Selected Papers from the 4th MODE Workshop on Differentiable Programming for Experiment Design

Machine learning methods are being introduced at all stages of data reconstruction and analysis in various high-energy physics experiments. We present the development and application of convolutional neural networks with modified autoencoder architecture for the reconstruction of the pulse arrival time and amplitude in individual scintillating crystals in electromagnetic calorimeters and other detectors. The network performance is discussed as well as the application of xAI methods for further investigation of the algorithm and improvement of the output accuracy. Full article

Recent advances in machine learning have opened new avenues for optimizing detector designs in high-energy physics, where the complex interplay of geometry, materials, and physics processes has traditionally posed a significant challenge. In this work, we introduce the end-to-end. AI Detector Optimization framework (AIDO), which leverages a diffusion model as a surrogate for the full simulation and reconstruction chain, enabling gradient-based design exploration in both continuous and discrete parameter spaces. Although this framework is applicable to a broad range of detectors, we illustrate its power using the specific example of a sampling calorimeter, focusing on charged pions and photons as representative incident particles. Our results demonstrate that the diffusion model effectively captures critical performance metrics for calorimeter design, guiding the automatic search for a layer arrangement and material composition that align with known calorimeter principles. The success of this proof-of-concept study provides a foundation for the future applications of end-to-end optimization to more complex detector systems, offering a promising path toward systematically exploring the vast design space in next-generation experiments. Full article

Muon tomography leverages the small, continuous flux of cosmic rays produced in the upper atmosphere to measure the density of unknown volumes. The multiple Coulomb scattering that muons undergo when passing through the material can either be leveraged or represent a measurement nuisance. In either case, the scattering dependence on muon momentum is a significant source of imprecision. This can be alleviated by including dedicated momentum measurement devices in the experiment, which have a potential cost and can interfere with measurement. An alternative consists of leveraging information on scattering withstood through a known medium. We present a comprehensive study of diverse machine-learning algorithms for this regression task, from classical feature engineering with a fully connected network to more advanced architectures such as recurrent and graph neural networks and transformers. Several real-life requirements are considered, such as the inclusion of hit reconstruction efficiency and resolution and the need for a momentum resolution prediction that can improve reconstruction methods. Full article

We study the application of a neural network architecture for identifying charged particle trajectories via unsupervised learning of delays and synaptic weights using a spike-time-dependent plasticity rule. In the considered model, the neurons receive time-encoded information on the position of particle hits in a tracking detector for a particle collider, modeled according to the geometry of the Compact Muon Solenoid Phase-2 detector. We show how a spiking neural network is capable of successfully identifying in a completely unsupervised way the signal left by charged particles in the presence of conspicuous noise from accidental or combinatorial hits, opening the way to applications of neuromorphic computing to particle tracking. The presented results motivate further studies investigating neuromorphic computing as a potential solution for real-time, low-power particle tracking in future high-energy physics experiments. Full article

Information field theory (IFT) provides a powerful framework for reconstructing continuous fields from noisy and sparse data. Based on Bayesian statistics, IFT allows for the approximation of posterior distributions over field-like parameter spaces in high-dimensional problems. In this contribution, we discuss two applications of IFT in the context of astroparticle physics. First, we present its intended use for the calibration of the newly installed radio detector upgrade of the Pierre Auger Observatory. Second, we demonstrate its application to infer the initial directions of ultra-high-energy cosmic rays before their deflection in the Galactic magnetic field using a simplified model. Full article

The civil engineering industry faces a critical need for innovative non-destructive evaluation methods, particularly for ageing critical infrastructure, such as bridges, where current techniques fall short. Muography, a non-invasive imaging technique, constructs three-dimensional density maps by detecting the interactions of naturally occurring cosmic-ray muons within the scanned volume. Cosmic-ray muons offer both deep penetration capabilities due to their high momenta and inherent safety due to their natural source. However, the technology’s reliance on this natural source results in a constrained muon flux, leading to prolonged acquisition times, noisy reconstructions, and challenges in image interpretation. To address these limitations, we developed a two-model deep learning approach. First, we employed a conditional Wasserstein Generative Adversarial Network with Gradient Penalty (cWGAN-GP) to perform predictive upsampling of undersampled muography images. Using the Structural Similarity Index Measure (SSIM), 1-day sampled images were able to match the perceptual qualities of a 21-day image, while the Peak Signal-to-Noise Ratio (PSNR) indicated a noise improvement to that of 31 days worth of sampling. A second cWGAN-GP model, trained for semantic segmentation, was developed to quantitatively assess the upsampling model’s impact on each of the features within the concrete samples. This model was able to achieve segmentation of rebar grids and tendon ducts embedded in the concrete, with respective Dice–Sørensen accuracy coefficients of 0.8174 and 0.8663. This model also revealed an unexpected capability to mitigate—and in some cases entirely remove—z-plane smearing artifacts caused by the muography’s inherent inverse imaging problem. Both models were trained on a comprehensive dataset generated through Geant4 Monte Carlo simulations designed to reflect realistic civil infrastructure scenarios. Our results demonstrate significant improvements in both acquisition speed and image quality, marking a substantial step toward making muography more practical for reinforced concrete infrastructure monitoring applications. Full article

An automatic optimization procedure is proposed for some operational parameters of a Parallel-Plate Avalanche Counter with Optical Readout, a detector designed for heavy-ion tracking and imaging. Exploiting differentiable programming and automatic differentiation, we model the reconstruction of the position of impinging 5.5 MeV alpha particles for different detector configurations and build an optimization cycle that minimizes an objective function. We analyze the performance improvement using this method, exploring the potential of these techniques in detector design. Full article

Muon collisions are considered a promising means for exploring the energy frontier, leading to a detailed study of the possible feasibility challenges. Beam intensities of the order of ${10}^{12}$ muons per bunch are needed to achieve the necessary luminosity, generating a high flux of secondary and tertiary particles from muons decay that reach both the machine elements and the detector region. To limit the impact of this background on the physics performance, tungsten shieldings have been studied. A machine learning-based approach to the geometry optimization of these shieldings will be discussed. Full article

One of the primary challenges for future nuclear fusion power plants is understanding how neutron irradiation affects reactor materials. To tackle this issue, the IFMIF-DONES project aims to build a facility capable of generating a neutron source in order to irradiate different material samples. This will be achieved by colliding a deuteron beam with a lithium jet. In this work, within the DONES-FLUX project, deep learning surrogate models are applied to the design and optimization of the IFMIF-DONES linear accelerator. Specifically, neural operators are employed to predict deuteron beam envelopes along the longitudinal axis of the accelerator and neutron irradiation effects at the end, after the beam collision. This approach has resulted in models that are able of approximating complex simulations with high accuracy (less than 17% percentage error for the worst case) and significantly reduced inference time (ranging from 2 to 6 orders of magnitude) while being differentiable. The substantial speed-up factors enable the application of online reinforcement learning algorithms, and the differentiable nature of the models allows for seamless integration with differentiable programming techniques, facilitating the solving of inverse problems to find the optimal parameters for a given objective. Overall, these results demonstrate the synergy between deep learning models and differentiable programming, offering a promising collaboration among physicists and computer scientists to further improve the design and optimization of IFMIF-DONES and other accelerator facilities. This research will lay the foundations for future projects, where optimization efforts with differentiable programming will be performed. Full article
