Search Results (21)

In the current energy landscape, efficiency is a critical topic. Therefore, even in the case of geared transmissions, it is essential to predict and calculate power losses as accurately as possible from the design phase. There are mainly three categories of losses in a gear unit: friction—the power losses due to the contact between teeth in rotation on the one hand and the seals with the spindles on the other hand; churning—the power losses generated by the air–lubricant mixture compression around teeth roots during rotation; and windage—the power losses due to the teeth aerodynamic trail in the air–lubricant mixture. While the first two categories of losses are intensively studied in the literature, the papers focusing on windage power losses are less representative. An estimation of windage power losses can be performed by numerical simulation, and the accuracy of the results depends on the mesh density and the available computing power. The present study discusses the influence of meshing on the windage torque of an orthogonal face gear immersed in air and compares numerical results generated by SolidWorks 2025 Flow Simulation software with experimental data measured on a test rig. Full article

This paper introduces an experimental approach to study the distribution of power losses in an oil jet-lubricated planetary gear set, with the aim of increasing the efficiency of these gearboxes. A thermal model is developed to estimate power losses associated with temperature distribution. This model is applied to analyze experimental data collected from a dedicated test setup. Different configurations are studied to progressively validate the thermal network. In this paper, only a configuration composed of a rotating ring gear and a fixed planet carrier is studied. This configuration enables the validation of a thermal network developed from a basic configuration where power loss sources are not numerous. The study reveals that, for this configuration, load-independent power losses are primarily attributed to hydrodynamic losses in the bearings, while the gear windage effects are of second order. The power losses are then compared to those generated by the same planetary gear set but using a rotating planet carrier. The comparison shows that the configuration composed of the rotating ring gear and fixed planet carrier produces less power loss than the other configuration. Full article

To suppress the adverse effect of the gear windage phenomenon in the high-speed aeronautic industry, a shroud as an effective alternative strategy is usually to enclose gears to reduce the windage behaviors of high-speed gears. To deeply understand these no-load power losses, this paper proposes a new simulation methodology based on the Lattice Boltzmann method to study the windage losses of a shrouded spur gear and conducts a series of numerical studies. The models reproduce a shroud spur gear varying radial and axial clearances to evaluate the influence of casing walls on windage losses. The simulation results were then compared with experimental values, showing a satisfactory agreement. Furthermore, a torque containment factor integrating the air compressibility at high Mach numbers is introduced to represent the reduction in torque (windage power losses) for the shrouded gear compared to the free case, and the theoretical formulae for predicting windage power losses are further improved for better applicability as the tight shroud approaches the gear during the preliminary design stage. Full article

This paper presents comparable sets of the no-load power loss as a product of windage and churning behaviors of a family of various rotating parts (i.e., disc, spur gear, straight bevel gear, and orthogonal face gear). Experimental measurements were carried out under pure air only and under partial immersion in oil to qualify and quantify the windage and churning effects of no-load power losses of a family of spur, bevel, and face gears along with a representative disc as the baseline. Aiming at exploring the influence of gear teeth on the total no-load power losses, two different theoretical analytical approaches are introduced to account for the churning contributions, by which the total power losses are estimated. Both analytical approaches compare well with the experimental findings. Furthermore, a spatial intersecting cross-axis gear (e.g., straight bevel gear and orthogonal face gear) results in higher no-load power losses than that of a representative disc or a parallel-axes gear. The significance of gear teeth (gear vs. disc) on windage behavior is presented, as well as the gear windage effects on the churning phenomenon in a high-speed splash-lubricated gear. Full article

Under the conditions of high speed and density flow, the windage loss in the gap behind an impeller has an important influence on its thermal power conversion efficiency. Daily and Nece took the relative gap and Reynolds number as the characteristic parameters and divided the flow of a rotating disk in a closed chamber into four flow regions through laminar flow, turbulent flow and state of boundary layers. In this paper, the skin-friction coefficient model of Regio III and IV was verified by a numerical method under conditions corresponding to the typical Reynolds number range for a radial impeller. The results show that when the relative gap increases, the relative deviation between the numerical calculation and the model prediction results decreases, and the maximum deviation is −12.4%. With the increase of Reynolds number, the Region IV model is more accurate. Region III has the flow state of boundary layers merging and separation at the same time. Both models have good prediction accuracy with different mediums of air, water-liquid and critical CO₂. The deviation in Region III is larger and shows a decreasing trend with respect to Region IV, Based on the two models, a method for predicting the optimal gap is proposed. The method is verified to be reliable and can minimize windage loss. Full article

A supercritical CO₂ (S-CO₂) Brayton cycle is a compact and simple power conversion system with competitive efficiency. However, the strong real gas effects of S-CO₂ pose challenges to the design of a cycle and its components. In particular, designing turbomachinery for expansion and compression processes has to accurately reflect real gas effects. Windage loss is one of the major losses that affects the motor load and heat generation in turbomachinery. The windage loss has a substantial impact on the overall turbomachinery efficiency especially in an S-CO₂ power cycle since the windage loss is reported to be the dominant loss mechanism due to high fluid density and high rotational speed. Therefore, an accurate windage loss model reflecting the real gas effect of S-CO₂ is essential to obtaining an optimal design of turbomachinery as well as maximizing the performance of an S-CO₂ power cycle. In this study, existing windage loss models are first compared to the recently obtained data from S-CO₂ windage loss experiments conducted by the KAIST research team under S-CO₂ conditions in order to understand the turbomachinery performance uncertainty caused by the windage loss models. This is followed by proposing a new windage model which explains data better. Full article

In recent decades, the request for more efficient performances in the aeronautical sector moved researchers to pay particular attention to all the related mechanisms and systems, especially with respect to the saving of power. In this context, the bearing modeling and design, as well as gear coupling, play a fundamental role. Moreover, the need for low power losses also concerns the study and the implementation of advanced lubrication systems, especially for high peripheral speed. With the previous aims, this paper presents a new validated model for toothed gears, added to a bearing model; with the link of these different submodels, the whole model describes the system’s dynamic behavior, taking into account the different kinds of power losses (windage losses, fluid dynamic losses, etc.) generated by the mechanical system parts (especially rolling bearings and gears). As the bearing model, the proposed model is characterized by high numerical efficiency and allows the investigation of different rolling bearings and gears with different lubrication conditions and frictions. A comparison between the experimental and simulated results is also presented in this paper. The analysis of the results is encouraging and shows a good agreement between experiments and model simulations, with particular attention to the power losses in the bearing and gears. Full article

Windage power loss plays a leading role in the total power loss of high-speed gears, which seriously affects the transmission efficiency of gear systems and leads to high energy consumption. This paper proposes a negative pressure regulation method to reduce windage power loss. Based on the computational fluid dynamics theory, the flow field distribution and windage power loss in the gearbox under different negative pressure conditions are studied, and the effect of the negative pressure environment and speed on the windage power loss is obtained. In order to further save calculation costs, an optimization algorithm of the BP neural network based on a genetic algorithm is proposed to effectively predict the windage power loss. The results show that the high-speed airflow near the tooth’s surface will produce a large pressure moment, which is the main cause of wind resistance loss. The windage power loss increases with the increase in the negative pressure or speed of the gearbox, but the effect of speed is more obvious. The prediction results of the optimization algorithm are in good agreement with the finite element simulation data and the open literature, which can predict the best parameters for reducing windage power loss. Full article

To investigate the effects of surface roughness on windage loss and flow characteristics in a shaft-type gap, the skin friction coefficient (C_f) and flow versus Reynolds number (Re) at different surface roughness (Ra) and radius ratio (η) values were investigated. The results showed that C_f decreased as Re increased, and the rate of decrease was constant at low Re but reduced at high Re. The growing relative deviations between the coefficients of smooth and rough walls with Ra indicated that C_f was influenced by rough walls when Re > 10². Moreover, C_f and the variation rate increased with η and were easily influenced by Ra for larger η at low Re, since the interaction between wall roughness and fluid influences windage loss. In addition, the flow field implied the flow had transitioned to Taylor-Couette flow, Taylor vortexes occurred when Re > 10², and the number of vortexes increased with increasing Ra and were reduced with increasing η. The velocity was divided into three regions and the pressure rose from the rotational to stationary walls, but decreased with growing η as a whole. This paper improves the research exploring windage loss and will help design smaller supercritical CO₂ power devices. Full article

On the basis of previous experimental and numerical studies, the windage operation of low-pressure turbine rear stage is investigated. The state of the steam within the rotor channel was correlated to measurements carried out downstream of the blades for different ventilation regimes. Considering very-low-volume flow conditions, the ventilation power was related to the drag force acting on the moving blades. A correlation was identified between the drag coefficient and a Reynolds number relative to the reverse flow height. This correlation can be used in order to predict the power loss of a last-stage moving blade operating at low load. Full article

This research aimed to introduce a comprehensive mathematical modeling approach based on the maximization of the power coefficient (Cp) to obtain the regulation in pitch angle and tip speed ratio (TSP), taking into account the detailed power losses at the different stages of the power train of the wind turbine. The model is used to track the optimal power coefficient of the wind turbine power train, considering both direct (without gearbox) and indirect (with gearbox) drive configurations. The result of the direct driveline was validated with a 100 W horizontal-axis wind turbine experimental system. The model estimated the optimal value of Cp at 0.48 for a pitch angle of 0 degrees and a TSR of 8.1, which could be obtained at a wind speed of around 11.2 m/s. The results also revealed that, within the lower wind regime, windage, hysteresis, and eddy current losses dominated, while during higher wind regimes, the copper, stray load, and insulator gate bipolar transistor (IGBT) losses gained high values. The developed model was applied to a 20 kW indirect drive wind turbine installed in Gwadar city in Pakistan. Compared with the direct coupling, the optimal value of Cp was obtained at a higher value of the pitch angle (1.7 degrees) and a lower value of TSR (around 6) due to the significant impact of the gear and copper losses in an indirect drivetrain. Full article

Windage power loss (WPL) is significant and cannot be neglected in a study on transmission efficiency and reducing the energy consumption of high-speed gear. The influence mechanism of the baffle on the reduction of WPL needs to be further studied. Based on computational fluid dynamics (CFD) technology, this paper puts stress on analyzing the influence of axial and radial baffles on viscous and pressure effects in WPL and the influence of baffles with groove structures on reducing WPL. The numerical calculation model of windage torque considering the baffle’s regulation is established, and the calculation results of WPL with different baffle configurations are obtained. The results indicate that the radial baffle mainly reduces pressure loss, while power loss caused by the viscous effect is mainly affected by the axial baffle. The baffle with the smallest clearance achieves the most significant suppression effect on windage. On this basis, adding groove structures to a smooth baffle can have a positive or negative impact on reducing WPL, and the baffles with circular grooves can further promote the reduction of WPL by 8.2%, compared with smooth baffles. This paper provides a reference for the optimal design of baffles in engineering applications. Full article

With the increasing speed of aviation gear, windage loss has been the main component of power loss. Reducing windage is of great significance to improving the transmission efficiency of aviation spiral bevel gear. Firstly, the calculation model of enclosed spiral bevel gear was established, and the basic physical mechanism of windage power loss was illustrated by numerical simulation, so as to obtain the mechanical and energy characteristics of windage loss. Then, the influence of the geometry and clearance parameters of the shroud on the windage loss was studied by orthogonal test, variance analysis and optimization design. The mechanism of the shroud to reduce the windage loss under the multi-factors was also studied, and their interaction was obtained. The results show that the tooth surface clearance, heel clearance and meshing opening are significant factors, and the most significant factor is the heel clearance. The non-significant factor is the interaction of each factor. The least significant factor is the toe clearance. In other words, the windage power loss can be reduced to the greatest extent by simultaneously reducing the meshing opening of the shroud and the clearance value between shroud and the surface of the gear. Finally, based on the mechanism of reducing windage loss of shroud, the optimization design principle affecting the structural performance of shroud is put forward, which provides theoretical guidance for the practical application of shroud in windage reduction engineering. Full article

Based on the theory of computational fluid dynamics (CFD), with the help of the Fluent software and the powerful parallel computing capability of the super cloud computer, the single-phase flow transient simulation calculation of the windage power loss of the engagement spiral bevel gear pair (SBGP) was performed. The two-equation SST k-ω turbulence model based on the assumption of eddy viscosity was adopted, which was improved from the standard k-ε model combined with the Wilcox k-ω model. The SST k-ω turbulence model inherited the respective advantages of the Wilcox k-ω model in the near-wall region and the k-ε model in the free shear layer and could more accurately describe the resistance and separation effect of the gear tooth surface on the airflow. The simulation analyzed the airflow characteristics around SBGP and the mechanism of the windshield to reduce the windage loss of the gear. It also studied the influence of the windshield clearance and opening size on the windage power loss. Then the orthogonal experimental analysis method was adopted to perform numerical simulation analysis. The windage torque was studied under different clearance values between the windshield and the gear tooth surface, as well as the large end and the small end. The variance analysis was performed on the numerical simulation data. The results showed that when the windshield clearance value was 1 mm and the engagement opening was 30°, the windage torque was the smallest, and the effect of reducing the windage power loss was the best. According to the changes in the pressure, velocity, and turbulent kinetic energy cloud diagram of the flow field in the reducer during multi-group simulation tests, the local optimal windshield configuration was obtained, which provided a method for further research on the multi-objective optimization of the windshield and the windage loss of the gear pair under the oil–gas two-phase flow and also provided a reference for the practical engineering application of the windshield. Full article

Currently, one of the most used motor types for high-speed applications is the permanent-magnet synchronous motor. However, this type of machine has high costs and rare earth elements are needed for its production. For these reasons, permanent-magnet-free alternatives are being sought. An overview of high-speed electrical machines has shown that the switched reluctance motor is a possible alternative. This paper deals with design and optimization of this motor, which should achieve the same output power as the existing high-speed permanent-magnet synchronous motor while maintaining the same motor volume. The paper presents the initial design of the motor and the procedure for analyses performed using analytical and finite element methods. During the electromagnetic analysis, the influence of motor geometric parameters on parameters such as: maximum current, average torque, torque ripple, output power, and losses was analyzed. The analysis of windage losses was performed by analytical calculation. Based on the results, it was necessary to create a cylindrical rotor shape. The rotor modification method was chosen based on mechanical analysis. Using thermal analysis, the design was modified to meet thermal limits. The result of the work was a design that met all requirements and limits. Full article
