Search Results (434)

In recent years, the majority of countries have focused on the development of earth-penetrating weapons and the construction of deep underground fortifications. It is therefore necessary to assess the damage to underground structures under the attacks of earth-penetrating weapons. In this paper, fluid–solid coupling and restarting methods are used to simulate the damage processes of a granite chamber subjected to the combined action of penetration and explosion with the commercial software of LS-DYNA R11. The applicability of the penetration model and the blasting model is verified by the previous penetration and blasting tests. The verified models are used to simulate the complete process of the underground granite chamber attacked by the earth-penetrating weapons. Based on peak particle velocity (PPV) damage criteria, the numerical results show that the hypervelocity impact of the earth penetrating weapons only causes local damage to the granite rock mass, and more serious damage is caused by the subsequent explosion. During the subsequent explosion, part of the detonation products and energy can escape along the penetration trajectory with the blast loading, resulting in the attenuation of blast stress waves. Subsequently, the relationship between the overlay thickness and the vibration attenuation in granite is also studied, which provides a fast method to determine the threshold damage level for an underground chamber to collapse under the attacks of earth-penetrating weapons. Full article

The polytetrafluoroethylene/aluminum (PTFE/Al) granular composite, a common formulation in impact-initiated energetic materials, undergoes mechanochemical coupling reactions under sufficiently strong dynamic loading. This investigation discusses the dynamic properties and the constitutive relationship of the PTFE/Al granular composite to provide a preliminary guide for the research on mechanical properties of a series of composite materials based on PTFE/Al as the matrix. Firstly, the 26.5Al-73.5PTFE (wt.%) composite specimens are prepared by preprocessing, mixing, molding, high-temperature sintering, and cooling. Then, the quasi-static compression and Hopkinson bar tests are performed to explore the mechanical properties of the PTFE/Al composite. Influences of the strain rate of loading on the yield stress, the ultimate strength, and the limited strain are also analyzed. Lastly, based on the experimental results, the material parameters in the Johnson–Cook constitutive model are obtained by the method of piecewise fitting to describe the stress–strain relation of the PTFE/Al composite. Combining the experimental details and the obtained material parameters, the numerical simulation of the dynamic compression of the PTFE/Al composite specimen is carried out by using the ANSYS/LS-DYNA platform. The results show that the computed stress–strain curves present a reasonable agreement with the experimental data. It should be declared that this research does not involve the energy release behavior of the 26.5Al-73.5PTFE (wt.%) reactive material because the material is not initiated within the strain rate range of the dynamic test in this paper. Full article

With the development of underground space in urban areas, the demand for tunneling through existing railways is increasing. The adverse effects of cut-blasting during the construction of tunnels under crossing existing railways are investigated. Combined with the principle of blasting seismic wave superposition, LS-DYNA numerical simulation is used to analyze the seismic wave superposition law under different superposition methods. This study also investigates the vibration reduction effect of millisecond blasting for cut-blasting under the different classes of surrounding rocks. The results show that the vibration reduction forms of millisecond blasting can be divided into separation and interference of waveform. Based on the principle of superposition of blasting seismic waves, vibration reduction through wave interference is further divided. At the same time, a new vibration reduction mode is proposed. This vibration reduction mode can significantly improve construction efficiency while improving damping efficiency. The new vibration reduction mode can increase the vibration reduction to 80% while improving construction efficiency. Additionally, there is a significant difference in the damping effect of different classes of surrounding rock on the blasting seismic wave. Poor-quality surrounding rock enhances the attenuation of seismic wave velocity and peak stress in the surrounding rock. In the Zhongliangshan Tunnel, a tunnel cut-blasting construction at a depth of 42 m, the best vibration reduction plan of Class III is 3 ms millisecond blasting, in which the surface points achieve separation vibration reduction. The best vibration reduction plan of Class V is 1 ms millisecond blasting, in which the surface points achieve a new vibration reduction mode. During the tunnel blasting construction process, electronic detonators are used for millisecond blasting of the cut-blasting. This method can reduce the vibration effects generated by blasting. The stability of the existing railway is ultimately guaranteed. This can improve construction efficiency while ensuring construction safety. This study can provide significant guidance for the blasting construction of the tunnel through the railway. Full article

This paper presents an analysis of the ultimate strength of wooden joints of the structures of ancient wooden ships. The aim is to contribute to the discussion about how joining technology and types of joints contributed to the transition from ‘shell-first’ to ‘frame-first’ construction, of which the latter is still traditional Mediterranean wooden shipbuilding technology. Historically, ship construction has consisted of two main structural types of elements: planking and stiffening. Therefore, two characteristic carvel planking joints and two longitudinal keel joints were selected for analysis. For planking, the joint details of the ship Uluburun (14th c. BC) and the ship Kyrenia (4th c. BC) were chosen, while two different types of scarf joints belonging to the ship Jules-Verne 9 (6th c. BC) and the ship Toulon 2 (1st c. AD) were selected. The capacity, i.e., the ultimate strength of the joint, is compared to the strength of the structure as if there was no joint. The analysis simulates the independent joint loading of each of the six numerical models in bending, tension, and compression until collapse. The results are presented as load-end-shortening curves, and the calculation was performed as a nonlinear FE analysis on solid elements using the LSDYNA explicit solver. Since wood is an anisotropic material, a large number of parameters are needed to describe the wood’s behaviour as realistically as possible. To determine all the necessary mechanical properties of two types of wood structural material, pine and oak, a physical experiment was used where results were compared with numerical calculations. This way, the material models were calibrated and used on the presented joints’ ultimate strength analysis. Full article

Aero-engine casings with excellent impact resistance are a practical requirement for ensuring the safe operation of aero-engines. In this paper, we report on numerical simulations of broken rotating blades impacting aluminum honeycomb sandwich casings under different temperatures and optimization of structural parameters. Firstly, an impact test system with adjustable temperature was established. Restricted by the temperature range of the strain gauge, ballistic impact tests were carried out at 25 °C, 100 °C, and 200 °C. Secondly, a finite element (FE) model including a pointed bullet and an aluminum honeycomb sandwich plate was built using LS-DYNA. The corresponding simulations of the strain–time curve and damage conditions showed good agreement with the test results. Then, the containment capability of the aluminum honeycomb sandwich aero-engine casing at different temperatures was analyzed based on the kinetic energy loss of the blade, the internal energy increment of the casing, and the containment state of the blade. Finally, with the design objectives of minimizing the casing mass and maximizing the blade kinetic energy loss, the structural parameters of the casing were optimized using the multi-objective genetic algorithm (MOGA). Full article

During centralizer hydroforming, internal pressure and axial feed critically influence the forming outcome. Insufficient feed causes excessive thinning and cracking, while excessive feed causes thickening and wrinkling. Achieving uniform wall thickness necessitates careful design of the pressure and feed curves. Using max/min wall thickness as objectives and key control points on these curves as variables, the study integrated Non-dominated Sorting Genetic Algorithm (NSGA-II), Multi-Objective Particle Swarm Optimization (MOPSO), Neighborhood Cultivation Genetic Algorithm (NCGA), and Archive-based Micro Genetic Algorithm (AMGA) with LS-DYNA to automatically optimize loading paths. The results demonstrate the following: ① NSGA-II, NCGA, and AMGA successfully generated optimized paths; ② NSGA-II and AMGA produced larger sets of higher-quality Pareto solutions; ③ AMGA required more iterations for satisfactory Pareto sets; ④ MOPSO exhibited a tendency towards premature convergence, yielding inferior results; ⑤ Multi-objective optimization efficiently generated diverse Pareto solutions, expanding the design space for process design. Full article

Hydraulic support (Hs) is an important support equipment in coal mining. With the continuous increase in coal mining intensity, stricter technical specifications have been put forward for the effectiveness of Hs. Hs is always in a dynamic coupling state with the surrounding rock. Investigating its dynamic adaptation characteristics in relation to surrounding rock is of great significance for improving its performance. In this work, a numerical analysis model of the ‘support–surrounding rock’ coupling system was established by taking the Hs (type ZZ 17000/33/72D) in the Kouzidong coal mine as an example and using explicit dynamic analysis software Ls-dyna R12. The dynamic response and pressure distribution characteristics of the hydraulic ‘support–surrounding rock’ coupling system under different mining heights and load conditions were investigated. The key vulnerable connection components of the Hs and their critical connection unit instability conditions were identified. These findings provide a theoretical basis for the structural optimization of four-column Hs, which will be beneficial in promoting the improvement of its load-bearing stability. Full article

The aim of this paper is to identify the most suitable material model for the numerical simulation of the incremental forming of polymeric materials using the finite element method. The analysis program used was Ls-Dyna, and two material models, namely material 24 (Piecewise Linear Plasticity) and material 89 (Plasticity Polymer), were chosen for comparison from the library of the program. A comparison was made between two polymeric materials, polyamide PA 6.6 and polyethylene HDPE 1000, with the following dimensions of the forming tools: punch diameter, D_p = 6 mm; die length, L_d = 190 mm; die radius, R_d = 5 mm; die corner radius, R_corner = 10 mm; and blankholder length, L_bl = 190 mm. The simulation using the finite element method was performed with the Ls-Dyna software, and the experimental research was carried out using the Kuka KR210-2 robot. The strains were measured with the Aramis 2M optical system. Experimental investigations were carried out simultaneously, and the results obtained were compared in terms of main strains, thickness reduction, and forces on three directions. Close results were obtained between theoretical and experimental research for both material models. Full article

When deep-buried tunnels are excavated using the drill-and-blast method, the surrounding rock is subjected to combined cyclic blasting loads and excavation-induced stress unloading. Understanding the distribution characteristics of rock damage zones under these conditions is crucial for the design and safety of building-integrated underground structures. This study investigates the relationship between surrounding rock damage and in situ stress conditions through numerical simulation methods. A constitutive model suitable for simulating rock mass damage was developed and implemented in the LS-DYNA (version R12) code via a user-defined material model, with parameters determined using the Hoek–Brown failure criterion. A finite element model was established to analyze surrounding rock damage under cyclic blasting loads, and the model was validated using field data. Simulations were then carried out to explore the evolution of the damage zone under various stress conditions. The results show that with increasing hydrostatic pressure, the extent of the damage zone first decreases and then increases, with blasting-induced damage dominating under lower pressure and unloading-induced shear failure prevailing at higher pressure. When the hydrostatic pressure is less than 20 MPa, the surrounding rock stabilizes at a distance greater than 12.6 m from the tunnel face, whereas at hydrostatic pressures of 30 MPa and 40 MPa, this distance increases to 29.4 m. When the lateral pressure coefficient is low, tensile failure occurs mainly at the vault and floor, while shear failure dominates at the arch waist. As the lateral pressure coefficient increases, the failure mode at the vault shifts from tensile to shear. Additionally, when the horizontal stress perpendicular to the tunnel axis (σ_H) is less than the vertical stress (σ_v), variations in the axial horizontal stress (σ_h) have a significant effect on shear failure. Conversely, when σ_H exceeds σ_v, changes in σ_h have little impact on the extent of rock damage. Full article

This research explores how RC columns respond to blast-induced dynamic effects, with a novel focus on partially submerged scenarios, bridging a gap between air blast and underwater explosion (UNDEX) research. Using advanced finite element modeling in LS-DYNA, the study captures the unique behavior of RC columns under mixed-media conditions, where shockwaves propagate through water and air interfaces. Comprehensive parametric analyses explore the influence of charge size, blast stand-off, and depth of water, revealing distinct dampening mechanisms and structural responses. Key findings include a measurable reduction in peak displacement of partially submerged explosions compared to fully submerged explosions, attributed to the moderating effects of the water–air interface. A total of 60 simulation cases were conducted to systematically analyze partially submerged scenarios, providing robust insights into energy transmission and damage mechanisms. The numerical models, validated against published experimental data by others, demonstrate the accuracy of computational modeling in simulating damage profiles, displacement histories, and energy dissipation trends. This research offers practical implications for designing resilient RC structures in coastal and maritime environments. The results contribute significantly to the field of blast mechanics, advancing our understanding of mixed-media shockwave dynamics and their impact on critical infrastructure. Full article

To evaluate the performance of quasi-planetary cutting tools, three shrubs were selected and studied using a combination of numerical simulation and cutting test bench experiments. Based on the constitutive model of shrub material and LS-DYNA simulation, the effects of tool speed (n), feed speed (v), and shrub diameter (D_a) on peak cutting force (F_max) and peak cutting power (P_max) were analysed through a single-factor simulation test. Using the shrub-cutting test bench, an orthogonal test was designed with n, v, and moisture content (w) as factors and F_max and P_max as indicators. A regression model was established, and a single-factor comparison test for w was conducted. The results indicate that F_max decreases as n increases, while P_max initially decreases and then increases. Both F_max and P_max increase with rising v and D_a. As w increases, F_max and P_max first decrease and then increase. When n is 1813 r/min, v is 30 mm/s, and w is 10.9%, F_max and P_max reach their optimal values of 8.42 N and 282.99 W, respectively, with verification test errors of 2.68% and 1.56%. The findings provide methodological and data support for studying the cutting performance of new cutting tools. Full article

Traditional manufacturing processes yield plastic containers in large batches, even for minimal production runs, resulting in elevated production costs. Three-dimensional printing has emerged as a viable alternative for very low production volumes, offering properties comparable to traditional methods at significantly reduced costs. To assess the tensile strength, specimens printed with identical geometric parameters to the 3D-printed containers were tested according to ASTM D638 standards, enabling the determination of the stress–strain curve behavior. A compression test was conducted on containers obtained from both manufacturing processes to establish their respective resistance and deformation characteristics. The results revealed a 67% difference in resistance, indicating greater rigidity in the 3D-printed container, and a higher deformation in the blow-molded container, reaching up to 4 mm in height without fracture. Similarly, impact resistance was analyzed using finite element analysis with Ls-Dyna software, showing deformation differences of 0.91% and stress differences of 2.15%. Therefore, 3D printing presents itself as a compelling alternative for the fabrication of plastic containers in small production runs. Full article

Doors are considered vulnerable to failure in structures when subjected to extreme loads, such as blasts. Consequently, blast-resistant doors are designed to withstand blast pressure in important structures. This study developed a multi-layer Steel, Aluminum Foam, and Steel–Concrete–Steel composite door panel with Energy Absorption Connectors (SAFSCS-EACs) under near and far field blast loading using finite element analysis in LS-DYNA. Three dynamic response modes were observed based on the crushing strength of energy absorption connectors (EACs) for the SAFSCS-EAC composite door under both near and far field blasts. In addition, the membrane stretching phenomena was observed in the face steel plate. The AF shows a local densification in near field blasts and a global densification in far field blasts. For the SCS panel, a punching-like failure and a global flexural failure were observed in near and far field blasts, respectively. AF has a high energy absorption capacity as a first energy absorption layer, while the EAC also effectively dissipates blast energy through the rotation of the plastic hinges of curved steel plates, thereby reducing the damage to the SCS panel and increasing the door’s structural integrity. Moreover, to check the influence of the curved steel plate thickness of EACs and the core concrete thickness, a parametric study was carried out. The results showed that the blast resistance performance of the SAFSCS-EAC composite door could increase by appropriately designing the EAC curved steel plates’ thickness and ensuring that the compression displacement of the EAC under blast is close to its densification displacement. Additionally, increasing concrete thickness can reduce the degree of damage to the steel–concrete–steel composite panel during the blast, but it leads to a reduction in the energy dissipation of the EAC. Full article

The accurate modeling of dynamic soil–structure interaction processes under impact loading is critical for advancing the design of soil-embedded barrier systems. Full-scale crash testing remains the benchmark for evaluating barrier performance; however, such tests are costly, logistically demanding, and subject to variability that limits repeatability. Recent advancements in computational methods, particularly the development of large-deformation numerical schemes, such as the multi-material arbitrary Lagrangian–Eulerian (MM-ALE) and smoothed particle hydrodynamics (SPH) approaches, offer viable alternatives for simulating soil behavior under impact loading. These methods have enabled a more realistic representation of granular soil dynamics, particularly that of the Manual for Assessing Safety Hardware (MASH) strong soil, a well-graded gravelly soil commonly used in crash testing of soil-embedded barriers and safety features. This soil exhibits complex mechanical responses governed by inter-particle friction, dilatancy, confining pressure, and moisture content. Nonetheless, the predictive fidelity of these simulations is governed by the selection and implementation of soil constitutive models, which must capture the nonlinear, dilatant, and pressure-sensitive behavior of granular materials under high strain rate loading. This review critically examines the theoretical foundations and practical applications of a range of soil constitutive models embedded in the LS-DYNA hydrocode, including elastic, elastoplastic, elasto-viscoplastic, and multi-yield surface formulations. Emphasis is placed on the unique behaviors of MASH strong soil, such as confining-pressure dependence, limited elastic range, and strong dilatancy, which must be accurately represented to model the soil’s transition between solid-like and fluid-like states during impact loading. This paper addresses existing gaps in the literature by offering a structured basis for selecting and evaluating constitutive models in simulations of high-energy vehicular impact events involving soil–structure systems. This framework supports researchers working to improve the numerical analysis of impact-induced responses in soil-embedded structural systems. Full article

Recent catastrophic bridge fire incidents have highlighted the critical need for effective post-fire assessment of bridges, thereby challenging the dominant practice of complete replacement following these destructive events. This study investigates the post-fire performance of bare, isolated, and Carbon Fiber Reinforced Polymer (CFRP)-repaired Reinforced Concrete (RC) bridge columns under single-unit truck impact followed by air blast. This extreme loading scenario was deliberately selected given the increased vulnerability of bridge columns to this loading scenario in the recent few years. Three-dimensional Finite Element (FE) models of the structural system and surrounding environment were developed and validated in LS-DYNA. The effectiveness of two in-situ retrofitting schemes in mitigating damage and enhancing structural integrity of three column diameters under the selected multi-hazards was assessed. Results demonstrated that wrapping the bottom half of the column height prevents shear failure and significantly reduces the damage under the coupled impact and blast. In contrast, employing a combination of CFRP bars and externally bonded sheets showed limited enhancement on post-fire impact and blast performance. This study provides critical insights into the feasibility and efficacy of retrofitting bridge columns that have experienced fire, thus laying the groundwork for the reconsideration of current design and rehabilitation protocols. Full article
