Search Results (14)

Laser wire directed energy deposition (LWDED) has garnered significant attention for the fabrication of large metallic components. However, the complex coupling effects among its process parameters pose challenges for porosity control. Optimizing parameter combinations to effectively minimize porosity is therefore critical to the broader adoption of this technology. In this study, systematic experiments and modeling were conducted to optimize the LWDED process parameters and predict porosity. First, single-factor and orthogonal experiments were performed to evaluate the individual effects of laser power, scanning speed, wire feeding speed, and air pressure on porosity. Subsequently, range analysis and analysis of variance were employed to determine the influence of each parameter and the significance of their interactions. Four machine learning models—SVR, RF, GPR, and XGBoost—were then trained and compared. Among them, the SVR model exhibited the best predictive performance, achieving an R² of 0.8960, an RMSE of 0.19, and an MAE of 0.15, outperforming the other three models. Based on this, the SVR model was further utilized to establish the mapping between process parameters and porosity. Contour maps and three-dimensional surface plots were generated to visualize porosity variation patterns under interacting parameters. Validation experiments showed that the maximum relative error between model predictions and experimental measurements was 0.514%, with an average error of 0.251%. This study provides a reliable reference for selecting low-porosity parameter combinations in the LWDED fabrication of 5356 aluminum alloy components. Full article

Ground-penetrating radar (GPR) is widely used for thickness or compaction degree detection of asphalt pavement layers, where the dielectric properties of asphalt mixtures serve as a key parameter influencing detection accuracy. These properties are closely related to the composition of the mixture and are susceptible to environmental factors such as water or ice. To clarify the influence of various factors on the dielectric behavior of asphalt mixtures, an experimental study was conducted under controlled environmental conditions. Asphalt mixture specimens with different air void contents (5.49~10.29%) were prepared, and variables such as void fraction, moisture, and ice presence were systematically controlled. Air-coupled GPR was employed to measure the specimens, and the relative permittivity was calculated using both the reflection coefficient method (RCM) and the thickness inversion algorithm (TIA). Discrepancies between the two methods were compared and analyzed. Results indicate that the RCM is significantly influenced by surface water or ice and is only suitable for dielectric characterization under dry pavement conditions. In contrast, the TIA yields more reliable results across varying surface environments. A unified model (the optimized shape factor u = −4.5 and interaction coefficient v = 5.1) was established to describe the relationship between the dielectric properties of asphalt mixtures and their volumetric parameters (bulk specific density, air void content, voids in mineral aggregate, and voids filled with asphalt). This study enables quantitative analysis of the effects of water, ice, and mixture composition on the dielectric properties of asphalt mixtures, providing a scientific basis for non-destructive and accurate GPR-based evaluation of asphalt pavements. Full article

Air-coupled ground penetrating radar (GPR) systems are widely used for subsurface imaging in demining, geological surveys, and infrastructure assessment applications. However, strong surface reflections can introduce interference, leading to receiver saturation and reducing the clarity of subsurface features. This paper presents a novel surface reflection suppression algorithm for stepped-frequency continuous wave (SFCW) GPR systems. The proposed method estimates the surface reflection component and applies phase-compensated subtraction at the receiver site, effectively suppressing background reflections. A modular SFCW radar system was developed and tested in a laboratory setup simulating a low-altitude airborne deployment to validate the proposed approach. B-scan and time-domain analyses demonstrate significant suppression of surface reflections, improving the visibility of subsurface targets. Unlike previous static echo cancellation methods, the proposed method performs on-board pre-downconversion removal of surface clutter that compensates for varying ground distance, which is a unique contribution of this work. Full article

This paper investigates the use of ground-penetrating radar (GPR) technology for detecting shallow buried objects, utilizing an air-coupled stepped frequency continuous wave (SFCW) radar system that operates within a 2 GHz bandwidth starting at 500 MHz. Different GPR data acquisition methods for air-coupled systems are compared, specifically down-looking, side-looking, and circular acquisition strategies, employing the back projection algorithm to provide focusing of the acquired GPR data. Experimental results showed that the GPR can penetrate up to 0.6 m below the surface in a down-looking mode. The developed radar and the back projection focusing algorithm were used to acquire data in the side-looking and circular mode, providing focused images with a resolution of 0.1 m and detecting subsurface objects up to 0.3 m below the surface. The proposed approach transforms B-scans of the GPR-based data into 2D images. The provided approach has significant potential for advancing shallow object detection capabilities by transforming hyperbola-based features into point-like features. Full article

As the number and length of high-speed railway tunnels increase in China, implicit defects such as insufficient lining thicknesses, voids, and poor compaction have become increasingly common, posing a serious threat to train operation safety. It is, therefore, imperative to conduct a comprehensive census of the defects within the tunnel linings. In response to this problem, this study proposes a high-speed railway tunnel detection method based on vehicle-mounted air-coupled GPR. Building on a forward simulation of air-coupled GPR, the study proposes the F-K filtering and BP migration algorithms based on the practical considerations of random noise and imaging interference from the inherent equipment. Through multi-dimensional quantitative comparisons, these algorithms are shown to improve the spectrum entropy values and instantaneous amplitude ratios by 4.6% and 11.6%; and 120% and 180%, respectively, over the mean and bandpass filtering algorithms, demonstrating their ability to suppress clutter and enhance the internal signal prominence of the lining. The experimental results are consistent with the forward simulation trends, and the verification using the ground-coupled GPR detection confirms that air-coupled GPR can meet the requirements of high-speed railway tunnel lining inspections. A comprehensive GPR detection model is proposed to lay the foundation for a subsequent defect census of high-speed railway tunnels. Full article

The objective of this work is to build a Digital Twin of a semi-industrial furnace using Gaussian Process Regression coupled with dimensionality reduction via Proper Orthogonal Decomposition. The Digital Twin is capable of integrating different sources of information, such as temperature, chemiluminescence intensity and species concentration at the outlet. The parameters selected to build the design space are the equivalence ratio and the benzene concentration in the fuel stream. The fuel consists of a ${\mathrm{H}}_2$/${\mathrm{CH}}_4$/$\mathrm{CO}$ blend, doped with a progressive addition of ${\mathrm{C}}_6{\mathrm{H}}_6$. It is an ${\mathrm{H}}_2$-rich fuel mixture, representing a surrogate of a more complex Coke Oven Gas industrial mixture. The experimental measurements include the flame temperature distribution, measured on a $6\times 8$ grid using an air-cooled suction pyrometer, spatially resolved chemiluminescence measurements of ${\mathrm{OH}}^{*}$ and ${\mathrm{CH}}^{*}$, and the species concentration (i.e., $\mathrm{NO}$, ${\mathrm{NO}}_2$, $\mathrm{CO}$, ${\mathrm{H}}_2\mathrm{O}$, ${\mathrm{CO}}_2$, ${\mathrm{O}}_2$) measured in the exhaust gases. The GPR-based Digital Twin approach has already been successfully applied on numerical datasets coming from CFD simulations. In this work, we demonstrate that the same approach can be applied on heterogeneous datasets, obtained from experimental measurements. Full article

The primary objectives of this study are to investigate the interference of ground penetrating radar (GPR) signals with air-cavities behind concrete linings subjected to three experimental parameters (GPR antenna frequency, thickness of concrete lining, and thickness of air-cavities), and their effects on the evaluation of important engineering parameters (thickness of concrete, and length and thickness of air-cavities) for tunnel structure inspection using GPR. For these purposes, first, a concrete model specimen is fabricated in the laboratory, which simulates air-cavity defects with various thicknesses (0 mm, 30 mm, 100 mm, 200 mm, and 300 mm) behind concrete with four different thicknesses (100 mm, 200 mm, 300 mm, and 400 mm) in tunnel structures. Second, a series of GPR survey is performed on the fabricated concrete model specimen using three ground-coupled GPR antennas with nominal center frequencies of 400 MHz, 900 MHz, and 1600 MHz. Third, a practical signal interpretation method is proposed to evaluate air-cavities in concrete tunnel linings subjected to the three experimental parameters. It is demonstrated that the cross-correlation analysis is effective for identifying air-cavities behind concrete, and for characterizing the length of the air-cavities. In addition, the thicknesses of air-cavities are estimated by a new approach in this study, measuring the apparent time delay of partially overlapped electromagnetic wave reflections within air-cavities. The results in this study provide a fundamental basis to improve GPR signal interpretation techniques for the evaluation of air-cavities behind concrete tunnel linings. Full article

Continuous Wave (CW) radars systems, especially air-coupled Ground-Penetrating Radar (GPR) or Through-Wall Imaging Radar (TWIR) systems, echo signals reflected from a stationary target with high energy, which may cause receiver saturation. Another effect caused by reflection of stationary targets is noticeable as background within a radargram. Nowadays, radar systems use automatic gain control to prevent receiver saturation. This paper proposes a method to remove stationary targets automatically from the received signal. The method was designed for a radar system with a moving platform, with an assumption that the distance between the surface and target is constant. The design is proposed of an SFCW radar with an integrated system for real-time multiple static target Echo Cancellation (EC). The proposed EC system removes the static target using active Integrated Circuit (IC) components, which generate the corresponding EC signal for each frequency step of the SFCW radar and sum it with the received echo signal. This has the main advantage of removing even multiple echoes at any distance, and excludes the need for a high-dynamic-range receiver. Additionally, the proposed system has minimal impact on the radar size and power consumption. Besides static target removal, the antenna coupling can be removed if the signal appears to be constant. The operating frequency was selected between 500 MHz and 2.5 GHz, due to the limitation of the used electronic components. The experimental results show that the simulated target’s echo using a cable with a known length could be suppressed to up to 38 dB. Experimental results using a moving radar platform and the real environment scenario with static and dynamic targets, show that the proposed EC system could achieve up to 20 dB attenuation of the static target. The system does not affect any other target of interest, which can even move at any distance during the measurement. Therefore, this could be a promising method for further compact implementation into SFCW radars, or any other radar type that generates CW single frequencies. Full article

The paper gives an overview of a ground penetrating radar (GPR) experiment to survey debonding areas within pavement structure during accelerated pavement tests (APT) conducted on the university Gustave Eiffel’s fatigue carrousel. Thirteen artificial defect sections composed of three types of defects (Tack-free, Geotextile, and Sand-based) were embedded during the construction phase between the top and the base layers. The data were collected in two stages covering the entire life cycle of the pavement structure using four GPR systems: An air-coupled ultra-wideband GPR (SF-GPR), two wideband 2D ground coupled GPRs (a SIR-4000 with a 1.5 GHz antenna and a 2.6 GHz-StructureScan from GSSI manufacturer), and a wideband 3D GPR (from 3D-radar manufacturer). The first stage of the experiments took place in 2012–2013 and lasted up to 300 K loadings. During this stage, the pavement structure presented no clear degradation. The second stage of experiments was conducted in 2019 and continued until the pavement surface demonstrated a strong degradation, which was observed at 800 K loadings. At the end of the GPR experiments, several trenches were cut at various sections to get the ground truth of the pavement structure. Finally, the GPR data are processed using the conventional amplitude ratio test to study the evolution of the echoes coming from the debonded areas. Full article

Deployment of a ground penetrating radar (GPR) on a flying machine allows one to substantially extend the application area of this geophysical method and to simplify carrying out large surveys of dangerous and hard-to-reach terrain, where usual ground-based methods are hardly applied. There is a necessity to promote investigations in this direction by modifying hardware characteristics and developing specific proceeding algorithms. For this purpose, we upgraded commercial ground-based subsurface sounding hardware and performed corresponding computer simulation and real experiments. Finally, the first experimental flights were done with the constructed GPR prototype mounted on a helicopter. Using our experience in the development of ground-based GPR and the results of numerical simulations, an appropriate configuration of antennas and their placing on the flying machine were chosen. Computer modeling allowed us to select an optimal resistive loading of transmitter and receiver dipoles; calculate radiation patterns on fixed frequencies; analyze the efficiency of different conductor diameters in antenna circuit; calculate cross-coupling of transmitting and receiving antennas with the helicopter. Preliminary laboratory experiments to check the efficiency of the designed system were performed on an urban building site, using a tower crane with the horizontal jib to operate the measuring system in the air above the ground area to be sounded. Both signals from the surface and subsurface objects were recorded. To interpret the results, numerical modeling was carried out. A two-dimensional model of our experiment was simulated, it matches well the experimental data. Laboratory experiments provided an opportunity to estimate the level of spurious reflections from the external objects, which helps to recognize weak signals from subsurface objects in GPR surveys under live conditions. Full article

The main objectives of this study are to investigate the variations of the dielectric constant of concrete on Korean expressways by using a 1 GHz air-coupled Ground Penetrating Radar (GPR) system and to develop a practical approach to the condition assessment of concrete bridge decks with asphalt overlay on Korean expressways by dielectric constant measurements. A total of 684 GPR investigations of 601 actual concrete bridge decks, which are in service between 2 and 43 years, were carried out during the period between 1999 and 2013. Statistical analysis revealed that the dielectric constant of asphalt-covered concrete bridge decks reduced with service age and this trend continued until service age of over 40 years. As a result, this study provides a practical dielectric constant curve that could be used for condition evaluation of top concrete in asphalt-covered bridge decks with consideration of concrete age. Based on regression analyses of the GPR field survey data and experiences through the field survey, a double cut-off dielectric constant criterion was proposed for condition assessment of asphalt-covered concrete bridge decks on Korean expressways. In addition, a GPR field survey was performed at an actual bridge on the Yeongdong expressway in Korea to test the proposed GPR signal interpretation method. The field survey results provide fundamental data to better understand the variation of the dielectric constant of concrete in actual bridges with asphalt overlay and to develop a practical approach to condition assessment of asphalt-covered concrete bridge decks on Korean expressways by dielectric constant measurements using air-coupled GPR. Full article

Ground penetrating radar (GPR) technology has been widely used in pavement assessment over the last decade. Assessing the subgrade condition and monitoring its temporal variation provide valuable information regarding changes associated with pavement deterioration, allowing for the beneficial prediction of future road maintenance. This paper presents a method to estimate the density and water content of prepared subgrade soils of highly plastic silt using a 2 GHz GPR scan system and a simple exponential model. A bulk density prediction model was developed based on electromagnetic mixing theory to back calculate subgrade soils density. The model developed determines the soil’s dielectric constant, considering dielectric and volumetric properties of the three major components of soil: air, water, and solid particles. A series of laboratory tests was conducted on six (6) soil samples at various density levels to validate the newly developed model. For validation purposes, sand cone and dynamic cone penetration (DCP) tests were performed and compared with the estimated soils strength from GPR data. The results show that the prediction of soils density and stiffness using nondestructive technology helps efficiently forecast not only pavement deterioration, but potential risks to the subsurface pavement structure with all the advances of time saving using air coupled GPR antenna mounted on a moving vehicle. Full article

Asphalt pavement compaction quality control and quality assurance (QC/QA) are traditionally based on destructive drilled cores and/or nuclear gauge results, which both are spot measurements representing significantly less than 1 percent of the in-service pavement. Ground penetrating radar (GPR) is emerging as a tool that can be used for nondestructive continuous assessment of asphalt pavement compaction quality through measuring the pavement dielectric constant. Previous studies have established that asphalt pavement dielectric constant measurements are inversely proportional to the air void content for a given asphalt mixture. However, field cores are currently required to calibrate the measured dielectric constant to the pavement density. In this paper, a method is proposed to eliminate the need for field calibration cores by measuring the dielectric constant of asphalt specimens compacted to various air void contents. This can be accomplished with a superpave gyratory compactor (SGC), which is routinely used in the pavement industry to fabricate 6 in. (15.2 cm.) diameter specimens. However, this poses difficulties with the GPR antenna height, direct coupling, and the Fresnel zone in relation to the asphalt specimen dimension limitation. These challenges are overcome by employing a plastic spacer with a known dielectric constant between the SGC specimen and the antenna. The purpose of the spacer is to reduce GPR wave speed so that the signal reflected from the specimen is separated from the direct coupling effects at an antenna height where the Fresnel zone of the GPR is not affected by the specimen dimension. The specimen dielectric constant can then be measured using the reflection coefficient-based surface reflection method (SR) or the pulse velocity-based time-of-flight method (TOF). Also, The Hoegh–Dai model (HD model) is demonstrated to reasonably predict pavement density based on the results of field measurements and corresponding core validation, especially as compared to the conventional exponential model. Results are presented from multiple days of paving on one project, as well as a single paving day on a project with significantly different mix properties. The agreement between the HD model, coreless prediction, and field cores shows the promise for implementation of dielectric-based asphalt compaction evaluation without the need for destructive field core calibration. Full article

Delamanintions and reinforcement corrosion are two common problems in concrete bridge decks. No single nondestructive testing method (NDT) is able to provide comprehensive characterization of these defects. In this work, two NDT methods, acoustic scanning and Ground Penetrating Radar (GPR), were used to image a straight concrete bridge deck and a curved intersection ramp bridge. An acoustic scanning system has been developed for rapid delamination mapping. The system consists of metal-ball excitation sources, air-coupled sensors, and a GPS positioning system. The acoustic scanning results are presented as a two-dimensional image that is based on the energy map in the frequency range of 0.5–5 kHz. The GPR scanning results are expressed as the GPR signal attenuation map to characterize concrete deterioration and reinforcement corrosion. Signal processing algorithms for both methods are discussed. Delamination maps from the acoustic scanning are compared with deterioration maps from the GPR scanning on both bridges. The results demonstrate that combining the acoustic and GPR scanning results will provide a complementary and comprehensive evaluation of concrete bridge decks. Full article
