1. Introduction
Lung cancer is the commonest form of cancer with the highest death rate both in developed and developing countries. In Taiwan, it has ranked first in terms of cancer mortality for more than five years. Female lung cancer is the number one cause of cancer-related death among women in Taiwan. Lung cancer is the leading cause of death in the United States and East Asia [
1,
2]. The smoking behaviors and environmental factors that cause lung cancer have been extensively studied [
3]. Lung cancer is asymptomatic in the initial stage; therefore, approximately 70% to 75% of most newly diagnosed lung cancers are terminal. Traditionally, chest x-rays, computed tomography (CT), and magnetic resonance imaging have been used to physically analyze tissues to diagnose lung cancer [
4,
5]. Systemic therapy for these patients includes chemotherapy or targeted therapy. Early detection of lung cancer is critical in reducing misdiagnosis by physicians. Because of rapid advancements in computer software, the application of computer aided detection (CAD) software has become common. CAD assists imaging specialists to determine, identify, and evaluate lung lesions and nodules in digital CT images. In particular, the discovery of small nodules between 5 and 15 mm in diameter allows the early detection and treatment of lung diseases.
The current wave of artificial intelligence technology has achieved several breakthroughs, such as recognition, generation, and analysis of images [
6,
7,
8], and speech [
9], in the natural user interfaces. Machines have features that enable humans to interact with users. Modern devices not only have more affinity, but also a more reasonable and intelligent judgment and response to the surrounding environment. Such products have large development potential, including driverless cars, drones, smart homes, manufacturing robots, and chat robots. Convolutional neural networks (CNN) are a major development in deep learning. CNNs are capable of classifying images and are widely applied in object detection tasks [
10,
11,
12]. Furthermore, they have been continuously developed and improved. The handwritten font recognition model LeNet-5 [
13] was developed in 1994 and is one of the earliest CNNs. LeCun et al. compared the multilayer back propagation network and CNN. The excellent design of LeNet5 helps extract features using operations such as convolution, parameter sharing, and pooling, thus reducing computational costs. Finally, the fully connected neural network is used for classification and recognition. This network is the basis for several neural network architectures. Developed in 2012, AlexNet [
14] won the Imagenet competition. ReLU, instead of traditional activation functions, is used in AlexNet. However, the GPU memory limits the network size, Therefore, AlexNet was extended on two GPUs, which were trained in parallel. However, none of the aforementioned architectures has a rapid method of determining optimal parameters. Therefore, in this study, we used the Taguchi method to determine optimal parameters.
Experiments should be conducted to obtain sufficient relevant data to determine the mechanism of the observed phenomena. Most researchers use the trial and error approach to determine optimal parameters. Trial and error is a type of learning in which various responses in a situation are attempted, seemingly at random, until one response achieves the relevant goal. Through successive trials, the successful response is strengthened and occurs earlier. However, this method is time consuming. Therefore, an efficient method should be used to obtain experimental data. Taguchi [
15,
16] developed a method based on the orthogonal array (OA) experiment, which considerably reduces variance for the experiment by optimal setting control parameters. Therefore, a combination of experimental design and control parameter optimization is used in the Taguchi method to obtain the best results. An OA provides a well-balanced set of experiments. The Taguchi signal-to-noise ratio (S/N) is a logarithmic function of the desired output. It is an optimized objective function, which is helpful for data analysis and the prediction of the optimal results. The Taguchi method is a scientifically standardized mechanism for evaluating and implementing improvements in products, processes, materials, equipment, and facilities. These improvements are designed to optimize the program to produce the best results and simultaneously reducing the number of defects. In recent years, several researchers [
17,
18] have used the evolutionary computation methods to optimize parameters of CNN. Esteban et al. [
17] used evolutionary techniques at unprecedented scales to discover models and DNA-based coding schemes for CIFAR-10 and CIFAR-100 datasets. Ma et al. [
18] proposed an autonomous and continuous learning (ACL) algorithm that can automatically generate a deep convolutional neural network (DCNN) architecture for each given visual task. They divided the DCNN into multiple stacked meta-convolutional blocks and fully connected blocks, each of which may contain convolution, pooling, full connection, batch normalization, activation and exit operations to convert the architecture to integer code. According to the above-mentioned methods, these methods can obtain good accuracy. However, they take more time to determine the architecture parameters [
17,
18]. We used the CNN-based Taguchi method to classify lung nodules in CT images. Our objective was to improve the CNN accuracy and decrease the experimental time.
The remainder of the paper is organized as follows.
Section 2 introduces the relevant CNN based Taguchi method. In
Section 3, the experimental results of the proposed method are described.
Section 4 presents conclusions.
2. CNN-Based Taguchi Method
This section details how a Taguchi-based CNN is used for detecting gender from an image data set. The flow chart of the proposed method is presented in
Figure 1.
2.1. CNNs
CNNs consists of one or more convolutional and fully connected layers, and pooling layers. Compared with other deep learning structures, CNNs can provide better results in image and speech recognition. This model can also be trained using back-propagation algorithms. AlexNet was used in this study [
14].
The AlexNet network structure has eight layers. The first five layers are convolutional layers (C), the next three layers are fully connected (FC) layers, and the output of the last fully connected layer is passed to a 1000-channel softmax layer, which corresponds to the distribution of 1000 class labels. Lung nodules are classified using two labels, namely benign and malignant. Therefore, we changed the last FC layer to a two-channel softmax layer, which corresponded to the distribution of the two-class label.
Table 1 lists the parameters of show the AlexNet architecture.
2.2. Taguchi Method
Statistical methods are used in quality engineering to improve product quality and reduce costs. These methods are also used in biology, marketing, and advertising. Professional statisticians concur with the goals and advancements of quality engineering. The most substantial advantage of the Taguchi method is that useful information can be obtained with fewer experiments. Although it is not as favorable as the full factor method for determining the exact optimization position, it requires fewer trends to determine the optimization trend. The feasibility is considerably greater than the full factor method. The Taguchi method has the following characteristics: (1) quality characteristics based on the quality loss function, (2) definition and selection of experimental factors, (3) S/N ratio, and (4) the Taguchi OA.
In the full factor method, when the control factor and number of levels increase, the number of experiments increases exponentially. Therefore, partial factorial design increases the complexity of the experimental method. If an OA is used, fewer experiments are required to obtain a reliable factor effect. The use of OA to conduct experiments is key to Taguchi quality engineering. Before the OA is constructed, the number of factors that affect the quality characteristics, the level of each factor, and the difficulties that may occur in the experiment should be determined. Then, an appropriate OA should be selected, and the factors should be preconfigured before experiments are conducted. An appropriate OA is configured for the selected control factor for experiments. Finally, the S/N ratio is calculated based on the experimental observations obtained by the experiment, and the best factor is analyzed using the S/N ratio.
The analysis of experimental data is based on the S/N ratio created by Dr. Taguchi. The quality characteristics can be divided into the larger the better (LTB), smaller the better, and nominal the best. This paper presents a static parameter design. A larger quality characteristic and higher experimental is preferred. We used the following LTB formula:
where
T is the number of experiments, and
is the
experimental result.
4. Conclusions
In radiology, it is important to improve the accuracy of lung nodule classification. An excellent CAD can not only assist the radiologist, but also reduce the burden on the radiologist. In this study, we used the Taguchi method to design experiments and improve the classification accuracy of AlexNet. Compared with the trial and error method, the proposed method saves substantial experimental time. The selected five parameters with three levels and one parameter with two levels in AlexNet require 486 experiments using the trial and error method, while only 18 experiments are required using the Taguchi method. The S/N ratio reaction table is used to determine the response of the factor to the system at this level, and then determine the best level. The order of the influence of each factor on the system is C5 Padding, C1 Kernel Size, C5 Stride, C1 Stride, C5 Kernel, and C1 Padding. The accuracy of the best factor using Taguchi-based CNN is improved by 2.764%. The training times using the Taguchi-based CNN and the trial and error method are 4.5 h, and 5 days and 1.5 h, respectively. Experimental results indicate that the proposed method takes less training time than other methods. In future work, the proposed method can also be applied to breast cancer, brain tumors, and liver tumors. In addition, some incremental data methods, such as Generative Adversarial Network (GAN), can be used to increase the amount of training data and improve the accuracy of classification.
