Application of Ultrasonic Non-destructive Testing

A special issue of Applied Sciences (ISSN 2076-3417). This special issue belongs to the section "Acoustics and Vibrations".

Deadline for manuscript submissions: closed (20 February 2025) | Viewed by 16023

Special Issue Editor


E-Mail Website
Guest Editor
Department of Electrical and Computer Engineering, University of Coimbra, 3030-290 Coimbra, Portugal
Interests: ultrasonic non-destructive characterization of materials; ultrasonic guided waves; composite inspection; biologic tissue characterization by ultrasounds
Special Issues, Collections and Topics in MDPI journals

Special Issue Information

Dear Colleagues,

This Special Issue is intended for the presentation of new ideas and experimental results related to applications of ultrasound non-destructive testing (UNDT). Ultrasound is an important technique in NDT, being largely used in industry. Metal and composite materials used in critical applications, such as aerospace structures, require appropriate NDT to guarantee safety. Thus, contributions on the latest R&D achievements on ‘Ultrasonic Non-Destructive Testing’, methodologies of testing, and evaluation, as well as on the development of new equipment, analyses, and approaches to non-destructive measurements are welcome.

Authors are encouraged to submit contributions in any of the following or related areas for UNDT:

  • Ultrasonic non-destructive testing/ultrasonic non-destructive evaluation;
  • Ultrasonic-based structural health monitoring and damage detection;
  • Material characterization;
  • NDT of composites;
  • Ultrasound phased arrays;
  • Guided waves;
  • Process monitoring;
  • Ultrasound sensors, transducers, and sensor networks;
  • Instruments, devices, and systems for ultrasound research and applications;
  • Ultrasound in civil, aerospace, and geological materials.

Dr. Mário João S. F. Santos
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Applied Sciences is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • ultrasound in civil, aerospace, and geological materials
  • ultrasonic NDT
  • ultrasonic NDE
  • ultrasonic-based SHM
  • material characterization
  • ultrasound phased arrays
  • guided waves
  • ultrasound transducers

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue policies can be found here.

Published Papers (11 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

Jump to: Review

28 pages, 12079 KiB
Article
Ultrasound Reconstruction Tomography Using Neural Networks Trained with Simulated Data: A Case of Theoretical Gradient Damage in Concrete
by Carles Gallardo-Llopis, Jorge Gosálbez, Sergio Morell-Monzó, Santiago Vázquez, Alba Font and Jordi Payá
Appl. Sci. 2025, 15(8), 4273; https://doi.org/10.3390/app15084273 - 12 Apr 2025
Viewed by 323
Abstract
Gradient damage processes in cementitious materials are generally produced by chemical and/or physical processes that travel from outside to inside. Depending on the type of damage, it can cause different effects such as decreased porosity, cracking, or steel corrosion in the case of [...] Read more.
Gradient damage processes in cementitious materials are generally produced by chemical and/or physical processes that travel from outside to inside. Depending on the type of damage, it can cause different effects such as decreased porosity, cracking, or steel corrosion in the case of carbonation, or increased porosity, micro-cracks, expansion, and spalling (also present in thermal damage) in the case of external attack by sulphates or acid attack. Therefore, estimating the boundaries of this damage is an essential task for concrete quality assessment. The first objective of this work was to use neural networks (NNs) for ultrasound tomographic reconstruction of concrete samples in order to estimate the advance front in gradient damage. Unlike the usual X-ray tomography, ultrasound tomography is affected by diffraction, among other factors. NNs can learn to compensate for these effects; however, they require a large amount of training data to achieve accurate results. In the case of cement-based materials, obtaining and measuring a real training database could be complicated, expensive, and time-consuming. For this purpose, a training process using simulated measurements was carried out. The second objective of this work was to demonstrate the feasibility of training neural networks through simulations, which reduces costs. Finally, the trained neural network for tomographic reconstruction was evaluated using real cylindrical concrete specimens. Each specimen consisted of an outer cylinder, representing externally exposed cement, and an inner cylinder, simulating the unaffected core. The Structural Similarity Index (SSIM) was used as a metric to assess the reconstruction accuracy, achieving values of 0.95 for simulated signals and up to 0.82 for real signals. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

11 pages, 1240 KiB
Article
Calibration of a Quartz Tuning Fork as a Sound Detector
by Judith Falkhofen and Marcus Wolff
Appl. Sci. 2025, 15(7), 3655; https://doi.org/10.3390/app15073655 - 26 Mar 2025
Viewed by 165
Abstract
This study compares the performance of a quartz tuning fork (QTF) with a highly sensitive ultrasound microphone in the context of acoustic measurements, applying the substitution calibration method. QTF sensors are increasingly used for high-precision tasks due to their sensitivity and stability, while [...] Read more.
This study compares the performance of a quartz tuning fork (QTF) with a highly sensitive ultrasound microphone in the context of acoustic measurements, applying the substitution calibration method. QTF sensors are increasingly used for high-precision tasks due to their sensitivity and stability, while microphones are still the standard in general acoustic measurements. The aim of this study is to evaluate both technologies across several key performance metrics, including linearity of response, sensitivity, noise characteristics, and acoustic detection limit. Which sensor is better suited to which acoustic and physical condition? The results show that QTFs perform exceptionally well in applications requiring high precision, especially in high-frequency and narrow-band measurements. The signal-to-noise-ratio (SNR) of the QTF at its resonance frequency is 14 dB higher than that of the microphone, whereas the detection limit and linearity are comparable. The findings suggest that QTF sensors are particularly advantageous for specialized applications like photoacoustic spectroscopy (PAS). Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

15 pages, 1801 KiB
Article
Numerical Evaluation of Ultrasonic Detection of Solid Occlusions in CSP Molten Salt Piping
by Raffaele Dragonetti, Rosario Aniello Romano and Elio Di Giulio
Appl. Sci. 2025, 15(3), 1373; https://doi.org/10.3390/app15031373 - 29 Jan 2025
Viewed by 660
Abstract
This work presents a numerical evaluation of the applicability of non-invasive ultrasonic techniques for detecting solid inclusions in concentrated solar power (CSP) systems using molten salts. Under stagnant conditions, molten salts, such as the NaNO3–KNO3 mixture, solidify when the temperature [...] Read more.
This work presents a numerical evaluation of the applicability of non-invasive ultrasonic techniques for detecting solid inclusions in concentrated solar power (CSP) systems using molten salts. Under stagnant conditions, molten salts, such as the NaNO3–KNO3 mixture, solidify when the temperature drops below approximately 240 °C at ambient pressure. The study was conducted using finite element method (FEM) simulations in the time domain to model ultrasonic wave propagation and interaction with the solidified inclusions. Numerical analyses revealed that the energy of ultrasonic signals transmitted from the source and captured by the receiver can be used to quantify the energy reflected and scattered by solid inclusions and to statistically determine their spatial distribution within the piping. The study highlights the potential of detecting solid occlusions through statistical analysis of ultrasonic signals. Such an approach would enable decision making for trigger heating strategies to re-melt the solidified inclusions by raising the system’s temperature. This approach contrasts with traditional temperature-based control, which fails to quantify the degree of solidification and may result in frequent, energy-intensive heating whenever the temperature drops below the threshold. The proposed ultrasonic-based detection method thus offers a more energy-efficient and precise solution for managing solidification in CSP molten salt piping. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

22 pages, 5527 KiB
Article
Ultrasonic Non-Destructive Testing of Accelerated Carbonation Cured-Eco-Bricks
by Joy Ayankop Oke and Hossam Abuel-Naga
Appl. Sci. 2024, 14(19), 8954; https://doi.org/10.3390/app14198954 - 4 Oct 2024
Viewed by 1041
Abstract
This study aimed to investigate the behavior of accelerated carbonation-cured laboratory specimens using the ultrasonic non-destructive testing (UNDT) method and compare the results with the destructive testing (DT) method. The materials used in the study included a blend of lime kiln dust and [...] Read more.
This study aimed to investigate the behavior of accelerated carbonation-cured laboratory specimens using the ultrasonic non-destructive testing (UNDT) method and compare the results with the destructive testing (DT) method. The materials used in the study included a blend of lime kiln dust and ground granulated blast furnace slag (LKD-GBFS) wastes, natural fine aggregate (sand), and alternative fine aggregates from waste tires. The chemical analysis of the LKD and GBFS samples highlighted them as suitable alternatives to OPC, hence their utilization in the study. A 60:40 (LKD-GBFS) blending ratio and a 1:2 mix design (one part LKD-GBFS blend and two part sand) was considered. The natural fine aggregate was partially replaced with fine waste tire rubber crumbs (TRCs) in stepped increments of 0, 5, and 10% by the volume of the sand. The samples produced were cured using three curing regimens: humid curing (HC), accelerated carbonation curing (ACC) with no water curing (NWC) afterwards, and water curing after carbonation (WC). From the results, an exponential model was developed, which showed a direct correlation between the UNDT and DT results. The developed model is a useful tool that can predict the CS of carbonated samples when cast samples are unavailable. Lastly, a total CO2 uptake of 15,912 g (15.9 kg) was recorded, which underscores ACC as a promising curing technique that can be utilized in the construction industry. This technique will bring about savings in terms of the time required to produce masonry units while promoting a change in the basic assumptions of a safer and cleaner environment. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

19 pages, 5069 KiB
Article
Delamination Localization in Multilayered CFRP Panel Based on Reconstruction of Guided Wave Modes
by Mastan Raja Papanaboina, Elena Jasiuniene, Vykintas Samaitis, Liudas Mažeika and Paulius Griškevičius
Appl. Sci. 2023, 13(17), 9687; https://doi.org/10.3390/app13179687 - 27 Aug 2023
Cited by 5 | Viewed by 1480
Abstract
Multi-layered composite materials are being used in various engineering fields, such as aerospace, automobile, and wind energy, because of their superior material properties. Due to various impact loads during the service life of composite structures, different types of defects can occur, such as [...] Read more.
Multi-layered composite materials are being used in various engineering fields, such as aerospace, automobile, and wind energy, because of their superior material properties. Due to various impact loads during the service life of composite structures, different types of defects can occur, such as matrix cracking, fiber breakage, delaminations, etc. In this research, a novel SHM technique for delamination detection and localization using a minimum number of sensors is proposed. The analytical, numerical, and experimental analysis of GW was performed to increase the probability of detection and localization of delaminations in CFRP material. A new analytical model was developed, which enables identifying converted and transmitted modes in the presence of multiple GW modes. A 2D FFT-based spatial filtering was used to filter the GW modes. The dominant A0 mode was separated to inspect the delamination. Phase velocity is one of the important features in GW inspection to localize the delamination. A phase spectrum approach was developed to reconstruct the phase velocity dispersion of the GW modes in case material properties are unknown. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

14 pages, 1095 KiB
Article
Characterizing the As-Fabricated State of Additively Fabricated IN718 Using Ultrasonic Nondestructive Evaluation
by Zebadiah Miles, Beytullah Aydogan, Guillermo Huanes-Alvan, Himanshu Sahasrabudhe and Sunil Kishore Chakrapani
Appl. Sci. 2023, 13(14), 8137; https://doi.org/10.3390/app13148137 - 13 Jul 2023
Cited by 4 | Viewed by 1662
Abstract
This article reports on the characterization of the “as-fabricated” state of Inconel 718 samples fabricated using laser directed energy deposition (DED). Laser-DED is known to produce complex metastable microstructures that can significantly influence the baseline ultrasonic response compared to conventional processing methods. The [...] Read more.
This article reports on the characterization of the “as-fabricated” state of Inconel 718 samples fabricated using laser directed energy deposition (DED). Laser-DED is known to produce complex metastable microstructures that can significantly influence the baseline ultrasonic response compared to conventional processing methods. The present work uses three parameters to characterize the samples: (a) ultrasonic velocity, (b) an attenuation coefficient, and (c) a backscatter coefficient. The baseline ultrasonic response from the DED sample was compared against the ultrasonic properties of conventional IN718 samples reported in the literature. The results suggest that strong grain boundary scattering from large macrograins can lead to attenuation and backscatter values that are significantly higher than conventional samples. Additionally, the results including velocities, attenuation and backscatter coefficients were found to be dependent on the fabrication direction, with the build direction being different from the transverse directions. Finally, destructive analysis was used to develop conjectures to explain the experimentally observed ultrasonic response. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

15 pages, 41221 KiB
Article
Adhesive Single-Lap Joint Evaluation Using Ultrasound Guided Waves
by Mário Santos and Jaime Santos
Appl. Sci. 2023, 13(11), 6523; https://doi.org/10.3390/app13116523 - 26 May 2023
Cited by 5 | Viewed by 1544
Abstract
This work deals with the evaluation of adhesive single-lap joints using ultrasound guided waves; in particular, it is intended to characterize the signal propagation when defects are present in the adhesive joint by simulation and experimental approaches. The propagation of guided waves in [...] Read more.
This work deals with the evaluation of adhesive single-lap joints using ultrasound guided waves; in particular, it is intended to characterize the signal propagation when defects are present in the adhesive joint by simulation and experimental approaches. The propagation of guided waves in the joint is developed from matrix formulations. The behavior of the guided wave modes that exist in the bonded region is characterized. It is found that its amplitudes can be estimated from the properties of the incoming wave that propagates in the non-bonded region. It is verified that the excitation of these modes is related to the degree to which the shapes of both modes match each other. A 3D simulation of two aluminum-bonded plates using 500 kHz ultrasonic transducers in a pitch-and-catch configuration was implemented using the Matlab k-Wave toolbox. Scattering effects, due to some defects located in the bond line of the joints, were simulated. The experimental setup with some artificial defects produced in the aluminum joints was used in order to compare it with the simulation. Qualitative agreement was observed between the two approaches. The observed deviation can be due to the different characteristics of the experimental and simulated defects. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

19 pages, 5345 KiB
Article
Measurement of Air Layer Thickness under Multi-Angle Incidence Conditions Based on Ultrasonic Resonance Reflection Theory for Flange Fasteners
by Fei Shang, Bo Sun and Honghui Zhang
Appl. Sci. 2023, 13(10), 6057; https://doi.org/10.3390/app13106057 - 15 May 2023
Cited by 4 | Viewed by 1764
Abstract
During the servicing of flange fasteners, the sealing gasket and the flange cover interface are prone to separation and air contamination due to factors such as stress, corrosion, and vibration. In the detection process, there are two main issues: firstly, the conventional ultrasonic [...] Read more.
During the servicing of flange fasteners, the sealing gasket and the flange cover interface are prone to separation and air contamination due to factors such as stress, corrosion, and vibration. In the detection process, there are two main issues: firstly, the conventional ultrasonic measurement methods based on the theory of acoustic elasticity are not applicable due to the small thickness of the air layer; secondly, the use of conventional vertical incidence detection methods is difficult to ensure due to the influence of the actual structure. To address these issues, this paper first establishes a mathematical model of ultrasonic resonance reflection, and then calculates the corresponding relationship between the air layer thickness and the resonance frequency under vertical incidence conditions. However, this model is difficult to use to calculate the resonance frequency under different incidence angles. To meet the requirements of different working conditions, a finite element simulation model is further established. By comparing the calculation results of the two models under vertical incidence, the reliability of the established finite element model is verified. The reflection and transmission pressure acoustic field distribution under different incidence angles and air layer thicknesses is simulated, and the function relationship between the incidence angle, air layer thickness, and the corresponding first-order resonance frequency is derived. This enables the measurement of the air layer thickness at any incidence angle, providing technical and theoretical support for practical industrial applications. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

10 pages, 808 KiB
Communication
Numerical Study of Mode Conversion between Fundamental Lamb and Rayleigh Waves
by Alex Vu, Leonard J. Bond and Sunil K. Chakrapani
Appl. Sci. 2023, 13(9), 5613; https://doi.org/10.3390/app13095613 - 1 May 2023
Cited by 4 | Viewed by 2122
Abstract
This article reports the findings of a numerical study of mode conversion between fundamental Lamb and Rayleigh waves and vice versa in quarter and half spaces. Fundamental Lamb wave (A0 and S0) propagation in a plate attached to a [...] Read more.
This article reports the findings of a numerical study of mode conversion between fundamental Lamb and Rayleigh waves and vice versa in quarter and half spaces. Fundamental Lamb wave (A0 and S0) propagation in a plate attached to a quarter space and the subsequent mode conversion to a Rayleigh wave was studied using finite element analysis. B-Scans show that a beat-like phenomenon can be observed for the R → L conversion and a generation length can be observed for the L → R conversion. The quarter-space model was also used to study the Rayleigh to Lamb mode conversion. Two hypotheses were developed based on the observed mode conversion efficiencies: (a) the main driving factor of mode conversion between Lamb and Rayleigh waves is the grazing incidence of bulk modes and (b) due to scattering and diffraction, the modes will require a generation length to stabilize in amplitude. Both hypotheses were tested and confirmed using numerical models, including a half-space model to study the diffraction of bulk waves from an incident Lamb wave. The results are of significance for nondestructive evaluation of complex structures where such structural discontinuities exist and it becomes important to understand the fundamental mode conversion phenomenon. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

14 pages, 6033 KiB
Article
An Interface Pressure Detection Method of Cable Silicone Rubber-XLPE Based on Nonlinear Ultrasound
by Chunhua Fang, Jianben Liu, Aoqi Sun, Junxiong Wu, Rong Xia, Benhong Ouyang, Yilin Zhang and Fang Li
Appl. Sci. 2023, 13(9), 5404; https://doi.org/10.3390/app13095404 - 26 Apr 2023
Cited by 2 | Viewed by 1686
Abstract
The interface pressure between the cable attachment and the body is crucial for the stable long-term operation of the cable. To solve the issue of interface insulation characteristics’ damage caused by the pressure transducer measurement method, a non-destructive testing method of silicone rubber [...] Read more.
The interface pressure between the cable attachment and the body is crucial for the stable long-term operation of the cable. To solve the issue of interface insulation characteristics’ damage caused by the pressure transducer measurement method, a non-destructive testing method of silicone rubber interface pressure using nonlinear ultrasound is presented. Initially, the study analyzes the propagation characteristics of ultrasonic waves at the interface of cross-linked polyethylene and silicone rubber. The study also establishes the relationship between the nonlinear coefficient and the interface pressure. Subsequently, a nonlinear ultrasonic test platform is constructed using the pulse reflection method to measure the interface pressure of flat silicone rubber and cross-linked polyethylene through nonlinear ultrasonic testing. Theoretical and experimental results indicate that the fundamental amplitude of the frequency domain of the interface reflection wave decreases, and the second harmonic amplitude and nonlinear coefficient both increase as pressure increases. These results demonstrate that the nonlinear ultrasound, non-destructive testing method can accurately evaluate the interfacial pressure state of the cable accessories. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1

Review

Jump to: Research

24 pages, 8214 KiB
Review
Recent Advancements in Guided Ultrasonic Waves for Structural Health Monitoring of Composite Structures
by Mohad Tanveer, Muhammad Umar Elahi, Jaehyun Jung, Muhammad Muzammil Azad, Salman Khalid and Heung Soo Kim
Appl. Sci. 2024, 14(23), 11091; https://doi.org/10.3390/app142311091 - 28 Nov 2024
Cited by 4 | Viewed by 2060
Abstract
Structural health monitoring (SHM) is essential for ensuring the safety and longevity of laminated composite structures. Their favorable strength-to-weight ratio renders them ideal for the automotive, marine, and aerospace industries. Among various non-destructive testing (NDT) methods, ultrasonic techniques have emerged as robust tools [...] Read more.
Structural health monitoring (SHM) is essential for ensuring the safety and longevity of laminated composite structures. Their favorable strength-to-weight ratio renders them ideal for the automotive, marine, and aerospace industries. Among various non-destructive testing (NDT) methods, ultrasonic techniques have emerged as robust tools for detecting and characterizing internal flaws in composites, including delaminations, matrix cracks, and fiber breakages. This review concentrates on recent developments in ultrasonic NDT techniques for the SHM of laminated composite structures, with a special focus on guided wave methods. We delve into the fundamental principles of ultrasonic testing in composites and review cutting-edge techniques such as phased array ultrasonics, laser ultrasonics, and nonlinear ultrasonic methods. The review also discusses emerging trends in data analysis, particularly the integration of machine learning and artificial intelligence for enhanced defect detection and characterization through guided waves. This review outlines the current and anticipated trends in ultrasonic NDT for SHM in composites, aiming to aid researchers and practitioners in developing more effective monitoring strategies for laminated composite structures. Full article
(This article belongs to the Special Issue Application of Ultrasonic Non-destructive Testing)
Show Figures

Figure 1
