Purpose: The aim of this study is to achieve automated energy capture and charging for the ADXL355 accelerometer, enhance the vibration energy collection efficiency, and widen the energy trapping frequency band of a system in a working environment for bridge health state detection. Methods: A vibration energy harvester based on a magnetic coupling cantilever beam in an orthogonal direction was proposed. The harvester works by adjusting the angle and magnetic spacing between the two cantilever-beam piezoelectric oscillators, enabling the oscillators to produce large-scale and stable vibrations when excited by an external broadband vibration source. Results: Sinusoidal frequency sweep experiments showed that, under an excitation amplitude of 0.2 g, the proposed broadband vibration energy harvester based on orthogonal magnetic coupling double cantilever beams achieved the best energy harvesting performance when the magnetic angle of the double cantilever beam system was 130°, and the radius was 16 mm. In the frequency range of 5–20 Hz, the system can effectively capture higher effective voltages across all frequency bands, with a total captured voltage value of approximately 15.3 V. Compared with the control group, the system’s energy harvesting capacity under this working condition increases by 770%. Additionally, the effective frequency band of the system was broadened by 3.7 Hz. Conclusions: Unlike previous studies, which often limited the angles of the magnetic fields generated by the magnets at the ends of piezoelectric beams to specific values, this study explores the influence of rotating these magnetic fields to general angles on the working frequency band of the structure. The findings provide a new perspective and theoretical basis for the optimal design of broadband vibration energy harvesters. Full article

This paper proposes an enhanced vibration-based damage detection index leveraging autoregressive moving average (ARMA) time-series modeling. The method relies on the fact that material deterioration alters the vibration features of the structure. Thus, the proposed method employs an innovative usage of the ARMA time-series modeling to capture subtle shifts in the vibration response. Specifically, first, a reference ARMA model is fitted on the acceleration response of the undamaged structure. Next, a damage index (DI) is built from the goodness of fit between predicted responses from the reference ARMA model and the actual measured damaged-state acceleration data. Experimental validation was conducted on a steel beam subjected to a controlled accelerated corrosion (up to 40% thickness loss), simulating real-world degradation. Accelerations due to quick-release tests were collected using two accelerometers, along with thickness measurements providing ground-truth damage progression. Results demonstrate that the proposed method can provide sufficient sensitivity in detecting early-stage corrosion progression. This finding highlights the proposed usage of ARMA model’s potential for early structural damage detection, offering significant advantages for safety and maintenance strategies in civil engineering applications. Full article

Understanding and predicting the behaviour of fatigue cracks are essential for ensuring safety, optimising maintenance strategies, and extending the lifespan of critical components in industries such as aerospace, automotive, civil engineering and energy. Traditional methods using vibration-based dynamic responses have provided effective tools for crack detection but often fail to predict crack propagation paths accurately. This study focuses on identifying crack propagation paths in an aluminium alloy 2024-T42 cantilever beam using dynamic response through numerical simulations and artificial neural networks (ANNs). A unified damping ratio of the specimens was measured using an ICP^® accelerometer vibration sensor for the numerical simulation. Through systematic investigation of 46 crack paths of varying depths and orientations, it was observed that the crack propagation path significantly influenced the beam’s natural frequencies and resonance amplitudes. The results indicated a decreasing frequency trend and an increasing amplitude trend as the propagation angle changed from vertical to inclined. A similar trend was observed when the crack path changed from a predominantly vertical orientation to a more complex path with varying angles. Using ANNs, a model was developed to predict natural frequencies and amplitudes from the given crack paths, achieving a high accuracy with a mean absolute percentage error of 1.564%. Full article

Vibration-based structural health monitoring (SHM) is essential for evaluating structural integrity. Traditional methods using contact vibration sensors like accelerometers have limitations in accessibility, coverage, and impact on structural dynamics. Recent digital advancements offer new solutions through high-speed camera-based measurements. This study explores how camera settings (speed and resolution) influence the accuracy of dynamic response measurements for detecting small cracks in damped cantilever beams. Different beam thicknesses affect damping, altering dynamic response parameters such as frequency and amplitude, which are crucial for damage quantification. Experiments were conducted on 3D-printed Acrylonitrile Butadiene Styrene (ABS) cantilever beams with varying crack depth ratios from 0% to 60% of the beam thickness. The study utilised the Canny edge detection technique and Fast Fourier Transform to analyse vibration behaviour captured by cameras at different settings. The results show an optimal set of camera resolutions and frame rates for accurately capturing dynamic responses. Empirical models based on four image resolutions were validated against experimental data, achieving over 98% accuracy for predicting the natural frequency and around 90% for resonance amplitude. The optimal frame rate for measuring natural frequency and amplitude was found to be 2.4 times the beam’s natural frequency. The findings provide a method for damage assessment by establishing a relationship between crack depth, beam thickness, and damping ratio. Full article

By addressing the phenomenon of carbody abnormal vibrations in the field, the acceleration of the carbody and bogie was measured using accelerometers, and the diamond mode of the carbody was identified. The equivalent conicity of the wheelset and the acceleration at the frame end indicated that the shaking of the carbody was caused by bogie hunting. In the SIMPACK simulation, the acceleration frequency and amplitude at the frame end and midsection of the side beam were calculated. The lateral deformation amplitude of the side beam in the finite element model was extracted, and a modal shape function for the diamond-shaped mode was established. By utilizing the modal vibration equation, the modal generalized forces of the carbody were computed, revealing that, during carbody shaking, the yaw damper force contributed significantly among the forces of the secondary suspension, with the phase difference between the front and rear bogies approaching 180°. This insight offers a novel perspective for subsequent active control strategies. Subsequently, these modal generalized forces were applied as external excitation to a coupled vibration model encompassing both the carbody and transformer. Aiming to reduce the acceleration amplitude at the side beam, the transformer was treated as a dynamic vibration absorber, allowing for the optimization of its lateral suspension parameters. As a result, the lateral and vertical acceleration amplitudes at the side beam were concurrently reduced, with the maximum decrease reaching 58.5%, significantly enhancing the ride comfort. Full article

Accelerometers are commonly used to measure vibrations for condition monitoring in mechanical and civil structures; however, their high cost and point-based measurement approach present practical limitations. With rapid advancements in computer vision and deep learning, research into tracking the motion of individual pixels with vision cameras has increased. The recently developed CoTracker, a transformer-based model, has demonstrated excellence in motion tracking, yet its performance in measuring structural vibrations has not been fully explored. This paper investigates the efficacy of the CoTracker model in extracting full-field structural vibrations using cameras. It is initially applied to capture the dense point movements in video sequences of a cantilever beam recorded using a high-speed camera. Subsequently, modal analysis using delay-embedding dynamic mode decomposition (DMD) is conducted to extract modal parameters including natural frequencies, damping ratios, and mode shapes. The results, benchmarked against those from a reference accelerometer and the Finite Element Method (FEM) result, demonstrate CoTracker’s high potential for general applicability in structural vibration measurements. Full article

Curvature-based damage detection has been previously applied to identify damage in concrete structures, but little attention has been given to the capacity of this method to identify distributed damage in multiple damage zones. This study aims to apply for the first time an enhanced existing method based on modal curvature analysis combined with wavelet transform curvature (WTC) to identify zones and highlight the damage zones of a beam made of ultra-high-performance fiber-reinforced concrete (UHPFRC), a construction material that is emerging worldwide for its outstanding performance and durability. First, three beams with a 2 m span of UHPFRC material were cast, and damaged zones were created by sawing. A reference beam without cracks was also cast. The free vibration responses were measured by 12 accelerometers and calculated by operational modal analysis. Moreover, for the sake of comparison, a finite element model (FEM) was also applied to two identical beams to generate numerical acceleration without noise. Second, the modal curvature was calculated for different modes for both experimental and FEM-simulated acceleration after applying cubic spline interpolation. Finally, two damage identification methods were considered: (i) the damage index (DI), based on averaging the quadratic difference of the local curvature with respect to the reference beam, and (ii) the WTC method, applied to the quadratic difference of the local curvature with respect the reference beam. The results indicate that the developed coupled modal curvature WTC method can better identify the damaged zones of UHPFRC beams. Full article

Activity monitoring of living creatures based on the structural vibration of ambient objects is a promising method. For vibration measurement, multi-axial inertial measurement units (IMUs) offer a high sampling rate and a small size compared to geophones, but have higher intrinsic noise. This work proposes a sensing device that combines a single six-axis IMU with a beam structure to enable measurement of small vibrations. The beam structure is integrated into the PCB of the sensing device and connects the IMU to the ambient object. The beam is designed with finite element method (FEM) and optimized to maximize the vibration amplitude. Furthermore, the beam oscillation creates simultaneous translation and rotation of the IMU, which is measured with its accelerometers and gyroscopes. On this basis, a novel sensor fusion algorithm is presented that adaptively combines IMU data in the wavelet domain to reduce intrinsic sensor noise. In experimental evaluation, the proposed sensing device using a beam structure achieves a 6.2-times-higher vibration amplitude and an increase in signal energy of 480% when compared to a directly mounted IMU without a beam. The sensor fusion algorithm provides a noise reduction of 5.6% by fusing accelerometer and gyroscope data at 103 Hz. Full article

In response to the growing demand for high-sensitivity accelerometers in vector hydrophones, a piezoelectric MEMS accelerometer (PMA) was proposed, which has a four-cantilever beam integrated inertial mass unit structure, with the advantages of being lightweight and highly sensitive. A theoretical energy harvesting model was established for the piezoelectric cantilever beam, and the geometric dimensions and structure of the microdevice were optimized to meet the vibration pickup conditions. The sol-gel and annealing technology was employed to prepare high-quality PZT thin films on silicon substrate, and accelerometer microdevices were manufactured by using MEMS technology. Furthermore, the MEMS accelerometer was packaged for testing on a vibration measuring platform. Test results show that the PMA has a resonant frequency of 2300 Hz. In addition, there is a good linear relationship between the input acceleration and the output voltage, with V = 8.412a − 0.212. The PMA not only has high sensitivity, but also has outstanding anti-interference ability. The accelerometer structure was integrated into a vector hydrophone for testing in a calibration system. The results show that the piezoelectric vector hydrophone (PVH) has a sensitivity of –178.99 dB@1000 Hz (0 dB = 1 V/μPa) and a bandwidth of 20~1100 Hz. Meanwhile, it exhibits a good “8” shape directivity and consistency of each channel. These results demonstrate that the piezoelectric MEMS accelerometer has excellent capabilities suitable for use in vector hydrophones. Full article

To meet the measurement needs of multidimensional high-g acceleration in fields such as weapon penetration, aerospace, and explosive shock, a biaxial piezoresistive accelerometer incorporating tension–compression is meticulously designed. This study begins by thoroughly examining the tension–compression measurement mechanism and designing the sensor’s sensitive structure. A signal test circuit is developed to effectively mitigate cross-interference, taking into account the stress variation characteristics of the cantilever beam. Subsequently, the signal test circuit of anti-cross-interference is designed according to the stress variation characteristics of the cantilever beam. Next, the finite element method is applied to analyze the structure and obtain the performance indices of the range, vibration modes, and sensitivity of the sensor. Finally, the process flow and packaging scheme of the chip are analyzed. The results show that the sensor has a full range of 200,000 g, a sensitivity of 1.39 µV/g in the X direction and 1.42 µV/g in the Y direction, and natural frequencies of 509.8 kHz and 510.2 kHz in the X and Y directions, respectively. Full article

In this paper, a high-sensitivity microelectromechanical system (MEMS) piezoelectric accelerometer based on a Scandium-doped Aluminum Nitride (ScAlN) thin film is proposed. The primary structure of this accelerometer is a silicon proof mass fixed by four piezoelectric cantilever beams. In order to enhance the sensitivity of the accelerometer, the Sc_0.2Al_0.8N piezoelectric film is used in the device. The transverse piezoelectric coefficient d₃₁ of the Sc_0.2Al_0.8N piezoelectric film is measured by the cantilever beam method and found to be −4.7661 pC/N, which is approximately two to three times greater than that of a pure AlN film. To further enhance the sensitivity of the accelerometer, the top electrodes are divided into inner and outer electrodes; then, the four piezoelectric cantilever beams can achieve a series connection by these inner and outer electrodes. Subsequently, theoretical and finite element models are established to analyze the effectiveness of the above structure. After fabricating the device, the measurement results demonstrate that the resonant frequency of the device is 7.24 kHz and the operating frequency is 56 Hz to 2360 Hz. At a frequency of 480 Hz, the sensitivity, minimum detectable acceleration, and resolution of the device are 2.448 mV/g, 1 mg, and 1 mg, respectively. The linearity of the accelerometer is good for accelerations less than 2 g. The proposed piezoelectric MEMS accelerometer has demonstrated high sensitivity and linearity, making it suitable for accurately detecting low-frequency vibrations. Full article

The structural health monitoring (SHM) technique is a highly competent operative process dedicated to improving the resilience of an infrastructure by evaluating its system state. SHM is performed to identify any modification in the dynamic properties of an infrastructure by evaluating the acceleration, natural frequencies, and damping ratios. Apart from the vibrational measurements, SHM is employed to assess the displacement. Consequently, sensors are mounted on the investigated framework aiming to collect frequent readings at regularly spaced time intervals during and after being induced. In this study, a LabVIEW program was developed for vibrational monitoring and system evaluation. In a case study reported herein, it calculates the natural frequencies as well as the damping and displacement parameters of a cantilever steel beam after being subjected to excitation at its free end. For that purpose, a Bridge Diagnostic Inc. (BDI) accelerometer and a displacement transducer were parallelly mounted on the free end of the beam. The developed program was capable of detecting the eigenfrequencies, the damping properties, and the displacements from the acceleration data. The evaluated parameters were estimated with the ARTeMIS modal analysis software for comparison purposes. The reported response confirmed that the proposed system strongly conducted the desired performance as it successfully identified the system state and modal parameters. Full article

The modal parameters of structures, and in particular their mode shapes, are generally determined based on the measurement of accelerometers or laser vibrometers. However, these sensors do not allow the performance of full-field measurements. In this study, the free vibration of a beam triggered by a shock is investigated using a high-speed camera with high image definition. With the help of digital image correlation (DIC), the beam displacement fields are deduced from the images. To analyse the DIC measurement quality, different tests and analyses are performed. First, the systematic errors and uncertainties in the DIC calculation for a simple translation are analysed considering different speckles. Then, tests on two configurations of a vibrating beam are filmed and full-field displacement measurements are computed. The modal parameters of the beam are deduced from these measurements using a continuous wavelet transform method. Particular care was taken to adapt the method to the post-processing of the numerous and noisy signals obtained for these experiments. All the steps of the post-processing are detailed in this paper. Finally, the modal parameters obtained with the proposed method are compared with those obtained in a more classical way using accelerometers and from the beam theory. In particular, the comparison of the signal-to-noise ratio of the different measurement methods is discussed. Full article

We focus on the design, optimization, fabrication, and testing of fiber Bragg grating (FBG) cantilever beam-based accelerometers to measure vibrations from active seismic sources in the external environment. These FBG accelerometers possess several advantages, such as multiplexing, immunity to electromagnetic interference, and high sensitivity. Finite Element Method (FEM) simulations, calibration, fabrication, and packaging of the simple cantilever beam-based accelerometer based on polylactic acid (PLA) are presented. The influence of the cantilever beam parameters on the natural frequency and sensitivity are discussed through FEM simulation and laboratory calibration with vibration exciter. The test results show that the optimized system has a resonance frequency of 75 Hz within a measuring range of 5–55 Hz and high sensitivity of ±433.7 pm/g. Finally, a preliminary field test is conducted to compare the packaged FBG accelerometer and standard electro-mechanical 4.5-Hz vertical geophones. Active-source (seismic sledgehammer) shots are acquired along the tested line, and both systems’ experimental results are analyzed and compared. The designed FBG accelerometers demonstrate suitability to record the seismic traces and to pick up the first arrival times. The system optimization and further implementation offer promising potential for seismic acquisitions. Full article

A flexible piezoresistive sensor was developed as an accelerometer based on Graphene/PVDF nanocomposite to detect low-frequency and low amplitude vibration of industrial machines, which may be caused due to misalignment, looseness of fasteners, or eccentric rotation. The sensor was structured as a cantilever beam with the proof mass at the free end. The vibration caused the proof mass to accelerate up and down, which was converted into an electrical signal. The output was recorded as the change in resistance (response percentage) with respect to the acceleration. It was found that this accelerometer has a capability of detecting acceleration up to 8 g_pk-pk in the frequency range of 20 Hz to 80 Hz. The developed accelerometer has the potential to represent an alternative to the existing accelerometers due to its compactness, simplicity, and higher sensitivity for low frequency and low amplitude applications. Full article
