The research demonstrates, through simulation and laboratory validation, the development of a low-voltage DC-link (LVDC) back-to-back converter system that enables multi-frequency power transfer. The system operates in two distinct modes, which include a three-phase grid-connected converter transferring fundamental and 5th and 7th harmonic power to a three-phase residential inverter supplying a clean 50 Hz load and another mode that uses a DC–DC buck–boost converter to integrate a battery storage unit for single-phase load supply. The system allows independent control of each harmonic component and maintains a clean sinusoidal voltage at the load side through DC-link isolation. The LVDC link functions as a frequency-selective barrier to suppress non-standard harmonic signals on the load side, effectively isolating the multi-frequency power grid from standard-frequency household loads. The proposed solution fills the gap between the multi-frequency power systems and the single-frequency loads because it allows the transfer of total multi-frequency grid power to the traditional household loads with pure fundamental frequency. Experimental results and simulation outcomes demonstrate that the system achieves high efficiency, robust harmonic isolation, and dynamic adaptability when load conditions change. Full article

Distributed photovoltaic storage charging piles in remote rural areas can solve the problem of charging difficulties for new energy vehicles in the countryside, but these storage charging piles contain a large number of power electronic devices, and there is a risk of resonance in the system under weak grid conditions. Firstly, the topology of a photovoltaic storage charging pile is introduced, including a bidirectional DC/DC converter, unidirectional DC/DC converter, and single-phase grid-connected inverter. Then, the maximum power tracking control strategy based on improved conductance micro-increment is derived for a photovoltaic power generation system, and a constant voltage and constant current charge–discharge control strategy is derived for energy storage equipment. Additionally, a segmented reflective charging control strategy is introduced for charging piles, and the quasi-PR controller is introduced for single-phase grid-connected inverters. In addition, an improved second-order general integrator phase-locked loop (SOGI-PLL) based on feed-forward of the grid current is derived. Finally, a simulation model is built to verify the performance of the solar–storage charging pile and lay the technical groundwork for future integrated control strategies. Full article

This paper analyzes the electromagnetic characteristics of an interior permanent magnet synchronous motor (IPMSM) for electric vehicle traction under various control imbalance conditions in a twin inverter system, assuming that one of the inverters fails to operate properly. The imbalance conditions are first investigated through dynamometer experiments and then applied to finite element method (FEM) simulations to evaluate their electromagnetic effects. Since the focus is on scenarios where a single inverter malfunctions, a stator winding configuration is first redefined to ensure stable operation in a single inverter system by preventing voltage and current imbalances within the circuit. When the stator winding is configured with eight parallel paths, the dynamometer test results show a phase voltage imbalance. However, when the number of parallel circuits is reduced to four, this voltage imbalance disappears. Using this configuration, a twin inverter system is constructed, and various imbalance conditions are applied to intuitively examine the electromagnetic characteristics when one inverter fails to accurately control current magnitude or phase angle. The simulation results showed that applying unbalanced conditions to the current and current phase angle led to a decrease in torque and an increase in torque ripple. In addition, when one of the inverters was completely disconnected, the motor performance analysis showed that it operated with approximately half of its original performance. Based on dynamometer experiments and finite element method (FEM) simulations, the electromagnetic characteristics under inverter fault conditions and appropriate stator winding configurations were analyzed. When an optimal number of parallel circuits is applied to the stator winding and a twin inverter system is employed, the load on each individual inverter is reduced, enabling accurate control. This makes the application to high-voltage and high-current systems feasible, allowing higher performance. Moreover, even if one inverter fails, the system can still operate at approximately half its capacity, ensuring high operational reliability. Full article

T-type three-level inverters have been extensively utilized in renewable energy generation, motor drive systems, and other power conversion applications. However, failures in semiconductor devices critically reduce the operational reliability of power conversion systems. While significant progress has been made in the diagnosis of single-switch open-circuit (OC) faults, the precise location and detection of simultaneous double-switch OC faults remain challenging. Therefore, this paper proposes a fault diagnosis method, integrating an improved adaptive sliding mode observer (IASMO) and dynamic current threshold detection. First, the IASMO is constructed through the hybrid logic dynamic model, achieving accurate and rapid estimation of phase currents. Then, integrating estimated with actual currents accomplishes the design of detection variables and adaptive thresholds. Subsequently, fault location variables are formulated to achieve accurate localization of both single-switch and double-switch faults. Finally, Simulation and experimental results demonstrate that the proposed method effectively identifies 18 types of OC faults within 75% of the current cycle, with high efficiency and robustness. Full article

In areas such as remote, rural, and mountainous regions, supplying low-voltage three-phase power has traditionally required distribution line extension and transformer installation. However, these areas often yield low electricity revenues, making cost recovery difficult for utilities. To address this challenge, this paper proposes a Single-to-Three-Phase Converter (STPC) capable of converting single-phase low-voltage input into three-phase output for use in low-voltage distribution systems. The STPC topology employs a single-phase half-bridge AC–DC stage and a three-phase full-bridge inverter stage using SiC-MOSFETs. To validate the system, simulations and experiments were conducted under various load conditions, including unbalanced, nonlinear, and motor loads. The results show that STPC maintains output stability while minimizing impact on the existing grid. The findings demonstrate STPC’s feasibility as an alternative to conventional line extension and transformer installation, with potential for application in grid-forming and low-voltage distribution current (LVDC) systems. Full article

With the rapid development of the industrial sector, the single-inverter power device is increasingly unable to meet the industry’s high-power needs due to the power limitations of semiconductor devices; as a result, parallel connection of multiple devices has become the main means of expanding the capacity of power conversion systems. To address the issues of circulating current and power imbalance caused by discrepancies in the output voltage amplitude and phase among power conversion system (PCS) modules, this paper proposes a master–slave mode-based collaborative control method for energy storage inverters operating in parallel—the method consists of two main components: phase synchronization control and equal amplitude control. The master sends the synchronization signal and voltage amplitude to the slave inverters via the CAN bus, and each slave then adjusts its phase based on the synchronization signal and calculates the modulation ratio of the wave according to their own power supply conditions. This ensures that the output voltage amplitude, phase, and frequency of all slave inverters are fully aligned. Experimental results validate the effectiveness of the proposed parallel coordinated control method, ensuring the stable operation of the parallel system. Full article

In recent years, the study of model predictive control (MPC) in power electronics has gained significant attention due to its ability to optimize system performance and improve the dynamic control of complex power converters. There are two types of MPC: finite control set (FCS) and continuous control set (CCS). The FCS–MPC has been studied more in regard to these two types of control due to its easy and intuitive implementation. However, FCS–MPC has some drawbacks, such as the exponential growth of the computational burden as the prediction horizon increases and, in some cases, a variable frequency. In contrast, generalized predictive control (GPC), part of CCS–MPC, offers significant advantages. It enables the use of a longer prediction horizon without increasing the computational burden in regard to its implementation, which has practical implications for the efficiency and performance of power converters. This paper presents the design of GPC applied to single-phase multilevel voltage source inverters, highlighting its advantages over FCS–MPC. The controller is optimized offline, significantly reducing the computational cost of implementation. Moreover, the controller is tested in regard to R, RL, and nonlinear loads. Finally, the validation results using a medium-performance controller and a Hardware-in-the-Loop device highlight the improved behavior of the proposed GPC, maintaining a harmonic distortion of less than 1.2% for R and RL loads. Full article

This paper presents an enhanced bipolar control strategy for 400 Hz three-phase inverters in aviation ground power supplies, with a focus on maintaining symmetry in power output under unbalanced load conditions. The strategy integrates Linear Active Disturbance Rejection Control (LADRC) for robust positive sequence voltage regulation, Proportional Integral with repetitive control (PI + RC) for harmonic suppression in positive sequence currents, and a Quasi-Proportional Resonance (QPR) controller for negative sequence components in the static coordinate system. By doing so, it simplifies negative sequence control and combines PI + RC to improve the dynamic response and eliminate periodic errors. In the context of symmetry, the proposed strategy effectively reduces the total harmonic distortion (THD) and the three-phase current imbalance degree. Simulation results show significant improvements: under balanced loads, THD is reduced by 41.5% (from 1.95% to 1.14%) compared to traditional PI control; under single-phase and three-phase unbalanced loads, THD decreases by 52.7% (2.56% to 1.21%) and 48.1% (2.39% to 1.24%), respectively. The system’s settling time during load transients is shortened by over 30%, and the three-phase current imbalance degree is reduced by 60–70%, which validates the strategy’s effectiveness in enhancing power quality and system stability, thus restoring and maintaining the symmetry of the power output. Full article

We present a single-capture multimodal bright-field (BF) and quantitative phase imaging (QPI) approach that enables the analysis of large, connected, or extended samples, such as confluent cell layers or tissue sections. The proposed imaging concept integrates a fiber-optic Mach–Zehnder interferometer-based off-axis digital holographic microscopy (DHM) with an inverted commercial optical BF microscope. Utilizing 8-bit grayscale dynamic range multiplexing, we simultaneously capture both BF images and digital holograms, which are then demultiplexed numerically via Fourier filtering, phase aberration compensation, and weighted image subtraction procedures. Compared to previous BF-DHM systems, our system avoids synchronization challenges caused by multiple image recording devices, improves acquisition speed, and enhances versatility for fast imaging of large, connected, and rapidly moving samples. Initially, we perform a systematic characterization of the system’s multimodal imaging performance by optimizing numerical as well as coherent and incoherent illumination parameters. Subsequently, the application capabilities are evaluated by multimodal imaging of living cells. The results highlight the potential of single-capture BF-DHM for fast biomedical imaging. Full article

Envelope modeling is an efficient way to obtain the large-signal amplitude and phase dynamics of fast-varying sinusoidal signals required for, e.g., resonant frequency tracking or energy transfer rate regulation in power converters. In addition, the method eliminates fast-varying parameters from the model so that the simulation time and memory requirements are reduced. This paper reveals the envelope-modeling process of a capacitor-powered resonant inverter feeding a time-varying series RLC load, often employed in pulsed-power applications. Such an arrangement is nontrivial since the system does not reach a steady state within a single pulse duration. Furthermore, model order reduction is carried out without performing linearization due to large variations in the expected operation point. As a result, a reduced-order nonlinear envelope model is derived and validated by simulations. Both the proposed modeling method and the derived model aim to simplify the challenging task of feedback controller design. Full article

The surface magnetic field of three-core cables is essential for estimating phase currents and locating the single-phase grounding faults. However, the double-layer steel tape-wrapped structure will shield the magnetic field, affecting the measurement of the surface magnetic field of the three-core cable. Disregarding the shielding effect of the steel tape during the measurement of the surface magnetic field of the cable leads to an erroneous phase current obtained from the inversion of the observed magnetic field. To measure the surface magnetic field and invert it to obtain three-phase currents accurately, a model to evaluate the shielding effect of the steel tape is proposed, and a differential evolutionary algorithm method is proposed to invert it to obtain the three-phase currents. The results indicate that the difference between the analytical and numerical solutions is below 5%. As the thickness of steel tape increases, the shielding coefficient also increases. The differential evolution algorithm can accurately estimate the three-phase currents. The differential evolutionary algorithm measured the current amplitude of phases A, B, and C to 354.62 A, 354.33 A, and 323.46 A, respectively. Additionally, the algorithm measured the current phase magnitudes to be −8.21°, −128.01°, and 111.87°. The maximum value of the amplitude error of the three-phase current is 4.83%, and the maximum value of the phase error is 8.01°. Full article

The deployment of photovoltaic single-phase inverters has been rapidly increasing worldwide. However, the performance of these systems is highly influenced by atmospheric conditions and load variations, necessitating the development of performance indices to enhance their efficiency and energy quality. In this study, four performance indices are proposed to evaluate the efficiency and energy quality of photovoltaic systems quantitatively. The entire process is analyzed, encompassing solar energy capture, DC-DC and DC-AC conversion, and filtering, to deliver maximum energy and quality to the load. Furthermore, eight system parameters are optimized using advanced techniques such as genetic algorithms, particle swarm optimization, and gray wolf optimization. These optimizations enhance the global performance of two critical stages: (1) the maximum power point tracking algorithm based on sliding mode control, which minimizes switching losses in the boost stage, and (2) the effective transfer of captured solar power to the load by optimizing the gains of a PI controller. The PI controller computes the switching triggers for the inverter stage, significantly improving the total harmonic distortion of voltage and current waveforms. Simulation results validate the proposed approach, demonstrating a marked improvement in overall system efficiency (95.8%) when compared to the incremental conductance method (−11.8%) and a baseline sliding mode control configuration (−1.14%). Full article

Fault diagnosis in power converters is essential for keeping electrical systems stable, efficient and long-lasting. Park’s Vector Transform, discrete wavelet transform, Artificial Neural Network, Fuzzy Logic and other methods are used to diagnose faults in the power converter in both single and multiple open switch situations. These methods are implemented on the digital signal processor or controller, which needs additional hardware and consumes more processing time. This paper presents a hardware-based open switch fault diagnostic method in a 3ϕ voltage source inverter to minimize fault diagnosis time and cost. An innovative hardware-based approach that utilizes a single neuron for open switch fault diagnosis in 3ϕ voltage source inverters was successfully implemented without using a digital signal processor or controller. A gradient descent algorithm calculates the weight and bias values of a single processing neuron. Furthermore, a high-speed multiplier and adder circuit seamlessly integrate with the single processing neuron, enabling rapid real-time fault diagnosis. This method is capable of diagnosing single and multiple switch open circuit faults in switching devices under variable load conditions at different frequencies. The proposed system ensures good effectiveness and resistivity, detecting faults in less than one cycle with low implementation effort and no tuning or threshold dependence. It achieves 98% accuracy, 96% precision and 95% recall, with a 2% false positive rate. Unlike traditional methods, it eliminates DSP/controller dependency by using a single neuron-based processing circuit, reducing cost and improving real-time fault diagnosis in three-phase voltage source inverters. Full article

Compared with the line-frequency transformer (LFT), the emerging power electronic transformers (PETs) have gained wide concerns due to the significant merits of higher power density, higher reliability, more flexibility, and multiple functions. However, the need for bulky energy storage elements, multi-stage power conversion and reduced conversion efficiency, and the intrinsic twice-frequency pulsating power issue are the main disadvantages of the conventional single-phase PETs. To overcome the above shortcomings of conventional single-phase PETs, this paper develops a matrix-type single-phase AC-AC PET without bulky energy storage elements. The proposed PET consists of a line-frequency commutated rectifier, a half-bridge LLC resonant converter with a fixed switching frequency, a boost converter, and a line-frequency commutated inverter. The LLC operates efficiently with unity voltage gain and acts as a high-frequency isolated DC transformer (DCX). The boost converter provides AC output voltage regulation function and the line-frequency commutated inverter unfolds the output voltage of the boost converter to generate the sinusoidal AC output voltage. As a result, high power density, reduced power conversion stages, direct AC-AC power conversion without twice-frequency pulsating power, high conversion efficiency, and high reliability are achieved. The experimental results on a 1kW PET prototype show that sinusoidal input current and output voltage, ZVS of the LLC stage, and output voltage regulation capability are realized. The experimental results verify the correctness and feasibility of the presented methods. Full article

This study aims to minimize component requirements by presenting a novel topology for a single-phase 15-level asymmetrical multilevel inverter. Utilizing an H-bridge configuration, the proposed design achieves a maximum 15-level output voltage using asymmetrical DC sources. The initial 15-level inverter structure is further enhanced to support a 25-level variant suitable for renewable energy applications, effectively reducing system costs and size. However, the increased component count in multilevel inverters poses reliability challenges, particularly concerning total harmonic distortion reduction, which remains a focal point for researchers. Various parameters, including total standing voltage, multilevel inverter cost function, and power loss, are analyzed for both the proposed 15-level and the expanded 25-level multilevel inverters. This study contributes a new topology for a single-phase 15-level asymmetrical multilevel inverter, optimizing component usage and paving the way for renewable energy integration. Despite the advantages of multilevel inverters, addressing reliability concerns related to total harmonic distortion reduction remains crucial for future advancements in this domain. Full article
