Vertical-cavity surface-emitting lasers (VCSELs) have emerged as essential light sources for atomic-precision measurement, quantum-secure communication, high-speed optical transmission, and laser coherent scanning detection, owing to their low power consumption, high-quality beam characteristics, and ease of two-dimensional integration. However, the fundamental limitation on linewidth narrowing in VCSELs arises from their inherently short resonator, resulting in a natural linewidth on the order of 50–100 MHz. This limitation prevents conventional VCSELs from meeting the stringent requirements of advanced applications, making the ultra-narrow linewidth a key focus in optoelectronics research. This review analyzes representative achievements and application scenarios of narrow-linewidth VCSELs, evaluates the merits and limitations of industrial-grade devices, and envisions future directions in next-generation optoelectronic systems. Distinct from existing reviews, it integrates key single-mode fabrication techniques, quantitative linewidth requirements across applications, silicon photonic integration, and scalable manufacturing trends, establishing a complete mechanism–technology–application–industry analytical framework. Full article

In this work, we report the realization of curved distributed Bragg reflectors (DBRs) without the need for lithography to achieve strong lateral confinement in a GaN-based vertical cavity. By embedding SiO₂ nanospheres during deposition, curved DBRs with a funnel-shaped cross-section were fabricated. Based on the formed curved DBRs, a vertical cavity with a quality factor exceeding 2800 and a mode volume below 0.14 μm³ was successfully fabricated. The optical pumping threshold power of a vertical cavity surface-emitting laser (VCSEL) with a curved DBR was reduced to 76 nW, which is one order of magnitude lower than that of the same VCSEL with double-planar DBRs. Near-field patterns revealed that the curved-DBR VCSEL emits a circularly symmetric TEM₀₀ mode with a full width at half maximum (FWHM) of only 1.8 μm. We believe this is an effective technique for fabricating low-threshold or small-aperture VCSELs. Full article

Multimode fibers (MMFs) have been a key component in short-reach transmission systems for over 50 years and remain the predominant transmission medium for Vertical Cavity Surface-Emitting Laser (VCSEL)-based short links in data centers. To meet the growing demand for higher data rates, MMFs have continuously evolved to enhance bandwidth performance. This paper provides an overview of the fundamental properties of MMFs, with an emphasis on fiber parameters that influence bandwidth capabilities. We discuss trends in increasing data rates for MMF transmission systems in data centers and review recent progress in MMF technology aimed at boosting bandwidth. In particular, we highlight innovative fiber designs, including high-bandwidth 50 μm MMFs, large-core MMFs, long-wavelength MMFs, universal fibers, MMF bundles, and multicore fibers. Full article

Vertical-External-Cavity Surface-Emitting Lasers (VECSELs) have gained significant attention over the past two decades due to their versatility in a wide range of photonic applications. This review focuses on VECSEL configurations for dual-wavelength emission, highlighting their use in high-resolution spectroscopy, terahertz (THz) generation, and advanced optical communication. We explore recent developments in VECSEL designs, including systems utilizing birefringent crystals for polarization-based frequency separation and configurations with dual-VECSEL chips or dual-gain regions within a single cavity. These two-wavelength VECSELs enable diverse operation modes, including narrow-linewidth, pulsed, multimode, and frequency-converted emission, with high-brightness output, excellent beam quality, and tunable wavelengths. Additionally, the review discusses advancements in dual-frequency VECSELs, with applications in LIDAR systems for environmental monitoring, highly stable optical clocks, and fiber sensors. We examine improvements in cavity design, semiconductor structures, and power stabilization, which have enhanced frequency stability and spectral purity, making VECSELs suitable for precision metrology and sensing applications. Full article

We present the simulation-guided design and experimental demonstration of high-speed 940 nm vertical-cavity surface-emitting lasers (VCSELs). Utilizing established device optimization principles, a simulation study was conducted focusing on the number of oxide layers and the aperture size, which predicted a maximum modulation bandwidth of over 35 GHz. To validate the simulation, a device with a 4-μm double-oxide aperture was fabricated and characterized. Additionally, a Zn-diffusion process was incorporated during fabrication to reduce p-DBR resistance and suppress higher-order transverse modes. The fabricated device achieved an experimental modulation bandwidth of 34 GHz and demonstrated successful 100 Gbit/s PAM-4 data transmission. The close agreement between the simulated and measured performance highlights the successful practical integration of these techniques for developing high-speed optical interconnects. Full article

The growing demand for lithium-ion batteries, along with the imperative for sustainable and cost-efficient production, necessitates the exploration of innovative technological approaches. Among the most energy-intensive steps in battery manufacturing is the electrode drying process. This study examined the impact of rapid laser-based drying on critical quality parameters of anode electrodes. A vertical-cavity surface-emitting laser (VCSEL) was employed, enabling precise and independent control of the power distribution. By applying various intensity profiles, the influence of laser power modulation on electrode drying behaviour and resulting quality was systematically investigated. The outcomes were compared to both conventional convection drying and laser drying at constant power. The objective was to assess the viability of profile-controlled laser drying as a stand-alone alternative and to identify its benefits and limitations with regard to electrode quality and process efficiency. Full article

Spin-exchange relaxation-free (SERF) atomic magnetometers have emerged as highly promising candidates for ultra-weak magnetic field detection, particularly in biomagnetic imaging, owing to their exceptional sensitivity, amenability to miniaturization, and near-room-temperature operation. While current miniaturized magnetometers typically employ laser chips with fixed optical power, the quantitative impact of laser power on critical performance metrics remains to be fully elucidated. This study systematically investigates the influence of laser power on sensitivity, bandwidth, and dynamic range by incorporating considerations of power broadening, saturation absorption, and noise constraints. A miniaturized probe, integrated with an actively controlled vertical-cavity surface-emitting laser (VCSEL), was developed for experimental validation. Theoretical and experimental results consistently demonstrate that as optical power increases, sensitivity exhibits a non-monotonic dependence, whereas both bandwidth and dynamic range manifest a monotonic upward trend, aligning well with theoretical simulations. The optimized sensor achieved a peak sensitivity of 16 fT/√Hz at 300 μW, while the bandwidth and dynamic range reached 230 Hz and ±5.4 nT at 500 μW, respectively. This work establishes a robust theoretical and experimental framework for the comprehensive performance optimization of laser-integrated miniaturized atomic magnetometers. Full article

The inherently high-voltage-length product (V_πL) of thin-film lithium niobate (TFLN) modulators in the O-, C-, and L-telecom bands restricts further scaling of photonic integrated circuits’ bandwidth density, driving their migration toward shorter operating wavelengths. Nevertheless, the corresponding grating couplers, as critical optical input/outputs (optical I/Os) interfaces, remain largely undeveloped. Here, we demonstrate an 850 nm TFLN grating coupler designed based on topological unidirectional guided resonance (UGR). By breaking C₂ symmetry of the unit cell and precisely tailoring its geometry, we achieve unidirectional upward radiation with a 63.7 dB up/down intensity ratio. Subsequent apodization of groove widths and periods enables precise control of the electrical field distribution in both real and momentum spaces. This yields a vertical-cavity surface-emitting laser (VCSEL)-matched, highly fabrication-tolerant TFLN grating coupler that attains, to the best of our knowledge, the highest simulated coupling efficiency of −0.6 dB without mirrors or hybrid materials. This work delivers a high-efficiency, layout-flexible, and complementary metal oxide semiconductor (CMOS)-compatible optical I/Os solution for short-wavelength TFLN modulators with low V_πL. It offers substantial engineering value and broad applicability for on-chip light source integration and high-bandwidth-density short-reach optical interconnects. Full article

The rapidly increasing demand for compact, high-performance beam-steering solutions in LiDAR systems has driven substantial advances in vertical-cavity surface-emitting laser (VCSEL) technologies. In this paper, we present a high-power, ultra-low-divergence VCSEL-based beam scanner array that integrates multi-wavelength seed lasers with extended-length optical amplifiers, thereby simultaneously achieving wide-angle beam steering, near-diffraction-limited beam quality, and watt-class output power. The proposed architecture exploits slow-light modes supported by laterally extended VCSEL waveguides incorporating precisely engineered surface gratings. This design enables fully electronic beam steering over an angular range exceeding 30°, with an angular resolution surpassing 1600 resolvable points. Systematic characterization of seed lasers with distinct grating periods confirms robust single-mode operation and yields a cumulative wavelength tuning range exceeding 22 nm. When integrated with optical amplifiers up to 6 mm in length, the system achieves a record-low beam divergence of 0.018°, approaching the theoretical diffraction limit. Under continuous-wave operation and without active thermal management, the device delivers output powers exceeding 1.6 W. By overcoming the long-standing trade-offs among steering range, beam quality, and output power, this work establishes a transformative paradigm for compact VCSEL-based beam-steering systems and represents a significant step toward next-generation solid-state LiDAR technologies. Full article

The connectivity demands of high-performance computing (HPC), artificial intelligence (AI) and data centers are driving the development of a new generation of multimode optical components. This paper discusses the vertical cavity surface emitting laser (VCSEL) bandwidth and noise performance needed to support 106 Gbd line rates with PAM4 modulation for 200 Gbps per lane multimode optical links. A −3 dB bandwidth greater than 35 GHz and a RIN of less than −152 dB/Hz are demonstrated. No uncorrectable errors were observed over 50 m of OM4 fiber, demonstrating good link stability. VCSEL device performance and the associated wear-out life are presented. Leveraging good device reliability and low power consumption of VCSEL-based links, a novel VCSEL near-packaged optics (NPO) concept is proposed for optical interconnects in AI scale-up network applications. Optical interconnects allow for longer reaches, compared to copper interconnects, which facilitate larger AI clusters with network disaggregation. The proposed VCSEL NPO can achieve an energy efficiency of ~1 pJ/bit, which is the highest among optical interconnects. Full article

Vertical cavity surface emitting lasers (VCSELs) have shown great potential in high-speed communication, quantum information processing, and 3D sensing due to their excellent beam quality and low power consumption. However, generating high-purity and controllable circularly polarized light usually requires external optical components such as quarter-wave plates, which undoubtedly increases system complexity and volume, hindering chip-level integration. To address this issue, we propose a monolithic integration scheme that directly integrates a custom-designed double-layer asymmetric metasurface onto the upper distributed Bragg reflector of a chiral VCSEL. This metasurface consists of a rotated GaAs elliptical nanocolumn array and an anisotropic grating above it. By precisely controlling the relative orientation between the two, the in-plane symmetry of the structure is effectively broken, introducing a significant optical chirality response at a wavelength of 1550 nm. Numerical simulations show that this structure can achieve a near 100% high reflectivity for the left circularly polarized light (LCP), while suppressing the reflectivity of the right circularly polarized light (RCP) to approximately 33%, thereby obtaining an efficient in-cavity circular polarization selection function. Based on this, the proposed VCSEL can directly emit high-purity RCP without any external polarization control components. This compact circularly polarized laser source provides a key solution for achieving the next generation of highly integrated photonic chips and will have a profound impact on frontier fields such as spin optics, secure communication, and chip-level quantum light sources. Full article

A double-cavity vertical-cavity surface-emitting laser (VCSEL) can effectively suppress high-order transverse modes and achieve a high side-mode suppression ratio (SMSR). However, the double cavity also results in increased fundamental mode loss, reducing output power. In this study, both p-type and n-type oxide layers were simultaneously incorporated into a double-cavity VCSEL and the structure was numerically simulated using Pics3D (2024) software. The simulation results indicate that this approach can significantly enhance the output power, strengthen the single-transverse-mode characteristic, and thus improve the side-mode suppression ratio (SMSR). Generally, as the number of oxide layers increases, their ability to confine the optical field also enhances, trapping more high-order transverse modes within the oxide aperture, leading to a decrease in SMSR. However, in this study, the introduction of an n-type layer resulted in an abnormal increase in the SMSR, because the n-type oxide layer is situated between the active region and the second cavity. When the optical field oscillates between these two regions, some high-order transverse modes are blocked by the n-type oxide holes and cannot participate in mode competition, thereby increasing the SMSR. Full article

We propose a novel scheme for generating high-frequency millimeter-wave signals by exploiting period-one (P1) dynamics in a mutual injection configuration of two spin-polarized vertical-cavity surface-emitting lasers (spin-VCSELs). The frequency of the generated millimeter-wave signal is jointly determined by the birefringence rate of the spin-VCSEL and the frequency detuning between the two lasers. By leveraging the complex dynamics of free-running spin-VCSELs, we explore the coupling of three distinct dynamic states: continuous-wave (CW) injected into CW, CW injected into P1 oscillation, and P1 oscillation injected into P1 oscillation. Our results reveal that these interactions not only enhance the tunability and frequency of the millimeter-wave output but also significantly reduce the linewidth, offering substantial advantages for reconfigurable photonic systems. This study demonstrates the remarkable potential of mutually injected spin-VCSELs for generating high-performance, tunable photonic millimeter waves and highlights their promising applications in advanced communication and radar systems. Full article

Vertical-cavity surface-emitting lasers (VCSELs) have generated extensive enthusiasm in scientific research on and applications of lasers. However, thermal resistance has seriously limited the performance of such devices for a long time, especially in high-power single-chip large-area VCSEL array modules. In this study, in order to determine the packaging thermal resistance bottleneck of the high-power VCSEL array laser module and achieve better performance, the thermal characteristics of an 808 nm VCSEL module were analyzed quickly with electrical transient measurements without any damage, which consisted of a 6 mm × 6 mm, 85 W, AlGaAs/GaAs VCSEL array chip encapsulated on a submount and a water-cooled heat sink. The quantitative components of the device’s thermal resistance were clearly segmented and rapidly obtained within merely 25 s using the structure function algorithm. The packaging thermal resistances together accounted for an astonishing 70% of the total thermal resistance when the loading current was 8 A. Among them, R_submount and R_solder2 were the main focus areas, which accounted for 54% of the total thermal resistance. We also applied the spectroscopy method to calculate the total thermal resistance of the module on a large scale from another perspective for the comparative verification of the electrical transient method. The values obtained by the two methods were relatively close. More importantly, this research will have a positive impact and an indicative effect on reducing the main thermal resistances of the VCSEL array module. Full article

With the rapid deployment of artificial intelligence (AI) data centers, demand for optical modules surges—alongside faster upgrades and stricter low-power requirements. However, traditional optical driver integrated circuits (ICs) rely on device-specific customization, which lengthens driver design cycles, delays module deployment, and raises costs, becoming a bottleneck for optical module evolution. To address these issues, this work proposes a unified optical transmitter electronic integrated circuit (EIC) design approach featuring synergistic driver-laser/modulator co-design and a versatile output driver (VOD). The VOD can be configured into three output impedance states (open-drain, differential 50-$\Omega$, or differential 100-$\Omega$), enabling it to drive various optical devices like distributed feedback lasers (DFBs), vertical-cavity surface-emitting lasers (VCSELs), electro-absorption modulated lasers (EMLs), and Mach-Zehnder modulators (MZMs) with a single design, minimizing device-specific customization. Meanwhile, its power consumption is also adjustable to maximize the power efficiency. The proposed design approach demonstrates the potential to address the critical interoperability, cost, and power challenges faced by AI data centers, providing a scalable template for next-generation coherent and 4-level pulse amplitude modulation systems and facilitating rapid deployment. Full article
