An Energy Logger for Kinetic-Powered Wrist-Wearable Systems

Department of Electrical and Electronics Engineering, Universidad Del Norte, Barranquilla 080002, Colombia
*
Author to whom correspondence should be addressed.
Electronics 2020, 9(3), 487; https://doi.org/10.3390/electronics9030487
Received: 28 January 2020 / Revised: 25 February 2020 / Accepted: 26 February 2020 / Published: 15 March 2020
Kinetic energy harvesting is a promising technology towards the development of alternative battery-charging schemes or even self-powered wearable devices that obtain their power supply from human motion. Although there are many developments with schemes that leverage piezoelectric materials and human motion to power devices especially from footsteps, some other body locations like the wrist still need assessment with piezoelectric generators to evaluate their potential of limitations. In this work, we present the results of logging the energy transference from a wrist-worn piezoelectric harvester to a battery in a wearable device. This system is the continuation of our previous work where we implemented the harvester with a resistive load previously tuned to obtain maximum power and assessed the energy harvested during physical activities. Now, we replace the linear load with a charge controller and a Li-ion battery in the same wearable set-up. These new conditions are not optimal for the piezoelectric generator but present a more realistic environment for the kinetic harvester and allows a more precise study of the feasibility of a self-powered system. Tests show that five minutes of activities that involve arm motion can provide between 1.75 mJ and 2.98 mJ of energy, which can represent between 3.6 seconds and 6.2 seconds of additional battery duration. Hence, these results provide an insight of the limitations and challenges remaining in the piezoelectric-based kinetic harvesting field for wearable devices. View Full-Text
Keywords: kinetic energy harvesting; piezoelectric generator; wearable devices kinetic energy harvesting; piezoelectric generator; wearable devices
Show Figures

Figure 1
