Search Results (45)

This study utilizes the Standard k-ε turbulence model and ANSYS CFX software to tackle silt erosion in the top cover clearances of guide vane of the Francis turbine at Genda Power Station (Minjiang River Basin section, 103°17′ E and 31°06′ N) under sediment-laden flow conditions. A numerical simulation of a solid–liquid two-phase flow along the whole flow route was performed under rated operating circumstances to examine the impact of varying guide vane end clearance heights (0.3 mm, 0.5 mm, and 1.0 mm) on internal flow patterns and sediment erosion characteristics. The simulation parameters employed an average sediment concentration of 2.9 kg/m³ and a median particle size of 0.058 mm, indicative of the flood season. The findings demonstrate that augmenting the clearance height intensifies leaky flow and secondary flow, resulting in a 0.49% reduction in efficiency. As the gap expanded from 0.3 mm to 1.0 mm, the leakage flow velocity notably increased to 40 m/s, exacerbating flow separation, enlarging the vortex structures in the vaneless space, and augmenting the sediment velocity gradient and concentration, consequently heightening the risk of erosion. An experimental setup was devised based on the numerical results, and the dynamic resemblance between the constructed test section and the prototype turbine was confirmed for flow velocity, concentration, and Reynolds number. Tests on sediment erosion revealed that the erosion resistance of the anti-sediment erosion material 04Cr13Ni5Mo markedly exceeded that of the base cast steel, especially in high-velocity areas. This study delivers a systematic, quantitative analysis of clearance effects on flow and erosion, along with an experimental wear model specifically for the Gengda Power Station, thereby providing direct theoretical support and engineering guidance for its wear protection strategy and maintenance planning. Full article

Understanding the interaction between submerged water jets and cohesive deep-sea sediment is critical for optimizing deep-sea polymetallic nodule hydraulic mining techniques. This research investigated the distinct erosion behavior of cohesive sediments through laboratory experiments and numerical simulations. Cohesive deep-sea sediments were simulated using bentonite–kaolinite mixtures. A series of laboratory experiments, including vane shear tests and viscosity tests under varying moisture content, were conducted to assess the sediments’ mechanical properties. Experimental submerged water jet erosion tests provided basic data for validating the numerical simulations. A Eulerian multi-fluid (EMF) model was implemented to capture sediment–water jet interactions under varying operational parameters, including jet velocities and nozzle heights. The erosion process was found to comprise three distinct stages, including rapid erosion, steady erosion, and stabilization. Two distinct erosion mechanisms were identified, depending on the jet intensity, which affected the depth and shape of the erosion pits. Quantitative analysis revealed that erosion depth exhibits an approximately linear relationship with jet velocity and nozzle height, whereas the erosion diameter shows nonlinear characteristics. These findings enhance the fundamental understanding of cohesive sediment responses under hydraulic disturbances, providing crucial insights for the design and optimization of efficient deep-sea mining systems. Full article

High-quality observational datasets are essential for climate research and models, but validating and filtering decades of meteorological measurements is an enormous task. Advances in machine learning provide opportunities to expedite and improve quality control while offering insight into non-linear interactions between the meteorological variables. The Cabauw Experimental Site for Atmospheric Research in the Netherlands, known for its 213 m observation mast, has provided in situ observations for over 50 years. Despite high-quality instrumentation, measurement errors or non-representative data are inevitable. We explore machine-learning-assisted quality control, focusing on wind vane stalling at 10 m height. Wind vane stalling is treated as a binary classification problem as we evaluate five supervised methods (Logistic Regression, K-Nearest Neighbour, Random Forest, Gaussian Naive Bayes, Support Vector Machine) and one semi-supervised method (One-Class Support Vector Machine). Our analysis determines that wind vane stalling occurred 4.54% of the time annually over 20 years, often during stably stratified nocturnal conditions. The K-Nearest Neighbour and Random Forest methods performed the best, identifying stalling with approximately 75% accuracy, while others were more affected by data imbalance (more non-stalling than stalling data points). The semi-supervised method, avoiding the effects of the inherent data imbalance, also yielded promising results towards advancing data quality assurance. Full article

Sediment-induced erosion is a primary cause of failure in the flow-passage components of Francis turbine units. This study adopted the Realizable k–ε turbulence model to numerically simulate the effects of sediment-induced erosion on the guide components of Francis turbines. Specifically, using flow similarity theory, a testing device suitable for studying the sediment-induced erosion behavior of turbine vanes was designed, and the similarity between the flow fields of actual vanes and testing device vanes was validated. The results revealed a high degree of consistency between the near-wall flow velocities and sediment volume fractions experienced by both vanes at 0.5 vane height. For instance, the midsection of the suction side of the stay and guide vanes exhibited relatively stable velocities of 12.5 m/s and 42 m/s, respectively. Further, sediment volume fractions at the leading edge of the stay and guide vanes reached 0.015, respectively, owing to the impact of sediment-laden flow. Overall, the proposed testing device design methodology can predict the operational lifespan of actual vanes and assess the wear resistance of various coating materials. These findings provide valuable scientific guidance for optimizing the design and operation of hydropower plants. Full article

In order to explore the influence of change in the structural parameters ofguide vane cyclones on the cyclone spinning effect, this paper mainly used numerical simulations and physical experiments to analyze the energy of the hydrodynamic flow of acyclone with different guide vane heights by taking the structuralparameters of the guide vane height as the research object. The results show that the rotational kinetic energy of the water flow inside the cyclone was almost zero in the upstream and straight sections of the guide vane section, and it only existed in the leading edge section of the guide vane. In the twisted section of the guide vane, the rotational kinetic energy increased along the flow path, while it decreased in the downstream section of the guide vane. An increase in the height of the guide vanes led to an increase in local mechanical energy loss at the leading and trailing edges of the guide vanes of the cyclone. In the guide vane section, the mechanical energy loss of the water flow remained almost constant along the path, but the mechanical energy loss was faster for cyclones with greater heights. During the deflection of the guide vane, pressure energy was converted into kinetic energy, and the higher the height of the guide vane, the greater the kinetic energy growth and mechanical energy consumption. The proportion of additional mechanical energy loss in the total loss increased with the increase in guide vane height, and the influence of guide vane height was greater than that of the Reynolds number. The mechanical efficiency ηdecreased with the increase in guide vane height, whereas the mechanical efficiency increased slightly with the increase in Reynolds number. The research results in this paper provide a theoretical basis for further optimizing the structural parameters of cyclones. Full article

This paper introduces the prototype design, magnetic field analysis and experimental test of a double-rotating ferrofluid vane micropump with an embedded fixed magnet. The micropump is based on the working principle of a positive-displacement pump, as well as the magnetic characteristics and flow properties of magnetic fluid. Through the numerical analysis of the pump cavity magnetic field and the experimental test, the structural parameters of the micropump are optimized reasonably. The pumping flow and pumping height of the micropump were characterized at different driving speeds. The maximum pumping flow rate is approximately 410 μL/min, and the maximum pumping height is approximately 111.4 mm water column. The micropump retains the advantages of simple structure, easy manufacture, flexible control, self-sealing, self-lubrication, low heat production, etc., and can block the pumped liquid backflow. The resulting double-rotating ferrofluid blades can improve pumping efficiency and pumping capacity, and can improve pumping reliability and stability to a certain extent. Full article

The energy efficiency of water supply systems in high-rise residential buildings has become a significant concern for sustainable development in recent times. This work presents a numerical investigation on the influence of diffuser vane height on flow variation and hydraulic loss in the volute for a water supply centrifugal pump. Experiments and numerical simulations were conducted with four different vane height ratios. The numerical results were validated against experimental data. The hydraulic losses of different flow components were numerically evaluated at varying guide vane blade heights. The changes in flow patterns within the volute and the resulting discrepancies in hydraulic losses due to variations in the inlet flow conditions at different blade heights were studied. The findings indicate that the total pressure drop within the volute is affected significantly. Compared to traditional guide vanes, the reduced height vanes can reduce the hydraulic loss in the volute by nearly 75%. Once the vane height is reduced, the high-pressure gradient is improved, and the small-scale vortex vanishes. The influence area of the large-scale vortex in the volute outlet pipe decreases, leading to a weakening of the deflection of the main flow and ultimately resulting in reduced hydraulic loss. Full article

In turbomachinery, geometric variances of the blades, due to manufacturing tolerances, deterioration over a lifetime, or blade repair, can influence overall aerodynamic performance as well as aeroelastic behaviour. In cooled turbine blades, such deviations may lead to streaks of high or low temperature. It has already been shown that hot streaks from the combustors lead to inhomogeneity in the flow path, resulting in increased blade dynamic stress. However, not only hot streaks but also cold streaks occur in modern aircraft engines due to deterioration-induced widening of cooling holes. This work investigates this effect in an experimental setup of a five-stage axial turbine. Cooling air is injected through the vane row of the fourth stage at midspan, and the vibration amplitudes of the blades in rotor stage five are measured with a tip-timing system. The highest injected mass flow rate is 2% of the total mass flow rate for a low-load operating point. The global turbine parameters change between the reference case without cooling air and the cold streak case. This change in operating conditions is compensated such that the corrected operating point is held constant throughout the measurements. It is shown that the cold streak is deflected in the direction of the hub and detected at 40% channel height behind the stator vane of the fifth stage. The averaged vibration amplitude over all blades increases by 20% for the cold streak case compared to the reference during low-load operating of the axial turbine. For operating points with higher loads, however, no increase in averaged vibration amplitude exceeding the measurement uncertainties is observed because the relative cooling mass flow rate is too low. It is shown that the cold streak only influences the pressure side and leads to a widening of the wake deficit. This is identified as the reason for the increased forcing on the blade. The conclusion is that an accurate prediction of the blade’s lifetime requires consideration of the cooling air within the design process and estimation of changes in cooling air mass flow rate throughout the blade’s lifetime. Full article

The promotion and use of liquid feeding face the challenge of insufficiently stable delivery. This issue can be resolved, in part, by using the spiral flow produced by a spiral pipe (SPP). The aim of this study is to investigate how the structural characteristics of the spiral pipe affect the flow state of the liquid feed, and for this purpose, the computational fluid dynamics (CFD) technique has been employed and the liquid feed delivery process has been simulated by means of an Eulerian two-fluid model The results reveal a significant improvement in the slurry’s homogeneity as it traveled through a spiral pipe compared with a straight pipe (STP). The swirl number normally increased with the number, length, height, and angle of the spiral pipe’s guide vanes. The solid-phase distribution was more homogeneous when values of N = 1, L = 1D, H = 3/8R, and θ = 20° were used, respectively, and the COV within 10D downstream of the outlet of the spiral pipe was 3.902% smaller than that of the straight pipe. The results of this study can be used as a reference for the design of liquid feed-conveying pipes. Full article

The twisted wind flow (TWF), referring to the phenomenon of wind direction varying with height, is a common feature of atmospheric boundary layer (ABL) winds, noticeably affecting the wind-resistant structural design and the wind environment assessment. The TWF can be effectively simulated by a guide vane system in wind tunnel tests, but the proper design and configuration of the guide vanes pose a major challenge as practical experience in using such devices is still limited in the literature. To address this issue, this study aims to propose an approach to determining the optimal wind tunnel setup for TWF simulations using a numerical wind tunnel, which is a replica of its physical counterpart, using computational fluid dynamics (CFD) techniques. By analyzing the mechanisms behind guide vanes for generating TWF based on CFD results, it was found that the design must take into account three key parameters, namely, (1) the distance from the vane system to the side wall, (2) the distance from the vane system to the model test region, and (3) the separation between the vanes. Following the optimal setup obtained from the numerical wind tunnel, TWF profiles matching both the power-law and Ekman spiral models, which, respectively, reflect the ABL and wind twist characteristics, were successfully generated in the actual wind tunnel. The findings of this study provide useful information for wind tunnel tests as well as for wind-resistant structural designs and wind environment assessment. Full article

It is of great significance to obtain an accurate stress assessment when replacing traditional metal components with ceramic matrix composites (CMCs) in turbine engines. The current study aims to investigate the stress characteristics of CMCs turbine vanes with multilayer-structured environmental barrier coatings (EBCs) using numerical simulation techniques. A three-dimensional finite element model of CMCs turbine vanes coated with EBCs was formulated. The distribution of thermal residual stresses generated during the manufacturing process of EBCs and the distribution of stresses under different loading conditions were calculated and compared. The results show that the hoop stress (σ11) and spanwise stress (σ22) in the turbine vanes are significantly higher than the through-thickness stress (σ33) under coupled loads. The maximum hoop stress (σ11) is approximately 346 MPa. The thermal residual stress induced during the EBCs manufacturing process reaches a maximum of approximately 360 MPa. The loading conditions significantly influence the stress distribution of EBCs, and the stress distribution of EBCs exhibits certain regularities at different heights under varying loading conditions. These results enable us to gain a deeper understanding of the failure mechanism of CMCs/EBCs turbine vanes and can improve the optimization capabilities for these components. Full article

A novel compound multi-jet impingement system for enhanced cooling of a flat surface by augmenting its area with cylindrical protrusions (CPs) equipped with coaxial guide vanes (CGVs) and reducing deflection of jets by crossflow has been developed for high-heat removal applications. The cooling performance of coaxial circular jets impinging on the top faces of CPs placed in hexagonal configuration on a flat plate is evaluated by three-dimensional (3D) computational fluid dynamics (CFD) simulations. Jets impinging on the top faces of the protrusions are directed to their lateral faces and then to the base plate by the CGVs around the protrusions, resulting in up to 62.8% improvement in heat transfer rate with a minor increase in pressure drop. Effects of protrusion height and diameter on the pressure drop and cooling performance are studied for jet Reynolds ($Re$ number range of 5000–20,000. Due to both shortened jet impingement lengths as the height of protrusions is increased and directing the expended fluid away from the impinging jets by CGVs, adverse effects of jet–crossflow interactions on cooling performance and fluid pumping power are significantly reduced. Performance evaluation criterion ($PEC$) of the novel compound multi-jet impingement cooling system (CMJICS) can be as high as 1.52. Full article

Cyclones are devices used in various industries to remove particulate matter from gases and liquids. Commonly used in the power generation, cement, and mining industries, cyclones improve the efficiency and longevity of equipment by removing dust and other small particles that can cause wear and damage. Among centrifugal separation, reverse-flow cyclones are primarily used for particle separation, which can reach heights of several meters on an industrial scale and therefore, are difficult to access for maintenance. A uniflow centrifugal segregation system avoids these drawbacks of reverse-flow cyclones since their accessibility is good and their height usually does not exceed their diameter. The efficiency is a critical aspect of separating systems. This study systematically examines the collection efficiency for particles ranging from 1 $\mathsf{\mu }\mathrm{m}$ to 29 $\mathsf{\mu }\mathrm{m}$ in diameter based on varying vane angles of the swirl inducer at flow rates ranging from 130 $\mathrm{L}$${\mathrm{s}}^{-1}$ to 236 $\mathrm{L}$${\mathrm{s}}^{-1}$. Full article

The high-pressure polyethylene process uses cyclone separators to separate ethylene gas, polyethylene, and its oligomers. The oligomers larger than 10 microns that cannot be separated must be filtered through a filter to prevent them from entering the compressor and affecting its normal operation. When the separation efficiency of the cyclone separator is low, the filter must be cleaned more frequently, which will reduce production efficiency. Research shows that improving the separation efficiency of the separator is beneficial for the separation of small-particle oligomers and reduces the frequency of filter cleaning. For this reason, Computational Fluid Dynamics simulations were performed for 27 sets of cyclone separators to determine the effects of eight structural factors (cylinder diameter, cylinder height, cone diameter, cone height, guide vane height, guide vane angle, exhaust pipe extension length, and umbrella structure height) on separation efficiency and pressure drop. The equations for separation efficiency and pressure drop using these eight factors and the equations based on energy-efficiency parameters were determined. The optimization analysis showed that separation efficiency can be improved by 98.7% under the premise that the pressure drop is only increased by 8.2%. By applying the improved structure to the high-pressure polyethylene process, separation efficiency is increased by 17.7%, which could effectively reduce the frequency of filter cleaning for this process, and thereby greatly improve production efficiency. Full article

Large-eddy simulations (LES) were performed to study the turbulent flow in a channel of height H with a staggered array of pin fins with diameter D = H/2 as a function of heating loads that are relevant to the cooling of turbine blades and vanes. The following three heating loads were investigated—wall-to-coolant temperatures of T_w/T_c = 1.01, 2.0, and 4.0—where the Reynolds number at the channel inlet was 10,000 and the back pressure at the channel outlet was 1 bar. For the LES, two different subgrid-scale models—the dynamic kinetic energy model (DKEM) and the wall-adapting local eddy-viscosity model (WALE)—were examined and compared. This study was validated by comparing with data from direct numerical simulation and experimental measurements. The results obtained show high heating loads to create wall jets next to all heated surfaces that significantly alter the structure of the turbulent flow. Results generated on effects of heat loads on the mean and fluctuating components of velocity and temperature, turbulent kinetic energy, the anisotropy of the Reynolds stresses, and velocity-temperature correlations can be used to improve existing RANS models. Full article
