A Novel Digital Control Method of a Single-Phase Grid-Connected Inverter Based on a Virtual Closed-Loop Circuit and Complex Vector Representation
Abstract
:1. Introduction
2. Virtual Closed-Loop Construction
3. Discrete Model of the Inverter Considering the Influence of Delay Based on Complex Vectors
4. Complex Vector-Based Controller
4.1. Discrete Model of the Complex Vector-Based Inverter
4.2. Controller Design
5. Experimental Results
6. Conclusions
Acknowledgments
Author Contributions
Conflicts of Interest
Abbreviations
