This paper presents a real-time magnetic adhesion force estimation framework for wall-climbing robots equipped with Halbach permanent magnet arrays (PMAs) and air-gap–adjustable mechanisms. Accurately computing the magnetic adhesion force between a PMA and a large ferromagnetic surface is challenging due to the nonlinear magnetization behavior of soft magnetic materials and the strongly coupled, highly nonuniform magnetic fields generated by Halbach arrays. Conventional analytical models fail to capture these effects, while finite element methods (FEM) incur prohibitive computational cost for real-time applications. To address this, we propose an analytical magnetic-force estimation model based on the magnetostatic MoI (Method of Images), which replaces the unknown magnetization inside the steel plate with an equivalent image magnet distribution that satisfies boundary conditions at the air–steel interface. The method avoids solving complex magnetization in soft magnetic media and enables a unified force computation for arbitrarily oriented magnet elements. Additionally, complex Halbach PMA geometries are approximated through cuboid-element segmentation into cuboid magnet array, allowing efficient force evaluation. Comparative studies demonstrate that the proposed method achieves accuracy comparable to FEM while reducing computation time by several orders of magnitude. Experimental validation using a linear Halbach array and a large steel plate proved that the framework can reliably estimate magnetic adhesion force across varying air-gap distances, meeting the real-time requirements of air-gap–adjustable wall-climbing robots. Full article

The increasing demand for electric power in hybrid electric aircraft platforms prompts the development of multi-megawatt generators featuring high specific power, compactness and intrinsic fault tolerance. Air-core machines constitute a promising solution to overcome the magnetic saturation and mass limitations of conventional iron-core designs. This paper presents a comparative electromagnetic design study of two air-core synchronous generator topologies for aircraft applications, namely a permanent magnet machine with a Halbach array rotor and an electrically excited synchronous machine featuring a high-temperature superconducting field winding. Both the generators are designed for identical output and adopt a double three-phase stator winding to enhance safety and redundancy. The Halbach array machine is used as the reference configuration representative of a technologically mature solution, whereas the superconducting generator targets high magnetic loadings by means of the superconducting excitation, to minimize the active volume. The solutions proposed in this paper are developed in the frame of a national (Italian) research project dedicated to the study of stages of multi-megawatt fault-tolerant aircraft generators. Full article

This paper investigates the feasibility of an interior permanent magnet (IPM) rotor for 1 MW-class high-speed permanent magnet synchronous machines (PMSMs) in a hybrid propulsion system of electrified aviation. A double-layer IPM machine and a surface-mounted PM (SPM) benchmark machine with Halbach-array PMs, which are typically employed in aviation applications; are designed using the same design specifications, the same stator, double-three-phase winding layout, physical air-gap length, outer and inner diameters of rotor; and the same materials. The rotor robustness of the IPM machine using high-strength iron material has been verified through mechanical strength analysis with an outstanding safety factor margin. The electromagnetic performances of IPM and SPM benchmark machines are compared. It is found that the IPM design can achieve similar high torque/power density and high efficiency to the SPM benchmark machine, using 48% less rare-earth PM materials and a simpler rotor structure without a carbon fiber sleeve for easy manufacturing. The investigation confirms the feasibility of IPM topology for MW-class high-speed aviation propulsion machines for lower cost and more sustainable purposes. Full article

To achieve global carbon-neutrality goals, magnetic levitation (maglev) technologies offer a promising pathway toward sustainable, energy-efficient transportation systems. In this study, a comprehensive methodology was developed to analyse and optimise the levitation performance of high-temperature superconducting (HTS) maglev systems. Several permanent magnet guideway (PMG) configurations were compared, and an optimised PMG Halbach array design was identified that enhances flux concentration and significantly improves levitation performance. To accurately model the electromagnetic interaction between the HTS bulk and the external magnetic field, finite element models based on the H-formulation were established in both two dimensions (2D) and three dimensions (3D). An HTS maglev demonstrator was built using YBCO bulks, and an experimental platform was constructed to measure levitation force. While the 2D model offers fast computation, it shows deviations from the measurements due to geometric simplifications, whereas the 3D model predicts levitation forces for the cylindrical bulk with much higher accuracy, with errors remaining below 10%. The strong agreement between experimental measurements and the 3D simulation across the entire force–height cycle confirms that the proposed model reliably reproduces the electromagnetic coupling and resulting levitation forces in HTS maglev systems. The paper provides a practical and systematic reference for the optimal design and experimental validation of HTS bulk-based maglev systems. Full article

This study addresses the issues with traditional rolling protection bearings in vertical magnetic levitation flywheel energy storage systems (FESSs), which are prone to impact, wear, and temperature rise under abnormal conditions, such as drops. It designed a permanent magnet axial protection bearing based on a Halbach array, utilizing N42SH permanent magnet material. The five-layer Halbach array achieved a maximum axial magnetic force of 86 KN and a maximum air gap magnetic flux density of 2.2 T, meeting the application requirements. Simulation results, combined with rotor drop dynamics and thermal analysis, show that under an 8000 rpm drop condition, the permanent magnet bearing reduces radial and axial contact forces by approximately 60% and 54%, respectively, and wear by around 70%. Additionally, the maximum system temperature decreases from 109 °C to 74 °C, with a 32% reduction in temperature rise. Friction experimental analysis indicates that low frequency, low load, and moderate temperatures improve friction stability and reduce wear. Overall, the permanent magnet axial protective bearing effectively mitigates drop impact, reduces friction heat and wear, and enhances the safety and reliability of the flywheel energy storage system under abnormal working conditions, providing valuable theoretical support and a design reference for engineering applications. Full article

The permanent magnet levitation (PML) transportation system utilizes Halbach arrays to achieve zero-power levitation. However, the system’s lateral negative stiffness characteristic leads to a significant increase in lateral force during operation, exacerbating lateral vibration and compromising system stability. Taking the Xingguo Line PML system as the research object, this study systematically analyzes the nonlinear characteristics of the levitation force and lateral force in a single-point levitation system through theoretical modeling, finite element simulation, and experimental validation. The concept of a ‘Magnetic Wheelset’ coupling the left and right levitation points of the bogie is proposed. The influence of five mounting forms—Aligned, X-type, Different center distance, Double V-type, and Single V-type—on the levitation performance of the Magnetic Wheelset is investigated. The coefficient of variation (CV) method is employed to evaluate force stability, and an optimal case is subsequently screened out using a dual-objective constraint approach that incorporates mean levitation force and lateral force thresholds. Results indicate that the X-type mounting at 25° is the optimal case. At 40 km/h, compared to the baseline Aligned configuration, the root mean square (RMS) values of the bogie’s vertical and lateral vibration accelerations are reduced by 14.7% and 23.8%, respectively. The vehicle’s vertical and lateral ride comfort indices decrease by 0.33 and 0.27, respectively, and the track beam’s vertical and lateral vibration accelerations are reduced by 19.4% and 13.3%. The methodology presented in this study provides a valuable reference for vibration suppression in PML systems. Full article

The rim-driven device (RDD) integrates the motor and the impeller, which can achieve shaftless, modular, and integrated operation of the turbomachinery system and has broad application prospects. To reduce the axial length and radial thickness of the RDD, a motor with a thin-yoke wide-tooth fractional slot concentrated winding stator and a coreless Halbach permanent magnet array rotor is designed. Theoretical and finite element simulation analyses of its air gap magnetic field characteristics were carried out. The results show that, for the thin-yoke wide-tooth fractional slot concentrated winding permanent magnet motor, the harmonic magnetic field generated by the magnetic poles should mainly consider the magnetic field components produced by the interaction between the harmonic magnetomotive force of the magnetic poles and the constant air gap specific magnetic permeability, as well as the magnetic field components generated by the interaction between the fundamental magnetomotive force of the magnetic poles and the fundamental and second-order harmonic air gap specific magnetic permeability. The harmonic magnetic field generated by the current should mainly consider the magnetic field components produced by the interaction between the harmonic magnetomotive force with a small number of pole pairs (NOPP) and large amplitude generated by the current and the constant air gap specific magnetic permeability. Compared with radial magnetic flux density, tangential magnetic flux density has the same NOPP and frequency components, with a phase difference of 90°. The fundamental amplitude difference between them is larger, while the harmonic amplitude difference between them is smaller. Full article

The Halbach array permanent magnet can improve the power density of motors. This paper uses analytical modeling to analyze and optimize the Halbach array permanent magnet synchronous motor (PMSM). Firstly, a general motor model is established to obtain the air gap flux density. Secondly, the flux linkage and back electromotive force (EMF) were calculated. The analytical results are consistent with the finite element model (FEM) results. Thirdly, the effects of slot opening, magnetization angle, and main magnetic pole width on air gap flux density and back-EMF were studied. Finally, based on the optimization results, a prototype was manufactured, and performance testing was conducted successfully. Verification of the back-EMF of the prototype shows that the relative errors between FEM and the measured values are 1.1%, and the relative errors between the analytical values and measured values are 1.6%, which verifies the accuracy of the proposed analytical modeling. The proposed analytical model is universal and can be used to quickly adjust the magnetization form, magnetization angle, and pole width without remodeling in the finite element software, which is convenient for optimizing parameters in the early stage of motor design. Full article

Surface-mounted permanent magnet synchronous generators (SPMSGs) are well suited for wind power applications mainly because of their high power density, low cogging torque, and effective thermal management. This study proposes an eccentric Halbach PM array pole shape to enhance the power generation capability of SPMSGs specifically designed for low-speed wind power generation. The topology of the proposed eccentric Halbach PM arrangement is optimized using a genetic algorithm. Two-dimensional finite element simulations indicate that the eccentric Halbach configuration significantly improves flux focusing and magnetic field distribution. Compared to the conventional design, the proposed structure exhibits a substantial increase in electromotive force with reduced total harmonic distortion. Cogging torque is reduced by 48.6%, supporting improved starting and low-speed operation. Under on-load, the proposed design delivers higher average torque with reduced ripple, contributing to smoother operation. At a rated speed, the output power increases by 25%, with consistently higher power generation capability across a wide range of load conditions. Additionally, the proposed generator achieves higher efficiency across all operating speeds. These findings confirm the effectiveness of the eccentric Halbach array configuration in improving the power generation capability of SPMSG, thereby reinforcing its applicability to low-speed wind energy systems aligned with long-term sustainability objectives. Full article

Tidal energy, as a stable and predictable renewable energy source, is garnering increasing attention. However, tidal energy generation faces challenges such as low energy conversion efficiency and high mechanical losses in low-velocity environments. To address these issues, this paper proposes a novel design for a tidal energy generator based on an axial field coreless structure. This design significantly reduces mechanical losses and enhances energy conversion efficiency by employing a direct-drive structure and a coreless stator. Additionally, the introduction of a Halbach array permanent magnet and soft magnetic composite further optimizes the generator’s electromagnetic performance, thereby increasing power output. Simulation results demonstrate that the designed generator can achieve a power output of 300 W at a tidal velocity of 1.8 m/s, with an average generation efficiency of 90.6%. This design exhibits excellent performance in low-velocity tidal environments and provides valuable technical support for the design of tidal energy generators. Full article

The ultra-high-speed rocket sled plays an important role in the ground test by simulating altitude flight. Rocket sleds can only be lifted for a short time with thermally uninsulated superconductors moving among an eddy-current-induced copper array. For the purpose of durable lifting, an electrodynamic suspension (EDS) with a permanent magnet (PM) Halbach array moving over a conductor plate can be adopted to upgrade the rocket sled. The earlier study built a two-dimensional (2D) model for the PM EDS system. Yet, 2D modelling in our earlier research ignored the magnetic field variation along both widths of the Halbach array and conductor plate. This resulted in a more than 50% error between the analytical electromagnetic forces with both the three-dimensional (3D) simulated and experimental results. To reduce the error, this paper puts forward more accurate analytical electromagnetic force formulas by a 3D modelling method encompassing both widths of the Halbach array and conductor plate. The 3D model was built by periodically extending the PM EDS system along both directions of the width and length. Then, by double Fourier series expansion and omitting high-order components, the electromagnetic forces can be approximated by brief formulas. Moreover, lift-to-weight and lift-to-drag optimization are discussed. Finally, the correctness of the 3D electromagnetic force formulas was verified by both the numerical simulation and experiment. Full article

This paper proposes a two-dimensional (2D) generalized equivalent magnetic network (GEMN) model suitable for surface-mounted permanent magnet electric machines (SPEMs). The model divides the SPEM into eight types of regions: stator yoke, stator tooth body, stator tooth tips, stator slot body, stator slot openings, air gap, rotor permanent magnets, and rotor yoke. Each region is subdivided radially and tangentially into multiple 2D magnetic network units containing radial and tangential magnetic circuit parameters, forming a regular magnetic network covering all regions of the SPEM. The topology of this magnetic network remains unchanged during rotor rotation and can accommodate various surface-mounted permanent magnet structures including Halbach arrays, which enhances the generality of the model significantly. The proposed model can be used to calculate the 2D magnetic flux density distribution, winding electromotive force, electromagnetic torque, stator iron loss, and permanent magnet demagnetization in the influence of magnetic saturation, stator slotting, and current harmonic. Comparative analysis with the accurate subdomain method (ASDM) and finite element method (FEM) demonstrates that the GEMN model achieves a good balance between computational speed and accuracy, making it particularly suitable for efficient electromagnetic performance evaluation of SPEMs. Full article

High-temperature pipelines, as core facilities in the fields of petrochemical and power, are constantly exposed to extreme working conditions ranging from 450 to 600 °C, facing risks of stress corrosion, creep damage, and other defects. Traditional shutdown inspections are time-consuming and costly. Meanwhile, existing electromagnetic acoustic transducers (EMATs) are restricted by their high-temperature tolerance (≤500 °C) and short-term stability (effective working duration < 5 min). This paper proposes a high-frequency circumferential guided wave (CLamb wave) EMAT based on a Halbach permanent magnet array. Through magnetic circuit optimization (Halbach array) and multi-layer insulation design, it enables continuous and stable detection on the surface of 600 °C pipelines for 10 min. The simulations revealed that the Halbach array increased the magnetic flux density by 1.4 times and the total displacement amplitude by 2 times at a magnet’s large lift-off (9 mm). The experimental results show that the internal temperature of the sensor remained stable below 167 °C at 600 °C. It was capable of detecting the smallest defect of a φ3 mm half-hole (depth half of the wall thickness), with a signal attenuation rate of only 0.32%/min. The signal amplitude of Q235 pipelines under high-temperature short-term detection (<5 min) was 1.5 times higher than that at room temperature. However, material degradation under high temperature led to insufficient long-term stability. This study breaks through the bottleneck of long-term detection of high-temperature EMATs, providing a new scheme for efficient online detection of high-temperature pipelines. Full article

A magnetic lead screw (MLS) uses the magnetic field of permanent magnets to convert between linear and rotational motions while achieving a gearing action. This mechanism converts low-speed, high-force linear motion to high-speed, low-torque rotational motion. The MLS is ideal for wave energy applications, where the low-speed oscillatory motion of waves can be converted into usable electrical energy. It harnesses the high-force, low-speed linear motion of waves and converts it into rotational motion for generators, all while maintaining contact-free power transfer, reducing maintenance and machine size compared to linear machines. In this study, two controllers are proposed for an ideal Halbach magnetic lead screw: a proportional-resonant (PR) controller and an observer-based state feedback controller (O-SFC). The proportional-integral (PI) controller is also presented as a benchmark. These controllers are developed based on the linearized model of the ideal Halbach MLS and validated through simulation studies of its non-linear model. Results show that both the PR and O-SFC controllers significantly improve system performance compared to the PI controller, with the O-SFC providing superior performance over both the PR and PI controllers. Full article

This paper investigates an improved permanent magnet synchronous planar motor (PMSPM) featuring a moving magnet configuration to enhance thrust density and positioning accuracy. A novel split Halbach permanent magnet (PM) array is introduced, and the optimization begins with adjusting the pole size ratio α, analyzing the flux density distribution, and calculating thrust using an electromagnetic force model. Results demonstrate that the optimized Halbach array reduces thrust fluctuations and improves the uniformity of the air gap magnetic field. Multi-objective optimization using the non-dominated sorting genetic algorithm-II (NSGA-II) fine-tunes auxiliary magnet width and magnetization angles, resulting in a segmented auxiliary permanent magnet structure that achieves a 9.1% improvement in thrust density over conventional designs. Additionally, the optimized Halbach array effectively reduces thrust fluctuations and improves the uniformity of the air gap magnetic field, addressing key challenges in planar motor design. Extensive simulations and experimental validation demonstrate the superior performance of the proposed structure in terms of thrust density and positioning precision. These enhancements make the PMSPM suitable for high-precision, high-dynamic industrial applications. A detailed comparison of motor parameters and thrust performance validates the effectiveness of the proposed structure. Full article
