Search Results (20)

In this study, the dynamic responses of railway bridges generated by both blast motions and earthquakes are comparatively studied. A numerical model of a three-span continuous prestressed concrete (PSC) box girder bridge, a representative type of railway structure, was developed to investigate its dynamic performance. Dynamic analyses were conducted under two blast-induced ground motions and four earthquake ground motions, and the structural responses at the girder top were employed to evaluate the dynamic behavior of the railway bridge. The results indicate that the blast-induced bridge responses are relatively small compared to the earthquake-induced bridge responses (2–3% of the bridge response). This implies that the blast vibration limit provided in the Korean standard manual could be excessively conservative when applied to the railway bridges. Also, the results show that the blast vibration limit should be revisited, with a consideration of different structures and conditions. Full article

This study quantifies shear and flexural stiffnesses and their changes over time to support structural health monitoring of in-service bridge superstructures across four girder types: reinforced concrete (RC) beams, prestressed concrete (PSC) girders, steel girders, and ultra-high-performance concrete (UHPC) sections, using field ambient vibration testing. A total of 20 bridges across Georgia and Iowa are assessed, involving over 100 hours of on-site data collection and traffic control strategies. Results show that field-measured natural frequencies differ from theoretical predictions by average of 30–35% for RC, and 20–25% for PSC, 15–25% for steel and 2% for UHPC, reflecting the complexity of in situ structural dynamics and challenges in estimating material properties. Site-placed RC beams showed stiffness reduction due to deterioration, whereas prefabricated PSC girders maintained consistent stiffness with predictable variations. UHPC sections exhibited the highest stiffness, reflecting superior performance. Steel girders matched theoretical values, but a span-level test revealed that deck damage can reduce frequencies undetected by localized measurements. Importantly, vibration-based measurements revealed reductions in structural stiffness that were not apparent through conventional visual inspection, particularly in RC beams. The research significance of this work lies in establishing a portfolio-based framework that enables cross-comparison of stiffness behavior across multiple girder types, providing a scalable and field-validated approach for system-level bridge health monitoring and serving as a quantitative metric to support bridge inspections and decision-making. Full article

Structural health monitoring using various sensors has been widely employed to assess the structural conditions of bridges. In addition, the concept of a digital twin was introduced, which encompasses the life cycle information of a bridge and its real-time data acquisition and utilization. However, the obtained real-time data from sensors primarily reflect the global behavior of the system, making it challenging to identify the root causes of structural changes. For a highly reliable assessment of the global behavior of a bridge, previous history information, that is, a prerequisite model, is required. This study defines a baseline digital twin model (B-DTM) as the stage preceding real-time data utilization in digital twins. The B-DTM is structured into a pre-update phase, which involves the collection of members and system historical data, and a post-update phase, which focuses on model updating. For the case of model updating, due to the inherent complexity of bridge systems, identifying the global optimum for updating remains challenging. In the pre-update phase, a probabilistic approach to historical data such as member stiffness restricts the search domain for model updating, whereas, in the post-update phase, deflection, mode shapes, and natural frequencies derived from load test results representing the real bridge’s behavior are utilized to explore the global optimum solution. The proposed B-DTM was validated using collected data and load test results from a PSC-I girder bridge decommissioned after 45 years of service. Full article

The Sheikh Jaber Al-Ahmad Al-Sabah Causeway consists of an asymmetric cable-stayed bridge (340 m) and a prestressed concrete (PSC) box girder bridge (35.80 km) linking Kuwait City and Northern Kuwait. The full load tests were performed on the PSC box girder bridge and the load scale was set to 14,092 kNm which was 98.47% of the maximum design moment (14,310 kNm). A total of 12 individual 40 tonf dump trucks were exerted on the bridge for the tests. Based on the influence line of the target bridge, displacement sensors, and strain gauges were installed at the points where the maximum bending moment would occur. The collected deflection and strain data were compared with the finite element method analysis to analyze the change in stiffness of the bridge. From the analysis, it was found that higher stiffness behavior was identified compared to the design load. Full article

Development of U-type pre-stressed girders has been attempted to increase the length of I-type girders in South Korea. However, a length of 30 m or less is common because the self-weight, according to the post-tension method, is large. In this study, the pre-tension method was applied without limiting the post-tension method to induce a reduction in self-weight and in the materials used because of the decrease in the cross section. In addition, the authors proposed an application of an on-site pre-tensioning method using the internal reaction arm of a U-type girder. A pre-stressed concrete U-type girder bridge is composed of a concrete deck slab and a composite section. Structural performance characteristics, such as resistance and rigidity, were improved compared to those of the PSC I-type girders. Construction safety is also improved in the manufacturing and installation stages, and the elongation ratio is reduced because of the reduction in the weight of the girders. Therefore, it is possible to ensure the aesthetic landscape and economic efficiency of bridges. As a result, it is expected that efficient construction will be possible with high-quality factory-made and cast-in-place members. In this study, the pre-tension method is introduced in the field, and the analytical performance of the anchoring block used for tension is verified. Full article

This paper investigates the analytical results of the seismic response of multi-span prestressed concrete (PSC) I-girder bridges under seismic loads. To perform numerical analyses, a three-span PSC I-girder bridge with a width of 12 m, a total length of 100 m, and a maximum span length of 40 m was modeled, and a virtual location was selected to consider the soil properties of the area where the bridge was constructed. The seismic load acting on the PSC I-girder bridge was applied in consideration of the soil properties around the pier and the wave passage effect of the bedrock in the artificial seismic load generated, according to the U.S. Nuclear Regulatory Commission (NRC) standard. The analysis results confirmed that the seismic load, with consideration of the soil properties and wave passage effect, generated the maximum response acceleration and bending moment at the deck of the bridge—152% and 232% greater than without considering them, respectively. Therefore, in order to ensure the earthquake resistance of the bridge, the soil properties of the area where the bridge will be built and the wave passage effect of the bedrock must be considered. Full article

The PSC box girder bridge is a pre-stressed box girder bridge that accounts for a considerable part of large-scale bridges. However, when concrete is poured, even small mistakes might result in voids that appear during long-term maintenance. In this paper, we present a technique for detecting the void in the duct inside the PSC box girder bridge. Data are acquired utilizing the non-destructive impact-echo (IE) approach to detect these voids. IE creates time-series data as signal data initially; however, we want to use a CNN auto-encoder (AE). A scalogram, which is a kind of wavelet transformation, is used to convert time series data into an image. An AE is a type of unsupervised learning that aims to minimize the difference between the input and output. By comparing histograms, the difference is calculated. To begin, we create scalogram images from all IE signal data, which were randomly sampled as 98% normal and 2% void. The CNN AE is then trained and evaluated utilizing all the data. Finally, we examine the input and output histogram similarity distributions. As a consequence, only 4% of the normal data had a similarity of less than two standard deviations from the mean, whereas 34.7% of the void data did. As a result, the existence of voids inside the PSC duct could be demonstrated to be predictive in the absence of annotated data. Full article

Maintenance of bridges in use is essential and measuring the live load distribution factor (LLDF) of a bridge to examine bridge integrity and safety is important. A vehicle loading test has been used to measure the LLDF of a bridge. To carry this out on a bridge in use, traffic control is required because loading must be performed at designated positions using vehicles whose details are known. This makes it difficult to measure LLDF. This study proposed a method of estimating the LLDF of a bridge using the vertical displacement response caused by traveling vehicles under ambient vibration conditions in the absence of vehicle control. Since the displacement response measured from a bridge included both static and dynamic components, the static component required for the estimation of LLDF was extracted using empirical mode decomposition (EMD). The vehicle loading and ambient vibration tests were conducted to verify the validity of the proposed method. It was confirmed that the proposed method can effectively estimate the LLDF of a bridge if the vehicle type and driving lane on the bridge are identified in the ambient vibration test. Full article

Although integral abutment bridges (IABs) have become a preferred construction choice for short- to medium-length bridges, they still have unclear bridge design guidelines. As IABs are supported by nonlinear boundaries, bridge geometric parameters strongly affect IAB behavior and complicate predicting the bridge response for design and assessment purposes. This study demonstrates the effect of four dominant parameters: (1) girder material, (2) bridge length, (3) backfill height, and (4) construction joint below girder seats on the response of IABs to the rise and fall of AASHTO extreme temperature with time-dependent effects in concrete materials. The effect of factors influencing bridge response, such as (1) bridge construction timeline, (2) concrete thermal expansion coefficient, (3) backfill stiffness, and (4) pile-soil stiffness, are assumed to be constant. To compare girder material and bridge geometry influence, the study evaluates four critical superstructure and substructure response parameters: (1) girder axial force, (2) girder bending moment, (3) pile moment, and (4) pile head displacement. All IAB bridge response values were strongly related to the four considered parameters, while they were not always linearly proportional. Prestressed concrete (PSC) bridge response did not differ significantly from the steel bridge response. Forces and moments in the superstructure and the substructure induced by thermal movements and time-dependent loads were not negligible and should be considered in the design process. Full article

This paper presents a multi-functional strand capable of introducing prestressing force in prestressed concrete (PSC) girders and sensing their static and dynamic behavior as well. This innovative strand is developed by replacing the core steel wire of the strand used in PSC structures with a carbon fiber-reinforced polymer (CFRP) wire with a built-in optical Fiber Bragg Grating (FBG) sensor. A full-scale girder specimen was fabricated by applying this multi-function strand to check the possibility of tracking the change of prestressing force at each construction stage. Moreover, dynamic data could be secured during dynamic loading tests without installing accelerometers and made it possible to obtain the natural frequencies of the structure. The results verified the capability to effectively manage the prestressing force in the PSC bridge structure by applying the PC strand with a built-in optical sensor known for its outstanding practicability and durability. Full article

This study intends to verify analytically and experimentally the performance of a new type of prestressed concrete (PSC) I-girder for its application as railway bridge. Since the girder-type railway bridge develops relatively low torsional rigidity, there is risk for the dynamic responses to amplify due to the superposition of the torsional mode and flexural mode. The superposition of the torsional and flexural modes as well as the dynamic stability of the railway bridge were examined through dynamic analysis. Three-dimensional modelling was built to be suitable for carrying out moving load analysis. Four different span lengths of 30, 35, 40 and 45 m adopted considering the most applied span length currently and future lengthening of the span length. Moreover, a full-scale girder specimen with span length of 35 m was fabricated and subjected to dynamic loading. The measured dynamic responses were then compared to the analytic values. Finally, the ultimate bearing capacity of the specimen was verified by static loading test. Full article

The proper distribution of prestressing force (PF) is the basis for the design of prestressed concrete (PSC) structures. However, the PF distribution obtained by predictive equations of prestress losses has not been sufficiently validated by comparison with measured data due to the poor reliability and durability of conventional sensing technologies. Therefore, the Smart Strand with embedded fiber optic sensors was developed and applied to PSC structures to investigate the long-term characteristics of PF distribution as affected by concrete creep and shrinkage. The data measured in a 20 m-long full-scale specimen and a 60 m-long PSC girder bridge were analyzed by comparing them with the theoretical estimation obtained from several design equations. Although the long-term decreasing trend of the PF distribution was similar in the measurement and theory, the equation of Eurocode 2 for estimating the long-term prestress losses showed better agreement with the measurement than ACI 209R and ACI 423.10R did. This can be attributed to the more refined form of the predictive equation of Eurocode 2 in dealing with the time-dependency of the PF. The study results also confirmed the need to compensate for the temperature variation in the long-term monitoring to derive the actual mechanical strain related to the PF. We expect our developed Smart Strand to be applied practically in PF measurement for the reasonable safety assessment and maintenance of PSC structures by improving several of the existing drawbacks of conventional sensors. Full article

The friction-type high-strength bolted (FHSB) T-stub connection has been widely used in steel structures, due to their good fatigue resistance and ease of installation. While the current studies on FHSB T-stub connections mainly focus on the structural behaviors under both shear and tensile force, no research has been reported on the mechanical responses of the connections under the combined effects of shear and compression. To make up for this gap, this paper presents a novel FHSB T-stub connection, which is simple in structure, definite in load condition, and easy to construct. Static load tests were carried out on 21 specimens under different shear–compression ratios, and the finite-element (FE) models were created for each specimen. The failure modes, initial friction loads and ultimate strengths of the specimens were compared in details. Then, 144 FE models were adopted to analyze the effects of the friction coefficient, shear–compression ratio, bolt diameter and clamping force on the initial friction load and ultimate strength. The results showed that the FHSB T-stub connection under shear and compression mainly suffers from bolt shearing failure. The load–displacement curve generally covers the elastic, yield, hardening and failure stage. If the shear–compression ratio is small and the friction coefficient is large, its curve only contains the elastic and failure stage. The friction coefficient and shear–compression ratio have great impacts on the initial friction load and ultimate strength. For every 1 mm increase in bolt diameter, the initial friction load increased by about 10%, while the ultimate strength increased by about 8.5%. For each 10% increase/decrease of the design clamping force, the initial friction load decreases/increases by 7.8%, while the ultimate load remains basically the same. The proposed formula of shear capacity and self-lock angles of FHSB T-stub connection can be applied to the design of CSS-enhanced prestressed concrete continuous box girder bridges (PSC-CBGBs) and diagonal bracing. Full article

Imaging devices attached to unmanned aerial vehicles (UAVs) are used for crack measurements of railway bridges constructed for high-speed trains. This research aims to investigate track-side wind induced by high-speed trains and its effect on UAV thrust near the railway bridge. Furthermore, the characteristics of train-induced wind in three axial directions along a track, wind velocity, and the effect of train-induced wind on the UAV thrust were analyzed. This was achieved by installing 3-axis ultrasonic anemometers and a UAV thrust measurement system on top of a PSC box girder bridge. The changes in the train-induced wind velocity were monitored along the train travel, width, and height directions. The train-induced wind was measured at distances of 0.8, 1.3, 2.3, and 2.8 m away from the train’s body to analyze wind velocity based on distance. It was found that the maximum wind velocity decreased linearly as the distance from the train’s body increased. The UAV thrust increased by up to 20% and 60%, owing to train-induced wind when the leading and trailing power cars of a high-speed train passed, respectively. Thus, it is necessary to conduct further research to develop robust control and a variable pitch-propeller that can control thrust. Full article

This paper proposes a performance-based resistance deterioration model that reflects the site environment and inspection data for highway bridges. Traffic characteristics and corrosive environment are considered as the site environment. The corrosive environments and traffic characteristics are classified into three categories, namely mild, normal, and severe for the former and light, normal, and heavy for the latter. The deterioration of the resistance capacity due to corrosive environments is evaluated considering both the service period and the concrete crack widths in the pre-stressed concrete (PSC) girder and the reinforced concrete (RC) slab. The deterioration model of the resistance capacity is calibrated by combining the performance degradation model. The performance degradation model is also calibrated using previous bridge inspection results from the standard performance degradation model, which has been developed based on the large amount of data available on many pre-stressed concrete-I (PSC-I) type girder bridges. The developed performance-based resistance deterioration model is used to evaluate the reliability of a bridge in the future. The results show that the performance inspection outcomes, either based on the current status or lifetime inspection history, are critical in estimating the future degradation of the reliability level, inherent to the bridge. Full article
