Driven by the rapid development of automotive fuel cells, compact and lightweight system demands require upgraded centrifugal air compressors, as conventional high speed motors at 50,000–80,000 rpm within 15 kW fail to meet current specifications. Since motor size and weight are dominated by torque, raising the rotational speed to improve power density has become the mainstream direction for ultra high speed permanent magnet synchronous motors (HSPMSMs), targeting over 100,000 rpm and 30 kW for fuel cell air compressor applications. This paper presents an 18-slot 2-pole HSPMSM with parallel magnetization, which achieves 35 kW rated power at 100,000 rpm. Electromagnetic performance, rotor mechanical strength, thermal behavior and rotor dynamics are systematically optimized by simulations and experiments. Full article

The permanent magnet synchronous linear motor (PMSLM) is a key technology for the ultra-high-speed acceleration in maglev transport systems over short distances. It has attracted significant research interest owing to its high power density, high efficiency, and excellent control performance. Nevertheless, the design of such motors faces several challenges. These include the accurate calculation of inductance parameters and the achievement of high thrust force density. To overcome these issues, this study first derives analytical expressions for per-unit-length inductance and thrust force. Based on these, key electromagnetic parameters and structural parameters of the motor are designed. A segmented design scheme is also proposed. A finite element model of a bilateral long-stator PMSLM is then established using Ansys Maxwell. Simulations are performed to analyze the motor’s back electromotive force (EMF), electromagnetic thrust force, inductance distribution, and induced voltage. The results show a good agreement between the simulation and theory. The error in inductance calculations ranges from −5.5% to +6.65%. The absolute error between the calculated and simulated thrust force values is below 0.8 kN. Furthermore, the non-uniformity in inductance distribution and the causes of thrust force fluctuation are investigated. Odd-order harmonics, such as the third and fifth, are identified in the induced voltage. This research offers a design methodology and simulation verification for ultra-high-speed PMSLMs. It lays a foundation for the future development of end-effect compensation and harmonic suppression strategies. Full article

The performance degradation of Permanent Magnet Synchronous Motors (PMSMs) is caused by nonlinear friction torque during low-speed operation, a phenomenon known as low-speed crawling. To address this issue, a composite compensation strategy based on a piecewise modeling approach is proposed in this paper. To accurately characterize the friction behavior, a dynamic learning rate neural network (DLRNN) is utilized for the ultra-low-speed region, while an optimal 5th-order polynomial model is established for the low-speed region. Building on this piecewise modeling, a composite control strategy with friction compensation is studied. This strategy employs a friction compensator for the feedforward compensation of the deterministic friction torque components. Furthermore, a reduced-order extended state observer (RESO) is designed to estimate and compensate for residual friction errors and random disturbance torques, thereby achieving high-precision motor control. Finally, experimental results on a surface-mounted PMSM validate that the proposed strategy effectively improves tracking accuracy and suppresses torque ripple near zero-speed, all while remaining within the computational constraints of standard industrial control hardware. Full article

Interior permanent magnet synchronous motors (IPMSMs) offer performance advantages such as saliency effect, high mechanical strength, and a wide speed regulation range. The magnetic and mechanical properties of the core material significantly influence IPMSM performance. By investigating the effects of different core materials on IPMSM performance, an optimal material combination can be identified to enhance the overall motor performance. This paper takes a $\overline{\mathrm{V}}$-shaped IPMSM for use as a main drive motor in new energy vehicles as the research object. First, the influence of the iron loss characteristics of non-oriented silicon steel (NOSS) on IPMSM performance is analyzed, and the material selection principles for the stator and rotor cores under this condition are summarized. Subsequently, the influence of the magnetic flux density characteristics of NOSS on IPMSM performance is analyzed, and the corresponding material selection principles for the stator and rotor cores are summarized. Furthermore, ultra-high-yield-strength NOSS is applied as the motor core material to reduce the width of the rotor magnetic flux barrier, and the resulting performance advantages for the IPMSM are analyzed. Finally, prototypes of the IPMSM are manufactured and tested to validate the results of the analysis. Full article

Permanent magnet synchronous motor (PMSM)-driven position servo systems in high-speed flight vehicles face severe challenges from extreme thermal environments, which induce significant parameter variations up to 25% (e.g., motor torque constant) and complex multi-scale disturbances. This paper proposes a novel adaptive robust control strategy integrating three key components: (1) an ultra-local model formulation motivated by physically consistent thermal effect analysis of electromagnetic, mechanical, and tribological parameters; (2) a dual-layer disturbance observer architecture comprising a third-order finite-time convergent extended state observer (FTCESO) for fast-varying disturbances and a σ-modification adaptive estimator for slow-varying thermal drifts; and (3) a global nonlinear integral terminal sliding mode controller with a cycloidal reaching law. Stability analysis based on homogeneous system theory and Lyapunov methods establishes practical finite-time convergence with explicit bounds. The experimental results on a TMS320F28335-based servo platform demonstrate that the proposed method reduces the maximum position deviation by 83–94% compared to PID, LADRC, and conventional SMC controllers under the tested disturbance conditions, achieving settling time reductions exceeding 90%. Under combined thermal drift and external loading, the proposed approach limits the maximum tracking error to below 0.45° while maintaining a steady-state error under 0.08°. Full article

The gimbal servo system in a control moment gyroscope (CMG) is critical for high-precision spacecraft attitude control, where comprehensive performance testing and evaluation are essential for ensuring spacecraft reliability and service life. Traditional motor testbenches exhibit limitations, whereas the electric motor emulator (EME) based on power electronic converters is a promising alternative for testing extreme operating conditions, such as ultra-low speed operation and fault scenarios. However, existing EME control methods suffer from limited system bandwidth and insufficient emulation accuracy, which limits their applicability. To address these issues, this paper proposes an improved current control strategy for the ultra-low speed permanent magnet synchronous motor (PMSM) emulator. First, a mathematical model of the EME based on the topology of the voltage source converter is established. Then, based on the deadbeat control concept, a deadbeat predictive current control (DPCC) strategy is developed to enhance the dynamic performance. Furthermore, to suppress the parameter mismatch disturbance, an optimization scheme based on a cascaded extended state observer (CESO) is introduced. The first-stage ESO is applied to estimate and compensate for total disturbances, while the second-stage ESO is a supplement to suppress the remaining disturbances in the EME system, which improves the robustness of the DPCC controller. Finally, the effectiveness of the improved emulation accuracy of the proposed method is verified through experiments. Full article

Conventional model-free control (MFC) is widely used in motor drives due to its simplicity and model independence, yet its performance suffers from imperfect disturbance estimation and input gain mismatch. To address these issues, this paper proposes an adaptive enhanced model-free speed control (AEMFSC) scheme based on an ultra-local model for permanent magnet synchronous motor (PMSM) drives. First, by integrating a nonlinear disturbance observer (NDOB) and a PD control law into the generalized model-free controller, an enhanced model-free speed controller (EMFSC) was developed to ensure closed-loop stability. Compared with a conventional MFSC, the proposed method eliminated steady-state errors, reduced the speed overshoot, and achieved faster settling with improved disturbance rejection. Second, to address the performance degradation induced by input gain $\alpha$ mismatch during time-varying load conditions, we developed an online parameter identification method for real-time $\alpha$ estimation. This adaptive mechanism enabled automatic controller parameter adjustment, which significantly enhanced the transient tracking performance of the PMSM drive. Furthermore, an algebraic-framework-based high-precision identification technique is proposed to optimize the initial $\alpha$ selection, which effectively reduces the parameter tuning effort. Simulation and experimental results demonstrated that the proposed AEMFSC significantly enhanced the PMSM’s robustness against load torque variations and parameter uncertainties. Full article

To improve the precision of the position and speed estimation in ultra-high-speed (UHS) permanent magnet synchronous motors (PMSM) without position sensors, multiple refinements to the traditional extended electromotive force (EEMF) estimation algorithm are proposed in this paper. The key improvements include discretization compensation, high-frequency harmonic filtering, and the real-time adjustment of the phase-locked loop (PLL) bandwidth. Firstly, a discrete model is introduced to address EMF cross-coupling issues. Secondly, an improved proportional resonant (IPR) controller eliminating static errors is utilized in place of the conventional proportional-integral (PI) controller and low-pass filter (LPF) to enable precise electromotive force extraction, effectively filtering high-frequency harmonics that arise in low carrier ratio conditions. Based on a standard PR design, the IPR controller offers a streamlined calculation for target leading angles in delay compensation schemes to effectively mitigate discretization and delay errors. Additionally, an adaptive phase-locked loop (AQPLL) dynamically adjusts its bandwidth during acceleration to balance noise rejection and phase delay, reducing position estimation errors and optimizing torque. Simulations and experimental analyses on a motor (90,000 rpm, 30 kW) validate the effectiveness of the proposed sensorless driving techniques and demonstrate enhanced performance in position and velocity estimation, compared to the conventional EEMF approach. Full article

Intersecting disciplines, as an important trend in the development of modern academic research and education, have exerted a profound and positive influence on scientific research activities. Based on control theory and fractional-order theory, this paper presents a novel approach for the speed regulation of a permanent magnet synchronous motor (PMSM) in the presence of uncertainties and external disturbances. The proposed method is a composite control based on a model-free sliding mode and a fractional-order ultra-local model. The model-free sliding mode is a control strategy that utilizes the sliding mode control methodology without explicitly relying on a mathematical model of the system being controlled. The fractional-order ultra-local model is a mathematical representation of a dynamic system that incorporates the concept of fractional-order derivatives. The core of the controller is a new type of fractional-order fast nonsingular terminal sliding mode surface, which ensures high robustness, quick convergence, while preventing singularity. Moreover, a novel fractional-order nonlinear extended state observer is proposed to estimate both internal and external disturbances of the fractional-order ultra-local model. The stability of the system is analyzed using both the Lyapunov stability theory and the Mittag–Leffler stability theory. The analysis confirms the convergence stability of the closed-loop system under the proposed control scheme. The comparison results indicate that the proposed composite control based on the fractional-order ultra-local model is a promising solution for regulating the speed of PMSMs in the presence of uncertainties and disturbances. Full article

Extended back electromotive force (EEMF)-based position sensorless field-oriented control (FOC) is widely utilized for ultra-high-speed surface-mounted permanent magnet synchronous motors (UHS-SPMSMs) driven fuel cell air compressors in medium-high speed applications. Unfortunately, the estimated position is imprecise due to too small EEMF under low speed operation. Hence, current-to-frequency (I-f) control is more suitable for startup. Conventional I-f methods rarely achieve the tradeoff between startup acceleration and load capacity, and the transition to sensorless FOC is mostly realized in the constant-speed stage, which is unacceptable for UHS-SPMSM considering the critical requirement of startup time. In this article, a new closed-loop I-f control approach is proposed to achieve fast and efficient startup. The frequency of reference current vector is corrected automatically based on the active power and the real-time motor torque, which contributes to damping effect for startup reliability. Moreover, an amplitude compensator of reference current vector is designed based on the reactive power, ensuring the maximum torque per ampere operation and higher efficiency. Furthermore, the speed PI controller is enhanced by variable bandwidth design for smoother sensorless transition. These theoretical advantages are validated through experiments with a 550 V, 35 kW UHS-SPMSM. The experimental results demonstrated the enhanced startup performance compared with conventional I-f control. Full article

The ultra-high-speed electric air compressor (UHSEAC) is affected by the electromagnetic torque components of the ultra-high-speed permanent magnet synchronous motor (UHSPMSM) during wide-range speed regulation, resulting in intense speed fluctuation. Electromagnetic torque components are generated by the effects of permanent magnet field harmonics, stator slotting, and current harmonics. It is very important to conduct simulation comparisons and theoretical descriptions of different sources of pulsation factors. In this paper, firstly, the electromagnetic torque model of UHSPMSM with a rated speed of 80,000 rpm is constructed and verified by an experimental bench. Secondly, the electromagnetic torque components of UHSPMSM are extracted on the basis of the electromagnetic torque model. Finally, the electromagnetic torque components’ characteristic law is investigated under different ultra-high-speed operating conditions. The results show that under ultra-high-speed operation, the frequency and amplitude of electromagnetic torque components become larger with increasing speed. And the amplitude of electromagnetic torque components becomes larger with increasing torque. This paper constructs the observation object of the high-frequency state observer and does the preliminaries for the design of the UHSEAC controller. Full article

Predictive current control (PCC) is an advanced control strategy for permanent magnet synchronous motors (PMSM). When the motor drive system is undisturbed, predictive current control exhibits a good dynamic response speed and steady−state performance, but the conventional PCC control performance of PMSM that depends on the motor body model is vulnerable to parameter perturbation. Aiming at this problem, an improved model−free predictive current control (IMFPCC) strategy based on a high−gain disturbance observer (HGDO) is proposed in this paper. The proposed strategy is introduced with the idea of model−free control, relying only on the system input and output to build an ultra−local current prediction model, which gets rid of the constraints of the motor body parameters. In the paper, the ultra−local structure is optimized by comparing and analyzing the equation of the state of the classical ultra−local structure and PMSM system. The system’s current state variables are incorporated into the ultra−local system modeling, as a result, the current estimation errors existing in the classical ultra−local structure are eliminated. For the unmodeled and parametric perturbation part of the ultra−local system, a high−gain disturbance observer is designed to estimate it in real time. Finally, the proposed IMFPCC strategy is compared with the conventional model−based predictive current control (MPCC) and the conventional model−free predictive current control (CMFPCC) in simulation and experiment. The results show that the current steady−state error of the IMFPCC strategy in the case of parameter variation is only 50% of the MPCC method, which proves the effectiveness and correctness of the proposed strategy. Full article

At present, the cogging torque of permanent magnet synchronous motors (PMSM) seriously limits the Los pointing accuracy of aviation photoelectric stabilization platforms based on PMSM, which also restricts the requirements of ultra-long-distance and high-precision aviation reconnaissance and detection. For this problem, an off-line iterative learning control (ILC) was designed, and on this basis, a control method of negative effect compensation of disturbance (NECOD) is proposed. Firstly, the “dominant disturbance torque” in the system, that is, the cogging torque with the characteristics of position periodicity, was suppressed by off-line ILC according to different positions. Then, for the “residual disturbance” after compensation, NECOD was used to suppress it. In the constant speed scanning experiment of the aviation photoelectric stabilization platform, the method of combining the off-line iterative learning controller and the negative effect compensation of disturbance (NECOD + ILC) proposed in this paper significantly improved the Los control accuracy of the platform when compared with the classical active disturbance rejection control (ADRC) and ADRC + ILC methods, and the Los pointing error of the constant speed scanning process had only increased by less than 5% when the system had ±15% parameter perturbation. In addition, NECOD + ILC has fewer parameters and is easy to adjust, which is conducive to engineering application and promotion. Full article
