A Straightforward Methodology for the Quantification of Long Chain Branches in Polyethylene by 13C NMR Spectroscopy
Abstract
:1. Introduction
2. Materials and Methods
3. Results and Discussion
3.1. Detection of LCB in the Absence of Overlapping SCB
3.2. Detection of LCB in the Presence of Overlapping SCB
3.3. Analysis of a Representative Industrial Sample
4. Conclusions
- If only one Cβ signal at 27.05 ppm is present, the polymer contains only LCB
- If two Cβ signals at 27.05 and 27.01 ppm are present and exhibit a 2:1 integral ratio, the polymer contains only hexyl-type SCB
- If two Cβ signals at 27.05 and 27.01 ppm are present and exhibit an integral ratio higher than 2:1, the polymer contains both hexyl-type SCB and LCB, and the contribution of the latter can be estimated using Equation (1) (or Equation (2)).
