Search Results (18)

To address the unobservability of distribution networks caused by insufficient coverage of measurement terminals as well as communication failures and missing data, and to cope with operating-state fluctuations induced by distributed generation integration and external environmental disturbances, this paper proposes an integrated state-estimation and voltage-regulation strategy that combines distribution-network-partitioning-based optimal PMU placement with pseudo-measurement construction using power transfer distribution factors (PTDFs). First, nodal reactive-power sensitivity information is derived from the power-flow Jacobian matrix, and an improved modularity function is employed to obtain the optimal partitioning of the distribution network, based on which PMUs are deployed at partition boundary buses. Second, PTDF-based power pseudo-measurements are constructed for unobservable buses and incorporated into the measurement model via a measurement transformation; a weighted least-squares method is then adopted to achieve system-wide state estimation. Finally, the estimated voltage states are fed into flexible voltage-regulation devices to enable fast and continuous voltage adjustment across buses. Case studies on the IEEE 33-bus system demonstrate that the proposed method effectively improves voltage quality. Full article

Peer-to-peer (P2P) energy-trading has emerged as a promising mechanism for decentralized electricity markets, but its practical deployment is often limited by the difficulty of accounting for physical network constraints and transmission losses in real time. This paper presents a decentralized P2P energy trading mechanism that incorporates network constraints and transmission losses directly into the market-clearing process. The framework combines Power Transfer Distribution Factors (PTDFs) for pre-trade feasibility validation with an Enhanced Least Squares Method (ELSM) for loss estimation, enabling loss-aware settlement without computationally intensive and redundant AC power flow calculations. The mechanism is implemented on Hyperledger Fabric using Attribute-Based Access Control, Access Control Lists and Private Data Collections to ensure privacy and auditability. Numerical studies on a 3-bus and the IEEE 39-bus system show that the proposed approach closely reproduces AC Optimal Power Flow dispatch and cost outcomes, while significantly improving simplified DC-based loss models. The results demonstrate that physically feasible and economically efficient decentralized trading can be achieved in a permissioned blockchain environment. Full article

Variable renewable energy sources and cross-zonal trades stress transmission grids, pushing them toward thermal limits. This systematic review, reported in accordance with PRISMA 2020, examines how demand-side response (DSR) can provide relief at the transmission scale. We screened peer-reviewed literature and operator documentation, from 2010 to 2025, indexed in Web of Science, Scopus, and IEEE Xplore; organized remedial actions across supply, network, and demand/storage levers; and categorized operational attributes (time to effect, spatial targeting, activation lead times, telemetry, and measurement and verification). Few reviewed sources explicitly link DSR to transmission congestion relief, highlighting the gap between its mature use in frequency and adequacy services and its still-limited, location-specific application on the grid. We identify feasibility conditions, including assets downstream of the binding interface, minute-scale activation, and feeder-grade baselines with rebound accounting. This implies the following design requirements: TSO–DSO eligibility registries and conflict resolution, portfolio mapping to power-flow sensitivities, and co-optimization with redispatch, HVDC, topology control, and storage within a security-constrained optimal-power-flow framework. No full-text risk-of-bias assessment or meta-analysis was undertaken; the review used English-only title/abstract screening. Registration: none. Funding: none. Full article

A growing interest in offshore wind energy in the Mediterranean Sea has been recently observed thanks to the potential for scale-up and recent advances in floating technologies and dynamic cables: in the Italian panorama, the offshore wind connection requests to the National Transmission Grid (NTG) reached almost 84 GW at the end of September 2024. Starting from a realistic estimate of the offshore wind power plants (OWPPs) to be realized off the southern coasts in a very long-term scenario, this paper presents a novel optimization procedure for meshed AC offshore network configuration, aiming at minimizing the offshore wind generation curtailment based on the DC optimal power flow approximation, assessing the security condition of the whole onshore and offshore networks. The reactive power compensation aspects are also considered in the optimization procedure: the optimal compensation sizing for export cables and collecting stations is evaluated via the AC optimal power flow (OPF) approach, considering a combined voltage profile and minimum short circuit power constraint for the onshore extra-high voltage (EHV) nodes. The simulation results demonstrate that the obtained meshed network configuration and attendant re-active compensation allow most of the offshore wind generation to be evacuated even in the worst-case scenario, i.e., the N1 network, full offshore wind generation output, and summer line rating, testifying to the relevance of the proposed methodology for real applications. Full article

The power system on Jeju Island currently faces challenges due to an imbalance between power supply and demand owing to increasing renewable energy (RE) generation. Consequently, the multi-infeed high-voltage direct-current (MIDC) systems are expected to play an important role in reducing RE curtailment and increasing RE penetration. However, despite the balance between power supply and demand, transmission line (TL) overloads on Jeju Island, which has a low permissible rating, may lead to RE curtailment. We propose an operational strategy for the MIDC systems to mitigate TL overloading and RE curtailment. This strategy was aimed at managing the possible congestion of TLs, maintaining a power supply–demand balance, and increasing the penetration level of RE. In this paper, we present a scheme for calculating the operating points of the MIDC systems and allocating RE curtailment using optimization with security constraints to mitigate TL overloading. The proposed optimization model simplifies solving the mathematical equations involved by employing a sensitivity factor called the power transfer distribution factor (PTDF), using which linear programming (LP) optimization can be performed. To verify the feasibility of the operational strategy, case studies are conducted using an actual Jeju Island power system with a power system analysis tool—Power System Simulator for Engineering (PSS/E). The optimization problem was solved using MATLAB. Full article

Consumers in electricity markets are becoming more proactive because of the rapid development of demand–response management and distributed energy resources, which boost the transformation of peer-to-peer (P2P) energy-trading mechanisms. However, in the P2P negotiation process, it is a challenging task to prevent private information from being attacked by malicious agents. In this paper, we propose a privacy-preserving, two-party, secure computation mechanism for consensus-based P2P energy trading. First, a novel P2P negotiation mechanism for energy trading is proposed based on the consensus + innovation (C + I) method and the power transfer distribution factor (PTDF), and this mechanism can simultaneously maximize social welfare and maintain physical network constraints. In addition, the C + I method only requires a minimum set of information to be exchanged. Then, we analyze the strategy of malicious neighboring agents colluding to attack in order to steal private information. To defend against this attack, we propose a two-party, secure computation mechanism in order to realize safe negotiation between each pair of prosumers based on Paillier homomorphic encryption (HE), a smart contract (SC), and zero-knowledge proof (ZKP). The energy price is updated in a safe way without leaking any private information. Finally, we simulate the functionality of the privacy-preserving mechanism in terms of convergence performance, computational efficiency, scalability, and SC operations. Full article

The ever-expanding power system is developed into an interconnected pattern of power grids. Zone partitioning is an essential technique for the operation and management of such an interconnected power system. Owing to the transmission capacity limitation, transmission congestion may occur with a regional influence on power system. If transmission congestion is considered when the system is decomposed into several regions, the power consumption structure can be optimized and power system planning can be more reasonable. At the same time, power resources can be properly allocated and system safety can be improved. In this paper, we propose a power system zone partitioning method where the potential congested branches are identified and the spectral clustering algorithm is improved. We transform the zone partitioning problem into a graph segmentation problem by constructing an undirected weighted graph of power system where the similarities between buses are measured by the power transfer distribution factor (PTDF) corresponding to the potential congested branches. Zone partitioning results show that the locational marginal price (LMP) in the same zone is similar, which can represent regional price signals and provide regional auxiliary decisions. Full article

The definition of bidding zones is a relevant question for electricity markets. The bidding zones can be identified starting from information on the nodal prices and network topology, considering the operational conditions that may lead to congestion of the transmission lines. A well-designed bidding zone configuration is a key milestone for an efficient market design and a secure power system operation, being the basis for capacity allocation and congestion management processes, as acknowledged in the relevant European regulation. Alternative bidding zone configurations can be identified in a process assisted by the application of clustering methods, which use a predefined set of features, objectives and constraints to determine the partitioning of the network nodes into groups. These groups are then analysed and validated to become candidate bidding zones. The content of the manuscript can be summarized as follows: (1) A novel probabilistic multi-scenario methodology was adopted. The approach needs the analysis of features that are computed considering a set of scenarios defined from solutions in normal operation and in planned maintenance cases. The weights of the scenarios are indicated by TSOs on the basis of the expected frequency of occurrence; (2) The relevant features considered are the Locational Marginal Prices (LMPs) and the Power Transfer Distribution Factors (PTDFs); (3) An innovative computation procedure based on clustering algorithms was developed to group nodes of the transmission electrical network into bidding zones considering topological constraints. Several settings and clustering algorithms were tested in order to evaluate the robustness of the identified solutions. Full article

This paper presents a static network equivalent model for Korean power systems. The proposed equivalent model preserves the overall transmission network characteristics focusing on power flows among areas in Korean power systems. For developing the model, a power transfer distribution factor (PTDF)-based k-means++ algorithm was used to cluster the bus groups in which similar PTDF characteristics were identified. For the reduction process, the bus groups were replaced by a single bus with a generator or load, and an equivalent transmission line was determined to maintain power flows in the original system model. Appropriate voltage levels were selected, and compensation for real power line losses was made for the correct representation. A Korean power system with more than 1600 buses was reduced to a 38-bus system with 13 generators, 25 loads, and 74 transmission lines. The effectiveness of the developed equivalent model was evaluated by performing power flow simulations and comparisons of various characteristics of the original and reduced systems. The simulation comparisons show that the developed equivalent model maintains inter-area power flows as close as possible to the original Korean power systems. Full article

Future power systems will be based on the more active role of distribution system and its cooperation with transmission system. The main issue, which will appear in the network, is the congestion. Congestion management will become one of the crucial elements of power system operation since Distributed Energy Resources (DERs) will be playing a more important role in power systems. Moreover, the evolution also changed the character of the systems to be more dynamic—the need for precise description of power flow and shares of particular nodes in line flows will emerge. This paper presents the potential solution to the congestion management problem by using the active role of the distribution system, which may dismantle the congestions by offering flexibility services. The tools which will be indispensable in this process will be Power Flow Tracing (PFT) methods. The main goal of this paper is to present modification of PFT method and its possible applications. The correctness of the Modified Inage Domain (MID) method is verified. The identification, verification and possible applications of the new MID method are also shown in the paper. It has been proven that the new method may be used in applications of allocation of transmission cost and in application in modern power systems for advanced congestion management. Full article

In power systems, flow allocation (FA) methods enable to allocate the usage and costs of the transmission grid to each single market participant. Based on predefined assumptions, the power flow is split into isolated generator-specific or producer-specific sub-flows. Two prominent FA methods, Marginal Participation (MP) and Equivalent Bilateral Exchanges (EBEs), build upon the linearized power flow and thus on the Power Transfer Distribution Factors (PTDFs). Despite their intuitive and computationally efficient concepts, they are restricted to networks with passive transmission elements only. As soon as a significant number of controllable transmission elements, such as high-voltage direct current (HVDC) lines, operate in the system, they lose their applicability. This work reformulates the two methods in terms of Virtual Injection Patterns (VIPs), which allows one to efficiently introduce a shift parameter q to tune contributions of net sources and net sinks in the network. In this work, major properties and differences in the methods are pointed out, and it is shown how the MP and EBE algorithms can be applied to generic meshed AC-DC electricity grids: by introducing a pseudo-impedance $\overline{\mathit{\omega }}$ , which reflects the operational state of controllable elements and allows one to extend the PTDF matrix under the assumption of knowing the current flow in the system. Basic properties from graph theory are used to solve for the pseudo-impedance in dependence of the position within the network. This directly enables, e.g., HVDC lines to be considered in the MP and EBE algorithms. The extended methods are applied to a low-carbon European network model (PyPSA-EUR) with a spatial resolution of 181 nodes and an 18% transmission expansion compared to today’s total transmission capacity volume. The allocations of MP and EBE show that countries with high wind potentials profit most from the transmission grid expansion. Based on the average usage of transmission system expansion, a method of distributing operational and capital expenditures is proposed. In addition, it is shown how injections from renewable resources strongly drive country-to-country allocations and thus cross-border electricity flows. Full article

Recently, there have been many cases in which direct current (DC) facilities have been placed in alternating current (AC) systems for various reasons. In particular, in Korea, studies are being conducted to install a back-to-back (BTB) voltage-sourced converter (VSC) high-voltage direct current (HVDC) to solve the fault current problem of the meshed system, and discussions on how to operate it have been made accordingly. It is possible to provide grid services such as minimizing grid loss by changing the HVDC operating point, but it also may violate reliability standards without proper HVDC operation according to the system condition. Especially, unlike the AC system, DC may adversely affect the AC system because the operating point does not change even after a disturbance has occurred, so strategies to change the operating point after the contingency are required. In this paper, a method for finding the operating point of embedded HVDC that minimizes losses within the range of compliance with the reliability criterion is proposed. We use the Power Transfer Distribution Factor (PTDF) to reduce the number of buses to be monitored during HVDC control, reduce unnecessary checks, and determine the setpoints for the active/reactive power of the HVDC through system total loss minimization (STLM) control to search for the minimum loss point using Powell’s direct set. We also propose an algorithm to search for the operating point that minimizes the loss automatically and solves the overload occurring in an emergency through security-constrained loss minimization (SCLM) control. To verify the feasibility of the algorithm, we conducted a case study using an actual Korean power system and verified the effect of systematic loss reduction and overload relief in a contingency. The simulations are conducted by a commercial power system analysis tool, Power System Simulator for Engineering (PSS/E). Full article

Separating point clouds into ground and non-ground points is a preliminary and essential step in various applications of airborne light detection and ranging (LiDAR) data, and many filtering algorithms have been proposed to automatically filter ground points. Among them, the progressive triangulated irregular network (TIN) densification filtering (PTDF) algorithm is widely employed due to its robustness and effectiveness. However, the performance of this algorithm usually depends on the detailed initial terrain and the cautious tuning of parameters to cope with various terrains. Consequently, many approaches have been proposed to provide as much detailed initial terrain as possible. However, most of them require many user-defined parameters. Moreover, these parameters are difficult to determine for users. Recently, the cloth simulation filtering (CSF) algorithm has gradually drawn attention because its parameters are few and easy-to-set. CSF can obtain a fine initial terrain, which simultaneously provides a good foundation for parameter threshold estimation of progressive TIN densification (PTD). However, it easily causes misclassification when further refining the initial terrain. To achieve the complementary advantages of CSF and PTDF, a novel filtering algorithm that combines cloth simulation (CS) and PTD is proposed in this study. In the proposed algorithm, a high-quality initial provisional digital terrain model (DTM) is obtained by CS, and the parameter thresholds of PTD are estimated from the initial provisional DTM based on statistical analysis theory. Finally, PTD with adaptive parameter thresholds is used to refine the initial provisional DTM. These contributions of the implementation details achieve accuracy enhancement and resilience to parameter tuning. The experimental results indicate that the proposed algorithm improves performance over their direct predecessors. Furthermore, compared with the publicized improved PTDF algorithms, our algorithm is not only superior in accuracy but also practicality. The fact that the proposed algorithm is of high accuracy and easy-to-use is desirable for users. Full article

Power system operators must schedule the available generation resources required to achieve an economical, reliable, and secure energy production in power systems. This is usually achieved by solving a security-constrained unit commitment (SCUC) problem. Through a SCUC the System Operator determines which generation units must be on and off-line over a time horizon of typically 24 h. The SCUC is a challenging problem that features high computational cost due to the amount and nature of the variables involved. This paper presents an alternative formulation to the SCUC problem aimed at reducing its computational cost using sensitivity factors and user cuts. Power Transfer Distribution Factors (PTDF) and Line Outage Distribution Factors (LODF) sensitivity factors allow a fast computation of power flows (in normal operative conditions and under contingencies), while the implementation of user cuts reduces computational burden by considering only biding N-1 security constraints. Several tests were performed with the IEEE RTS-96 power system showing the applicability and effectiveness of the proposed modelling approach. It was found that the use of Linear Sensitivity Factors (LSF) together with user cuts as proposed in this paper, reduces the computation time of the SCUC problem up to 97% when compared with its classical formulation. Furthermore, the proposed modelling allows a straightforward identification of the most critical lines in terms of the overloads they produce in other elements after an outage, and the number of times they are overloaded by a fault. Such information is valuable to system planners when deciding future network expansion projects. Full article

This paper presents an online economic re-dispatch scheme based on the generation cost optimization with security constraints to mitigate line overloads before and after line and generation contingencies. The proposed optimization model considers simplification of mathematical expressions calculated from online variables as the power transfer distribution factor (PTDF) and line outage distribution factor (LODF). Thus, a first algorithm that calculates economic re-dispatch for online operation to avoid overloads during the normal operation and a second algorithm that calculates online emergency economic re-dispatch when overloads occur due to line and generator contingencies are proposed in this paper. The results show that the proposed algorithms avoid overload before and after contingencies, improving power system security, and at the same time reducing operational costs. This scheme allows a reduction of power generation units in the electricity market during online operation that considers line overloads in the power system. Full article
