In order to exploit the deep underground space, the construction of ultra-deep excavation in Shanghai is growing rapidly. In multi-aquifer strata, deep excavations typically require dewatering of confined aquifers to ensure engineering safety. However, existing studies have seldom conducted in-depth analysis on the influence of the soil parameters and construction measures on the deformation of retaining structures. In this study, a three-dimensional hydro-mechanical numerical model was developed to evaluate the performances of excavation and dewatering of the foundation pit. The model was validated by comparing the calculated and measured wall deflections and groundwater drawdowns of a 45 m ultra-deep double-wall excavation in Shanghai. According to the characteristics of soil stratification and construction activities, three parameters were selected for subsequent analysis, including the hydraulic conductivity of aquitard below the bottom of the pit, the pumping rate in the second confined aquifer and the construction of TRD wall. The stress distributions on both sides of the diaphragm wall were examined to elucidate the deformation mechanism. The results indicate that the aquitard hydraulic conductivity directly affects the effective stress of the overlying aquifer, which plays a crucial role in resisting wall deflection. An increase in the hydraulic conductivity leads to smaller effective stress, greater wall deflection and larger ground settlement. While an appropriately increased pumping rate enhances effective stress, over-pumping may induce excessive wall deflection at depth and disproportionate ground settlement. The TRD wall is quite useful in terms of waterproofing but the effect on deformation control is limited. The findings of this study provide valuable insights for engineering practices and the optimization of deep excavation construction measures in multi-aquifer strata. Full article

The UK net zero strategy aims to fully decarbonize the power system by 2035, anticipating a 40–60% increase in demand due to the growing electrification of the transport and heating sectors over the next thirteen years. This paper provides a detailed technical and economic analysis of the role of energy storage technologies and transmission lines in balancing the power system amidst large shares of intermittent renewable energy generation. The analysis is conducted using the cost-optimizing energy system modelling framework REMix, developed by the German Aerospace Center (DLR). The obtained results of multiple optimization scenarios indicate that achieving the lowest system cost, with a 73% share of electricity generated by renewable energy sources, is feasible only if planning rules in England and Wales are flexible enough to allow the construction of 53 GW of onshore wind capacity. This flexibility would enable the UK to become a net electricity exporter, assuming an electricity trading market with neighbouring countries. Depending on the scenario, 2.4–11.8 TWh of energy storage supplies an average of 11% of the electricity feed-in, with underground hydrogen storage representing more than 80% of that total capacity. In terms of storage converter capacity, the optimal mix ranges from 32 to 34 GW of lithium-ion batteries, 13 to 22 GW of adiabatic compressed air energy storage, 4 to 24 GW of underground hydrogen storage, and 6 GW of pumped hydro. Decarbonizing the UK power system by 2035 is estimated to cost $37–56 billion USD, with energy storage accounting for 38% of the total system cost. Transmission lines supply 10–17% of the total electricity feed-in, demonstrating that, when coupled with energy storage, it is possible to reduce the installed capacity of conventional power plants by increasing the utilization of remote renewable generation assets and avoiding curtailment during peak generation times. Full article

Sindh is in the lower reaches of the Indus River; it is most vulnerable to a variety of upstream water development challenges. The aim of this research was to determine aquifer characteristics in the command area of Tando Allahyar-II distributary within the culmination of underground water potential. The hydraulic properties of the aquifer as well as the susceptibility of the formation to tedious extraction and saltwater upcoming were recognized. Three pumping tests were performed at head, middle, and tail reaches along the selected distributary. The drawdowns were measured at head reach (5.1667 h), at middle reach (6.0 h), and at tail reach (19.667 h) of the selected distributary by performing the pumping tests. Groundwater levels were lower at the tail reach compared to those at the head and middle reaches, likely due to a higher concentration of tubewells in the lower reach. The head and middle reaches showed higher groundwater levels, possibly due to constant head conditions promoting infiltration and recharge. The pumping test versus drawdown analysis revealed that the tubewells should be run with 7-h (on) and 4-h (off) operation. Further, the tubewells at all reaches (head, middle, and tail) should be closed for a minimum of 4 h between operations. This strategy would allow safe groundwater extraction, maintain water quality, and prevent water table depletion in the study area. The hydrodynamic and hydro-salinity behaviors were scrutinized in PWMIN 5.3 (version) by means of the MODFLOW mode. The results were estimated to compare the calibration and validation simulation outcomes using measured data. The model was successfully calibrated, and the root mean square (RMS) value of the head tubewell varied between 0.024 and 0.108, whereas it speckled between 0.0166 and 0.0349 for the middle tubewell and between 0.0659 and 0.0069 for the tail tubewell. The RMS values for hydrodynamic behavior for the head, middle, and tail reaches were less than 10%. These values represent a suitable match between the observed and simulated heads when a water table depletion of 1 to 2 m was observed due to extreme pumping. However, the average relative error values, for all validated procedures, were less than 10%. Full article

Various hydrogeological problems like groundwater inflow, water table drawdown, and water pressure redistribution may be encountered in the construction of hydraulic projects. How to accurately predict the occurrence of groundwater inflow and assess the drainage effect during construction are still challenging problems for engineering designers. Taking the Jinzhai pumped storage power station (JPSPS) of China as an example, this paper aims to use different methods to calculate the water inflow rates of an underground powerhouse and evaluate the drainage effect caused by tunnel inflow during construction. The methods consist of the analytical formulas, the site groundwater rating (SGR) method, and the Signorini type variational inequality formulation. The results show that the analytical methods considering stable water table may overestimate the water inflow rates of caverns in drained conditions, whereas the SGR method with available hydro-geological parameters obtains a qualitative hazard assessment in the preliminary phase. The numerical solutions provide more precise and reliable values of groundwater inflow considering complex geological structures and seepage control measures. Moreover, the drainage effects, including a seepage-free surface, pore water pressure redistribution, and hydraulic gradient, have been accurately evaluated using various numerical synthetic cases. Specifically, the faults intersecting on underground caverns and drainage structures significantly change the groundwater flow regime around caverns. This comparative study can not only exactly identify the capabilities of the methods for cavern inflow in drained conditions, but also can comprehensively evaluate the drainage effect during cavern construction. Full article

Due to its poor hydro-physical properties and other characteristics, argillaceous dolomite is susceptible to seepage failure under high water pressure, affecting the seepage stability of a rock mass. To ensure the safety of the project, when the argillaceous dolomite is present, it is necessary to study the conditions pertaining to its seepage failure. Taking the argillaceous dolomite of Jurong Pumped Storage Power Station as the research object, the spatial distribution, occurrence, scale, degree of weathering, and mechanical and hydrogeological characteristics of the argillaceous dolomite were studied. Through on-site water pressure tests and laboratory variable head tests, the permeability characteristics of argillaceous dolomite were analyzed, and the hydraulic conductivity of the argillaceous dolomite in the upper reservoir and underground powerhouse areas was quantified. The argillaceous dolomite specimens were collected, and seepage failure tests were conducted to determine the critical water pressure for its seepage failure. Based on the results of the laboratory tests, a numerical model of groundwater flow was established. By changing the water level of the upper reservoir and the measures of the anti-seepage and drainage, the seepage stability of the argillaceous dolomite was discussed. The actual water pressure of argillaceous dolomite in the underground powerhouse area was identified during the operation of the Jurong pumped-storage power station. The calculations show that when fully enclosed anti-seepage and drainage measures are taken for the underground powerhouse, the maximum head of water is 98 m, which is lower than the critical water pressure of seepage failure for the argillaceous dolomite. Therefore, no seepage failure will occur. The results provide a scientific basis for the anti-seepage and drainage design of the underground powerhouse area. Full article

In ancient riverbed areas, the hydro-geological conditions are extremely complex because of the cutting of ancient river channels during the sedimentary process. How to lower groundwater level in water-riched gravel-confined aquifer during deep excavation is vital for underground engineering. Groundwater flow patterns had to be understood during foundation pit dewatering. This paper presents a field case study conducted at the deep foundation pit of the Qianjiang Century City station on Hangzhou Metro Line 6, which is notable for its 52 m deep unclosed waterproof curtain. A total of 34 pumping wells were installed within the pit. During the tests, one well was subjected to a pumping well, while the others served as observation wells. The research included two sets of multi-depth pumping tests, which differed in terms of their filter lengths, aimed at investigating the flow pattern around pump wells and the roots of diaphragm walls. The study found that the use of longer filters, higher pump rates, and filters placed nearer to aquifer roofs enhances dewatering efficiency and minimizes impact on the surrounding geological environment. This paper introduces a novel concept known as the diaphragm wall–pumping well effect, which regulates the water head outside the pit and the subsidence, thereby optimizing the drawdown of the deep foundation pit with an unclosed waterproof curtain. The findings were applied in the foundation pit dewatering of Qianjiang Century City station, and the drawdown in and outside the pit was effectively controlled. Full article

Low-carbon energy transitions taking place worldwide are primarily driven by the integration of renewable energy sources such as wind and solar power. These variable renewable energy (VRE) sources require energy storage options to match energy demand reliably at different time scales. This article suggests using a gravitational-based energy storage method by making use of decommissioned underground mines as storage reservoirs, using a vertical shaft and electric motor/generators for lifting and dumping large volumes of sand. The proposed technology, called Underground Gravity Energy Storage (UGES), can discharge electricity by lowering large volumes of sand into an underground mine through the mine shaft. When there is excess electrical energy in the grid, UGES can store electricity by elevating sand from the mine and depositing it in upper storage sites on top of the mine. Unlike battery energy storage, the energy storage medium of UGES is sand, which means the self-discharge rate of the system is zero, enabling ultra-long energy storage times. Furthermore, the use of sand as storage media alleviates any risk for contaminating underground water resources as opposed to an underground pumped hydro storage alternative. UGES offers weekly to pluriannual energy storage cycles with energy storage investment costs of about 1 to 10 USD/kWh. The technology is estimated to have a global energy storage potential of 7 to 70 TWh and can support sustainable development, mainly by providing seasonal energy storage services. Full article

Bayesian Optimization (BO) with Gaussian process regression is a popular framework for the optimization of time-consuming cost functions. However, the joint exploitation of BO and parallel processing capabilities remains challenging, despite intense research efforts over the last decade. In particular, the choice of a suitable batch-acquisition process, responsible for selecting promising candidate solutions for batch-parallel evaluation, is crucial. Even though some general recommendations can be found in the literature, many of its hyperparameters remain problem-specific. Moreover, the limitations of existing approaches in terms of scalability, especially for moderately expensive objective functions, are barely discussed. This work investigates five parallel BO algorithms based on different batch-acquisition processes, applied to the optimal scheduling of Underground Pumped Hydro-Energy Storage stations and classical benchmark functions. Efficient management of such energy-storage units requires parallel BO algorithms able to find solutions in a very restricted time to comply with the responsive energy markets. Our experimental results show that for the considered methods, a batch of four candidates is a good trade-off between execution speed and relevance of the candidates. Analysis of each method’s strengths and weaknesses indicates possible future research directions. Full article

The urgent energy transition needs a better penetration of renewable energy in the world’s energy mix. The intermittency of renewables requires the use of longer-term storage. The present system uses water displacement, in a lined rock cavern or in an aerial pressurised vessel, as the virtual piston of compressor and expander functions in a carbon dioxide heat pump cycle (HPC) and in an organic transcritical cycle (OTC). Within an impermeable membrane, carbon dioxide is compressed and expanded by filling and emptying pumped-hydro water. Carbon dioxide exchanges heat with two atmospheric thermal storage pits. The hot fluid and ice pits are charged by the HPC when renewable energy becomes available and discharged by the OTC when electricity is needed. A numerical model was built to replicate the system’s losses and to calculate its round-trip efficiency (RTE). A subsequent parametric study highlights key parameters for sizing and optimisation. With an expected RTE of around 70%, this CO₂ PHES (pumped-hydro electricity storage) coupled with PTES (pumped thermal energy storage) could become a game-changer by allowing the efficient storage of intermittent renewable energy and by integrating with district heating and cooling networks, as required by cities and industry in the future. Full article

This study researches the concept of underground pumped-storage hydro power plants in closed-down underground hard coal mines in Germany. After a review on how this could be realized technically, an economic feasibility analysis is presented, with a particular focus on the costs for the underground storage reservoir. The analysis is performed for different lower (i.e., underground) reservoir sizes and temporal arbitrage potentials (peak/off-peak electricity price spreads), and cost uncertainty is dealt with by means of a Monte Carlo simulation for two distinct head heights. The findings regarding costs and acceptability are compared with those of a classic (on-surface) pumped-storage hydro power plant in a mountainous area. Based on a techno-economic evaluation we conclude that under favorable conditions the realization of underground pumped-storage hydro power (UPSHP) plants seems both technically feasible and economically reasonable. More specifically, an extension of a tubular system seems the most promising option. A UPSHP plant in a mineshaft is probably slightly more expensive than a conventional one, an outcome that depends strongly on the feasible head height. However, the significant reduction of the adverse impacts on the landscape and on local residents, as well as a potentially large number of feasible sites in flat terrain, could make UPSHPs an interesting option for the future energy transition, not just in Germany but worldwide at sites where underground mining is being abandoned. Full article

We review the status of a 1.4 GW, 8 GWh underground pumped hydro storage (U-PHS) project in the southern Netherlands, which has been under development since the 1980s. Its history shows how the prospect of a large-scale U-PHS for The Netherlands (a country whose proverbial flatness prohibits PHS) has been attractive in every decade, based on proven technology in a subsurface location with validated properties, and solid analysis of its economics. Although the ongoing energy transition clearly requires massive electricity storage, (U-)PHS projects are challenging investment propositions, in The Netherlands, as elsewhere. This case study illustrates a point of general relevance, namely that although the project execution risk, related to uncertainty with respect to subsurface integrity, is very low, the transition risk, associated with the intrinsic uncertainties of an electricity system in transition, is significant. We point out mitigation strategies for both risk categories. Full article

This work aims at the economic evaluation of a semi-underground pumped hydro storage power plant erected in an abandoned open-pit mine. For the exploratory model-based analysis, we develop and apply both a simple deterministic and a stochastic net present value (NPV) approach, the latter of which uses a Monte Carlo simulation to account for revenue uncertainty from electricity price fluctuations. The analytical framework developed is applied to two promising sites in the Rheinland region in Germany, Hambach and Inden, making reasonable parameter value assumptions and considering and ignoring the lengthy duration of lower reservoir flooding. The investor’s value-at-risk is computed for alternative performance indicators (NPV, net cash recovery, profit-to-investment ratio, and specific production costs) to compare the different outcomes in terms of the project’s financial risk distribution. Calculations show that a semi-underground pumped hydro storage power plant in an abandoned open-pit mine can be constructed at reasonably low investment costs and operated at low specific production costs. However, because the investment has to be made long before the pit lake is (naturally) flooded—a process that for realistic flow rates may take up to 20 years—the project is highly uneconomical and would require substantial subsidies, as compared to a situation where flooding happens immediately. Full article

To avoid the geographical and topographical prerequisites of the conventional pumped hydro energy storage, the use of underground cavities as water reservoirs allows countries without steep topography, such as Belgium, to increase the potential of the energy storage capacity. Belgium abounds in disused mines and quarries convertible into water basins. In this article, two Belgian case studies are presented and discussed for their singularity. A slate quarry in Martelange is discussed in technical aspects proposing three operating scenarios. Moreover, a preliminary economic analysis of the underground pumped storage system and a greenhouse gas emission evaluation for the storage system’s lifetime are presented. The analysis for a 100 MW power plant estimates a total initial investment of over 12 million euros and two million of CO${}_2$ avoided over its lifetime. This article also proposes the use of the coal mine 500 m deep of Pérronnes-lez-Binche. The mine representation discussed here offers a high energy capacity, but the substantial head drop (from about 500 to 200 m) challenges the selection of the hydraulic turbomachinery. A 1D simulation computed in SIMSEN draws out the behaviour of the unusual hydraulic configuration of turbines in series. Full article

Renewable energy (wind and solar power, etc.) are developing rapidly around the world. However, compared to traditional power (coal or hydro), renewable energy has the drawbacks of intermittence and instability. Energy storage is the key to solving the above problems. The present study focuses on the compressed air energy storage (CAES) system, which is one of the large-scale energy storage methods. As a lot of underground coal mines are going to be closed in China in the coming years, a novel CAES system is proposed for application in roadways of the closing coal mines. The new system combines pumped-hydro and compressed-air methods, and features constant air pressure and temperature. Another specific character of the system is the usage of flexible bags to store the compressed air, which can effectively reduce air leakage. The governing equations of the system are derived, and the response of the system is analyzed. According to the equations, for a roadway with depth of 500 m and volume of 10,000 cubic meters, the power generation capacity of the CAES system is approximately 18 MW and the generating time is 1.76 h. The results show that the new CAES system proposed is reasonable, and provides a suitable way to utilize the underground space of coal mines. Full article

A fast-paced energy transition needs a higher penetration of renewables, of heating and cooling in the worldwide energy mix. With three novelties 1-of using shallow high-pressure LRC (Lined Rock Cavern) excavated close to storage needs, 2-of using a slow-moving CO₂ piston applying steady pressure on the hydro part of UPHES (Underground Pumped Hydro Energy Storage) and 3-of relying on inexpensive thermal stores for long-duration storage, CO₂ UPHES coupled with PTES (Pumped Thermal Electricity Storage) could become, at expected Capex cost of only 20 USD/kWh electrical, a game-changer by allowing the complete integration of intermittent renewable sources. Moreover, even though this early conceptual work requires validation by simulation and experimentation, CO₂ UPHES as well as UPHES-PTES hybrid storage could also allow a low-cost and low-emission integration of intermittent renewables with future district heating and cooling networks. Full article
