Open AccessArticle

High-Performance Time Server Core for FPGA System-on-Chip

Electronics Technology Department, E.T.S. Ingeniería Informática, University of Seville, Avda. Reina Mercedes s/n, 41012 Seville, Spain
*
Author to whom correspondence should be addressed.
Electronics 2019, 8(5), 528; https://doi.org/10.3390/electronics8050528
Received: 11 April 2019 / Revised: 3 May 2019 / Accepted: 7 May 2019 / Published: 11 May 2019
(This article belongs to the Special Issue New Applications and Architectures Based on FPGA/SoC)
  |
PDF [1174 KB, uploaded 21 May 2019]
  |

Abstract

This paper presents the complete design and implementation of a low-cost, low-footprint, network time protocol server core for field programmable gate arrays. The core uses a carefully designed modular architecture, which is fully implemented in hardware using digital circuits and systems. Most remarkable novelties introduced are a hardware-optimized timekeeping algorithm implementation, and a full-hardware protocol stack and automatic network configuration. As a result, the core is able to achieve similar accuracy and performance to typical high-performance network time protocol server equipment. The core uses a standard global positioning system receiver as time reference, has a small footprint and can easily fit in a low-range field-programmable chip, greatly scaling down from previous system-on-chip time synchronization systems. Accuracy and performance results show that the core can serve hundreds of thousands of network time clients with negligible accuracy degradation, in contrast to state-of-the-art high-performance time server equipment. Therefore, this core provides a valuable time server solution for a wide range of emerging embedded and distributed network applications such as the Internet of Things and the smart grid, at a fraction of the cost and footprint of current discrete and embedded solutions. View Full-Text
Keywords: system-on-chip; digital integrated circuits; field programmable gate array; network time synchronization; network time protocol; hardware timestamping; Internet of Things system-on-chip; digital integrated circuits; field programmable gate array; network time synchronization; network time protocol; hardware timestamping; Internet of Things
