Integration of BIM and Procedural Modeling Tools for Road Design

1
Department of Civil, Construction and Environmental Engineering, Federico II University of Naples, 80125 Naples, Italy
2
Faculty of Civil Engineering, Transportation Engineering and Architecture, University of Maribor, 2000 Maribor, Slovenia
*
Author to whom correspondence should be addressed.
Infrastructures 2020, 5(4), 37; https://doi.org/10.3390/infrastructures5040037
Received: 15 March 2020 / Revised: 15 April 2020 / Accepted: 18 April 2020 / Published: 20 April 2020
(This article belongs to the Special Issue Smart Cities and Infrastructures)
Building Information Modeling (BIM) is a design and management methodology strongly used in the Industry of Architecture, Engineering, and Construction (AEC). It allows the creation of a 3D model through parametric modelling in a workflow that updates data, geometry and semantics using the Industry Foundation Classes (IFC) standard. The purpose of this paper is to develop and apply a BIM method for road infrastructures. The creation of the BIM 3D models was carried out using different visual programming software and BIM tools, designing the spatial and parametric representation of the roadway. This way, it has been possible to discover the advantages of using procedural modelling to design road infrastructure through software that are usually used in the mechanical and architectural field. Finally, the interoperability of the software to extract and exchange information between these BIM tools was assessed. View Full-Text
Keywords: Building Information Modeling; smart infrastructure; BIM software tools Building Information Modeling; smart infrastructure; BIM software tools
Show Figures

Graphical abstract

  • Externally hosted supplementary file 1
    Doi: 10.5281/zenodo.3757120
    Link: http://doi.org/10.5281/zenodo.3757120
    Description: OpenScad and Python in Grasshopper full computer code used in the work "Integration of BIM and Procedural Modeling Tools for Road Design"
MDPI and ACS Style

Biancardo, S.A.; Capano, A.; de Oliveira, S.G.; Tibaut, A. Integration of BIM and Procedural Modeling Tools for Road Design. Infrastructures 2020, 5, 37.
