Metal–organic chemical vapor deposition (MOCVD) is a crystal growth technique used to achieve high-purity thin films, especially III–V materials, for fabricating semiconductor devices. It allows for thickness tunability, controlled doping, and composition of epilayers. This review focuses on the principle of MOCVD, its historical background, and its applications in III–V semiconductor devices such as solar cells, high electron mobility transistors (HEMTs), light-emitting diodes (LEDs), laser diodes (LDs), and photonic integrated circuits (PICs). This review highlights the recent developments in MOCVD aimed at improving its efficiency, performance, and sustainability. Finally, we emphasize emerging trends and challenges in MOCVD process innovation, reactor design, and material integration that are poised to drive the development of next-generation optoelectronic, photonic, and quantum technologies. Together, these findings underscore MOCVD’s pivotal role in enabling high-performance devices and sustaining leadership in post-Moore semiconductor technologies. Full article

Photonic-crystal surface-emitting lasers (PCSELs) are a new type of semiconductor laser with the potential for high-power output and high-beam-quality operation. Integrating a distributed Bragg reflector (DBR) into PCSELs can significantly enhance device performance. However, the growth of high-aluminum-content DBRs on photonic crystal layers with buried air holes presents two major challenges. First, the low mobility of aluminum atoms increases the propagation of surface roughness from the substrate into the DBR, increasing defect density. Second, the high growth temperatures required for DBR growth can deform the thermally unstable air holes. In this work, we investigated a metal–organic chemical vapor deposition (MOCVD) regrowth process for fabricating DBRs on PCSELs. By adjusting the epitaxial growth temperature and V/III ratio, we effectively controlled the diffusion of adatoms on both the sample surface and inside the holes. As a result, the root mean square (RMS) surface roughness decreased by ~96%, and uniform buried air holes were obtained, with a filling factor of ~ 18.8% and a depth of ~ 270 nm, without significant deformation. Finally, we fabricated a PCSEL device with a DBR structure, exhibiting a beam divergence angle of ~ 0.5° and a peak power of about 0.86 W. This study provides a key process solution for the development of PCSELs with high-quality DBR structures, enabling further improvement in optical output performance. Full article

Volatile coordination compounds are widely used as precursors for the gas phase synthesis of functional materials. However, such complexes are still very rare for alkali metals, especially for heavy representatives of this family (potassium, rubidium, cesium) due to the tendency to form polymeric structures. This work is devoted to the exploration of a potassium hexafluoroacetylacetonate complex with 18-crown-6 ether, K(18C6)(hfac), as a unique volatile precursor with an isolated molecular structure. A convenient synthesis procedure was developed, and key structural features were identified including temperature-dependent effects. The thermal properties of the complex were studied via thermogravimetry and measurements of saturated vapor pressure using the Knudsen effusion method with mass spectrometric registration of the gas phase composition. Both from solution and the gas phase, the molecular films of K(18C6)(hfac) obtained exhibit a strictly (h00) orientation, where half of the surface cations have a coordination sphere accessible to supramolecular contacts. For the first time, the possibility of producing potassium-containing films from a fluorinated precursor by metal–organic chemical vapor deposition (MOCVD) has been demonstrated. With oxygen as the reactant gas, potassium fluoride forms and interacts with the silicon substrate, while introducing water vapor significantly reduces the fluorine content, suggesting its suitability for the preparation of oxide films. Full article

From 4G to 5G to 6G, every few years, a new generation of data transmission technology emerges to meet the growing demand for faster and more efficient communication. Artificial intelligence, the Internet of Things and the increasing need for global connectivity are the key drivers of this evolution, pushing both research and industry toward ever-higher data rates. These advanced technologies already consume vast amounts of resources and energy, relying on high-tech nano-fabrication processes such as metal–organic chemical vapor deposition, dry etching, deposition and lithography, all of which typically occur in energy-intensive cleanroom environments. This study evaluates the epitaxy process of GaN on SiC for high-electron-mobility transistor (HEMT) devices and integrated circuits using life cycle assessment. GaN HEMTs offer high efficiency and excellent thermal conductivity, paving the way for reduced chip footprints for lower energy consumption. This analysis enables informed decision-making regarding sustainability by providing detailed data and interpretation of Fraunhofer IAF’s GaN-on-SiC HEMT technology. Full article

To achieve an atomically clean surface of single-crystal aluminum nitride (AlN) substrates, this study systematically evaluated the effects of each step in ex situ wet chemical cleaning (solvent, piranha solution, HF, HCl) and in situ hydrogen annealing. X-ray photoelectron spectroscopy (XPS) and atomic force microscopy (AFM) analyses revealed that while the combination of solvent and piranha solution exposed step morphology, its effectiveness in removing organic contaminants was limited. HF cleaning efficiently removed the oxide layer but introduced fluorine residues, whereas HCl cleaning left no chlorine residues but exhibited lower efficiency in oxide removal. In situ hydrogen annealing significantly reduced carbon and oxygen contamination, albeit accompanied by a transformation of the surface morphology from step to island mode. By modulating the low V/III ratio during low-temperature metal–organic chemical vapor deposition (MOCVD) growth, a controlled transition from 3D island growth to 2D step-flow growth was achieved. This research provides a basis for optimizing AlN substrate surface treatment, offering important insights for advancing nitride-based optoelectronic and power devices. Full article

A combined microanalysis and optical study of β-(Al_xGa_1−x)₂O₃ films grown on sapphire via metalorganic chemical vapour deposition, with thickness 350–1000 nm and Al fraction (x) from 0% to 45%, is presented. Al incorporation in the films showed a linear relation with nominal Al composition calculated from precursor flow rate, and the optical bandgap increased from 4.96 eV to 5.44 eV with a bowing parameter of 1.7 ± 0.5 eV. A high Al fraction led to reduced crystallinity, increased surface roughness, and diminished cathodoluminescence intensity. The topography revealed elongated surface features that evolved with Al content, and luminescence spectra exhibited a blueshift in peak emission attributed to the widening of the bandgap. These findings highlight the trade-off between bandgap tuning and material quality, informing future growth strategies for future electronic and optical devices. Full article

We report on the fabrication and characterization of InGaN-based ridge-waveguide laser diodes employing spin-on-glass (SOG) as the insulation and planarization layer. In contrast to conventional silicon dioxide (SiO₂) isolation deposited by PECVD, the SOG approach provides improved surface planarity, reduced processing complexity, and lower fabrication cost. The laser structures were grown on GaN substrates by MOCVD, with the active region consisting of In_0.11Ga_0.89N quantum wells. Following ridge formation and SOG deposition, an etch-back process was used to form the electrical contacts. We have demonstrated the formation of high-quality insulating surfaces with strong adhesion to the ridge sidewalls. When using a Ni protective layer, the fabricated devices exhibited favorable electrical and optical characteristics and achieved stable laser operation under both pulsed and continuous-wave conditions. These results indicate that the SOG-based insulation process represents a promising alternative for the scalable and cost-effective fabrication of InGaN laser diodes targeting advanced photonic applications. Full article

Ga₂O₃ and In₂O₃ are vital semiconductors with current and future electronic device applications. Here, we study the alloying of In₂O₃ and Ga₂O₃ (IGO) and the associated changes in structure, morphology, band gap, and electrical transport properties. Undoped films of IGO were deposited on sapphire substrates with varying indium (In) percentage from zero to 100% by metal-organic chemical vapor deposition (MOCVD). Some films were annealed in H₂ to induce electrical conductivity. The measurements showed the optical band gap decreased by adding In; this was confirmed by density functional (DFT) calculations, which revealed that the nature of the valence band maximum and conduction band minimum strongly relate to the chemistry and that the band gap drops by adding In. The as-grown films were highly resistive except for pure In₂O₃, which possesses p-type conductivity, likely arising from In vacancy-related acceptor states. N-type conductivity was induced in all films after H-anneal. DFT calculations revealed that the presence of In decreases the electron effective mass, which is consistent with the electrical transport measurements that showed higher electron mobility for higher In percentage. The work revealed the successful band gap engineering of IGO and the modification of its band structure while maintaining high-quality films by MOCVD. Full article

By employing graded-interfaces modeling, ~10 μm-emitting quantum cascade lasers (QCLs) are designed with previously found conditions for record-high wall-plug efficiency (WPE) operation of mid-infrared QCLs: direct resonant-tunneling injection from a prior-stage low-energy state into the upper-laser level, photon-induced carrier transport, and carrier-leakage suppression via the step-taper active-region (STA) approach. For devices with interface-roughness (IFR) parameters characteristic of optimized molecular-beam-epitaxy (MBE) growth, a maximum front-facet pulsed WPE value of 19.6% is projected for 60-stages STA-type devices. This results from several factors: 19 mV voltage defect at threshold, 72% voltage efficiency at the maximum WPE point, and ~93% injection efficiency due to strong carrier-leakage suppression. 2.7 W peak front-facet power is projected. For devices with our metal–organic chemical vapor deposition (MOCVD)-growth IFR parameters, the projected maximum pulsed WPE value is 17.1%, i.e., 1.7 times higher than the highest reported front-facet WPE value from ~10 μm-emitting MOCVD-grown QCLs. Studies regarding the WPE value variation with the stage number, while employing waveguide designs having the same empty cavity loss, reveal that the maximum WPE value remains almost the same for 50–60 stages devices. In turn, there is potential for obtaining significantly higher CW powers than from conventional ~10 μm-emitting QCLs. Full article

This work systematically investigates the heteroepitaxial growth of β-Ga₂O₃ thin films under varied substrate and temperature conditions via metalorganic chemical vapor deposition (MOCVD). Comprehensive characterization reveals that both the substrate type and growth temperature significantly influence the crystalline quality, surface morphology, chemical composition, and defect structure. Films grown at higher temperatures generally exhibit superior crystallinity and closer-to-stoichiometry composition, and thus suggest a reduction in oxygen deficiency. Certain substrates are shown to facilitate high-quality epitaxial growth with smooth surfaces and excellent crystallographic alignment. These findings offer key insights into optimizing growth parameters for high-performance β-Ga₂O₃-based devices. Full article

Al_xGa_1-xN layers with up to 53% Al composition and 1.3 µm total thicknesses were grown utilizing step-graded layers on dense arrays of 10 × 10 µm² GaN tiles. While the layers were fully relaxed and crack-free, the higher Al composition sample showed increased X-ray line width, which did not correlate with a lack of increased dislocation density (as measured by TEM). Full article

N-polar GaN HEMT technology has emerged as a disruptive technology that outperforms Ga-polar GaN HEMTs in terms of high-frequency power amplification capability. In this paper, the authors present a comprehensive review of the evolution of N-polar GaN HEMT technology from the perspective of crystal growth, dielectrics, and metals on N-polar GaN, transistor design, and performance. Specifically, the authors discuss the progress of the N-polar GaN HEMTs toward high-frequency, high-power, and high-efficiency applications with recent record-level performances, demonstrated by the authors, at mmWave frequencies. Full article

Direct chemical vapor deposition (CVD) growth of hexagonal boron nitride (h-BN) on insulating substrates offers a promising pathway to circumvent transfer-induced defects and enhance device integration. This comprehensive review systematically evaluates recent advances in CVD techniques for h-BN synthesis on insulating substrates, including metal–organic CVD (MOCVD), low-pressure CVD (LPCVD), atmospheric-pressure CVD (APCVD), and plasma-enhanced CVD (PECVD). Key challenges, including precursor selection, high-temperature processing, achieving single-crystalline films, and maintaining phase purity, are critically analyzed. Special emphasis is placed on comparative performance metrics across different growth methodologies. Furthermore, crucial research directions for future development in this field are outlined. This review aims to serve as a reference for advancing h-BN synthesis toward practical applications in next-generation electronic and optoelectronic devices. Full article

Tantalum oxide is a wide bandgap material commonly used as an insulating dielectric layer for devices. In this work, hexagonal Ta₂O₅ (δ-Ta₂O₅) films doped with tungsten (W) were deposited on α-Al₂O₃ (0001) by metal–organic chemical vapor deposition (MOCVD). The effects of W doping on the structural, morphology, and photoelectrical properties of the obtained films were studied. The results showed that all W-doped films were n-type semiconductors. The XRD measurement result exhibited that the increase in the W doping concentration leads to the changes in the preferred growth crystal plane of the films from δ-Ta₂O₅ ($10\overline{1}1$) to (0001). The 1.5% W-doped film possessed the best crystal quality and conductivity. The Hall measurement showed that the minimum resistivity of the film was 2.68 × 10⁴ Ω∙cm, and the maximum carrier concentration was 7.39 × 10¹⁴ cm³. With the increase in the W concentration, the surface roughness of the film increases, while the optical bandgap decreases. The optical band gap of the 1.5% W-doped film was 3.92 eV. The W doping mechanisms were discussed. Full article

Gallium nitride (GaN) is commonly used in various semiconductor systems owing to its high mobility and thermal stability; however, the production of GaN thin films using the currently employed methods requires improvement. To facilitate the growth of high-quality GaN epitaxial thin films, this study explored the crystallographic structures, properties, and influences of chromium nitride (CrN) buffer layers sputtered under various conditions. The crystallographic orientation of CrN played a crucial role in determining the GaN film quality. For example, even when the crystallinity of the CrN (111) plane was relatively low, a single-phase CrN (111) buffer layer could provide a more favorable template for GaN epitaxy compared to cases where both the CrN (111) and Cr₂N (110) phases coexisted. The significance of a low-temperature (LT) GaN nucleation layer deposited onto the CrN buffer layers was assessed using atomic force microscopy and contact angle measurements. The X-ray phi scan results confirmed the six-fold symmetry of the grown GaN, further emphasizing the contribution of an LT-GaN nucleation layer. These findings offer insights into the underlying mechanisms governing GaN thin film growth and provide guidance for the optimization of the buffer layer conditions to achieve high-quality GaN epitaxial films. Full article
