Search Results (35)

Foamed asphalt cold recycled mixtures can provide an effective approach for the reutilization of reclaimed asphalt pavement (RAP), but conventional asphalt foaming technology primarily exploits matrix asphalt as the raw material. To address this issue, this study explores rubberized asphalt with cold recycling technology to develop a foamed rubber asphalt cold recycled mixture (FRCM). The semi-circular bending (SCB) test was employed to investigate its cracking resistance. Load–crack mouth opening displacement (CMOD)–time curves under various temperatures were analyzed, and digital image technique was resorted to monitor crack propagation and growth rates. Fracture toughness, fracture energy, and flexibility index were compared with those of traditional foamed matrix asphalt cold recycled mixture (FMCM). The results show that, under the same test temperature, the FRCM exhibits slower crack propagation; larger peak load; and higher fracture toughness, fracture energy, and flexibility index in comparison with the FMCM. These improvements are more pronounced at low temperatures. For both mixtures, fracture toughness and fracture energy are decreased with increasing the temperature, while the flexibility index shows the opposite trend. The rigid zone accounts for a larger portion of fracture energy at low temperatures. The findings provide technical references for improving the cracking resistance of cold recycled asphalt layers using rubberized asphalt. Full article

This paper presents the results of experimental and numerical analysis of fracture mechanics testing of ductile metallic materials using a non-standard procedure with PRNT (pipe ring notched tensile) ring-shaped specimens, introduced in previous publications through analysis of 3D-printed polymer rings. The main focus of this research is the determination of the values of the plastic geometry factor η_pl since the specimen is not a standard one. Toward this aim, the finite element software package Simulia Abaqus was applied to evaluate the J-integral (by using the domain integral method) and the F-CMOD curve so that the plastic geometry factor η_pl can be evaluated for different values of the ratio of crack length to specimen width (a₀/W = 0.45 ÷ 0.55). In this way, a procedure and the possibility of practical implementation on the thin-walled pipelines are established. Full article

The objective of this study is to assess the influence of test configuration on the pullout response of hooked-end steel fibers embedded in a cementitious matrix and to analyze how variations in quantity, inclination, and spacing affect discrete–explicit numerical simulations. The experimental campaign was conducted using dog-bone-shaped specimens with variables of number of fibers (one, two, and four), fiber inclination (0°, 15°, and 30°), and spacing (7 mm and 14 mm), with 133 specimens tested (19 per configuration). The results obtained showed that fiber inclination significantly influences pullout behavior, with higher inclinations (up to 30°) increasing pullout loads (PL1 and PL2 being the maximum pullout and the intermediate pullout load values, respectively) but also leading to fiber rupture in approximately 21% of cases. Closely spaced fibers (7 mm) demonstrated enhanced load transfer compared to wider spacing (14 mm), particularly in setups with multiple fibers. Increasing the number of fibers reduced variability in pullout results, providing more consistent data. Numerical simulations effectively capture fiber–matrix interactions, with load–CMOD curves generally aligning with experimental data. However, discrepancies in the fR1 parameter highlighted the need for further calibration to improve accuracy in modeling early cracking stages. These findings underscore the importance of fiber configuration in optimizing pullout performance and the potential for refining numerical models to better predict post-cracking behavior in steel fiber-reinforced concrete. Full article

The dynamic fracture behavior of mass concrete is crucial to the dynamic analysis and safety evaluation of concrete dams subjected to strong earthquake shocks in the framework of fracture mechanics. In the presented research, cylindrical specimens with a ring of preset cracks were cast by three-graded mass concrete, and direct tension tests were performed with two loading rates considered, i.e., 10⁻⁶/s for quasi-static loading and 10⁻³/s for dynamic loading. The load–crack mouth opening displacement (P-CMOD) curves were obtained, from which the fracture toughness, fracture energy, and characteristic length of the mass concrete were obtained. In this process, the influence of the eccentricity in the tests was compensated by the numerical modeling of the tests. Next, the crack propagation process of the mass concrete was modeled using the extended finite element method. From the test results, it is found that, under quasi-static loading, the crack generally propagates along the interface between the aggregates and the matrix, while, under dynamic loading, more aggregates are fractured. As compared to the case of quasi-static loading, the energy absorption capacity, fracture energy, and fracture toughness increase for dynamic loading, while the characteristic length decreases. Moreover, the numerically predicted P-CMOD curves agree reasonably well with the experimental measurements. Full article

This study investigates the influence of fiber dimensions on the bridging performance of polyvinyl alcohol fiber-reinforced cementitious composite (PVA-FRCC) through an experimental and analytical program. Bending tests, bridging law calculations, and section analysis are conducted. Bending tests of notched specimens of PVA-FRCC with six different PVA fiber dimensions are performed to determine the load–deflection (LPD) and bending moment–crack mouth opening displacement (CMOD) relationships. The fiber volume fraction for all PVA-FRCCs is set to 2%. It is found that the load capacity of PVA-FRCC with a 27 μm diameter fiber is much higher than that of the other fibers, and the load capacity decreases as the fiber diameter increases. The study proposes parameters for the characteristic points of the tri-linear model for the single-fiber pullout model as functions of diameter, bond fracture energy, elastic modulus, cross-sectional area, and perimeter of the fiber. These findings provide valuable insights into the behavior of PVA-FRCC under different fiber dimensions. Bridging law calculations are conducted to obtain tensile stress–crack width relationships using the developed single-fiber pullout models. The Popovics model for the complete tensile stress–crack width relationship is adopted to obtain a better fit with the bridging law calculation, and then section analysis is conducted. The bridging law calculation results show that the maximum tensile stress decreases as the fiber diameter increases. It is also determined that most of the smaller-diameter fibers ruptured, whereas the larger fiber diameters pulled out from the matrix. The section analysis results show good agreement with the maximum bending moments obtained from the bending test. Full article

The fracture mechanism and macro-properties of SVSAC were studied using a novel test system combined with numerical simulations, which included three-point bending beam tests, the digital image correlation (DIC) technique, scanning electron microscopy (SEM), and ABAQUS analyses. In total, 9 groups and 36 specimens were fabricated by considering two critical parameters: initial notch-to-depth ratios (a₀/h) and concrete mix components (seawater and volcanic scoria coarse aggregate (VSCA)). Changes in fracture parameters, such as the load-crack mouth opening displacement curve (P-CMOD), load-crack tip opening displacement curve (P-CTOD), and fracture energy (G_f), were obtained. The typical double-K fracture parameters (i.e., initial fracture toughness ($K_{\mathrm{IC}}^{\mathrm{ini}}$) and unstable fracture toughness ($K_{\mathrm{IC}}^{\mathrm{un}}$)) and tension-softening (σ-CTOD) curve were analyzed. The test results showed that the initial cracking load (P_ini), G_f, and characteristic length (L_ch) of the SVSAC increased with decreasing a₀/h. Compared with the ordinary concrete (OC) specimen, the P-CMOD and P-CTOD curves of the specimen changed after using seawater and VSCA. The evolution of the crack propagation length was obtained through the DIC technique, indicating cracks appeared earlier and the fracture properties of specimen decreased after using VSCA. Generally, the $K_{\mathrm{IC}}^{\mathrm{un}}$ and $K_{\mathrm{IC}}^{\mathrm{ini}}$ of SVSAC were 36.17% and 8.55% lower than those of the OC specimen, respectively, whereas the effects of a₀/h were negligible. The reductions in P_ini, G_f, and L_ch of the specimen using VSCA were 10.94%, 32.66%, and 60.39%, respectively; however, seawater efficiently decreased the negative effect of VSCA on the fracture before the cracking width approached 0.1 mm. Furthermore, the effects of specimen characteristics on the fracture mechanism were also studied through numerical simulations, indicating the size of the beam changed the fracture toughness. Finally, theoretical models of the double-K fracture toughness and the σ-CTOD relations were proposed, which could prompt their application in marine structures. Full article

Phosphogypsum-based materials have gained much attention in the field of road infrastructure from the economic and sustainable perspectives. The Three-point bending test, the Four-point bending test and the Semi-circular bending test are three typical test methods applied for fracture energy measurement. However, the optimal test method for fracture energy evaluation has not been determined for phosphogypsum-based materials. To contribute to the gap, this study aims to analyze and compare the three test methods for fracture energy evaluation of phosphogypsum materials based on the peridynamic theory. For this purpose, the load–displacement, vertical displacement–Crack Mouth Opening Displacement (CMOD) and fracture energy of the phosphogypsum-based materials were measured and calculated from the three test methods. The simulated load–displacement and vertical displacement–CMOD by PD numerical models, with different fracture energy as inputs, were compared to the corresponding tested values according to simulation error results. The results showed that the Four-point bending test led to minimized errors lower than 0.189 and indicators lower than 0.124, demonstrating the most optimal test method for the fracture energy measurement of phosphogypsum-based material. The results of this study can provide new methodological references for the selection of material fracture energy measurement tests. Full article

(1) Modeling and characterization of ductile fracture in metals is still a challenging task in the field of computational mechanics. Experimental testing offers specific responses in the form of crack-mouth (CMOD) and crack-tip (CTOD) opening displacement related to applied force or crack growth. The main aim of this paper is to develop a phase-field-based Finite Element Method (FEM) implementation for modeling of ductile fracture in stainless steel. (2) A Phase-Field Damage Model (PFDM) was coupled with von Mises plasticity and a work-densities-based criterion was employed, with a threshold to propose a new relationship between critical fracture energy and critical total strain value. In addition, the threshold value of potential internal energy—which controls damage evolution—is defined from the critical fracture energy. (3) The material properties of AISI 316L steel are determined by a uniaxial tensile test and the Compact Tension (CT) specimen crack growth test. The PFDM model is validated against the experimental results obtained in the fracture toughness characterization test, with the simulation results being within 8% of the experimental measurements. (4) The novel implementation offers the possibility for better control of the ductile behavior of metallic materials and damage initiation, evolution, and propagation. Full article

The K_R resistance curve for hydraulic crack propagation in a concrete beam was determined and discussed. A semi-analytical method was introduced to calculate the hydraulic crack propagation in concrete. A series of concrete beams with various hydraulic pressures and initial crack depths were tested, and the hydraulic crack propagation in these beams was calculated. The calculated P-CMOD curves were first verified, and then the calculated K_R resistance curve for hydraulic crack propagation was determined. Based on the test results and calculation results, the following conclusions can be drawn: The proposed analysis method can accurately predict the hydraulic crack propagation process in concrete. The K_R resistance to hydraulic crack propagation in concrete decreases with the increase in hydraulic pressure but is less influenced by the initial crack depth of the test beams. In addition, the concrete beams collapse immediately under hydraulic fracturing once the K_Iw curve reaches the K_R resistance curve. This indicates that the failure of concrete structures under hydraulic fracturing occurs immediately once the driving force of crack propagation, dominated by the hydraulic pressure in the crack, becomes significant. Full article

Modern concrete mix design is a complex process involving superplasticisers, fine powders, and fibres, requiring time and energy due to the high number of trial tests needed to achieve rheological properties in the fresh state. Concrete batching involves the extensive use of materials, time, and the testing of chemical admixtures, with various methodologies proposed. Therefore, in some instances, the required design properties (physical and mechanical) are not achieved, leading to the loss of resources. The concrete equivalent mortar (CEM) method was introduced to anticipate concrete behaviour at fresh and hardened states. Moreover, the CEM method saves time and costs by replacing coarse aggregates with an equivalent sand mass, resulting in an equivalent specific surface area at the mortar scale. This study aims to evaluate the performance of fibre in CEM and concrete and determine the relationships between the CEM and the concrete in fresh and hardened states. Steel and polypropylene fibres were used to design three series of mixtures (CEM and concrete): normal-strength concrete (NSC), high-strength concrete (HSC), high-strength concrete with fly ash (HSCFA), and equivalent normal-strength mortar (NSM), high-strength mortar (HSM), and high-strength mortar with fly ash (HSMFA). This study used three-point bending tests and digital image correlation to evaluate load and crack mouth opening displacement (CMOD) curves. An analytical mode I crack propagation model was developed using a tri-linear stress–crack opening relationship. Post-cracking parameters were optimised using inverse analysis and compared to actual MC2010 characteristic values. The concrete slump is approximately half of the CEM flow; its compressive strength ranges between 78% and 82% of CEM strength, while its flexural strength is 60% of CEM strength. The post-cracking behaviour showed a significant difference attributed to the presence of aggregates in concrete. The fracture energy of concrete is 28.6% of the CEM fracture energy, while the critical crack opening of the concrete is 60% of that of the CEM. Full article

Background: Multiple organ dysfunction syndrome (MODS) is common in intensive care units (ICUs) and is associated with high mortality. Although there have been multiple investigations into a multitude of organ dysfunctions, little is known about the role of liver dysfunction. In addition, clinical and laboratory findings of liver dysfunction may occur with a significant delay. Therefore, the aim of this study was to investigate whether a liver function test, based on indocyanine green (ICG)-clearance, contains prognostic information for patients in the early phase of MODS. Methods: The data of this analysis were based on the MODIFY study, which included 70 critically ill patients of a tertiary medical ICU in the early phase of MODS (≤24 h after diagnosis by an APACHE II score ≥ 20 and a sinus rhythm ≥ 90 beats per minute, with the following subgroups: cardiogenic (cMODS) and septic MODS (sMODS)) over a period of 18 months. ICG clearance was characterized by plasma disappearance rate = PDR (%/min); it was measured non-invasively by using the LiMON system (PULSION Medical Systems, Feldkirchen, Germany). The PDR was determined on the day of study inclusion (baseline) and after 96 h. The primary endpoint of this analysis was 28-day mortality. Results: ICG clearance was measured in 44 patients of the MODIFY trial cohort, of which 9 patients had cMODS (20%) and 35 patients had sMODS (80%). Mean age: 59.7 ± 16.5 years; 31 patients were men; mean APACHE II score: 33.6 ± 6.3; 28-day mortality was 47.7%. Liver function was reduced in the total cohort as measured by a PDR of 13.4 ± 6.3%/min At baseline, there were no relevant differences between survivors and non-survivors regarding ICG clearance (PDR: 14.6 ± 6.1%/min vs. 12.1 ± 6.5%/min; p = 0.21). However, survivors showed better liver function than non-survivors after 96 h (PDR: 21.9 ± 6.3%/min vs. 9.2 ± 6.3%/min, p < 0.05). Consistent with these findings, survivors but not non-survivors show a significant improvement in the PDR (7.3 ± 6.3%/min vs. −2.9 ± 2.6%/min; p < 0.01) within 96 h. In accordance, receiver-operating characteristic curves (ROCs) at 96 h but not at baseline show a link between the PDR and 28-day mortality (PDR at 96 h: AUC: 0.87, 95% CI: 0.76–0.98; p < 0.01. Conclusions: In our study, we found that ICG clearance at baseline did not provide prognostic information in patients in the early stages of MODS despite being reduced in the total cohort. However, improvement of ICG clearance 96 h after ICU admission is associated with reduced 28-day mortality. Full article

Most semi-circular bend (SCB) tests on concrete have been conducted with a pre-crack with a straight-through tip, thereby undermining the determination of the tensile fracture toughness (K_Ic). Therefore, the present study involved mixed-mode (tensile–shearing) fracture propagation in concrete semi-circular chevron-notched disks (i.e., with a sharp notch tip) using SCB tests and the FRANC2D numerical simulation software. The inclined notch angle (β) was varied from 0° to 70° while the other settings remained fixed, and the crack mouth opening displacement (CMOD) of the notch was measured constantly. The stress distribution was analyzed using finite-element simulations, and the experimental results showed that this testing method was robust. The maximum failure load and the fracture propagation angle increased with β, and wing fracture was observed. With FRANC2D simulating these SCB tests successfully, it was found that the tensile stress concentration around the notch tip moved toward the upper face of the notch, and the compressive stress concentration formed on the notch tip. The tensile mode was generated as the CMOD kept increasing for β = 0–30°, whereas the mixed mode became more evident as the CMOD kept decreasing for β = 45–70°. The fracture process zone was found for β = 0–30° but not for β = 45–70°. This mixed-mode fracture is predicted better by the criterion of extended maximum tangential strain than by other criteria, and there is a linear relationship between CMOD and K_Ic, as examined previously for pavement and concrete materials. Full article

The process of concrete cracking is a common problem because the first micro-cracks due to the loss of moisture may appear even before the concrete is loaded. The application of fracture mechanics allows for a better understanding of this problem. Steel-fiber-reinforced concrete (SFRC) samples with a notch were subjected to a three-point bending test, and the results for crack energy were used to analyze the concrete’s material properties. In this paper, an experimental and numerical analysis of SFRC with rapid changes in the force (F) crack mouth opening displacement (CMOD) curve (F-CMOD) is presented. In order to obtain the relevant F-CMOD diagrams, three-point bending tests were carried out with non-standard samples with a thickness equal to one-third of the width of standard samples. For analysis purposes, crimped steel fibers were adopted. A probabilistic analysis of the most important parameters describing the material in question, such as peak strength, post-cracking strength, crack mouth opening displacement (CMOD), fracture energy, and the post-cracking deformation modulus, was conducted. The tests and the analysis of their results show that the quasi-static numerical method can be applied to obtain suitable results. However, significant dynamic effects during experiments that influence the F-CMOD curves are hard to reflect well in numerical calculations. Full article

Structural health monitoring of concrete infrastructure is a critical concern for timely repair and maintenance. This study provides an innovative approach utilizing smart concrete integrated with multi-walled carbon nanotubes (MWCNTs) to enhance electrical conductivity. The smart concrete’s self-sensing capability is assessed through fractional change in electrical resistance (FCR) measured using a four-probe technique. Four-point bending and compressive tests explore the material’s response to cyclic and monotonic loads. Additionally, the impact of saturation levels on self-sensing sensitivity is investigated through compressive tests on varying saturation degrees. Remarkably, a substantial correlation between crack mouth opening displacement (CMOD) and FCR is observed during cyclic bending tests, where FCR increases significantly (from 0.019% to 154%) as CMOD rises from 0.004 mm to 0.55 mm. Digital image correlation (DIC) further validates CMOD measurements and their correlation with FCR. Moreover, this study reveals that amplitude of loading and degree of saturation have a significant effect on the self-sensing of the smart concrete. In saturated conditions, the self-sensing response of the material is insensitive to the mechanical strain, while with reduction in the saturation degree, a quasi-linear response is observed. To assess the sensitivity of the smart concrete, stress and strain sensitivities were evaluated, revealing a noteworthy enhancement of approximately 33% and 50% in stress and strain sensitivity, respectively, as saturation levels decreased. The self-sensing response of the material is very sensitive to the mechanical strain during monotonic loading and damage. These findings indicate the potential of smart concrete as a promising tool for comprehensive, real-time structural health monitoring for infrastructure during its entire life. Full article

Notched beam specimens were loaded by the three-point bending test device, and the effects of different volume contents and combinations of steel fibers on the tensile properties of hybrid steel fiber–reinforced self-compacting concrete (HSFRSCC) were studied. The failure law and strain field distribution of the specimens were studied by digital image correlation (DIC) technology. Moreover, the curves between the load and crack mouth opening displacement (CMOD) of 18 groups of hybrid steel fiber–reinforced concrete specimens were obtained, and the stress–strain curves of 18 groups of specimens were derived from the load–CMOD curves. The results show that both single and hybrid steel fibers can improve the crack deformation resistance and tensile properties of concrete, but hybrid steel fibers have a more significant improvement effect. Only when the content of steel fiber is more than 0.6% can it have a more obvious postpeak descending section, and hybrid steel fiber has higher postpeak deformation capacity and flexural toughness. The fundamental reason why concrete with hybrid steel fibers has better tensile properties is that micro and macro steel fibers cooperate with each other to resist cracks, improving the toughness of concrete after cracking. Finally, the mechanism of different size and volume content of steel fiber was analyzed from the micro level, which can be used as a reference for the engineering design of HSFRSCC in the future. Full article
