For complex mechanical transmission equipment, shaft bearings are usually enclosed together with the shaft in the internal space of the housing to maintain good sealing and reliability. However, it is difficult to monitor the status of the shaft bearing through external sensors on the housing, while internal sensors face challenges in energy supply and data transmission. Therefore, a piezoelectric transducer ring-based energy harvesting microelectromechanical system (PTR-EH-MEMS) is proposed for the condition monitoring of shaft bearings. Specifically, the piezoelectric transducer ring is designed to convert mechanical vibrations into electrical energy, which simultaneously acts as a self-powered monitoring sensor through energy harvesting. In addition, the MEMS is embedded for piezoelectric data processing and condition monitoring of the shaft bearings. To verify the proposed PTR-EH-MEMS, an experimental investigation is implemented under different conditions. The experimental results demonstrate that the system can achieve the maximum DC output of 0.8 V and the root mean square power of 43.979 μW within 128 s, which can effectively identify early-stage bearing faults frequency through a self-powered mode. By combining energy harvesting with condition monitoring capability, the PTR-EH-MEMS offers a compact and sustainable approach for predictive maintenance in rotating machinery, reducing the reliance on external power sources and enhancing the reliability of industrial systems. Full article

In recent years, there has been an increasing use of digital vibration sensors that are based on capacitive MEMS accelerometers for machine vibration monitoring and diagnostics. These sensors simplify the design of monitoring and diagnostic systems, thus reducing implementation costs. However, it is important to understand how effective these digital sensors are in detecting rolling bearing faults. This article describes a method for determining the diagnostic sensitivity of diagnostic parameters provided by commercially available vibration sensors based on MEMS accelerometers. Experimental tests were conducted in laboratory conditions, during which vibrations from 11 healthy and faulty rolling bearings were measured using two commercial vibration sensors based on MEMS accelerometers and a piezoelectric accelerometer as a reference sensor. The results showed that the diagnostic sensitivity of the parameters depends on the upper-frequency band limit of the sensors, and the parameters most sensitive to the typical fatigue faults of rolling bearings are the peak and peak-to-peak amplitudes of vibration acceleration. Despite having a lower upper-frequency range compared to the piezoelectric accelerometer, the commercial vibration sensors were found to be sensitive to rolling bearing faults and can be successfully used in continuous monitoring and diagnostics systems for machines. Full article

Rotor imbalance is considered to be one of the main mechanical faults of rotating machinery; which may result in bearing damage and even catastrophic system failure. Recent progress in the Internet of Things (IoT) has promoted the application of novel sensing and computing techniques in the industry, and it is promising to employ novel IoT techniques for imbalance detection to avoid potential failures. Existing sensing techniques suffer from the impact of bearing structure dynamics, loss of accuracy during their lifetime, and security risks introduced by the sensor cabling and supports, which may, in turn, interfere with the machine operations due to inappropriate design and installation. This investigation provides an on-shaft machine wearable vibration sensing technique for effectively monitoring the running state of rotors while minimizing the interference with their operations. In this work, key investigations include the following: (1) theoretical modeling and an analysis of rotor imbalance, and its measurement with an on-shaft micro-electromechanical system (MEMS) accelerometer; (2) the development of a wirelessly powered, cordless on-shaft vibration measurement (OSVM) sensor for unobtrusive sensing of the vibration of rotating shafts; (3) the in-sensor computing design for optimizing the distribution of computing resources and decreasing data transmission. The tests and evaluation of the proposed techniques were conducted with a rotor test rig to demonstrate their feasibility. The presented investigation is a typical example of applying new sensing and computing paradigms to improve the flexibility and convenience of applications, which is a good reference for related investigations and practices. Full article

Electric potential controlled lubrication, also known as triboelectrochemistry or electrotunable tribology, is an emerging field to regulate the friction, wear, and lubrication performance under charge distribution on the solid–liquid interfaces through an applied electric potential, allowing to achieve superlubrication. Electric potential controlled lubrication is of great significance for smart tunable lubrication, micro-electro-mechanical systems (MEMS), and key components in high-end mechanical equipment such as gears and bearings, etc. However, there needs to be a more theoretical understanding of the electric potential controlled lubrication between micro- and macro-scale conditions. For example, the synergistic contribution of the adsorption/desorption process and the electrochemical reaction process has not been well understood, and there exists a significant gap between the theoretical research and applications of electric potential controlled lubrication. Here, we provide an overview of this emerging field, from introducing its theoretical background to the advantages and characteristics of different experimental configurations (including universal mechanical tribometers, atomic force microscopes, and surface force apparatus/balances) for electric potential controlled lubrication. Next, we review the main experimental achievements in the performance and mechanisms of electrotunable lubrication, especially using ionic lubricants, including electrolyte solutions, ionic liquids, and surfactants. This review aims to survey the literature on electric potential controlled lubrication and provide insights into the design of superlubricants and intelligent lubrication systems for various applications. Full article

Friction, wear, and the consequent energy dissipation pose significant challenges in systems with moving components, spanning various domains, including nanoelectromechanical systems (NEMS/MEMS) and bio-MEMS (microrobots), hip prostheses (biomaterials), offshore wind and hydro turbines, space vehicles, solar mirrors for photovoltaics, triboelectric generators, etc. Nature-inspired bionic surfaces offer valuable examples of effective texturing strategies, encompassing various geometric and topological approaches tailored to mitigate frictional effects and related functionalities in various scenarios. By employing biomimetic surface modifications, for example, roughness tailoring, multifunctionality of the system can be generated to efficiently reduce friction and wear, enhance load-bearing capacity, improve self-adaptiveness in different environments, improve chemical interactions, facilitate biological interactions, etc. However, the full potential of bioinspired texturing remains untapped due to the limited mechanistic understanding of functional aspects in tribological/biotribological settings. The current review extends to surface engineering and provides a comprehensive and critical assessment of bioinspired texturing that exhibits sustainable synergy between tribology and biology. The successful evolving examples from nature for surface/tribological solutions that can efficiently solve complex tribological problems in both dry and lubricated contact situations are comprehensively discussed. The review encompasses four major wear conditions: sliding, solid-particle erosion, machining or cutting, and impact (energy absorbing). Furthermore, it explores how topographies and their design parameters can provide tailored responses (multifunctionality) under specified tribological conditions. Additionally, an interdisciplinary perspective on the future potential of bioinspired materials and structures with enhanced wear resistance is presented. Full article

The tribological characteristics of a below 1 mm micro ball bearing comprising steel disc and cages coated with thin copper and silver films were investigated. Electroplating and laser cutting were used to manufacture used elements. Friction was measured using a linear stage and an adapted version of a friction-loop method. The obtained results show an interesting relationship between the geometric properties of the micro scale thrust bearing and their performance and operational stability, which can be correlated to similar relationships observed in the macro scale. The most optimal design of the bearing showed stable operation, with the simplified rolling resistance coefficient in the range 0.002 to 0.003, independently of applied load, which was in range 150 mN to 1500 mN. The possibility of creating easily manufacturable micro ball bearings with a low rolling resistance coefficient comprised solely of cheap and sturdy elements was shown. Full article

In this paper, we present different microelectromechanical systems based on electrostatic actuators, and demonstrate their capacity to achieve large and stepwise displacements using a cooperative function of the actuators themselves. To explore this, we introduced micro-stepper actuators to our experimental systems, both with and without a guiding spring mechanism; mechanisms with such guiding springs can be applied to comb-drive and parallel-plate actuators. Our focus was on comparing various guiding spring designs, so as to increase the actuator displacement. In addition, we present systems based on cascaded actuators; these are converted to micromechanical digital-to-analog converters (DAC). With DACs, the number of actuators (and thus the complexity of the digital control) are significantly reduced in comparison to analog stepper-actuators. We also discuss systems that can achieve even larger displacements by using droplet-based bearings placed on an array of aluminum electrodes, rather than guiding springs. By commutating the voltages within these electrode arrays, the droplets follow the activated electrodes, carrying platforms atop themselves as they do so. This process thus introduces new applications for springless large displacement stepper-actuators. Full article

In the field of vibration monitoring and control, the use of low-cost multicomponent MEMS-based accelerometer sensors is nowadays increasingly widespread. Such sensors allow implementing lightweight monitoring systems with low management costs, low power consumption and a small size. However, for the monitoring systems to provide trustworthy and meaningful data, the high accuracy and reliability of sensors are essential requirements. Consequently, a metrological approach to the calibration of multi-component accelerometer sensors, including appropriate uncertainty evaluations, are necessary to guarantee traceability and reliability in the frequency domain of data provided, which nowadays is not fully available. In addition, recently developed metrological characterizations at the microscale level allow to provide detailed and accurate quantification of the enhanced technical performance and the responsiveness of these sensors. In this paper, a dynamic calibration procedure is applied to provide the sensitivity parameters of a low-cost, multicomponent MEMS sensor accelerometer prototype (MDUT), designed, developed and realized at the University of Siena, conceived for rolling bearings vibration monitoring in a broad frequency domain (from 10 Hz up to 25 kHz). The calibration and the metrological characterization of the MDUT are carried out by comparison to a reference standard transducer, at the Primary Vibration Laboratory of the National Institute of Metrological Research (INRiM). Full article

Micro deep drawing (MDD) is a fundamental process in microforming which has wide applications in micro electromechanical system (MEMS) and biological engineering. Titanium possesses excellent mechanical properties and biocompatibility, which makes it a preferred material in micromanufacturing. In this study, eco-friendly and low-cost water-based TiO₂ nanolubricants were developed and applied in the MDD with 40 μm-thick pure titanium foils. The lubricants consisting of TiO₂ nanoparticles (NPs), 10 wt% glycerol, 0.1 wt% sodium dodecyl-benzene sulfonate (SDBS) and balanced water were synthesised in a facile process. The MDD with 40 μm-thick pure titanium was carried out using the lubricants with varying concentrations of 0.5, 1.0 and 2.0 wt%. The results show that the formability of micro cups could be significantly improved when the nanolubricants are applied. Especially, the use of 1.0 wt% TiO₂ nanolubricant demonstrates the best lubrication performance by significantly reducing the final drawing forces, and surface roughness, and the wrinkles by up to 24.2%, 12.55% and 4.82%, respectively. The lubrication mechanisms including the ball bearing and mending effects of NPs on open lubricant pockets (OLPs) and close lubricant pockets (CLPs) areas were then revealed through microstructure observation. Full article

The high demand for pressure devices with miniaturization and a wide bearing range has encouraged researchers to explore new high-performance sensors from different approaches. In this study, a sensitive element based on graphene in-plane compression properties for realizing pressure sensing is experimentally prepared using microelectromechanical systems (MEMS) fabrication technology; it consists of a 50 µm thick, 1400 µm wide square multilayer component membrane and a graphene monolayer with a meander pattern. The prepared sample is extensively characterized and analyzed by using various techniques, including atomic force microscopy, Raman spectroscopy, infrared spectroscopy, X-ray photoelectron spectroscopy, COMSOL finite element method, and density functional theory. The sensing performance of the new pressure sensor based on the sensitive element are obtained by theoretical analysis for electromechanical measurements of the sensitive element before and after low-temperature annealing in atmosphere. Results demonstrate that atmospheric annealing at 300 °C enhances the pressure sensing sensitivity by 4 times compared to pristine graphene without annealing, which benefits from the desorption of hydroxyl groups on the graphene surface during annealing. The sensitivity is comparable and even better than that of previous sensors based on graphene in-plane properties. Our results provide new insights into realizing high-performance MEMS devices based on 2D sensitive materials. Full article

Centrifugal pumps have a wide range of applications in industrial and municipal water affairs. During the use of centrifugal pumps, failures such as bearing wear, blade damage, impeller imbalance, shaft misalignment, cavitation, water hammer, etc., often occur. It is of great importance to use smart sensors and digital Internet of Things (IoT) systems to monitor the real-time operating status of pumps and predict potential failures for achieving predictive maintenance of pumps and improving the intelligence level of machine health management. Firstly, the common fault forms of centrifugal pumps and the characteristics of vibration signals when a fault occurs are introduced. Secondly, the centrifugal pump monitoring IoT system is designed. The system is mainly composed of wireless sensors, wired sensors, data collectors, and cloud servers. Then, the microelectromechanical system (MEMS) chip is used to design a wireless vibration temperature integrated sensor, a wired vibration temperature integrated sensor, and a data collector to monitor the running state of the pump. The designed wireless sensor communicates with the server through Narrow Band Internet of Things (NB-IoT). The output of the wired sensor is connected to the data collector, and the designed collector can communicate with the server through 4G communication. Through cloud-side collaboration, real-time monitoring of the running status of centrifugal pumps and intelligent diagnosis of centrifugal pump faults are realized. Finally, on-site testing and application verification of the system was conducted. The test results show that the designed sensors and sensor application system can make good use of the centrifugal pump failure mechanism to automatically diagnose equipment failures. Moreover, the diagnostic accuracy rate is above 85% by using the method of wired sensor and collector. As a low-cost and easy-to-implement solution, wireless sensors can also monitor gradual failures well. The research on the sensors and pump monitoring system provides feasible methods and an effective means for the application of centrifugal pump health management and predictive maintenance. Full article

In the recent past, polymer coatings have gained the attention of many researchers due to their low cost, their ability to be coated easily on different substrates, low friction and good anti-corrosion properties. Various polymers such as polytetrafluroethylene (PTFE), polyether ether ketone (PEEK), polymethylmethacrylate (PMMA), polyurethane (PU), polyamide (PA), epoxy and ultra-high molecular weight polytheylene (UHMWPE) have been used to develop these coatings to modify the surfaces of different components to protect them from wear and corrosion. However, among all these polymers, UHMWPE stands out as a tribologist’s polymer due to its low friction and high wear resistance. These coatings have found their way into applications ranging from microelectro mechanical systems (MEMS) to demanding tribological applications such as bearings and biomedical applications. Despite its excellent tribological properties, UHMWPE suffers from limitations such as low load bearing capacity and low thermal stability. To overcome these challenges researchers have developed various routes such as developing UHMWPE composite and hybrid composite coatings with several types of nano/micro fillers, developing composite films system and developing dual film systems. The present paper is an effort to summarize these various routes adopted by different researchers to improve the tribological performance of UHMWPE coatings. Full article

A robust micro-electro-mechanical systems (MEMS) infrared thin film transducer of an ultra-large-scale array was proposed and fabricated on a 4-inch silicon wafer. The silicon substrate and micro cavities were introduced. This novel transducer had excellent mechanical stability, time response, and state-of-the-art pixel scale. It could bear a load of 1700 g and its load pressure was improved by more than 5.24 times and time constant decreased by 50.7% compared to the traditional soft infrared thin film transducer. The array scale of its pixels exceeded 2k × 2k. The simulation and measured results of the transient temperature and radiation intensity were well consistent. Illuminated by a 532 nm laser with a frequency of 50 Hz and 50% duty cycle, the thermal decay time of the proposed transducer was 6.0 ms. A knife-edge image was utilized for spatial resolution test and the full width at half maximum (FWHM) of the proposed transducer was 24% smaller than the traditional soft one. High-resolution infrared images were generated using the proposed robust transducer. These results proved that the robust transducer was promising in infrared image generation. Full article

Machine-induced vibrations represent, for several reasons, a crucial design issue for industrial buildings. At the early design stage, special attention is thus required for the static and dynamic performance assessment of the load-bearing members, given that they should optimally withstand ordinary design loads but also potentially severe machinery operations. The knowledge and reliable description of the input vibration source is a key step, similarly to a reliable description of the structural system, to verify. However, such a kind of detailing is often unavailable and results in a series of simplified calculation assumptions. In this paper, a case-study eyewear factory built in 2019 is investigated. Its layout takes the form of a two-story, two-span (2 × 14.6 m) precast concrete frame (poor customer/designer communication on the final equipment resulted in various non-isolated computer numerical control (CNC) vertical machines mounted on the inter-story floor, that started to suffer from pronounced resonance issues. Following past experience, this paper investigates the validity of a coupled experimental–numerical method that could be used for efficient assessment predictive studies. Based on on-site experiments with Micro Electro-Mechanical Systems (MEMS) accelerometers mounted on the floor and on the machine (spindle included), the most unfavorable machine-induced vibration sources and operational conditions are first characterized. The experimental outcomes are thus used to derive a synthetized signal that is integrated in efficient one-bay finite element (FE) numerical model of the floor, in which the machine–structure interaction can be taken into account. The predictability of marked resonance issues is thus emphasized, with a focus on potential and possible limits of FE methods characterized by an increasing level of detailing and computational cost. Full article

Condition monitoring techniques have been successfully applied to detect damaged bearings. However, the signal acquisition and the subsequent processing are typically outsourced to expensive data acquisition boards and complex software, resulting in expensive solutions. As a side effect, the integration of condition monitoring systems in wireless sensor networks can be tough to achieve. Aiming to overcome such issues, a low-cost and small-size electronic module to be placed in the proximity of the bearing to be monitored was developed. The acoustic signal delivered by the bearing is acquired, and the corresponding frequency spectrum is evaluated on-board. Based on that, the developed module automatically detects the presence of defects and notifies the remote controller via a wireless connection only when a fault is detected, thus avoiding the use of data cables whilst minimizing the amount of transferred data. Experimental tests carried out on the proposed system assessed the accuracy of the evaluated frequency spectrum, resulting in an amplitude error within $\pm 0.6\%$, as well as the fault detection capability in the presence of environmental acoustic noise. Full article
