Search Results (28)

Search Parameters:
Keywords = wide range VCO

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
21 pages, 11260 KiB
Article
GaN HEMT Oscillators with Buffers
by Sheng-Lyang Jang, Ching-Yen Huang, Tzu Chin Yang and Chien-Tang Lu
Micromachines 2025, 16(8), 869; https://doi.org/10.3390/mi16080869 - 28 Jul 2025
Viewed by 238
Abstract
With their superior switching speed, GaN high-electron-mobility transistors (HEMTs) enable high power density, reduce energy losses, and increase power efficiency in a wide range of applications, such as power electronics, due to their high breakdown voltage. GaN-HEMT devices are subject to long-term reliability [...] Read more.
With their superior switching speed, GaN high-electron-mobility transistors (HEMTs) enable high power density, reduce energy losses, and increase power efficiency in a wide range of applications, such as power electronics, due to their high breakdown voltage. GaN-HEMT devices are subject to long-term reliability due to the self-heating effect and lattice mismatch between the SiC substrate and the GaN. Depletion-mode GaN HEMTs are utilized for radio frequency applications, and this work investigates three wide-bandgap (WBG) GaN HEMT fixed-frequency oscillators with output buffers. The first GaN-on-SiC HEMT oscillator consists of an HEMT amplifier with an LC feedback network. With the supply voltage of 0.8 V, the single-ended GaN oscillator can generate a signal at 8.85 GHz, and it also supplies output power of 2.4 dBm with a buffer supply of 3.0 V. At 1 MHz frequency offset from the carrier, the phase noise is −124.8 dBc/Hz, and the figure of merit (FOM) of the oscillator is −199.8 dBc/Hz. After the previous study, the hot-carrier stressed RF performance of the GaN oscillator is studied, and the oscillator was subject to a drain supply of 8 V for a stressing step time equal to 30 min and measured at the supply voltage of 0.8 V after the step operation for performance benchmark. Stress study indicates the power oscillator with buffer is a good structure for a reliable structure by operating the oscillator core at low supply and the buffer at high supply. The second balanced oscillator can generate a differential signal. The feedback filter consists of a left-handed transmission-line LC network by cascading three unit cells. At a 1 MHz frequency offset from the carrier of 3.818 GHz, the phase noise is −131.73 dBc/Hz, and the FOM of the 2nd oscillator is −188.4 dBc/Hz. High supply voltage operation shows phase noise degradation. The third GaN cross-coupled VCO uses 8-shaped inductors. The VCO uses a pair of drain inductors to improve the Q-factor of the LC tank, and it uses 8-shaped inductors for magnetic coupling noise suppression. At the VCO-core supply of 1.3 V and high buffer supply, the FOM at 6.397 GHz is −190.09 dBc/Hz. This work enhances the design techniques for reliable GaN HEMT oscillators and knowledge to design high-performance circuits. Full article
(This article belongs to the Special Issue Research Trends of RF Power Devices)
Show Figures

Figure 1

12 pages, 2371 KiB
Communication
A 0.8 V Low-Power Wide-Tuning-Range CMOS VCO for 802.11ac and IoT C-Band Applications
by Jung-Jen Hsu, Yao-Chian Lin and Stephen J. H. Yang
J. Low Power Electron. Appl. 2025, 15(2), 32; https://doi.org/10.3390/jlpea15020032 - 16 May 2025
Viewed by 708
Abstract
This paper presents a 0.8 V low-power CMOS voltage-controlled oscillator (VCO) with a wide tuning range, fabricated using a TSMC 0.18 μm process. The proposed design incorporates body-biasing techniques and an optimized varactor structure to achieve a tuning range of 1124 MHz (5.829–4.705 [...] Read more.
This paper presents a 0.8 V low-power CMOS voltage-controlled oscillator (VCO) with a wide tuning range, fabricated using a TSMC 0.18 μm process. The proposed design incorporates body-biasing techniques and an optimized varactor structure to achieve a tuning range of 1124 MHz (5.829–4.705 GHz) and low phase noise of −117.6 dBc/Hz at a 1 MHz offset. Operating at an ultra-low supply voltage of 0.8 V, the VCO consumes only 3.4 mW, demonstrating excellent power efficiency. A buffer circuit is also employed to enhance output symmetry and suppress flicker noise without introducing additional control complexity. With a figure-of-merit (FOM) of −188.6 dBc/Hz and a wide tuning range of 22.2%, the proposed VCO is well-suited for modern low-power communication systems, including 802.11ac, 5G transceivers, satellite links, and compact IoT devices. Full article
Show Figures

Figure 1

18 pages, 3966 KiB
Article
An Adaptive 24 GHz PSO-Based Optimized VCO in Next-Generation Wireless Sensor Networks
by Khizra Tariq, Unal Aras, Tahesin Samira Delwar, Muhammad Nadeem Ali, Yangwon Lee, Jee-Youl Ryu and Byung-Seo Kim
Appl. Sci. 2025, 15(7), 3692; https://doi.org/10.3390/app15073692 - 27 Mar 2025
Viewed by 423
Abstract
Wireless sensor networks (WSNs) for self-driving vehicles are growing rapidly, requiring high-performance radar systems with strong communication abilities. The key component of these systems is the voltage-controlled oscillator (VCO), which performs at 24 GHz with low phase noise, low power consumption, and a [...] Read more.
Wireless sensor networks (WSNs) for self-driving vehicles are growing rapidly, requiring high-performance radar systems with strong communication abilities. The key component of these systems is the voltage-controlled oscillator (VCO), which performs at 24 GHz with low phase noise, low power consumption, and a wide range of tuning. In this paper, the adaptive particle swarm optimization (PSO) algorithm incorporates adaptive scaling to speed up the optimization process. The new adaptive PSO minimizes the number of calculations required for complex engineering problems where rapid optimization is crucial and finding the best solution quickly is important. In order to test the adaptive PSO, benchmark functions are used. When applied to the proposed VCO circuit design, it facilitates more efficient adjustment of component values and improved performance, resulting in faster optimization. This optimized VCO achieves low phase noise of −120 dBc/Hz with a 1 MHz offset and a tuning range of 21.2%, operates at just 0.9 V, and consumes just 1.35 mW of power. A comparison of adaptive PSOs with traditional PSO methods shows that they improve the performance of the VCO, making them a promising choice for future automotive radar systems. Full article
(This article belongs to the Special Issue Signal Processing and Communication for Wireless Sensor Network)
Show Figures

Figure 1

16 pages, 6003 KiB
Article
A Quad-Core Dual-Mode Colpitts Voltage-Controlled Oscillator with Octave Tuning Range and Low Phase Noise
by Shihao Qi, Shang Xu, Ruxin Deng, Guoan Wu and Lamin Zhan
Electronics 2025, 14(5), 957; https://doi.org/10.3390/electronics14050957 - 27 Feb 2025
Viewed by 809
Abstract
In this paper, a novel Colpitts voltage-controlled oscillator (VCO) with low phase noise and an octave frequency tuning range is presented. To achieve low phase noise and a wide tuning range concurrently, the designed VCO employs quad-core-coupled structures, series resonators, dual-mode-coupled inductors, and [...] Read more.
In this paper, a novel Colpitts voltage-controlled oscillator (VCO) with low phase noise and an octave frequency tuning range is presented. To achieve low phase noise and a wide tuning range concurrently, the designed VCO employs quad-core-coupled structures, series resonators, dual-mode-coupled inductors, and push–push structures. The quad-core-coupled structures are used for phase noise improvement. The presented series resonators effectively expand the tuning range while reducing phase noise deterioration from amplitude-to-phase modulation (AM/PM) conversion. The dual-mode operation based on coupled inductors and quad-core structures further expands the tuning range. In addition, the adopted push–push structure increases the output frequency. Designed in a 180 nm SiGe BiCMOS process, the proposed Colpitts VCO operates from 7.2 to 14.5 GHz with an octave tuning range of 67.3%. The phase noise ranges from −131.4 to −121.8 dBc/Hz with a peak figure-of-merit (FoM) of 183.0 dBc/Hz and figure-of-merit-tuning (FoMT) of 199.5 dBc/Hz at a 1 MHz offset. The proposed VCO exhibits superior performance in phase noise and tuning range and achieves an octave tuning range for the first time in Colpitts VCOs. Full article
Show Figures

Figure 1

26 pages, 8856 KiB
Article
A 60 GHz Class-C Wide Tuning-Range Two-Core VCO Utilizing a Gain-Boosting Frequency Doubling Technique and an Adaptive Bias Scheme for Robust Startup
by Ioannis Dimitrios Psycharis, Vasileios Tsourtis and Grigorios Kalivas
Sensors 2025, 25(3), 981; https://doi.org/10.3390/s25030981 - 6 Feb 2025
Cited by 1 | Viewed by 1259
Abstract
This paper presents the design and the performance of a wide tuning-range millimeter-wave (mm-wave) two-core class-C 60 GHz VCO in 40 nm CMOS process, which can be integrated into wireless communication transceivers and radar sensors. The proposed architecture consists of a two-core 30 [...] Read more.
This paper presents the design and the performance of a wide tuning-range millimeter-wave (mm-wave) two-core class-C 60 GHz VCO in 40 nm CMOS process, which can be integrated into wireless communication transceivers and radar sensors. The proposed architecture consists of a two-core 30 GHz fundamental VCO, a gain-boosted frequency doubler and an adaptive bias configuration. The two-core fundamental VCO structure achieves frequency generation in the vicinity of 30 GHz, where each VCO core targets a different frequency band. The two bands have sufficient overlap to accommodate for corner variations providing a large continuous tuning range. The desired frequency band is selected by activating or deactivating the appropriate VCO core, resulting in a robust switchless structure. This approach enables a considerably broad tuning range without compromising phase noise performance. Furthermore, the proposed topology utilizes an adaptive bias mechanism for robust start-up. Initially, the selected VCO core begins oscillating in class-B mode, and subsequently it transitions into class-C operation to offer improved performance. From post-layout simulations, after frequency doubling, the low-band VCO covers frequencies from 50.25 to 60.40 GHz, while the high-band VCO core spans frequencies from 58.8 to 73 GHz, yielding an overall tuning range of 36.92%. Owing to the gain-boosting topology, output power exceeds −14.2 dBm across the whole bandwidth. Simulated phase noise remains better than −92.1 dBc/Hz at a 1 MHz offset for all bands. Additionally, the two VCO cores never operate simultaneously, aiding in power efficiency. Full article
Show Figures

Figure 1

13 pages, 7428 KiB
Article
Novel Power-Efficient Fast-Locking Phase-Locked Loop Based on Adaptive Time-to-Digital Converter-Aided Acceleration Compensation Technology
by Ligong Sun, Yixin Luo, Zhiyao Deng, Jinchan Wang and Bo Liu
Electronics 2024, 13(18), 3586; https://doi.org/10.3390/electronics13183586 - 10 Sep 2024
Cited by 1 | Viewed by 1586
Abstract
This paper proposes an adaptive acceleration lock compensation technology for phase-locked loops (PLLs) based on a novel dual-mode programmable ring voltage-controlled oscillator (ring-VCO). In addition, a time-to-digital converter (TDC) is designed to accurately quantify the phase difference from the phase frequency detector (PFD) [...] Read more.
This paper proposes an adaptive acceleration lock compensation technology for phase-locked loops (PLLs) based on a novel dual-mode programmable ring voltage-controlled oscillator (ring-VCO). In addition, a time-to-digital converter (TDC) is designed to accurately quantify the phase difference from the phase frequency detector (PFD) in order to optimize the dead-zone effect while dynamically switching an auxiliary charge pump (CP) module to realize fast phase locking. Furthermore, a TDC-controlled three/five-stage dual-mode adaptively continuously switched VCO is proposed to optimize the phase noise (PN) and power efficiency, leading to an optimal performance tradeoff of the PLL. Based on the 180 nm/1.8 V standard CMOS technology, the complete PLL design and a corresponding simulation analysis are implemented. The results show that, with a 1 GHz reference signal as the input, the output frequency is 50–324 MHz, with a wide tuning range of 260 MHz and a low phase noise of −98.07 dBc/Hz@1 MHz. The key phase-locking time is reduced to 1.11 μs, and the power dissipation is lowered to 1.86 mW with a layout area of 66 μm × 128 μm. A significantly remarkable multiobjective performance tradeoff with topology optimization is realized, which is in contrast to several similar design cases of PLLs. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

15 pages, 5847 KiB
Article
A 500 mVpp Input Range First-Order VCO-Based ADC with a Multi-Phase Quantizer for EEG Recording Front Ends
by Wenhao Liu, Ying Hou, Xiaosong Wang and Yu Liu
Electronics 2024, 13(8), 1483; https://doi.org/10.3390/electronics13081483 - 13 Apr 2024
Cited by 1 | Viewed by 1876
Abstract
This paper proposes a VCO-based ADC with first-order noise shaping for EEG signal recording front ends. Addressing the challenge of applying analog integrators in advanced processes due to low voltage issues, a multi-phase quantizer structure is introduced based on V-F conversion within the [...] Read more.
This paper proposes a VCO-based ADC with first-order noise shaping for EEG signal recording front ends. Addressing the challenge of applying analog integrators in advanced processes due to low voltage issues, a multi-phase quantizer structure is introduced based on V-F conversion within the VCO structure, resulting in lower analog power consumption at the same output bit-width. By introducing a form of Gray code encoding, errors caused by circuit metastability are limited to within 1 bit. Considering the effects of motion artifacts and the electrode DC offset, the circuit achieves a wide input range of 500 mVpp by adjusting the feedback coefficients. A prototype ADC is fabricated using 180 nm CMOS technology, operating at a 1.8 V/1 V power supply voltage, with power consumption of 17.1 μW, while achieving a 62.1 dB signal-to-noise and distortion ratio (SNDR) and 55.2 dB dynamic range (DR). The proposed ADC exhibits input noise of 8.64 μVrms within a bandwidth of 0.5 Hz–5 kHz. Full article
(This article belongs to the Section Microelectronics)
Show Figures

Figure 1

9 pages, 2773 KiB
Communication
A Compact 0.73~3.1 GHz CMOS VCO Based on Active-Inductor and Active-Resistor Topology
by Chatrpol Pakasiri, Ke-Chung Hsu and Sen Wang
J. Low Power Electron. Appl. 2024, 14(2), 18; https://doi.org/10.3390/jlpea14020018 - 25 Mar 2024
Cited by 3 | Viewed by 2080
Abstract
In this paper, a wideband VCO that covers popular Long-Term Evolution (LTE) 0.7 GHz and LTE 2.6 GHz frequencies is designed and developed in a standard 0.18 μm CMOS process. The VCO utilizes active inductors to achieve coarse-tuning of the inductance and a [...] Read more.
In this paper, a wideband VCO that covers popular Long-Term Evolution (LTE) 0.7 GHz and LTE 2.6 GHz frequencies is designed and developed in a standard 0.18 μm CMOS process. The VCO utilizes active inductors to achieve coarse-tuning of the inductance and a compact chip area. Moreover, an active feedback resistor is introduced into the active inductor for fine-tuning of the inductance. The feedback resistor also affects the equivalent resistance of the active inductor; therefore, wide inductance tuning and low power consumption can be obtained by optimizing the resistor. The core area of the fabricated CMOS chip is merely 0.046 mm2, excluding all testing pads. With a 6.7~10.1 mW DC consumption, the measured oscillation frequencies range from 0.73 GHz to 3.1 GHz, which demonstrates a 123.8% tuning range. At the frequencies of interest, the measured phase noises are from −80.7 to −84.5 dBc/Hz at a 1 MHz offset frequency. Full article
(This article belongs to the Special Issue Analog/Mixed-Signal Integrated Circuit Design)
Show Figures

Figure 1

16 pages, 5537 KiB
Article
A 2.4 GHz Wide-Range CMOS Current-Mode Class-D PA with HD2 Suppression for Internet of Things Applications
by Nam-Seog Kim
Sensors 2024, 24(5), 1616; https://doi.org/10.3390/s24051616 - 1 Mar 2024
Viewed by 2003
Abstract
Short-range Internet of Things (IoT) sensor nodes operating at 2.4 GHz must provide ubiquitous wireless sensor networks (WSNs) with energy-efficient, wide-range output power (POUT). They must also be fully integrated on a single chip for wireless body area networks (WBANs) and wireless personal [...] Read more.
Short-range Internet of Things (IoT) sensor nodes operating at 2.4 GHz must provide ubiquitous wireless sensor networks (WSNs) with energy-efficient, wide-range output power (POUT). They must also be fully integrated on a single chip for wireless body area networks (WBANs) and wireless personal area networks (WPANs) using low-power Bluetooth (BLE) and Zigbee standards. The proposed fully integrated transmitter (TX) utilizes a digitally controllable current-mode class-D (CMCD) power amplifier (PA) with a second harmonic distortion (HD2) suppression to reduce VCO pulling in an integrated system while meeting harmonic limit regulations. The CMCD PA is divided into 7-bit slices that can be reconfigured between differential and single-ended topologies. Duty cycle distortion compensation is performed for HD2 suppression, and an HD2 rejection filter and a modified C-L-C low-pass filter (LPF) reduce HD2 further. Implemented in a 28 nm CMOS process, the TX achieves a wide POUT range of from 12.1 to −31 dBm and provides a maximum efficiency of 39.8% while consuming 41.1 mW at 12.1 dBm POUT. The calibrated HD2 level is −82.2 dBc at 9.93 dBm POUT, resulting in a transmitter figure of merit (TX_FoM) of −97.52 dB. Higher-order harmonic levels remain below −41.2 dBm even at 12.1 dBm POUT, meeting regulatory requirements. Full article
Show Figures

Figure 1

17 pages, 8800 KiB
Article
A Linear Multi-Band Voltage-Controlled Oscillator with Process Compensation for SerDes Applications
by Panagiotis Bertsias, Andreas Tsimpos and George Souliotis
Electronics 2024, 13(3), 581; https://doi.org/10.3390/electronics13030581 - 31 Jan 2024
Cited by 2 | Viewed by 2260
Abstract
A new voltage-controlled oscillator (VCO) topology for serializer–deserializer (SerDes) applications is proposed in this paper. The topology is suitable for SATA, PCI Express, and USB 3 protocols. The VCO is based on two-ring oscillator cores and operates in several frequency bands, as required [...] Read more.
A new voltage-controlled oscillator (VCO) topology for serializer–deserializer (SerDes) applications is proposed in this paper. The topology is suitable for SATA, PCI Express, and USB 3 protocols. The VCO is based on two-ring oscillator cores and operates in several frequency bands, as required by the corresponding protocol specifications, with a constant VCO gain and improved linear control over the frequency tuning. Additionally, it is supported by an automatic digital compensation mechanism for process variations. The VCO has been designed to cover the several speeds of the SATA and PCI Express protocols, with optimized performance in all of them, including the current consumption, the phase noise, and the frequency tuning in each case. Designed in a CMOS 22 nm technology node with a 0.8 V supply voltage, it can achieve, at 3 GHz frequency, a phase noise better than −90 dBc/Hz at 1 MHz offset and an average power consumption equal to 3.84 mW. Extended digital control can set optimized configurations for phase noise, current consumption, and VCO gain vs. process variations. Extensive post-layout simulation results verify the superior performance. Full article
(This article belongs to the Special Issue Feature Papers in Circuit and Signal Processing)
Show Figures

Figure 1

14 pages, 3511 KiB
Article
A Wideband and Low Reference Spur PLL with Clock Feedthrough Suppressed and Low Current Mismatch Charge Pump and Symmetrical CML Divider
by Yingxi Wang, Yueyue Liu, Haotang Xu, Zhongmao Li and Zhiqiang Li
Electronics 2023, 12(19), 4164; https://doi.org/10.3390/electronics12194164 - 7 Oct 2023
Cited by 4 | Viewed by 2194
Abstract
This paper presents the design and performance analysis of a wideband charge-pump phase-locked loop (CPPLL) characterized by low reference spur and low phase noise. The proposed CPPLL, operating as a wideband phase-locked loop (PLL) with a reference frequency of 100 MHz, achieves a [...] Read more.
This paper presents the design and performance analysis of a wideband charge-pump phase-locked loop (CPPLL) characterized by low reference spur and low phase noise. The proposed CPPLL, operating as a wideband phase-locked loop (PLL) with a reference frequency of 100 MHz, achieves a wide tuning range of 40% from 2.0 GHz to 3.0 GHz. A clock feedthrough suppressed charge pump with additional bias current branches is used to reduce the PLL’s loop reference spur. The 4-stage current mode logic (CML) divide-by-2/3 circuit is utilized in the frequency divider to achieve high-speed frequency division. The circuit of an AND gate and latch in the 2/3 divider adopts a full differential symmetric structure to minimize the phase error of high-frequency differential signals. The voltage-controlled oscillator (VCO) is designed to provide a wide tuning range while optimizing the trade-off between the phase noise and power consumption. The fabricated PLL is implemented using a 0.13 µm CMOS process. Experimental measurements reveal a reference spur of −74.39 dBc at an oscillation frequency of 2.4 GHz. Moreover, the CPPLL achieves phase noise of −102.55 dBc/Hz@100 kHz and −127.15 dBc/Hz@1 MHz, while consuming 33.6 mW under a 1.2 V supply voltage. The integrated root-mean-square (rms) jitter, measured from 10 kHz to 10 MHz, is 340.99 fs, and the figure-of-merit (FoM) is −234.08 dB at a carrier frequency of 2.4 GHz, highlighting the potential of the proposed PLL for integrated circuit applications. Full article
Show Figures

Figure 1

11 pages, 5300 KiB
Article
A 0.00426 mm2 77.6-dB Dynamic Range VCO-Based CTDSM for Multi-Channel Neural Recording
by Shiwei Wang, Xiaolin Yang, Chaohan Wang, Anastasios Vilouras and Carolina Mora Lopez
Electronics 2022, 11(21), 3477; https://doi.org/10.3390/electronics11213477 - 26 Oct 2022
Cited by 1 | Viewed by 2415
Abstract
Driven by needs in neuroscientific research, future neural interface technologies demand integrated circuits that can record a large number of channels of neural signals in parallel while maintaining a miniaturized physical form factor. Using conventional methods, it is challenging to reduce circuit area [...] Read more.
Driven by needs in neuroscientific research, future neural interface technologies demand integrated circuits that can record a large number of channels of neural signals in parallel while maintaining a miniaturized physical form factor. Using conventional methods, it is challenging to reduce circuit area while maintaining the high dynamic range, low noise, and low power consumption required in the neural application. This paper proposes to address this challenge using a VCO-based continuous-time delta-sigma modulator (CTDSM) circuit, which can record and digitize neural signals directly without the need for front-end instrumentation amplifiers and anti-aliasing filters, which are limited by the abovementioned circuit-area performance tradeoff. Thanks to the multi-level quantization and intrinsic mismatch-shaping capabilities of the VCO-based approach, the proposed first-order CTDSM can achieve comparable electrical performance to a higher-order CTDSM while offering further area and power reductions. We prototyped the circuit in a 22-channel test chip and demonstrate, based on the chip measurement results, that the proposed modulator occupies an area of 0.00426 mm2 while achieving input-referred noise levels of 6.26 and 3.54 µVrms in the action potential (AP) and local field potential (LFP) bands, respectively. With a 77.6 dB wide-dynamic range, the noise and total harmonic distortion meet the requirements of a neural interface with up to 149 mVpp input AC amplitude or up to ±68 mV DC offsets. We also validated the feasibility of the circuit for multi-channel recording applications by examining the impact of cross-channel VCO oscillation interferences on the circuit noise performance. The experimental results demonstrate the proposed architecture is an excellent candidate to implement future multi-channel neural-recording interfaces. Full article
(This article belongs to the Special Issue Advanced Analog Circuits for Emerging Applications)
Show Figures

Figure 1

12 pages, 4963 KiB
Article
A 500 kHz to 150 MHz Multi-Output Clock Generator Using Analog PLL and Open-Loop Fractional Divider with 0.13 μm CMOS
by Junting Jin, Yuhua Jin and Yebing Gan
Electronics 2022, 11(15), 2347; https://doi.org/10.3390/electronics11152347 - 27 Jul 2022
Cited by 2 | Viewed by 3107
Abstract
Clocks are widely used in multimedia and electronic devices, and they usually have different frequency demands. This paper presents the design of a multi-output clock generator using an analog integer-N phase-locked loop (PLL) and open-loop fractional dividers. The PLL based on a three-stage [...] Read more.
Clocks are widely used in multimedia and electronic devices, and they usually have different frequency demands. This paper presents the design of a multi-output clock generator using an analog integer-N phase-locked loop (PLL) and open-loop fractional dividers. The PLL based on a three-stage ring voltage-controlled oscillator (VCO) is used to transform the lower frequency reference into a high-frequency intermediate clock (600 MHz–900 MHz). Then, relying on the open-loop fractional divider, a wide frequency range of 500 kHz to 150 MHz can be generated. Due to the open-loop control characteristic, the clock generator has instantaneous frequency switching capability. In addition, phase-adjusting circuits added to the divider greatly improved the jitter performance of the output clock; its RMS jitter is 5.2 ps. This work was conducted with 0.13 μm CMOS technology. The open-loop divider occupies an area of 0.032 mm2 and consumes 7.7 mW from a 1.2 V supply. Full article
Show Figures

Figure 1

12 pages, 5638 KiB
Article
A 1-to-3 GHz 5-to-512 Multiplier Adaptive Fast-Locking Self-Biased PLL in 28 nm CMOS
by Binghui Wang, Haigang Yang and Yiping Jia
Electronics 2022, 11(13), 1954; https://doi.org/10.3390/electronics11131954 - 22 Jun 2022
Cited by 7 | Viewed by 2217
Abstract
Based on a self-biased architecture, this paper presents a novel adaptive fast-locking, wide operating range and low-jitter phase-locked loop (PLL). A current injection and adaptive bandwidth technology with minimum area overhead is employed to speed up the loop equilibrium acquisition process, without any [...] Read more.
Based on a self-biased architecture, this paper presents a novel adaptive fast-locking, wide operating range and low-jitter phase-locked loop (PLL). A current injection and adaptive bandwidth technology with minimum area overhead is employed to speed up the loop equilibrium acquisition process, without any adverse impact on the steady-state loop dynamics and the jitter performance. The proposed start-up circuit resets the loop to an appropriate initial state in order to shorten the initial ramp-up interval of the voltage-controlled oscillator (VCO), also resulting in cutting down the pull-in time. In addition, a proportional factor is introduced to give some kind of flexibility in the circuit design optimization. The proposed adaptive fast-locking self-biased PLL (AFL-SPLL) is designed and realized in a prototype based on TSMC 28 nm CMOS process, having a supply voltage of 0.9 V and an area of 0.0281 mm2. This PLL demonstrates a tuning range of 1 to 3 GHz and power consumptions from 0.91 mW at 1 GHz to 4.6 mW at 3 GHz operating frequency. The experimental results show that the capture process has been accelerated by up to 84.7% over large division ratios, yet the capture performance did not deteriorate at all for small division ratios. Meanwhile, the circuit implementation gave almost no area increase and yet achieved a reduction in the lock-in time of about 6.5 times, namely from 23.5 μs (without the adaptive locking) to only 3.6 μs (with the adaptive locking) on the maximum operation frequency condition of 3 GHz. Full article
(This article belongs to the Special Issue Design and Applications of Nonlinear Circuits and Systems)
Show Figures

Figure 1

10 pages, 8663 KiB
Article
A 3.7-to-10 GHz Low Phase Noise Wideband LC-VCO Array in 55-nm CMOS Technology
by Yan Yao, Zhiqun Li, Zhennan Li, Bofan Chen and Xiaowei Wang
Electronics 2022, 11(12), 1897; https://doi.org/10.3390/electronics11121897 - 16 Jun 2022
Cited by 3 | Viewed by 3489
Abstract
This paper presents a four-core LC-VCO array in 55 nm CMOS technology. Based on the multi-core VCO array technology and the switched capacitor array technology, the tuning range is expanded, and the phase noise optimization in a wide tuning range is achieved based [...] Read more.
This paper presents a four-core LC-VCO array in 55 nm CMOS technology. Based on the multi-core VCO array technology and the switched capacitor array technology, the tuning range is expanded, and the phase noise optimization in a wide tuning range is achieved based on the second harmonic noise filtering technology and the Q value degeneration technology, as well as the optimization of the capacitor array switching transistors. The proposed VCO array, occupying a chip area of 1.65 × 1.44 mm2, realizes a measured oscillation frequency range of about 3.7−10 GHz with phase noise of −127.5~−116.08 dBc/Hz at 1 MHz frequency offset, and achieves an output power of 2.69 dBm from a total power consumption of 52.8 mW. Full article
(This article belongs to the Special Issue Modeling and Design of Integrated CMOS Circuit)
Show Figures

Figure 1
