To investigate the flexural behavior of steel–concrete composite bridge decks with stud–perfobond leist (PBL) shear connectors, two specimens were designed with the stud spacing as the main variable, and static bending tests were conducted. Additionally, refined finite element models were constructed for evaluating the influence of shear connector types, concrete strength, stud diameter, stud height, and PBL hole diameter on the performance and flexural capacity of the structure. The results show that, under bending loads, the failure of the composite bridge deck is mainly concrete crushing and steel plate yielding. When the spacing of the stud decreases, both the flexural behavior of the composite bridge decks and the shear resistance at the steel–concrete interface are enhanced. The steel–concrete composite bridge decks with stud–PBL shear connectors showed higher overall flexural stiffness and flexural capacity than the steel–concrete composite bridge decks with single-type shear connectors. Concrete strength had a pronounced influence on the flexural capacity of the deck system, while the effects of stud diameter and height were minor. As the PBL hole diameter increased, the flexural capacity of the specimens exhibited a decreasing tendency. Full article

In response to the urgent need for performance predictions of damaged aerospace structures, this study undertakes a comprehensive investigation into the flutter characteristics of damaged variable-stiffness composite laminate (VSCL) plates. The governing boundary value problem for the dynamics of damaged VSCL plates is formulated using first-order shear deformation theory (FSDT). Additionally, the first-order piston theory is utilized to model the aerodynamic pressure in supersonic airflow. A novel coupling methodology is developed through the integration of penalty function methods and irregular mapping techniques, which effectively establishes the interaction between damaged and undamaged plate elements. The vibration characteristics and aeroelastic responses are systematically analyzed using the Chebyshev differential quadrature method (CDQM). The validity of the proposed model is thoroughly demonstrated through comparative analyses with the existing literature and finite element simulations, confirming its computational accuracy and broad applicability. A notable characteristic of this research is its ability to accommodate arbitrary geometric configurations within damaged regions. The numerical results unequivocally demonstrate that accurately predicting the flutter characteristics of damaged VSCL plates constitutes an effective strategy for mitigating structural stability degradation. This approach provides valuable insights for aerospace structural design and maintenance. Full article

This study introduces an analytical framework that integrates the state-space method with generalized thermoelasticity theory to obtain exact solutions for the static and dynamic behaviors of laminated plates featuring imperfect interfaces and resting on a Winkler foundation. The model comprehensively accounts for the foundation-structure interaction, interfacial imperfection, and the coupling between the thermal and mechanical fields. A parametric analysis explores the impact of the dimensionless foundation coefficient, interface flexibility coefficient, and thermal conductivity on the static and dynamic behaviors of the laminated plates. The results indicate that a lower foundation stiffness results in higher sensitivity of structural deformation with respect to the foundation parameter. Furthermore, an increase in interfacial flexibility significantly reduces the global stiffness and induces discontinuities in the distribution of stress and temperature. Additionally, thermal conductivity governs the continuity of interfacial heat flux, while thermo-mechanical coupling amplifies the variations in specific field variables. The findings offer valuable insights into the design and reliability evaluation of composite structures operating in thermally coupled environments. Full article

In functionally graded polymer foam, mechanical properties and chemical composition vary in a prescribed direction according to a power law distribution. However, most manufacturing methods lack precise control over pore size, limiting their application. In this case, the graded foam structure can be formed from separate layers, with each layer assigned unique values in terms of mechanical properties or chemical composition based on the power law distribution. The hypothesis of the work is that the application of functionally graded (FG) foam materials inside the rotor blades or wings of an unmanned aerial vehicle can provide the ability to vary their stiffness properties. The aim of this work is to conduct an investigation of the static behaviour of a composite box plate with constant and variable heights that simulate the dimensions and changing profile of a helicopter rotor blade. In the numerical analysis, two models of composite box plate are considered and the material properties of graded polymeric foam core are assumed to vary continuously by the power law along the width of cross-sectional structures. It is not possible to model the continuous flow of graded properties through the foam in construction; therefore, the layers of foam are modelled using discontinuous gradients, where the gradient factor changes step by step. The numerical results are obtained using ANSYS software. The results of the numerical calculation showed that the use of graded foam affects the parameters under study. The stiffness of a structure significantly decreases with an increase in the power law index. Full article

To reduce the cast in place work of concrete and realize the industrial production of a bamboo–concrete composite (BCC), innovative connection systems composed of an assembled bamboo–lightweight concrete composite (ABLCC) structure featuring perforated steel plate connectors are presented for use in engineering structures. This study examined the shear performance of connection systems composed of an assembled BCC structure featuring perforated steel plate connectors based on the design and fabrication of three groups of shear connectors with nine different parameters using bamboo scrimber, lightweight concrete, perforated steel plates, and grout. Push-out tests were conducted on these shear connectors. A linear variable differential transformer (LVDT) and digital image correlation (DIC) were utilized for measurements. The test parameters comprised fabrication techniques (assembled and cast-in-place/CIP) and connector size (steel plate thickness). This study investigated mechanical performance indicators, including the failure mode, load–slip relationship, shear stiffness, and shear capacity of the shear connectors. The experimental results showed that the shear connector failure modes involved concrete spalling near the connectors and deformation of the perforated steel plates. The load–slip curves generally included three stages: high slope linear increase, low slope nonlinear increase, and rapid decrease. The shear capacity and stiffness of the assembled shear connectors were 0.84 times and 2.46 times those of the CIP connectors, respectively. The stiffness of the 4 mm steel plate connectors increased by 42% compared to the 2 mm steel plate connectors. Analysis showed that the shear capacity of the BBC primarily consisted of four aspects: the end bearing force of the steel plate, contact friction, and forces due to the influence of tenon columns and the reinforcing impact of through-rebars. This study proposes a simple and suitable formula for obtaining the shear capacity of perforated steel plate connectors in the BCC structure, with the analytical values being in good agreement with the test results. Full article

Accurately determining the mechanical properties of complex materials is a key challenge in structural analysis, especially when using the finite element method (FEM). While homogeneous materials can be modeled with relative ease, heterogeneous materials such as composites or biological tissues with multiphase compositions pose significant difficulties due to the variability in their internal structures. The most used approach is numerical homogenization, which allows for the estimation of effective material properties by combining the characteristics of individual phases; however, this technique may not always be feasible, especially for materials with irregular or unknown phase distributions. This paper proposes an original methodology that combines non-destructive experimental testing with an inverse finite element modeling to extract the anisotropic elastic properties of quasi two-dimensional structures such as membranes and plates. The method involves modeling the component using membrane or plate finite elements, but managing a global stiffness matrix expressed analytically. While geometric information is incorporated in the global stiffness matrix, the material properties, specifically the components of the anisotropic elasticity matrix, remain unknown. The experimental data, comprising force and displacement measurements, are used to solve a nonlinear system, allowing for the identification of the material’s constitutive properties via numerical computation. To validate this approach, two experimental setups were conducted. The first involved a hyperelastic neoprene membrane, subjected to various biaxial preloading conditions, while the second focused on PLA plates produced through additive manufacturing including both homogeneous and reinforced variants. In both cases, the method successfully captured the full anisotropic elastic response, yielding accurate estimates of Young’s moduli, Poisson’s ratios, shear modulus, and orthotropy system orientation, in agreement with independent mechanical tests. This combined approach offers a practical and efficient solution for determining the elastic properties of complex materials, particularly in cases where traditional homogenization techniques are impractical or inadequate. Furthermore, this method can be a versatile tool for evaluating the damaging and aging effects on materials subjected to cyclic loading or those with irregular and complex internal structures. Full article

Swash plate axial piston pumps play an important role in hydraulic systems due to their superior performance and compact design. As the controlled object of the valve-controlled hydraulic cylinder, the swash plate is affected by the complex fluid dynamics effect and the mechanical structure, which is prone to vibration, during the working process, thereby adversely affecting the dynamic performance of the system. In this paper, an electronically controlled ball screw type variable displacement mechanism with stiffness compensation is proposed. By introducing piezoelectric ceramic materials into the nut assembly, dynamic stiffness compensation of the system is achieved, which effectively changes the vibration characteristics of the swash plate and thus significantly improves the working stability of the system. Based on this, the stiffness model of a double nut ball screw is established to obtain the relationship between piezoelectric ceramics and the double nut. An asymmetric Bouc–Wen piezoelectric actuator model with nonlinear hysteresis characteristics is also established, and a particle swarm algorithm with improved inertia weights is utilized to identify the parameters of the asymmetric Bouc–Wen model. Finally, a piezoelectric actuator model based on the feedforward inverse model and a PID composite control algorithm is applied to the variable displacement mechanism system for stiffness compensation. Full article

The aviation intelligent pump system is an effective solution to aircraft hydraulic systems’ inefficient power consumption and temperature increase. A self-supplied aviation intelligent pump (SAIP) has a high power-to-weight ratio and compact structure, making it the optimal choice for an intelligent pump. To analyze the output characteristics of a novel aviation intelligent pump, it is crucial to establish an accurate mathematical model that describes its dynamic characteristics. This can be achieved by analyzing the working principle and exploring the influence of critical parameters. The paper introduces the composition and working principle of a self-supplied electro-hydraulic servo variable displacement pump. It then establishes a mathematical model of the whole pump, with a detailed analysis and modeling of the critical variable mechanism and the swash plate assembly’s load moment. A simulation model was created to examine the impact of crucial structural parameters, such as the offset spring’s stiffness and control piston’s diameter, on the output characteristics of the intelligent pump. An experimental platform was also constructed, and the experimental results confirm the accuracy of the SAIP model presented in this paper. The investigation of the output characteristics fully reveals the dynamic performance of the SAIP. This provides the basis for the subsequent design of high-performance flow and pressure control strategies and aids in researching intelligent aircraft hydraulic systems. Full article

Variable Angle Tow (VAT) laminates offer a promising alternative to classical straight-fiber composites in terms of design and performance. However, analyzing these structures can be more complex due to the introduction of new design variables. Carrera’s unified formulation (CUF) has been successful in previous works for buckling, vibrational, and stress analysis of VAT plates. Typically, one-dimensional (1D) and two-dimensional (2D) CUF models are used, with a linear law describing the fiber orientation variation in the main plane of the structure. The objective of this article is to expand the CUF 2D plate finite elements family to perform free vibration analysis of composite laminated plate structures with curvilinear fibers. The primary contribution is the application of Reissner’s mixed variational theorem (RMVT) to a CUF finite element model. The principle of virtual displacements (PVD) and RMVT are both used as variational statements for the study of monolayer and multilayer VAT plate dynamic behavior. The proposed approach is compared to Abaqus three-dimensional (3D) reference solutions, classical theories and literature results to investigate the effectiveness of the developed models. The results demonstrate that mixed theories provide the best approximation of the reference solution in all cases. Full article

Variable stiffness composite laminates can improve the structural performance of composite structures by expanding the design space. This work explores the application of variable stiffness laminated composite structures to maximize the fundamental frequency by optimizing the tow angle. To this end, an optimization framework is developed to design the fiber angle for each layer based on the maximization of the fundamental frequency. It is assumed that the design process includes the manufacturing constraints encountered in the automated fiber placement process and a linear fiber angle variation. The current study improves existing results by considering embedded gap defects within the optimization framework. The plates are assumed symmetric, with clamped and simply supported boundary conditions. The optimal results and a comparison between the non-steered and steered plates with and without gaps are presented. Results show that, although gaps deteriorate the structural performance, fiber steering can still lead to an increase in the fundamental frequency depending on the plate’s geometry and boundary conditions. Full article

This paper proposes a novel density-based concurrent topology optimization method to support the two-scale design of composite plates for vibration mitigation. To have exceptional damping performance, dynamic compliance of the composite plate is taken as the objective function. The complex stiffness model is used to describe the material damping and accurately consider the variation of structural response due to the change of damping composite material configurations. The mode superposition method is used to calculate the complex frequency response of the composite plates to reduce the heavy computational burden caused by a large number of sample points in the frequency range during each iteration. Both microstructural configurations and macroscopic distribution are optimized in an integrated manner. At the microscale, the damping layer consists of periodic composites with distinct damping and stiffness. The effective properties of the periodic composites are homogenized and then are fed into the complex frequency response analysis at the macroscale. To implement the concurrent topology optimization at two different scales, the design variables are assigned for both macro- and micro-scales. The adjoint sensitivity analysis is presented to compute the derivatives of dynamic compliance of composite plates with respect to the micro and macro design variables. Several numerical examples with different excitation inputs and boundary conditions are presented to confirm the validity of the proposed methodologies. This paper represents a first step towards designing two-scale composite plates with optional dynamic performance under harmonic loading using an inverse design method. Full article

Nowadays, the application of composite materials and light-weight structures is required in those industrial applications where the primary design aims are weight saving, high stiffness, corrosion resistance and vibration damping. The first goal of the study was to construct a new light-weight structure that utilizes the advantageous characteristics of Carbon Fiber Reinforced Plastic (CFRP) and Aluminum (Al) materials; furthermore, the properties of sandwich structures and cellular plates. Thus, the newly constructed structure has CFRP face sheets and Al stiffeners, which was manufactured in order to take experimental measurements. The second aim of the research was the elaboration of calculation methods for the middle deflection of the investigated sandwich-like structure and the stresses that occurred in the structural elements. The calculation methods were elaborated; furthermore, validated by experimental measurements and Finite Element analysis. The third main goal was the elaboration of a mass and cost optimization method for the investigated structure applying the Flexible Tolerance optimization method. During the optimization, seven design constraints were considered: total deflection; buckling of face sheets; web buckling in stiffeners; stress in face sheets; stress in stiffeners; eigenfrequency of the structure and constraints for the design variables. The main added values of the research are the elaboration of the calculation methods relating to the middle deflection and the occurred stresses; furthermore, elaboration of the optimization method. The primary aim of the optimization was the construction of the most light-weighted structure because the new light-weight sandwich-like structure can be utilized in many industrial applications, e.g., elements of vehicles (ship floors, airplane base-plate); transport containers; building constructions (building floors, bridge decks). Full article

It is well known that fabrication processes inevitably lead to defects in the manufactured components. However, thanks to the new capabilities of the manufacturing procedures that have emerged during the last decades, the number of imperfections has diminished while numerical models can describe the ground truth designs. Even so, a variety of defects has not been studied yet, let alone the coupling among them. This paper aims to characterise the buckling response of Variable Stiffness Composite (VSC) plates subjected to spatially varying fibre volume content as well as fibre misalignments, yielding a multiscale sensitivity analysis. On the one hand, VSCs have been modelled by means of the Carrera Unified Formulation (CUF) and a layer-wise (LW) approach, with which independent stochastic fields can be assigned to each composite layer. On the other hand, microscale analysis has been performed by employing CUF-based Mechanics of Structure Genome (MSG), which was used to build surrogate models that relate the fibre volume fraction and the material elastic properties. Then, stochastic buckling analyses were carried out following a multiscale Monte Carlo analysis to characterise the buckling load distributions statistically. Eventually, it was demonstrated that this multiscale sensitivity approach can be accelerated by an adequate usage of sampling techniques and surrogate models such as Polynomial Chaos Expansion (PCE). Finally, it has been shown that sensitivity is greatly affected by nominal fibre orientation and the multiscale uncertainty features. Full article

The operational performance of cantilever composite structures can benefit from both stiffness tailoring and geometric design, yet, this potential has not been fully utilized in existing studies. The present study addresses this problem by simultaneously optimizing layer and taper angles of cantilever laminates. The design objective is selected as minimizing the average deflection of the tip edge subjected to shear loads while keeping the length and total volume constant. The plate stiffness properties are described by lamination parameters to eliminate the possible solution dependency on the initial assumptions regarding laminate configuration. The responses are computed via finite element analyses, while optimal design variables are determined using genetic algorithms. The results demonstrate that the plate aspect ratio significantly influences the effectiveness of stiffness tailoring and tapering as well as the optimal layer and taper angles. In addition, concurrent exploitation of the lamination characteristics and plate geometry is shown to be essential for achieving maximum performance. Moreover, individual and simultaneous optimization of layer and taper angles produce different optimal results, indicating the possible drawback of using sequential approaches in similar composite design problems. Full article

This research work has two main objectives, being the first related to the characterization of variable stiffness composite plates’ behavior by carrying out a comprehensive set of analyses. The second objective aims at obtaining the optimal fiber paths, hence the characteristic angles associated to its definition, that yield maximum fundamental frequencies, maximum critical buckling loads, or minimum transverse deflections, both for a single ply and for a three-ply variable stiffness composite. To these purposes one considered the use of the first order shear deformation theory in connection to an adaptive single objective method. From the optimization studies performed it was possible to conclude that significant behavior improvements may be achieved by using variable stiffness composites. Hence, for simply supported three-ply laminates which were the cases where a major impact can be observed, it was possible to obtain a maximum transverse deflection decrease of 11.26%, a fundamental frequency increase of 5.61%, and a buckling load increase of 51.13% and 58.01% for the uniaxial and biaxial load respectively. Full article
