In this study, ZnO thin-film ultrasonic transducers were directly fabricated by reactive radio-frequency magnetron sputtering for bolt preload detection. The effects of deposition pressure and Ar/O₂ ratio on the morphology, crystal structure, piezoelectric response, and ultrasonic performance of ZnO films were investigated. The ZnO film deposited at 2.0 Pa with an Ar/O₂ ratio of 3:1 exhibited strong c-axis preferred orientation and generated stable high-frequency longitudinal ultrasonic waves with a center frequency above 50 MHz. After being deposited on the bolt surface, the optimized transducer showed a strong linear relationship between ultrasonic time-of-flight and axial load, with an R² value greater than 99.99% and an average measurement error below 1% within the preload range. Field monitoring at a hydropower station further showed that the preload variation of randomly selected bolts was negatively correlated with temperature, mainly due to the thermal deformation mismatch between 35CrMo bolts and Q235-B flanges. The maximum preload variation was approximately 40 kN, accounting for about 6.7% of the specified preload of 600 kN, while no abnormal preload loss was observed. These results demonstrate that ZnO thin-film ultrasonic transducers provide a reliable and accurate approach for hydraulic bolt preload measurement and in-service monitoring, with better applicability than conventional torque-based methods. Full article

In this study, the sintering behavior and electrical properties of 0.7Pb(Zr_0.46Ti_0.54)O₃ (PZT)–0.1Pb(Zn₁/₃Nb₂/₃)O₃ (PZN)–0.2Pb(Ni₁/₃Nb₂/₃)O₃ (PNN) piezoelectric ceramics with different Pb(Fe₂/₃W₁/₃)O₃ (PFW) doping contents were investigated to obtain a formulation that can be co-fired with silver (Ag) electrodes below 900 °C for multilayer ceramics. PFW was introduced as a sintering aid, which effectively reduced the sintering temperature of the ceramics from 1200 °C to 850 °C. The sample with x = 0.12 exhibited the largest average grain size of 1.72 μm, achieving excellent comprehensive properties with piezoelectric constant (d₃₃) = 477 pC/N, planar electromechanical coupling factor (k_p) = 0.68, dielectric loss tangent (tanδ) = 0.0154, and relative density of 98.2%. Furthermore, the feasibility of fabricating piezoelectric actuators based on this optimized composition was verified. Multilayer piezoelectric devices were prepared via screen printing combined with a carbon-based sacrificial layer method. No obvious interdiffusion was observed at the interface between the Ag internal electrodes and the ceramic matrix. The 9-layer device attained a high d₃₃ = 1470 pC/N and produced a large displacement of 5.5 μm (corresponding to a strain = 1.83%) with a voltage of 500 V. The thickness of the multilayer piezoelectric film was approximately 0.3 mm. Through this, the feasibility of manufacturing a multilayered actuator with an Ag electrode was confirmed through the composition of 0.58PZT–0.1PZN–0.2PNN–0.12PFW. Full article

Surface Acoustic Wave (SAW) technology, long central to analog signal processing and RF filtering, is undergoing a major renewal. Driven by advances that decouple SAWs from traditional piezoelectric materials and fixed-function devices, the field is gaining unprecedented control over acoustic, optical, and electronic interactions at the micro and nanoscale. This review synthesizes these developments across four fronts: new physical mechanisms for SAW manipulation, emerging material platforms, ranging from thin films to 2D systems, along with reconfigurable device architectures and circuits, and the expanding landscape of applications they enable. Optical methods are reshaping how SAWs are generated and controlled, bypassing the limits of conventional electromechanical coupling. Coherent optical excitation of high-Q SAW cavities via Brillouin-like optomechanical interactions now grants access to modes in non-piezoelectric substrates such as diamond and silicon, while on-chip SAW excitation in photonic waveguides through backward stimulated Brillouin scattering opens new integrated sensing routes. In parallel, magneto-acoustic experiments have revealed nonreciprocal SAW diffraction from resonant scattering in magnetoelastic gratings. On the device side, ZnO thin-film transistors integrated on LiNbO₃ exploit acoustoelectric coupling to realize voltage-tunable phase shifters; UHF Z-shaped delay lines achieve high sensitivity in a compact footprint; and parametric synthesis of wideband, multi-stage lattice filters targets 5G-class performance. Atomistic simulations show that SAW propagation in 2D MXene films can be engineered via surface terminations, while aerosol jet printing and SAW-assisted particle patterning provide agile, cleanroom-light fabrication of microfluidic and magnetic components. These advances enable applications ranging from hybrid quantum systems and quantum links to lab-on-a-chip particle control, SBS-based and UHF sensing, reconfigurable RF front-ends, and soft robotic actuators based on patterned magnetic composites. At the same time, optical techniques offer non-contact probes of dissipation, and MXenes and other emerging materials open new regimes of acoustic control. Conclusively, they are transforming SAW technology into a versatile, programmable platform for mediating complex interactions in next-generation electronic, photonic, and quantum systems. Full article

Flexible piezoelectric materials demonstrate broad application potential in wearable health monitoring, human–machine interaction, and biosensing. However, the piezoelectric response of pure PVDF-TrFE is limited and insufficient to meet the requirements for highly sensitive sensing. In this study, ZnO/PVDF-TrFE composite films with varying ZnO doping contents (3–11 wt%) were fabricated and systematically characterized in terms of their structural, thermal, and electrical properties. The results indicate that ZnO significantly promotes the formation of the polar β-phase in PVDF-TrFE, with the maximum β-phase content (F_β = 24.76%) and optimal piezoelectric performance achieved at 9 wt% ZnO doping. Devices based on this optimal composition exhibited stable ultrasonic transmission and reception capabilities under high-frequency pulse excitation, enabling sensitive detection of minor static pressure variations (e.g., contact pressure) through changes in ultrasonic echo signals, thereby realizing wearable conformity monitoring. Moreover, a sensor designed with a three-channel flexible substrate successfully captured human wrist pulse signals with high accuracy, demonstrating the practical utility and reliability of the device in flexible bio-electronic sensing applications. Full article

Cellulose is a well-known biopolymer with excellent properties for a broad range of applications, including piezoelectricity for the development of nanogenerators. However, similar to other piezoelectric materials, the voltage outputs currently reported from cellulose-based piezoelectric nanogenerators (PENGs) could be overestimated due to the appearance of triboelectric processes. To understand the appearance of both phenomena, cellulose films and aerogels that had undergone several modifications to improve their piezoelectric behavior (i.e., thermal treatment and presence of piezoelectric/conductive particles) were developed and characterized. Our results show that these modifications significantly changed the dielectric properties (ε) and the piezoelectric coefficients (d₃₃), with increments as high as a factor of 4, although without a clear tendency regarding the sample characteristics. Under finger-tapping mechanical stimulation, nanogenerators (NGs) using pure cellulose films generated 6 V, whereas the modified cellulose films and aerogels either increased or decreased this value, with outputs between 2 and 10 V. Notably, ternary composites, having both conductive and piezoelectric ZnO particles, increased the generation up to 24 V. There was no correlation between the voltage generated and d₃₃ or d₃₃/ε values, although some relationship with ε was observed, meaning that a pure piezoelectric phenomenon was not observed. This lack of correlation and the drastic decrease in the voltage generated (around 0.2 V) after changing the NG configuration show that a triboelectric phenomenon from the multilayered structure significantly contributes to the voltage generation from cellulose samples. Full article

High-performance piezoelectric poly(vinylidene fluoride) (PVDF) has great application potential in the field of microsensors, but achieving efficient polarization remains a challenge. Here, the in situ doping electrospinning technique is employed to enhance the piezoelectric properties by introducing a single dose of zinc oxide (ZnO) or barium titanate (BaTiO₃,BTO) dopants. The effects of key processing parameters on the morphology of nanofiber membranes were systematically investigated. In addition, the influence of zinc oxide (ZnO) or barium titanate (BTO) dopant concentrations on the piezoelectric properties of PVDF was examined. The microstructure, electrical performance, and β-phase content of the composite membranes were characterized. Results indicate that the composite film with a doping formulation of 16 wt% PVDF and 10 wt% ZnO exhibits optimal overall performance: the β-phase content of PVDF reaches 52.8%, and the output voltage reaches 1.5 V, which is 2.5 times higher than that of the undoped PVDF nanofiber membranes. This study provides an effective doping strategy for the fabrication of high-performance piezoelectric nanofiber membranes. Full article

This paper presents a cost-effective and versatile pico-dispensing technique as an efficient and straightforward approach for depositing zinc oxide nanoparticle (ZnO—NP) thin films on micromechanical devices (MEMS). Due to its piezoelectric properties, bulk ZnO is commonly used as a material for micro-/nanocantilever actuation. The pico-dispensing process provides precise control over the deposition, allowing uniform and localized application of ZnO—NP on microcantilevers. Compared to traditional ZnO deposition techniques (e.g., sputtering or sol–gel), pico-dispensing of ZnO—NP offers advantages in simplicity, reduced material waste, and significantly lower costs. Furthermore, it is easy to tailor the composition and properties by incorporating nanoparticles of other materials. Experimental results demonstrate that ZnO—NP thin films deposited via pico-dispensing enable actuation with amplitudes of several nanometers and bandwidths up to 250 kHz, making them potentially suitable for actuation of micromechanical devices such as in dynamic AFM modes. Full article

Acoustic energy penetrates into the Si substrate at cavity boundaries. Due to this, the air cavity-based bulk acoustic resonators experience higher harmonic mode, parasitic resonance, and spurious mode. To overcome these effects and enhance the performance parameters, a backside air cavity is fabricated using the deep reactive ion etching (DRIE) method. The DRIE method helps to achieve the optimized active area of the resonator. SiO₂ film on a silicon substrate as the support layer and ZnO as the piezoelectric (PZE) film are used for the resonator. The crystal growth and surface morphology of ZnO film were investigated with X-ray diffraction, scanning electron microscopy, and atomic force microscopy. FBAR is modeled in a 1-D modified Butterworth–Van Dyke (mBVD) equivalent circuit. As RF measurement results, we successfully demonstrated a FBAR with optimized active area of 320 × 320 μm², center frequency of 1.261 GHz, having a quality factor of 583.8. Overall, this suppression of higher harmonic mode shows the great potential for improving the selectivity of the sensor and also in RF filter design applications. This integration of DRIE-based cavity formation with ZnO-based FBAR architecture not only enables compact design but also effectively suppresses spurious and higher-order modes, which demonstrates a performance-enhancing fabrication strategy not fully explored in the current literature. Full article

In this study, to enhance the output performance of a contact-separation mode triboelectric nanogenerator (TENG), a zinc oxide nanorod (ZnO NR) film with piezoelectric properties was integrated into a Polydimethylsiloxane (PDMS) film as the dielectric layer. The working mechanism of the PDMS-ZnO NR-based TENG was theoretically analyzed in two stages: charge transfer during contact electrification on the material surface and charge movement in the electrostatic induction process. The output characteristics of the PDMS-ZnO NR-based TENG were investigated and compared with those of a PDMS-based TENG. The experimental results demonstrate that the PDMS-ZnO NR-based TENG reached an open-circuit voltage of 39.34 V, representing an increase of 64.5% compared to the PDMS-based TENG. The maximum output power of a 4 cm × 4 cm PDMS-ZnO NR-based TENG reached 82.2 μW. Using a specially designed energy-harvesting circuit, the generated electrical energy was stored in a capacitor, which was charged to 1.47 V within 1 min and reached 3 V in just 2.78 min. This voltage was sufficient to power over 20 LEDs and small sensors. Additionally, the TENG was integrated into the sole of footwear, where the electrical signals generated by compression could be utilized for step counting and gait analysis. Full article

Flexible polymer-based piezoelectric nanogenerators (PENGs) have gained significant interest due to their ability to deliver clean and sustainable energy for self-powered electronics and wearable devices. Recently, the incorporation of fillers into the ferroelectric polymer matrix has been used to improve the relatively low piezoelectric properties of polymer-based PENGs. In this study, we investigated the effect of various nanofillers such as titania (TiO₂), zinc oxide (ZnO), reduced graphene oxide (rGO), and lead zirconate titanate (PZT) on the PENG performance of the nanocomposite thin films containing the nanofillers in poly(vinylidene fluoride-co-trifluoro ethylene) (P(VDF-TrFE)) matrix. The nanocomposite films were prepared by depositing molecularly thin films of P(VDF-TrFE) and nanofiller nanoparticles (NPs) spread at the air/water interface onto the indium tin oxide-coated polyethylene terephthalate (ITO-PET) substrate, and they were characterized by measuring their microstructures, crystallinity, β-phase contents, and piezoelectric coefficients (d₃₃) using SEM, FT-IR, XRD, and quasi-static meter, respectively. Multiple PENGs incorporating various nanofillers within the polymer matrix were developed by assembling thin film-coated substrates into a sandwich-like structure. Their piezoelectric properties, such as open-circuit output voltage (V_OC) and short-circuit current (I_SC), were analyzed. As a result, the PENG containing 4 wt% PZT, which was named P-PZT-4, showed the best performance of V_OC of 68.5 V with the d₃₃ value of 78.2 pC/N and β-phase content of 97%. The order of the maximum V_OC values for the PENGs of nanocomposite thin films containing various nanofillers was PZT (68.5 V) > rGO (64.0 V) > ZnO (50.9 V) > TiO₂ (48.1 V). When the best optimum PENG was integrated into a simple circuit comprising rectifiers and a capacitor, it demonstrated an excellent two-dimensional power density of 20.6 μW/cm² and an energy storage capacity of 531.4 μJ within 3 min. This piezoelectric performance of PENG with the optimized nanofiller type and content was found to be superior when it was compared with those in the literature. This PENG comprising nanocomposite thin film with optimized nanofiller type and content shows a potential application for a power source for low-powered electronics such as wearable devices. Full article

Zinc oxide (ZnO) exhibits piezoelectric properties due to its asymmetric structure, making it suitable for piezoelectric devices. This experiment deposited Fe-doped ZnO films on silicon substrates using a dual-target magnetron co-sputtering system. The films achieved a high c-axis orientation, and the piezoelectric coefficient of the film reached its optimal value of 44.35 pC/N when doped with 0.5 at% of Fe. This value is approximately three times that of undoped ZnO films with a piezoelectric coefficient of 13.04 pC/N. The study utilized a diffractometer, scanning electron microscopy, transmission electron microscopy, and atomic force microscopy to evaluate the crystal structure evolution of the zinc oxide films and employed X-ray photoelectron spectroscopy to assess the valence state of the Fe ions. Full article

This study has investigated the effects of different annealing temperatures on the microstructure, chemical composition, phase structure, and piezoelectric properties of ZnO films. The analysis focuses on how annealing temperature influences the oxygen content and the preferred c-axis (002) orientation of the films. It was found that annealing significantly increases the grain size and optimizes the columnar crystal structure, though excessive high-temperature annealing leads to structural degradation. This behavior is likely related to changes in oxygen content at different annealing temperatures. High resolution transmission electron microscopy (HR-TEM) reveals that the films exhibit high-resolution lattice stripes, confirming their high crystallinity. Although the films exhibit growth in multiple orientations, the c-axis (002) orientation remains the predominant crystallographic growth. Further piezoelectric property analysis demonstrates that the ZnO films annealed at 400 °C exhibit enhanced piezoelectric performance and stable linear piezoelectric behavior. These findings offer valuable support for optimizing the piezoelectric properties of ZnO films and their applications in piezoelectric sensors. Full article

The synthesis of reliable, cost-effective, and eco-friendly ZnO piezoelectric nanoparticles (NPs) can contribute to nanotechnology applications in electronics, sensors, and energy harvesting. Herein, ZnO NPs were synthesized using a hydrothermal method under varied reaction times and adding ammonium hydroxide, which provided an advantage of a low-cost, scalable, low-temperature, and environmentally friendly process. Characterization through UV–Vis spectroscopy revealed absorption peaks between 374 and 397 nm, showing a blue shift compared to bulk ZnO (400 nm) attributable to nanoscale dimensions. Transmission Electron Microscopy (TEM) analysis indicated particle dimensions with length and width ranges from 150 to 341 nm and from 83 to 120 nm, respectively. X-ray diffraction (XRD) confirmed high-crystalline quality, with crystallite sizes calculated using the Scherrer equation. In addition, the effective mass model provided an estimated band gap that matched with the reported data. Also, the lattice parameters, interplanar distances, and Zn-O bond lengths were consistent with Joint Committee on Powder Diffraction Standards (JCPDS). Finally, a ZnO NP film was deposited on a steel substrate, which generated a displacement of 150 nm under a square wave voltage of 10 V. The piezoelectric behavior of the synthesized ZnO NPs can be useful for fabrication of piezoelectric nanogenerators. The proposed synthesis can allow ZnO NPs with potential application in electronic devices, energy harvesters, and transducers. Full article

The acoustoelectric (AE) effect induced by the absorption of ultraviolet (UV) light at 365 nm in piezoelectric ZnO films was theoretically and experimentally studied. c-ZnO films 4.0 µm thick were grown by the RF reactive magnetron sputtering technique onto fused silica substrates at 200 °C. A surface acoustic wave (SAW) delay line was fabricated with two split-finger Al interdigital transducers (IDTs) photolithographically implemented onto the ZnO-free surface to excite and reveal the propagation of the fundamental Rayleigh wave and its third harmonic at about 39 and 104 MHz. A small area of a few square millimeters on the surface of the ZnO layer, in between the two IDTs, was illuminated by UV light at different light power values (from about 10 mW up to 1.2 W) through the back surface of the SiO₂ substrate, which is optically transparent. The UV absorption caused a change of the ZnO electrical conductivity, which in turn affected the velocity and insertion loss (IL) of the two waves. It was experimentally observed that the phase velocity of the fundamental and third harmonic waves decreased with an increase in the UV power, while the IL vs. UV power behavior differed at large UV power values: the Rayleigh wave underwent a single peak in attenuation, while its third harmonic underwent a further peak. A two-dimensional finite element study was performed to simulate the waves IL and phase velocity vs. the ZnO electrical conductivity, under the assumption that the ZnO layer conductivity undergoes an in-depth inhomogeneous change according to an exponential decay law, with a penetration depth of 325 nm. The theoretical results predicted single- and double-peak IL behavior for the fundamental and harmonic wave due to volume conductivity changes, as opposed to the AE effect induced by surface conductivity changes for which a single-peak IL behavior is expected. The phenomena predicted by the theoretical models were confirmed by the experimental results. Full article

Conductive multi-walled carbon nanotubes (MWCNTs) as well as piezoelectric zinc oxide (ZnO) nanoparticles are frequently used as a single additive and dispersed in polyvinylidene fluoride (PVDF) solutions for the fabrication of piezoelectric composite films. In this study, MWCNT/ZnO binary dispersions are used as spinning liquids to fabricate composite nanofibrous films by electrospinning. Binary additives are conducive to increasing the crystallinity, piezoelectric voltage coefficient, and consequent piezoelectricity of as-spun films owing to the stretch-enhanced polarization of the electrospinning process under an applied electric field. PCZ–1.5 film (10 wt. % PVDF/0.1 wt. % MWCNTs/1.5 wt. % ZnO nanoparticles) contains the maximum β-phase content of 79.0% and the highest crystallinity of 87.9% in nanofibers. A sensor using a PCZ–1.5 film as a functional layer generates an open-circuit voltage of 10 V as it is subjected to impact loads with an amplitude of 6 mm at 10 Hz. The piezoelectric sensor reaches a power density of 0.33 μW/cm² and a force sensitivity of 582 mV/N. In addition, the sensor is successfully applied to test irregular motions of a bending finger and stepping foot. The result indicates that electrospun PVDF/MWCNT/ZnO nanofibrous films are suitable for wearable devices. Full article
