Cavity silicon on insulator (Cavity-SOI) offers significant design flexibility for microelectromechanical systems (MEMS). Notably, the shape and depth of the cavity can be tailored to specific requirements, facilitating the realization of intricate multi-layer structural designs. The novelty of the proposed fabrication methodology is manifested in its employment of a micromachining process flow, which integrates dry etching, wafer level Au–Si eutectic bonding, and chemical mechanical polishing (CMP) to create Cavity-SOI. This innovative approach substantially mitigates the complexity of fabrication, and the implementation of wafer-level gold–silicon eutectic bonding and vacuum packaging can be achieved, representing a distinct advantage over conventional methods. To evaluate the technical viability, a MEMS resonant pressure sensor (RPS) was designed. Experimental findings demonstrate that during the formation of Cavity-SOI, dry etching can accurately fabricate cavities of predefined dimensions, wafer-level Au–Si eutectic bonding can achieve efficient sealing, and CMP can precisely regulate the depth of cavities, thus validating the feasibility of the Cavity-SOI formation process. Additionally, when implementing Cavity-SOI in the fabrication of MEMS RPS, it enables the spontaneous release of resonators, effectively circumventing the undercut and adhesion issues commonly encountered with hydrofluoric acid (HF) release. The sensors fabricated using Cavity-SOI exhibit a sensitivity of 100.695 Hz/kPa, a working temperature range spanning from −10–60 °C, a pressure range of 1–120 kPa, and a maximum error of less than 0.012% full scale (FS). The developed micromachining process for Cavity-SOI not only streamlines the fabrication process but also addresses several challenges inherent in traditional MEMS fabrication. The successful fabrication and performance validation of the MEMS RPS confirm the effectiveness and practicality of the proposed method. This breakthrough paves the way for the development of high-performance MEMS devices, opening up new possibilities for various applications in different industries. Full article

The demand for integrated circuit (IC) chips has risen markedly across various industries in conjunction with advancements in global technology. Prior to packaging, IC elements undergo several processes, including wafer dicing, wire bonding, and encapsulation. Scanning Acoustic Tomography (SAT) effectively analyzes the internal structures of integrated circuit products, thereby preventing the supply of defective components, including chip fractures, delamination, voids, and adhesion issues. The study aims to reduce operator eye strain, enhance productivity, and minimize employee turnover rates by proposing the use of convolutional neural networks (CNN) to develop a predictive model for automating defect detection in integrated circuit (IC) products within SAT images, replacing traditional visual inspections. To enhance the accuracy of the CNN model, we implement the flood-fill algorithm as the primary augmentation strategy and create an image augmentation model in Python. This method produces a training set that accurately reflects the true characteristics of defects, thereby mitigating the problem of limited defect data and ensuring the model is trained on reliable information. The incorporation of various rates and scaling factors into SAT defect images, along with the manipulation of the original defect, contributes to the development of a robust dataset suitable for real-world testing. The CNN model is trained using various batch sizes, resulting in customized training datasets and predictive models to improve accuracy. Key findings indicate that employing 40× augmentation alongside a batch size of 32 enhances the model’s performance, yielding a missed detection rate below 0.4% and a false alarm rate of 0.1%. This model offers an improved solution to the issue of manual inspections on assemblies, thereby alleviating operator stress and establishing a robust framework for automated integrated circuit quality management. Full article

Silicon–glass anode bonding is the key technology in the process of wafer-level packaging for MEMS sensors. During the anodic bonding process, the device may experience adhesion failure due to the influence of electric field forces. A common solution is to add a metal shielding layer between the glass substrate and the device. In order to solve the problem of device failure caused by the electrostatic attraction phenomenon, this paper designed a double-ended solidly supported cantilever beam parallel plate capacitor structure, focusing on the study of the critical size of the window opening in the metal layer for the electric field shielding effect. The metal shield consists of 400 Å of Cr and 3400 Å of Au. Based on theoretical calculations, simulation analysis, and experimental testing, it was determined that the critical size for an individual opening in the metal layer is 180 μm × 180 μm, with the movable part positioned 5 μm from the bottom, which does not lead to failure caused by stiction due to electrostatic pull-in of the detection structure. It was proven that the metal shielding layer is effective in avoiding suction problems in secondary anode bonding. Full article

An integrated optical isolator is a crucial part of photonic integrated circuits (PICs). Existing optical isolators, predominantly based on the silicon-on-insulator (SOI) platform, face challenges in integrating with active devices. We propose a broadband, compact TM mode Mach–Zehnder optical isolator based on InP-on-insulator platforms. We designed two distinct magneto-optical waveguide structures, employing different methods for bonding Ce:YIG and InP, namely O₂ plasma surface activation direct wafer bonding and DVS-benzocyclobutene (BCB) adhesive bonding. Detailed calculations and optimizations were conducted to enhance their non-reciprocal phase shift (NRPS). At a wavelength of 1550 nm, the direct-bonded waveguide structure achieved a 30 dB bandwidth of 72 nm with a length difference of 0.256 µm. The effects of waveguide arm length, fabrication accuracy, and dimensional errors on the device performance are discussed. Additionally, manufacturing tolerances for three types of lithographic processes were calculated, serving as references for practical manufacturing purposes. Full article

In soft electronics, anisotropic conductive adhesive films (ACFs) are the trending interconnecting approach due to their substantial softness and superior bondability to flexible substrates. However, low bonding pressure (≤1 MPa) and fine-pitch interconnections of ACFs become challenging while being extended in advanced device developments such as wafer-level packaging and three-dimensional multi-layer integrated circuit board assembly. To overcome these difficulties, we studied two types of ACFs with distinct conductive filler sizes (ACF-1: ~20 μm and ACF-2: ~5 μm). We demonstrated a low-pressure thermo-compression bonding technique and investigated the size effect of conductive particles on ACF’s mechanical properties in a customized testing device, which consists of flexible printing circuits and Flex on Flex assemblies. A consistency of low interconnection resistance (<1 Ω) after mechanical stress (cycling bending test up to 600 cycles) verifies the assembly’s outstanding electrical reliability and mechanical stability and thus validates the great effectiveness of the ACF bonding technique. Additionally, in numerical studies using the finite element method, we developed a generic model to disclose the size effect of Au/Ni-coated polymer fillers in ACF on device reliability under mechanical stress. For the first time, we confirmed that ACFs with smaller filler particles are more prone to coating fracture, leading to deteriorated electrical interconnections, and are more likely to peel off from substrate electrode pads resulting in electrical faults. This study provides guides for ACF design and manufacturing and would facilitate the advancement of soft wearable electronic devices. Full article

Flexible multielectrode arrays with glassy carbon (GC) electrodes and metal interconnection (hybrid MEAs) have shown promising performance in multi-channel neurochemical sensing. A primary challenge faced by hybrid MEAs fabrication is the adhesion of the metal traces with the GC electrodes, as prolonged electrical and mechanical stimulation can lead to adhesion failure. Previous devices with GC electrodes and interconnects made of a homogeneous material (all GC) demonstrated exceptional electrochemical stability but required miniaturization for enhanced tissue integration and chronic electrochemical sensing. In this study, we used two different methods for the fabrication of all GC-MEAs on thin flexible substrates with miniaturized features. The first method, like that previously reported, involves a double pattern-transfer photolithographic process, including transfer-bonding on temporary polymeric support. The second method requires a double-etching process, which uses a 2 µm-thick low stress silicon nitride coating of the Si wafer as the bottom insulator layer for the MEAs, bypassing the pattern-transfer and demonstrating a novel technique with potential advantages. We confirmed the feasibility of the two fabrication processes by verifying the practical conductivity of 3 µm-wide 2 µm-thick GC traces, the GC microelectrode functionality, and their sensing capability for the detection of serotonin using fast scan cyclic voltammetry. Through the exchange and discussion of insights regarding the strengths and limitations of these microfabrication methods, our goal is to propel the advancement of GC-based MEAs for the next generation of neural interface devices. Full article

This study conducted experimental and numerical investigations on piezoelectric wafer active sensors (PWASs) bonded to an aluminum plate to assess the impact of bonding degradation on Lamb wave generation. Three surface-bonded PWASs were examined, including one intentionally bonded with a reduced adhesive to create a defective bond. Thermal cyclic aging was applied, monitoring through laser Doppler vibrometry (LDV) and static capacitance measurements. The PWAS with the initially defective bond exhibited the poorest performance over aging cycles, emphasizing the significance of the initial bond condition. As debonding progressed, modifications in electromechanical behavior were observed, leading to a reduction in wave amplitude and distortion of the generated wave field, challenging the validity of existing analytical modeling of wave-tuning curves for perfectly bonded PWASs. Both numerical simulations and experimental observations substantiated this finding. In conclusion, this study highlights the imperative of a high-integrity bond for the proper functioning of a guided wave-based structural health monitoring (SHM) system, emphasizing ongoing challenges in assessing SHM performance. Full article

UV debonding acrylate adhesive (UDAA) plays a crucial role in the semiconductor industry, where its excellent adhesion is required to ensure the stability of silicon wafers and leave no residue on the surface after UV irradiation. The necessary UV debonding is achieved through the formation of rigid networks by the reactions of all the vinyl groups in the system. Acrylate copolymers with vinyl groups are typically obtained by the grafting reaction of isocyanate with a side-chain hydroxyl comonomer. However, these grafting reactions easily fail due to early cross-link formation. In this study, we illustrate a straightforward method for preparing UDAA by conducting a postgrafting reaction after one-step mixing of isocyanate functional monomer (IPDI-H) and hydroxyl acrylate copolymers (BA-H), thereby skipping the abovementioned vinyl grafting process. The chemical structures of the synthesized IPDI-H and BA-H were confirmed using Fourier transform infrared spectroscopy (FTIR) and proton nuclear magnetic resonance (¹H-NMR) analysis. Gel permeation chromatography (GPC) was employed to determine their molecular weights, while differential scanning calorimetry (DSC) was used to determine their glass transition temperatures. The postgrafting reactions successfully introduced vinyl groups onto the polyacrylate copolymer chains, resulting in high bonding strength during use and a significant decrease in peeling strength after UV irradiation. Rheological methods, including the three-interval thixotropy test (3ITT) and tack test modes, were employed to characterize a series of acrylate UV debonding adhesives. The recovery percentage of the storage modulus in the 3ITT mode indicated that a 0.6 wt% isocyanate curing agent made the UV debonding adhesives resistant to deformation. From the maximum normal force in the tack test mode, it was found that UDAA with 10 wt% PETA monomer and 30 wt% C5 tackifying resin exhibited excellent combined adhesion and debonding properties, which were further confirmed by peel strength tests. Microscope images of the wafer surfaces after removing the adhesive tapes demonstrated the excellent UV debonding properties achieved after 40 s of UV irradiation through the postgrafting reaction. The prepared UDAA has excellent properties; the peel strength can reach 15 N/25 mm before UV irradiation and can be reduced to 0.5 N/25 mm after ultraviolet irradiation. This research establishes a comprehensive method for understanding and applying UDAA in various applications. Full article

A common problem in deformable mirror assembly is that the adhesion of actuators to an optical mirror face sheet introduces unwanted topography due to large local stresses generated at the adhesive joint. A new approach to minimizing that effect is described, with inspiration taken from St. Venant’s principle, a fundamental precept in solid mechanics. It is demonstrated that moving the adhesive joint to the end of a slender post extending from the face sheet largely eliminates deformation due to adhesive stresses. A practical implementation of this design innovation is described, using silicon-on-insulator wafers and deep reactive ion etching. Simulation and experiments validate the effectiveness of the approach, reducing stress-induced topography on a test structure by a factor of 50. A prototype electromagnetic DM using this design approach is described, and its actuation is demonstrated. This new design can benefit a wide range of DMs that rely on actuator arrays that are adhesively bonded to a mirror face sheet. Full article

The use of polymers in silicon chips is of great importance for the development of microelectronic and biomedical industries. In this study, new silane-containing polymers, called OSTE-AS polymers, were developed based on off-stoichiometry thiol–ene polymers. These polymers can bond to silicon wafers without pretreatment of the surface by an adhesive. Silane groups were included in the polymer using allylsilanes, with the thiol monomer as the target of modification. The polymer composition was optimized to provide the maximum hardness, the maximum tensile strength, and good bonding with the silicon wafers. The Young’s modulus, wettability, dielectric constant, optical transparency, TGA and DSC curves, and the chemical resistance of the optimized OSTE-AS polymer were studied. Thin OSTE-AS polymer layers were obtained on silicon wafers via centrifugation. The possibility of creating microfluidic systems based on OSTE-AS polymers and silicon wafers was demonstrated. Full article

Advanced packaging solutions require insulation and passivation materials with exceptional properties which can also fulfill the reliability needs of electronics devices such as MEMS, sensors or power modules. Since bonding (cohesive/adhesive) properties of packaging coatings are very important for reliable functioning of electronics devices, the bonding of aliphatic fluorinate-4 (AF4) parylene coatings was assessed in this work. As there is a lack of data regarding its bonding towards different substrates, pull-off tests of 1.6 and 2.5 μm thick AF4 coatings on silicon (Si) and glass (SiO₂) substrates were performed. These showed a clear difference in the pull-off F/s curves between the AF4 coatings on Si and SiO₂ substrates. This difference is parameterized by the pull-off energy, which will be presented in this work. To further understand the origin of the distinction in the pull-off energies between the AF4-Si and AF4-SiO₂ samples and subsequently the cohesive/adhesive properties, mechanical and structural characterization was conducted on the AF4 coatings, where a clear difference in the E-modulus and crystallinity was observed. The Si and SiO₂ wafers were shown to facilitate the CVD growth of the AF4 film distinctively, which likely relates to the divergent thermal properties of the substrates. Understanding of the cohesive/adhesive properties of AF4 coatings on different substrate materials advances the usage of the AF4 in electronics packaging technologies. Full article

Improved hearing restoration by cochlear implants (CI) is expected by optical cochlear implants (oCI) exciting optogenetically modified spiral ganglion neurons (SGNs) via an optical pulse generated outside the cochlea. The pulse is guided to the SGNs inside the cochlea via flexible polymer-based waveguide probes. The fabrication of these waveguide probes is realized by using 6” wafer-level micromachining processes, including lithography processes such as spin-coating cladding layers and a waveguide layer in between and etch processes for structuring the waveguide layer. Further adhesion layers and metal layers for laser diode (LD) bonding and light-outcoupling structures are also integrated in this waveguide process flow. Optical microscope and SEM images revealed that the majority of the waveguides are sufficiently smooth to guide light with low intensity loss. By coupling light into the waveguides and detecting the outcoupled light from the waveguide, we distinguished intensity losses caused by bending the waveguide and outcoupling. The probes were used in first modules called single-beam guides (SBGs) based on a waveguide probe, a ball lens and an LD. Finally, these SBGs were tested in animal models for proof-of-concept implantation experiments. Full article

New modified off-stoichiometry thiol–enes polymers, called OSTE-MS polymers, were developed by introducing mercaptosilane into the polymer mixture. This modification made it possible to introduce silane groups into the polymer frame, due to which the polymer gained the ability to bond with silicon wafers without modification of the wafer surface by any adhesive. The optimal composition for creating 3D polymer structures on a chip was selected, which consists of a volume ratio of 6:6:1 of allyl monomer, mercapto monomer, and mercaptosilane, respectively. The hardness, shift force, tensile strength, Young’s modulus, optical transparency, glass transition temperature, thermal stability, and chemical resistance of the OSTE-MS polymer, and the viscosity for the prepolymer mixture were studied. On the basis of the OSTE-MS polymer, 3D polymer structures of the well type and microfluidic system on the silicon chips were obtained. Full article

Die-level thinning, handling, and integration of singulated dies from multi-project wafers (MPW) are often used in research, early-stage development, and prototyping of flexible devices. There is a high demand for thin silicon devices for several applications, such as flexible electronics. To address this demand, we study a novel post-processing method on two silicon devices, an electrochemical impedance sensor, and Complementary Metal Oxide Semiconductor (CMOS) die. Both are drawn from an MPW batch, thinned at die-level after dicing and singulation down to 60 µm. The thinned dies were flip-chip bonded to flexible substrates and hermetically sealed by two techniques: thermosonic bonding of Au stud bumps and anisotropic conductive paste (ACP) bonding. The performance of the thinned dies was assessed via functional tests and compared to the original dies. Furthermore, the long-term reliability of the flip-chip bonded thinned sensors was demonstrated to be higher than the conventional wire-bonded sensors. Full article

In this paper, we have fabricated InGaAs high-electron-mobility transistors (HEMTs) on Si substrates. The InAlAs/InGaAs heterostructures were initially grown on InP substrates by molecular beam epitaxy (MBE), and the adhesive wafer bonding technique was employed to bond the InP substrates to Si substrates, thereby forming high-quality InGaAs channel on Si. The 120 nm gate length device shows a maximum drain current (I${}_{D,max}$) of 569 mA/mm, and the maximum extrinsic transconductance (g${}_{m,max}$) of 1112 mS/mm. The current gain cutoff frequency (f${}_T$) is as high as 273 GHz and the maximum oscillation frequency (f${}_{MAX}$) reaches 290 GHz. To the best of our knowledge, the g${}_{m,max}$ and the f${}_T$ of our device are the highest ever reported in InGaAs channel HEMTs on Si substrates at given gate length above 100 nm. Full article
