The Asymmetric Double Cantilever Beam (ADCB) is a common test configuration used to produce mixed mode I/II in composite materials. It consists of two sublaminates with different thicknesses or elastic properties, a situation that usually occurs in bimaterial adhesive joints. During this test, the sample undergoes rotation. In this work, the influence of this rotation on the calculation of the energy release rate (ERR) in modes I and II was studied using the Finite Element Method (FEM). Several models with different degrees of asymmetry (different thickness ratio and/or elastic modulus ratio) and different applied displacements were prepared to obtain different levels of rotation during the test. As is known, the concept of modes I and II refers to the components of the energy release rate calculated in the direction perpendicular and tangential to the delamination plane, respectively. If the model experiences significant rotation during the application of the load, this non-linearity must be considered in the calculation of the mode partition I/II. In this work, appreciable differences were observed in the values of modes I and II, depending on their calculation in a global system or a local system that rotates with the sample. When performing crack growth calculations, the difference between critical loads can be in the order of 4%, while the difference between mode I and mode II results can reach 4% and 14%, respectively, for an applied displacement of only 5 mm. Currently, this correction is not usually implemented in Finite Element calculation codes or in analytical developments. The purpose of this article is to draw attention to this aspect when the rotation of the specimen is not negligible. Full article

The Bi-directional Evolutionary Structural Optimization (BESO) method, owing to its algorithmic simplicity and strong scalability, has emerged as one of the most prevalent topology optimization methodologies in current research and industrial applications. To overcome the limitations of existing commercial finite element software (e.g., ABAQUS), particularly regarding the closed architecture of topology optimization modules and low efficiency in 3D complex structure optimization, this study proposes an ABAQUS–MATLAB cooperative framework. This innovative approach implements direct read/write operations via Python scripts on CAE/ODB model databases, coupled with MATLAB-based master control programs for sensitivity analysis, mesh filtering, and design variable updating. Compared with conventional integration methods employing INP/FIL file interactions, the proposed framework reduces computational time through MATLAB’s advanced matrix operations while maintaining solution accuracy. Validation cases including 2D cantilever beams and 3D wheel hubs demonstrate the method’s precision and computational efficiency. Practical applications in lightweight design of a hydraulic transmission test bench adapter support achieved 31% volume reduction while satisfying strength and stiffness requirements, significantly lowering material costs. The developed cooperative framework provides an extensible solution for high-efficiency topology optimization of complex engineering structures, balancing algorithmic transparency with practical applicability. Full article

As the trend towards the densification of integrated circuit (IC) devices continues, the complexity of interfaces involving dissimilar materials and thermo-mechanical interactions has increased. Highly integrated systems in packages now comprise numerous thin layers made from various materials. The interfaces between these different materials represent a vulnerable point in ICs due to imperfect adhesion and stress concentrations caused by mismatches in thermo-mechanical properties such as Young’s modulus, coefficients of thermal expansion (CTE), and hygro-swelling-induced expansion. This study investigates the impact of thermal variations on the fracture behavior of three bi-material interfaces used in semiconductor packaging: epoxy molding compound–silicon (EMC–Si), silicon oxide–polyimide (SiO₂–PI), and PI–EMC. Using double cantilever beam (DCB) tests, we analyzed these interfaces under mode I loading at three temperatures: −20 °C, 23 °C, and 100 °C, under both quasi-static and cyclic loading conditions. This provided a comprehensive analysis of the thermal effects across all temperature ranges in microelectronics. The results show that temperature significantly alters the failure mechanism. For SiO₂–PI, the weakest point shifts from silicon at low temperatures to the interface at higher temperatures due to thermal stress redistribution. Additionally, the fracture energy of the EMC–Si interface was found to be highly temperature-dependent, with values ranging from 0.136 N/mm at low temperatures to 0.38 N/mm at high temperatures. SiO₂–PI’s fracture energy at high temperature was 42% less than that of EMC–Si. The PI–EMC interface exhibited nearly double the crack growth rate compared to EMC–Si. The findings of this study provide valuable insights into the fracture behavior of bi-material interfaces, offering practical applications for improving the reliability and design of semiconductor devices, especially in chip packaging. Full article

Based on the basic theoretical framework of the Bi-directional Evolutionary Structural Optimization method (BESO) and the Solid Isotropic Material with Penalization method (SIMP), this paper presents a multiscale topology optimization method for concurrently optimizing the sandwich structure at the macro level and the core layer at the micro level. The types of optimizations are divided into macro and micro concurrent topology optimization (MM), macro and micro gradient concurrent topology optimization (MMG), and macro and micro layered gradient concurrent topology optimization (MMLG). In order to compare the multiscale optimization method with the traditional macroscopic optimization method, the sandwich simply supported beam is illustrated as a numerical example to demonstrate the functionalities and superiorities of the proposed method. Moreover, several samples are printed through micro-nano 3D printing technology, and then the static three-point bending experiments and the numerical simulations are carried out. The mechanical properties of the optimized structures in terms of deformation modes, load-bearing capacity, and energy absorption characteristics are compared and analyzed in detail. Finally, the multiscale optimization methods are extended to the design of 2D sandwich cantilever beams and 3D sandwich fully clamped beams. Full article

This paper presents a model of the bending behavior of a bi-layer cantilever composed of titanium nickelide and a magnetoactive elastomer embedded with magnetically hard particles. The cantilever is initially subjected to an external magnetic field in its high-temperature state, followed by cooling to a low-temperature state before the magnetic field is removed. This sequence results in residual bending deformation. Basic relations describing the material behavior of titanium nickelide and the magnetoactive elastomer are presented. A variational formulation for the problem under consideration is written down. The problem is solved numerically using the finite element method. The influence of the applied magnetic field magnitude and the thickness of the titanium nickelide layer on the cantilever deflection magnitude is studied. The dependence of the residual cantilever deflection on the applied magnetic field is obtained. The possibility of this structure as a controllable gripping element for applications in robotics and micro-manipulation is demonstrated. Full article

This study presents an innovative lateral flow microfluidic paper-based analytical device (μPAD) designed for conducting quantitative paper-based enzyme-linked immunosorbent assays (p-ELISA), seamlessly executing conventional ELISA steps in a paper-based format. The p-ELISA device utilizes a passive fluidic circuit with functional elements such as a multi-bi-material cantilever (B-MaC) assembly, delay channels, and a buffer zone, all enclosed within housing for autonomous, sequential loading of critical reagents onto the detection zone. This novel approach not only demonstrates a rapid assay completion time of under 30 min, but also boasts reduced reagent requirements, minimal equipment needs, and broad applicability across clinical diagnostics and environmental surveillance. Through detailed descriptions of the design, materials, and fabrication methods for the multi-directional flow assay (MDFA), this manuscript highlights the device’s potential for complex biochemical analyses in a user-friendly and versatile format. Analytical performance evaluation, including a limit of detection (LOD) of 8.4 pM for Rabbit IgG, benchmarks the device’s efficacy compared to existing p-ELISA methodologies. This pioneering work lays the groundwork for future advancements in autonomous diagnostics, aiming to enhance global health outcomes through accessible and reliable testing solutions. Full article

Examining crack propagation at the interface of bimaterial components under various conditions is essential for improving the reliability of semiconductor designs. However, the fracture behavior of bimaterial interfaces has been relatively underexplored in the literature, particularly in terms of numerical predictions. Numerical simulations offer vital insights into the evolution of interfacial damage and stress distribution in wafers, showcasing their dependence on material properties. The lack of knowledge about specific interfaces poses a significant obstacle to the development of new products and necessitates active remediation for further progress. The objective of this paper is twofold: firstly, to experimentally investigate the behavior of bimaterial interfaces commonly found in semiconductors under quasi-static loading conditions, and secondly, to determine their respective interfacial cohesive properties using an inverse cohesive zone modeling approach. For this purpose, double cantilever beam specimens were manufactured that allow Mode I static fracture analysis of the interfaces. A compliance-based method was used to obtain the crack size during the tests and the Mode I energy release rate ($G_{Ic}$). Experimental results were utilized to simulate the behavior of different interfaces under specific test conditions in Abaqus. The simulation aimed to extract the interfacial cohesive contact properties of the studied bimaterial interfaces. These properties enable designers to predict the strength of the interfaces, particularly under Mode I loading conditions. To this extent, the cohesive zone modeling (CZM) assisted in defining the behavior of the damage propagation through the bimaterial interfaces. As a result, for the silicon–epoxy molding compound (EMC) interface, the results for maximum strength and $G_{Ic}$ are, respectively, 26 MPa and 0.05 N/mm. The second interface tested consisted of polyimide and silicon oxide between the silicon and EMC layers, and the results obtained are 21.5 MPa for the maximum tensile strength and 0.02 N/mm for $G_{Ic}$. This study’s findings aid in predicting and mitigating failure modes in the studied chip packaging. The insights offer directions for future research, focusing on enhancing material properties and exploring the impact of manufacturing parameters and temperature conditions on delamination in multilayer semiconductors. Full article

This work presents a dynamic modeling approach for analyzing the behavior of a bi-material cantilever actuator structure, consisting of a strip of filter paper bonded to a strip of tape. The actuator’s response is induced by a mismatch strain generated upon wetting, leading to the bending of the cantilever. The study delves into a comprehensive exploration of the dynamic deflection characteristics of the bilayer structure. It untangles the intricate connections among the saturation, modulus, hygro-expansion strain, and deflection, while uniquely addressing the challenges stemming from fluid–structure coupling. To solve the coupled fluid–solid differential equations, a combined numerical method is employed. This involves the application of the Highly Simplified Marker and Cell (HSMAC) technique for fluid flow analysis and the Finite Difference Method (FDM) for response deflection computation. In terms of the capillary flow model, the Computational Fluid Dynamics (CFD) simulations closely align with the classical Washburn relationship, depicting the wetted front’s evolution over time. Furthermore, the numerical findings demonstrate that heightened saturation levels trigger an increase in hygro-expansion strain, consequently leading to a rapid rise in response deflection until a static equilibrium is achieved. This phenomenon underscores the pivotal interplay among saturation, hygro-expansion strain, and deflection within the system. Additionally, the actuator’s response sensitivity to material characteristics is highlighted. As the mismatch strain evolving from paper hygro-expansion diminishes, a corresponding reduction in the axial strain causes a decrease in response deflection. The dynamic parameter demonstrates that the deflection response of the bilayer actuator diminishes as dynamic pressure decreases, reaching a minimal level beyond which further changes are negligible. This intricate correlation underscores the device’s responsiveness to specific material traits, offering prospects for precise behavior tuning. The dependence of paper modulus on saturation levels is revealed to significantly influence bilayer actuator deflection. With higher saturation content, the modulus decreases, resulting in amplified deflection. Finally, strong concordance is observed among the present fluidically coupled model, the static model, and empirical data—a testament to the accuracy of the numerical formulation and results presented in this study. Full article

This research explores the dynamics of a fluidically loaded Bi-Material cantilever (B-MaC), a critical component of μPADs (microfluidic paper-based analytical devices) used in point-of-care diagnostics. Constructed from Scotch Tape and Whatman Grade 41 filter paper strips, the B-MaC’s behavior under fluid imbibition is examined. A capillary fluid flow model is formulated for the B-MaC, adhering to the Lucas–Washburn (LW) equation, and supported by empirical data. This paper further investigates the stress–strain relationship to estimate the modulus of the B-MaC at various saturation levels and to predict the behavior of the fluidically loaded cantilever. The study shows that the Young’s modulus of Whatman Grade 41 filter paper drastically decreases to approximately 20 MPa (about 7% of its dry-state value) upon full saturation. This significant decrease in flexural rigidity, in conjunction with the hygroexpansive strain and coefficient of hygroexpansion (empirically deduced to be 0.008), is essential in determining the B-MaC’s deflection. The proposed moderate deflection formulation effectively predicts the B-MaC’s behavior under fluidic loading, emphasizing the measurement of maximum (tip) deflection using interfacial boundary conditions for the B-MaC’s wet and dry regions. This knowledge of tip deflection will prove instrumental in optimizing the design parameters of B-MaCs. Full article

In this paper, the behavior of the Bi-Material Cantilever (B-MaC) response deflection upon fluidic loading was experimentally studied and modeled for bilayer strips. A B-MaC consists of a strip of paper adhered to a strip of tape. When fluid is introduced, the paper expands while the tape does not, which causes the structure to bend due to strain mismatch, similar to the thermal loading of bi-metal thermostats. The main novelty of the paper-based bilayer cantilevers is the mechanical properties of two different types of material layers, a top layer of sensing paper and a bottom layer of actuating tape, to create a structure that can respond to moisture changes. When the sensing layer absorbs moisture, it causes the bilayer cantilever to bend or curl due to the differential swelling between the two layers. The portion of the paper strip that gets wet forms an arc, and as the fluid advances and fully wets the B-MaC, the entire B-MaC assumes the shape of the initial arc. This study showed that paper with higher hygroscopic expansion forms an arc with a smaller radius of curvature, whereas thicker tape with a higher Young’s modulus forms an arc with a larger radius of curvature. The results showed that the theoretical modeling could accurately predict the behavior of the bilayer strips. The significance of paper-based bilayer cantilevers lies in their potential applications in various fields, such as biomedicine, and environmental monitoring. In summary, the novelty and significance of paper-based bilayer cantilevers lie in their unique combination of sensing and actuating capabilities using a low-cost and environmentally friendly material. Full article

In this paper, we present a novel and cost-effective lab-on-paper microfluidics platform for performing ELISA autonomously, with no user intervention beyond adding the sample. The platform utilizes two Bi-Material Cantilever Valves placed in a specially designed housing. The integration of these valves in a specific channel network forms a complete fluidic logic circuit for performing ELISA on paper. The housing also incorporates an innovative reagent storage and release mechanism that minimizes variability in the volume of reagents released into the reagent pads. The platform design was optimized to minimize variance in the time of fluid wicking from the reagent pad, using a randomized design of experiment. The platform adheres to the World Health Organization’s ASSURED principles. The optimized design was used to conduct an ELISA for detecting rabbit immunoglobulin G (IgG) in a buffer, with a limit of detection of 2.27 ng/mL and a limit of quantification of 8.33 ng/mL. This represents a 58% improvement over previous ELISA methods for detecting rabbit IgG in buffer using portable microfluidic technology. Full article

The novel paper-based Bi-Material Cantilever (B-MaC) valve allows the autonomous loading and control of multiple fluid reagents which contributes to the accurate operation of paper-based microfluidic devices utilized for biological and chemical sensing applications. In this paper, an extensive parametric study is presented to evaluate the effects of key geometric parameters of the valve, such as paper direction, cantilever width, paper type, tape type, and sample volume, in addition to the effects of relative humidity and temperature on the functionality of the B-MaC and to provide a better understanding of the rate of fluid flow and resulting deflection of the cantilever. Machine direction, cantilever width, paper type, and tape type were found to be important parameters that affect the B-MAC’s activation time. It was also observed that the rate of fluid imbibition in the B-MaC is considerably affected by change in humidity for high (55 °C) and low (25 °C) temperatures, while humidity levels have no significant effect during imbibition in the B-MaC at an ambient temperature of 45 °C. It was also found that a minimum distance of 4 mm is required between the B-MaC and the stationary component to prevent accidental activation of the B-MaC prior to sample insertion when relative humidity is higher than 90% and temperature is lower than 35 °C. The rate of fluid imbibition that determines the wetted length of the B-MaC and the final deflection of the cantilever are critical in designing and fabricating point-of-care microfluidic paper-based devices. The B-MaC valve can be utilized in a fluidic circuit to sequentially load several reagents, in addition to the sample to the detection area. Full article

Terahertz imaging technology has shown great potential in many fields. As the core component of terahertz imaging systems, terahertz detectors have received extensive attention. In this paper, a metasurface-based terahertz optomechanical detector is proposed, which is made of two fabrication-friendly materials: gold and silicon nitride. The optomechanical detector is essentially a thermal detector composed of metasurface absorber, bi-material micro-cantilevers and heat insulation pillars. Compared with traditional thermal terahertz detectors, the optomechanical detector employs a metasurface absorber as the terahertz radiation coupler and obtains an absorptivity higher than 90% from 3.24 to 3.98 THz, which is much higher than that of traditional terahertz detectors with absorbers made from natural materials. Furthermore, the detector is fabricated by MEMS process and its responsivity has been verified by a specifically designed optical read-out system; the measured optomechanical responsivity is 24.8 μm/μW, which agrees well with the multi-physics simulation. These results indicated that the detector can be employed as a pixel to form a terahertz focal plane array in the future, and further realize real-time terahertz imaging at room temperature. Full article

Topological optimization can realize the optimization of the mass distribution in the whole objective domain. Compared with morphology and size optimization, it has a higher degree of freedom. In this work, the three-dimensional topological optimization based on piezoelectric materials was discussed. Using the Optimality Criteria, topology optimization was applied to the cantilever piezoelectric transducer. The structure optimization was realized with the voltage and stiffness as the multi-objective function. The corresponding codes are given to show the process of optimization. With 70% of the origin volume, the bi-objective optimization increases the global stiffness by 50.9% and the voltage by 30%. As the iteration process shows, the results of bi-objective optimization prove the value of additive mass at the bottom of the cantilever. This lays the foundation for future piezoelectric transducer structural optimization. Using only stiffness as the objective, the final objective increases inconspicuously. Bi-objective optimization shows its superiority. There are quite a few papers that research the combination of stiffness and voltage, and research which studies three-dimensionality is a point of innovation. Furthermore, this is also the first time a piezoelectric topology code has been shared. Full article

The microfabrication with a magnetostrictive Tb_xDy_(1−x)Fe_y thin film for magnetic microactuators is developed, and the magnetic and magnetostrictive actuation performances of the deposited thin film are evaluated. The magnetostrictive thin film of Tb_xDy_(1−x)Fe_y is deposited on a metal seed layer by electrodeposition using a potentiostat in an aqueous solution. Bi-material cantilever structures with the Tb_0.36Dy_0.64Fe_1.9 thin-film are fabricated using microfabrication, and the magnetic actuation performances are evaluated under the application of a magnetic field. The actuators show large magnetostriction coefficients of approximately 1250 ppm at a magnetic field of 11000 Oe. Full article
