Exploring GNSS Crowdsourcing Feasibility: Combinations of Measurements for Modeling Smartphone and Higher End GNSS Receiver Performance

1
Finnish Geospatial Research Institute FGI, National Land Survey, PO Box 52, 00520 Helsinki, Finland
2
ITC faculty, EOS Department, University of Twente, PO Box 217, 7500 AE Enschede, The Netherlands
3
Airbus Defense and Space, 31400 Toulouse, France
*
Author to whom correspondence should be addressed.
Sensors 2019, 19(13), 3018; https://doi.org/10.3390/s19133018
Received: 24 May 2019 / Revised: 27 June 2019 / Accepted: 3 July 2019 / Published: 9 July 2019
(This article belongs to the Section Remote Sensors, Control, and Telemetry)
  |
PDF [3993 KB, uploaded 9 July 2019]
  |

Abstract

GNSS receiver data crowdsourcing is of interest for multiple applications, e.g., weather monitoring. The bottleneck in this technology is the quality of the GNSS receivers. Therefore, we lay out in an introductory manner the steps to estimate the performance of an arbitrary GNSS receiver via the measurement errors related to its instrumentation. Specifically, we do not need to know the position of the receiver antenna, which allows also for the assessment of smartphone GNSS receivers having integrated antennas. Moreover, the method is independent of atmospheric errors so that no ionospheric or tropospheric correction services provided by base stations are needed. Error models for performance evaluation can be calculated from receiver RINEX (receiver independent exchange format)data using only ephemeris corrections. For the results, we present the quality of different receiver grades through parametrized error models that are likely to be helpful in stochastic modeling, e.g., for Kalman filters, and in assessing GNSS receiver qualities for crowdsourcing applications. Currently, the typical positioning precision for the latest smartphone receivers is around the decimeter level, while for a professional-grade receiver, it is within a few millimeters. View Full-Text
Keywords: GNSS; smartphone; receiver error; combination of measurement; crowdsourcing; feasibility GNSS; smartphone; receiver error; combination of measurement; crowdsourcing; feasibility
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Lehtola, V.V.; Söderholm, S.; Koivisto, M.; Montloin, L. Exploring GNSS Crowdsourcing Feasibility: Combinations of Measurements for Modeling Smartphone and Higher End GNSS Receiver Performance. Sensors 2019, 19, 3018.
