Long-Term Study of Soluble Reactive Phosphorus Concentration in Fall Creek and Comparison to Northeastern Tributaries of Cayuga Lake, NY: Implications for Watershed Monitoring and Management
2. Materials and Methods
2.1. Geographic Setting and Watershed Characteristics
2.1.1. Long-Term Study of Fall Creek
2.1.2. Spatial Study
2.2. Sampling Sites, Sample Collection, and Sample Analysis
2.2.1. Long-Term Study of Fall Creek
2.2.2. Spatial Study
2.3. Discharge Records and Statistical Methods
3.1. Long-Term Study of Fall Creek.
3.2. Spatial Study
4.1. Long-Term Study of Fall Creek
4.2. Spatial Study
4.3. Implications for Future Monitoring and Management
- Sample High Flows and Record Flow Rates. Hydrology driven SRP export must be accounted for in monitoring protocols. A range of flow conditions must be sampled, with particular efforts to capture high flows. Rapid deployment of monitoring personnel in response to storm events is key. In ungaged streams flow rate at the time of sampling can be estimated using drainage basin ratios and data from nearby gaged streams . Alternatively, simple current velocity meters and stream dimensions can be used to roughly estimate flow rates, as long as high water does not pose safety concerns.
- Plan for the Long Term and for Extensive Sampling. Our data suggest that SRP in the Fall Creek watershed has been stable for decades. As we enter an era of TMDL-guided watershed management and efforts to reduce HABs, expectations of rapid watershed response are not realistic. Highly variable hydrology will confound our ability to detect changes attributable to decreased phosphorus inputs. Monitoring protocols should be designed and resourced for decadal timescales and large sample sizes.
- Incorporate Spatial Variety When Locating Monitoring Sites. Smaller tributaries in the northern part of the Cayuga Lake watershed represent a large data gap that we have begun to fill in this study using data collected by CSI and its volunteer partner groups. During TMDL implementation and assessment, the historical focus on southern tributaries and large sub-watersheds must be expanded to include more diversity in sub-watershed location and size.
Conflicts of Interest
- Liu, S.M.; Zhang, J.; Chen, H.T.; Wu, Y.; Xiong, H.; Zhang, Z.F. Nutrients in the Changjiang and its tributaries. Biogeochemistry 2003, 62, 1–18. [Google Scholar] [CrossRef]
- Grizzetti, B.; Bouraoui, F.; Aloe, A. Changes of nitrogen and phosphorus loads to European seas. Glob. Chang. Biol. 2012, 18, 769–782. [Google Scholar] [CrossRef]
- Romero, E.; Garnier, J.; Lassaletta, L.; Billen, G.; Le Gendre, R.; Riou, P.; Cugier, P. Large-scale patterns of river inputs in southwestern Europe: Seasonal and interannual variations and potential eutrophication effects at the coastal zone. Biogeochemistry 2013, 113, 481–505. [Google Scholar] [CrossRef]
- Sprague, L.A.; Lorenz, D.L. Regional nutrient trends in streams and rivers of the United States, 1993–2003. Environ. Sci. Technol. 2009, 43, 3430–3435. [Google Scholar] [CrossRef] [PubMed]
- Stammler, K.L.; Taylor, W.D.; Mohamed, M.N. Long-term decline in stream total phosphorus concentrations: A pervasive pattern in all watershed types in Ontario. J. Gt. Lakes Res. 2017, 43, 930–937. [Google Scholar] [CrossRef]
- Raney, S.M.; Eimers, M.C. Unexpected declines in stream phosphorus concentrations across southern Ontario. Can. J. Fish. Aquat. Sci. 2014, 71, 337–342. [Google Scholar] [CrossRef]
- Daloglu, I.; Cho, K.H.; Scavia, D. Evaluating causes of trends in long-term dissolved reactive phosphorus loads to Lake Erie. Environ. Sci. Technol. 2012, 46, 10660–10666. [Google Scholar] [CrossRef]
- Weigelhofer, G.; Hein, T.; Bondar-Kunze, E. Phosphorus and nitrogen dynamics in riverine systems: Human impacts and management options. In Riverine Ecosystem Management; Schmutz, S., Sendzimir, J., Eds.; Aquatic Ecology Series; Springer: London, UK, 2018; Volume 8, pp. 187–202. [Google Scholar]
- Kosten, S.; Huszar, V.L.M.; Mazzeo, N.; Scheffer, M. Lake and watershed characteristics rather than climate influence nutrient limitation in shallow lakes. Ecol. Appl. 2009, 19, 1791–1804. [Google Scholar] [CrossRef]
- Kelderman, P.; Koech, D.K.; Gumbo, B.; O’Keeffe, J. Phosphorus budget in the low-income, peri-urban area of Kibera, in Nairobi (Kenya). Water Sci. Technol. 2009, 60, 2669–2676. [Google Scholar] [CrossRef]
- Chen, Q.; Chen, J.; Wang, J.; Guo, J.; Jin, Z.; Yu, P.; Zhenzhen, M. In situ, high-resolution evidence of phosphorus release from sediments controlled by the reductive dissolution of iron-bound phosphorus in a deep reservoir, southwestern China. Sci. Total Environ. 2019, 666, 39–45. [Google Scholar] [CrossRef]
- Anderson, D.M. HABs in a Changing World: A Perspective on Harmful Algal Blooms, their Impacts, and Research and Management in a Dynamic Era of Climactic and Environmental Change. In Harmful Algae 2012, Proceedings of the 15th International Conference on Harmful Algae, Changwon, Gyeongnam, Korea, 29 October–2 November 2012; Kim, H.G., Reguera, B., Hallegraeff, G.M., Lee, C.K., Eds.; 2014. Available online: https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4667985/ (accessed on 23 June 2019).
- Gilbert, P.M. Eutrophication, harmful algae and biodiversity-challenging paradigms in a world of complex nutrient changes. Mar. Pollut. Bull. 2017, 124, 591–606. [Google Scholar] [CrossRef] [PubMed]
- Baker, D.B.; Confesor, R.; Ewing, D.E.; Johnson, L.T.; Kramer, J.W.; Merryfield, B.J. Phosphorus loading to Lake Erie from the Maumee, Sandusky and Cuyahoga rivers: The importance of bioavailability. J. Gt. Lakes Res. 2014, 40, 502–517. [Google Scholar] [CrossRef]
- Stow, C.A.; Borsuk, M.E.; Stanley, D.W. Long-term changes in watershed nutrient inputs and riverine exports in the Neuse River, North Carolina. Water Res. 2001, 35, 1489–1499. [Google Scholar] [CrossRef]
- Betanzo, E.A.; Choquette, E.F.; Reckhow, K.H.; Hayes, L.; Hagen, E.R.; Argue, D.M.; Cangelosi, A.A. Water Data to Answer Urgent Water Policy Questions: Monitoring Design, Available Data and Filling Data Gaps for Determining the Effectiveness of Agricultural Management Practices for Reducing Tributary Nutrient Loads to Lake Erie. Northeast-Midwest Institute Report. 2015. Available online: http://www.nemw.org/wp-content/uploads/2016/06/Final-Nutrient-Case-Study-Report.pdf (accessed on 23 June 2019).
- Murphy, J.; Sprague, L. Water-quality trends in US rivers: Exploring effects from streamflow trends and changes in watershed management. Sci. Total Environ. 2019, 656, 645–658. [Google Scholar] [CrossRef]
- Genesee-Finger Lakes Regional Planning Council. Cayuga Lake Watershed Characterization. 2000. Available online: https://www.cayugawatershed.org/documents/CLW_characterization_2000.pdf (accessed on 23 June 2019).
- Haith, D.A.; Hollingshead, N.; Bell, M.L.; Kreszewski, S.W.; Morey, S.J. Nutrient loads to Cayuga Lake, New York: Watershed modeling on a budget. J. Water Resour. Plan. Manag. 2012, 138, 571–580. [Google Scholar] [CrossRef]
- New York State Department of Environmental Conservation. Cayuga Lake TMDL Outreach. Available online: https://www.dec.ny.gov/lands/95403.html (accessed on 23 June 2019).
- Prestigiacomo, A.R.; Effler, S.W.; Gelda, R.K.; Matthews, D.A.; Auer, M.T.; Downer, B.E.; Kuczynski, A.; Walter, M.T. Apportionment of bioavailable phosphorus loads entering Cayuga Lake, New York. J. Am. Water Resour. Assoc. 2016, 52, 31–47. [Google Scholar] [CrossRef]
- Bouldin, D.; Johnson, A.; Lauer, D. The influence of human activity on the export of phosphorus and nitrate from Fall Creek. In Nitrogen and Phosphorus. Food Production, Waste and the Environment; Porter, K., Ed.; Ann Arbor Science: Ann Arbor, MI, USA, 1975; pp. 59–120. [Google Scholar]
- Upstate Freshwater Institute; Department of Biological and Environmental Science Cornell University; Cornell Biological Field Station; Department of Ecology and Evolutionary Biology Cornell University. Final Phase I Report: Monitoring and Modeling Support for a Phosphorus/Eutrophication Model for Cayuga Lake. 2014. Available online: https://energyandsustainability.fs.cornell.edu/file/Phase_I_Cayuga_Lake_Final_Report_121914.pdf (accessed on 23 June 2019).
- Johnson, A.H.; Bouldin, A.R.; Goyette, E.A.; Hedges, A.M. Phosphorus loss by stream transport from a rural watershed: Quantities, processes, and sources. J. Environ. Qual. 1976, 5, 148–157. [Google Scholar] [CrossRef]
- Johnson, M.S.; Woodbury, P.B.; Pell, A.N.; Lehmann, J. Land-use change and stream water fluxes: Decadal dynamics in watershed nitrate exports. Ecosystems 2007, 10, 1182–1196. [Google Scholar] [CrossRef]
- Copeland, C. Animal Waste and Water Quality: EPA’s response to the Waterkeeper Alliance court decision on regulation of CAFOs. Congressional Research Service Reports 43. 2010. Available online: https://digitalcommons.unl.edu/crsdocs/43/ (accessed on 23 June 2019).
- New York State Department of Environmental Conservation. Descriptive Data of Municipal Wastewater Treatment Plants in New York State. Available online: https://www.dec.ny.gov/docs/water_pdf/descdata2004.pdf (accessed on 23 June 2019).
- Oglesby, R.T. Limnological guidance for Finger Lakes management; Technical Report 89; Cornell University Water Resources and Marine Sciences Center: Ithaca, NY, USA, September 1974. [Google Scholar]
- Frankson, R.; Kunkel, K.; Champion, S.; Stewart, B.; Sweet, W.; DeGaetano, A.T. New York State Climate Summary; NOAA Technical Report NESDIS 149-NY; National Centers for Environmental Information: Asheville, NC, USA, 2017; p. 4. Available online: https://statesummaries.ncics.org/ny (accessed on 23 June 2019).
- Huang, H.; Winter, J.M.; Osterberg, E.C.; Horton, R.M.; Beckage, B. Total and extreme precipitation changes over the northeastern United States. J. Hydrometeorol. 2017, 18, 1783–1798. [Google Scholar] [CrossRef]
- Frei, A.; Kunkel, K.E.; Matonse, A. The seasonal nature of extreme hydrological events in the northeastern United States. J. Hydrometeorol. 2015, 16, 2065–2085. [Google Scholar] [CrossRef]
- Likens, G.E. The Runoff of Water and Nutrients from Watersheds Tributary to Cayuga Lake, New York; Technical Report No. 81; Cornell University Water Resources and Marine Sciences Center: Ithaca, NY, USA, 1974. [Google Scholar]
- Cornell University Facilities and Campus Services. Final Environmental Impact Statement, Lake Source Cooling, Cornell University. 1998. Available online: https://energyandsustainability.fs.cornell.edu/util/cooling/production/lsc/eis/default.cfm (accessed on 23 June 2019).
- New York State Department of Environmental Conservation. Harmful Algal Bloom Action Plan Cayuga Lake. Available online: https://www.dec.ny.gov/docs/water_pdf/cayugahabplan.pdf (accessed on 23 June 2019).
- Watson, S.B.; McCauley, E.; Downing, J.A. Patterns in phytoplankton taxonomic composition across temperate lakes of differing nutrient status. Limnol. Oceanogr. 1997, 42, 487–495. [Google Scholar] [CrossRef][Green Version]
- The Water Bulletin, Community Science Institute Newsletter, Fall 2018 ed.; Harmful Algal Blooms (HABs) on Cayuga Lake; Community Science Institute: Ithaca, NY, USA, 2018; Available online: http://www.communityscience.org/wp-content/uploads/2014/07/2018WaterBulletinHarmfulAlgalBloomsEditionRevised2.pdf (accessed on 23 June 2019).
- Stanton, B.F.; Conneman, G.J.; Crispell, C.A.; Hoskins, S.B.; Smith, S.F. 100 Years of Dairy Farming, Town of Dryden, Tompkins County, New York; Department of Applied Economics and Management, Cornell University: Ithaca, NY, USA, 2008; Available online: https://ecommons.cornell.edu/handle/1813/65072 (accessed on 9 September 2019).
- United States Census Bureau. Census Statistics. Available online: www.factfinder.census.gov (accessed on 23 June 2019).
- Census of Agriculture. County Profile, Tompkins County, New York. 2017. Available online: https://www.nass.usda.gov/Publications/AgCensus/2017/Online_Resources/County_Profiles/New_York/cp36109.pdf (accessed on 9 September 2019).
- Census of Agriculture, County Profile, Cayuga County, New York. 2017. Available online: https://www.nass.usda.gov/Publications/AgCensus/2017/Online_Resources/County_Profiles/New_York/cp36011.pdf (accessed on 9 September 2019).
- New York State Agriculture and Markets. New York State Dairy Statistics. Annual Summary. 2017. Available online: https://www.agriculture.ny.gov/DI/NYSAnnStat2017.pdf (accessed on 9 September 2019).
- American Public Health Association, American Water Works Association, Water Environment Federation. Standard Methods for the Examination of Water and Wastewater, 22nd ed.; Rice, E.W., Baird, R.B., Eaton, A.D., Clesceri, L.S., Eds.; American Water Works Association: Denver, CO, USA, 2012. [Google Scholar]
- Community Science Institute, Ithaca, NY. Available online: http://www.database.communityscience.org/ (accessed on 23 June 2019).
- Effler, S.W.; Prestigiacomo, A.R.; Matthews, D.A.; Gelda, R.K.; Peng, F.; Cowen, E.A.; Schweitzer, S.A. Tripton, trophic state metrics, and near-shore versus pelagic zone responses to external loads in Cayuga Lake, New York, U.S.A. Fundam. Appl. Limnol. 2010, 178, 1–15. [Google Scholar] [CrossRef]
- United States Environmental Protection Agency. Method 365.3: Phosphorous All Forms (Colorimetric, Ascorbic Acid, Two Reagent). Available online: https://www.epa.gov/sites/production/files/2015-08/documents/method_365-3_1978.pdf (accessed on 23 June 2019).
- Porter, K.; Lauer, D.; Messinger, J.; Bouldin, D. Flows of nitrogen and phosphorus on land. In Nitrogen and Phosphorus. Food Production, Waste and the Environment; Porter, K., Ed.; Ann Arbor Science: Ann Arbor, MI, USA, 1975; pp. 123–168. [Google Scholar]
- Withers, P.J.A.; Jarvie, H.P.; Stoate, C. Quantifying the impact of septic tank systems on eutrophication risk in rural headwaters. Environ. Int. 2011, 37, 644–653. [Google Scholar] [CrossRef] [PubMed]
- Asquith, W.H.; Roussel, M.C.; Vrabel, J. Statewide Analysis of the Drainage-Area Ratio Method for 34 Streamflow Percentile Ranges in Texas: U.S. Geological Survey Scientific Investigations Report 2006–5286. 2006. Available online: https://pubs.usgs.gov/sir/2006/5286/pdf/sir2006-5286.pdf (accessed on 17 July 2019).
|Fall Creek Watershed|
|Land Use [19,22]|
|Point Sources [22,27]||One wastewater treatment plant||One upgraded and one additional wastewater treatment plant|
|Sewered Population [22,27]||1400||3250|
|Improved Agricultural Practices/Regulation ||Rare||More widespread|
|Town of Dryden (243 km2) 1|
|Percent of town in dairy farms||17||8|
|Average size of dairy farms (ha)||121||234|
|Number of dairy cows||1775||1540|
|Milk sold (mill kg)||10||16|
|Corn silage per acre (metric tons)||12||20|
|Fall Creek||Northeastern Tributaries|
|Watershed Area (ha)||33,086||Paines and Dean’s1: 5847|
Lake Ridge, Mill, and Townline: 3409
|Land Use || Paines and Dean’s 1:|
|Point Sources ||Two wastewater treatment plants serving 3250 people||One wastewater treatment plant serving 900 people|
|Septic System Density ||Lower||Higher|
|Tompkins County2||Cayuga County3|
|Land area (km2)||1270||2240|
|Population per square km 4||80||36|
|Land in farms (% of county)||29||41|
|Average farm size (ha)||71||108|
|Dairy cows per square km 5||7||16|
|Agricultural practices (% farms)|
|Time Period||Year||Number of Samples||Number of Sampling Days|
|Waterbody||Year||Number of Samples||Number of Sampling Days|
|Mean SRP Concentration (µg/L) ± Standard Error (Sample Size)|
|Fall Creek||Northeastern Tributaries|
|High Flow Samples||32.8 ± 3.1 (16)||183.1 ± 27.5 (29)|
|Low Flow Samples||13.7 ± 1.0 (79)||106.6 ± 12.0 (208)|
|All Samples||16.9 ± 1.2 (95)||116.0 ± 11.2 (237)|
