Application of a Novel Measurement Setup for Characterization of Graphene Microelectrodes and a Comparative Study of Variables Influencing Charge Injection Limits of Implantable Microelectrodes

1
ITAP—Universidad de Valladolid, Paseo del Cauce 59, 47011 Valladolid, Spain
2
Department of Biomedical Microsystems, Fraunhofer-Institut für Biomedizinische Technik (IBMT), 66280 Sulzbach/Saar, Germany
3
Escuela de Ingenierías Industriales, Universidad de Málaga, Doctor Ortiz Ramos s/n, 29071 Málaga, Spain
*
Author to whom correspondence should be addressed.
Sensors 2019, 19(12), 2725; https://doi.org/10.3390/s19122725
Received: 21 May 2019 / Revised: 12 June 2019 / Accepted: 13 June 2019 / Published: 17 June 2019
(This article belongs to the Section Physical Sensors)
  |
PDF [2890 KB, uploaded 17 June 2019]
  |

Abstract

Depending on their use, electrodes must have a certain size and design so as not to compromise their electrical characteristics. It is fundamental to be aware of all dependences on external factors that vary the electrochemical characteristics of the electrodes. When using implantable electrodes, the maximum charge injection capacity (CIC) is the total amount of charge that can be injected into the tissue in a reversible way. It is fundamental to know the relations between the characteristics of the microelectrode itself and its maximum CIC in order to develop microelectrodes that will be used in biomedical applications. CIC is a very complex measure that depends on many factors: material, size (geometric and effectiveness area), and shape of the implantable microelectrode and long-term behavior, composition, and temperature of the electrolyte. In this paper, our previously proposed measurement setup and automated calculation method are used to characterize a graphene microelectrode and to measure the behavior of a set of microelectrodes that have been developed in the Fraunhofer Institute for Biomedical Engineering (IBMT) labs. We provide an electrochemical evaluation of CIC for these microelectrodes by examining the role of the following variables: pulse width of the stimulation signal, electrode geometry and size, roughness factor, solution, and long-term behavior. We hope the results presented in this paper will be useful for future studies and for the manufacture of advanced implantable microelectrodes. View Full-Text
Keywords: graphene microelectrode analysis; high frequency stimulation; cyclic voltammetry; voltage transient measurements; charge injection capacity graphene microelectrode analysis; high frequency stimulation; cyclic voltammetry; voltage transient measurements; charge injection capacity
