RMA, BAS, FS, and PFA, are presented. The phase errors in high-resolution spaceborne spotlight/sliding spotlight SAR imaging, especially the stop-and-go error, curved orbit error, and tropospheric delay error, are analyzed in detail. Furthermore, the autofocus methods are described. In addition, some new imaging SAR systems based on spotlight/sliding spotlight SAR mode, which have more advantages than the classic spaceborne spotlight/sliding spotlight SAR imaging, were shown in this paper. These include FMCW-based systems, multichannel systems, varying-PRF systems, and bistatic systems. Full article

A bistatic synthetic aperture radar (BiSAR) system with a Medium-Earth-Orbit (MEO) SAR transmitter and high-maneuvering receiver (MEO/HM-BiSAR) can achieve a wide swath and high resolution. However, due to the complex orbit characteristics and the nonlinear trajectory of the receiver, MEO/HM-BiSAR high-resolution imaging faces two major challenges. First, the complex geometric configuration of the BiSAR platforms is difficult to model accurately, and the ‘non-stop-go’ effects should also be considered. Second, non-negligible wavefront curvature caused by the nonlinear trajectories introduces residual phase errors. The existing spaceborne BiSAR imaging algorithms often suffer from image defocusing if applied to MEO/HM-BiSAR. To address these problems, a novel high-resolution imaging algorithm named MSSWCC (Modified Second-Order Space-Variant Wavefront Curvature Correction) is proposed. First, a high-precision range model is established based on an analysis of MEO SAR’s orbital characteristics and the receiver’s curved trajectory. Based on the echo model, the wavefront curvature error is then addressed by two-dimensional Taylor expansion to obtain the analytical expressions for the high-order phase errors. By analyzing the phase errors in the wavenumber domain, the compensation functions can be designed. The MSSWCC algorithm not only corrects the geometric distortion through reverse projection, but it also compensates for the second-order residual spatial-variant phase errors by the analytical expressions for the two-dimensional phase errors. It can achieve high-resolution imaging ability in large imaging scenes with low computational load. Simulations and real experiments validate the high-resolution imaging capabilities of the proposed MSSWCC algorithm in MEO/HM-BiSAR. Full article

In 2023, the Chinese company PIESAT launched the multi-static X-band SAR constellation Hongtu-1 (HT1). HT1 consists of the active monostatic SAR sensor HT1-A and the three additional passive SAR receivers HT1-B, HT1-C and HT1-D. The passive sensors are arranged as a cartwheel in a circle around the active sensor. For our SAR interferometric investigation, we were able to use a multi-static HT1 recording. After a brief introduction of HT1, we describe the processing performed. Based on the phases of the six single-pass interferometric pairs, we calculated height differences relative to the Copernicus DEM. Larger deviations were observed mainly for mining areas and for forest areas. Thanks to the simultaneous acquisition of the interferometric pairs, the high spatial resolution and the good signal quality, the necessary processing was relatively easy to perform. Besides the interferometric phase, we also investigated possible applications of multi-static coherence. Forest can be recognized by its reduced single-pass coherence values. Based on our results, we expect that the multi-static HT1 coherence and its dependence on the interferometric baseline can be used to estimate parameters such as forest biomass. Full article

This paper analyzes the advantages and the drawbacks of using the Synthetic Aperture Radar (SAR) azimuth multichannel technique known as Multi-Aperture Processing Scheme (MAPS), in a set of relevant application cases that are far from the canonical ones. In the scientific literature on this topic, equally distributed azimuth channels with the quasi-monostatic deployment are assumed. With this research, we aim at extending the models from the current literature to (i) a generic bistatic acquisition geometry, (ii) a set of cases where the number of receiving tiles is not the same for each channel, or (iii) the tiles are shared between adjacent channels thus creating an overlapping configuration. The paper introduces the mathematical models for the listed non-conventional MAPS cases. Dealing with the bistatic MAPS, we first solve the problem by interpreting multichannel acquisition as a bank of Linear Time Invariant (LTI) filters. Then, a more physical approach, based on discrimination of the direction of arrivals (DoAs) is pursued. The effectiveness of the two methods and the advantages of the second approach on the first are proved by using a simplified 1D end-to-end simulation. Even limiting to the monostatic configuration, the azimuth antenna tiles have always been supposed equally partitioned among the RX channels. Overcoming this limit has two advantages: (i) more MAPS possible solutions in case few azimuth tiles are available, as in the ROSE-L mission; (ii) the number of channels can be designed independently of the number of tiles, also allowing asymmetric solutions, useful for a phase array antenna with an odd number of tiles such as in the SAOCOM-1 mission. Conversely, sharing one or more receiving tiles in different receiving channels makes the input noise partially correlated. The drawback is an increase in the noise level. A trade-off is determined for the different solutions obtained using simulations with real mission parameters. The theoretical performance and the end-to-end simulations are compared. Full article

Bistatic and multistatic SAR technology, with its multi-dimensional, ultra-wide swath, and high-resolution advantages, is widely used in earth observation, military reconnaissance, deep space exploration, and other fields. The LuTan-1 (LT-1) mission employs two full-polarimetric L-band SAR satellites for the BiSAR system. The bistatic mode introduces phase errors in echo reception paths due to different transmission links, making echo compensation a key factor in ensuring BiSAR performance. This paper proposes a novel bistatic internal calibration strategy that combines ground temperature compensation, in-orbit internal calibration, and pulsed alternate synchronization to achieve echo compensation. Prior to launch, temperature compensation data for the internal calibration system are obtained via temperature experiments. During in-orbit operation, calibration data are acquired by executing the internal calibration pulse sequence and noninterrupted pulsed alternate synchronization. In ground processing, echo compensation is completed based on the above two parts of calibration data. A comprehensive analysis of the entire calibration chain reveals a temperature compensation accuracy of 0.10 dB/1.38°. Additionally, a ground verification system is established to conduct BiSAR experiments, achieving a phase synchronization accuracy of 0.16°. Furthermore, the in-orbit test obtained DSM products with an average error of 1.3 m. This strategy provides a valuable reference for future spaceborne bistatic and multistatic SAR systems. Full article

The EarthExplorer 10 mission Harmony by the European Space Agency ESA, scheduled for launch around 2029–2030, consists of two passive C-band synthetic-aperture-radar companion satellites flying in a flexible constellation with one Sentinel-1 radar satellite as an illuminator. Sentinel-1 will serve as transmitter and receiver of radar waves, and the two Harmonys will serve as bistatic receivers without the ability to transmit. During the first and last year of the 5-year mission, the two Harmony satellites will fly in a cross-track interferometric constellation, such as that known from TanDEM-X, about 350 km ahead or behind the assigned Sentinel-1. This constellation will provide 12-day repeat DEMs, among other regions, over most land-ice and permafrost areas. These repeat DEMs will be complemented by synchronous lateral terrain displacements from the well-established offset tracking method. In between the cross-track interferometry phases, one of the Harmony satellites will be moved to the opposite side of the Sentinel-1 to form a symmetric bistatic “stereo” constellation with ±~350 km along-track baseline. In this phase, the mission will provide opportunity for radar interferometry along three lines of sight, or up to six when combining ascending and descending acquisitions, enabling the measurement of three-dimensional surface motion, for instance sub- and emergence components of ice flow, or three-dimensional deformation of permafrost surfaces or slow landslides. Such measurements would, for the first time, be available for large areas and are anticipated to provide a number of novel insights into the dynamics and mass balance of a range of mass movement processes. Full article

The satellite–ground bistatic configuration, which uses geosynchronous synthetic aperture radar (GEO SAR) for illumination and ground equipment for reception, can achieve wide coverage, high revisit, and continuous illumination of interest areas. Based on the analysis of the signal characteristics of GEO satellite–ground bistatic SAR (GEO SG-BiSAR), it is found that the bistatic echo signal has problems of azimuth spectrum aliasing and 2-D spatial variability. Therefore, to overcome those problems, a novel SAR imaging method for a GEO SG-BiSAR system with severe azimuth spectrum aliasing and 2-D spatial variability is proposed. Firstly, based on the geometric configuration of the GEO SG-BiSAR system, the time-domain and frequency-domain expressions of the signal are derived in detail. Secondly, in order to avoid the increasing cost caused by traditional multi-channel reception technology and the processing burden caused by inter-channel errors, the azimuth deramping is executed to solve the azimuth spectrum aliasing of the signal under the special geometric structure of GEO SG-BiSAR. Thirdly, based on the investigation of azimuth and range spatial variability characteristics of GEO SG-BiSAR in the Range Doppler (RD) domain, the azimuth spatial variability correction strategy is proposed. The signal corrected by the correction strategy has the same migration characteristics as monostatic radar. Therefore, the traditional chirp scaling function (CSF) is also modified to solve the range spatial variability of the signal. Finally, the two-dimensional spectrum of GEO SG-BiSAR with modified chirp scaling processing is derived, followed by the SPECAN operation to obtain the focused SAR image. Furthermore, the completed flowchart is also given to display the main composed parts for GEO SG-BiSAR imaging. Both azimuth spectrum aliasing and 2-D spatial variability are taken into account in the imaging method. The simulated data and the real data obtained by the Beidou navigation satellite are used to verify the effectiveness of the proposed method. Full article

The GNSS-based bistatic SAR (GNSS-BSAR) system has emerged as a hotspot due to its low power consumption, nice concealment, and worldwide reach. However, the weak landing power density of the GNSS signal often necessitates prolonged integration to achieve an adequate signal-to-noise ratio (SNR). In this case, the effects of the receiver’s time-frequency errors and atmospheric disturbances are significant and cannot be ignored. Therefore, we propose an ionospheric scintillation compensation-based imaging scheme for dual-channel GNSS-BSAR system. This strategy first extracts the reference phase, which contains the ionospheric phase scintillation and other errors. Subsequently, the azimuth phase of the target is divided into difference phase and reference phase. We apply the two-step phase compensation to eliminate Doppler phase errors, thus achieving precise focusing of SAR images. Three sets of experiments using the GPS L5 signal as the illuminator were conducted, coherently processing a 1.5 km by 0.8 km scene about 300 s. The comparative results show that the proposed method exhibited better focusing performance, avoiding the practical challenges encountered by traditional autofocus algorithms. Additionally, ionospheric phase scintillation extracted at different times of the day suggest diurnal variations, preliminary illustrating the potential of this technology for ionospheric-related studies. Full article

The LuTan-1 (LT-1) mission, China’s first civilian bistatic spaceborne Synthetic Aperture Radar (SAR) mission, comprises two L-band SAR satellites. These satellites operate in bistatic InSAR strip map mode, maintaining a formation flight with an adjustable baseline to generate global digital elevation models (DEMs) with high accuracy and spatial resolution. This research introduces a dedicated interferometric calibration model for LT-1, tackling the unique challenges of the bistatic system, such as interferometric parameter coupling and the $\pi$-ambiguity problem caused by synchronization phase errors. This study validates the model using SAR images from LT-1 and Xinjiang corner reflector data, achieving interferometric phase accuracy better than 0.1 rad and baseline accuracy better than 2 mm, thereby producing high-precision DEMs with a height accuracy meeting the 5 m requirement. Full article

To address the challenge of achieving both temporal consistency and spatial continuity in Earth observation data of polar regions, this paper proposes an innovative concept of Moon-based/Highly Elliptical Orbit (HEO) Spaceborne Bistatic Synthetic Aperture Radar (MH-BiSAR), with transmitters on the Moon and receivers on HEO satellites. By utilizing ephemeris data and an orbit propagator, this study explores MH-BiSAR’s geometric coverage capabilities in polar regions and conducts a preliminary analysis of its characteristics. The findings reveal that MH-BiSAR could provide continuous multi-day revisit observations of polar regions within each sidereal month, presenting a significant advantage for monitoring high-dynamic and large-scale scientific phenomena, such as polar sea ice observations. This innovative observational method offers a new perspective for polar monitoring and is expected to deepen our understanding of polar phenomena. Full article

The PIESAT-01 constellation is the world’s first multi-baseline distributed synthetic aperture radar (SAR) constellation with a “Cartwheel” formation. The “Cartwheel” formation is a unique formation in which four satellites fly in companion orbits, ensuring that at any given moment, the main satellite remains at the center, with three auxiliary satellites orbiting around it. Due to this unique configuration of the PIESAT-01 constellation, four images of the same region and six pairs of baselines can be obtained with each shot. So far, there has been no imaging and interference research based on four-satellite constellation measured data, and there is an urgent need to explore algorithms for the “Cartwheel” configuration imaging and digital surface model (DSM) production. This paper introduces an improved bistatic SAR imaging algorithm under the four-satellites interferometric mode, which solves the problem of multi-orbit nonparallelism in imaging while ensuring imaging coherence and focusing ability. Subsequently, it presents an interferometric processing method for the six pairs of baselines, weighted fusion based on elevation ambiguity from different baselines, to obtain a high-precision DSM. Finally, this paper selects the Dingxi region of China and other regions with diverse terrains for imaging and DSM production and compares the DSM results with ICESat-2 global geolocated photon data and TanDEM DSM data. The results indicate that the accuracy of PIESAT-01 DSM meets the standards of China’s 1:50,000 scale and HRTI-3, demonstrating a high level of precision. Moreover, PIESAT-01 data alleviate the reliance on simulated data for research on multi-baseline imaging and multi-baseline phase unwrapping algorithms and can provide more effective and realistic measured data. Full article

The use of bistatic polarimetric SAR for rough surface observation has attracted increasing interest in recent years, with its acquisition of additional polarimetric information. In this paper, we investigate the sensitivity of polarimetric variables to soil moisture and surface roughness, with the intention of locating favorable bistatic geometries for soil moisture retrieval. However, in the bistatic setting, the expanded imaging geometry is convolved with the polarimetric scattering response along with the in-scene variations in the soil moisture and surface roughness. The probing polarization states continuously evolve with the bistatic geometry, incurring varying polarization orientation angles. In this investigation, we propose to first compensate the bistatic polarimetric observations for the geometry-induced polarization rotation. Simulations based on a two-scale rough surface scattering model are then used to evaluate the optimal imaging geometry for the best sensitivity to the soil moisture content. We show the different sensing geometries associated with a full list of common polarimetric variables, as we seek favorable bistatic geometries in non-specular directions. The influences of both surface roughness scales are evaluated, with the small-scale roughness parameter imposing the greatest limitation on our results. Full article
