Continuous population growth will lead to further expansion and densification of urban environments. In this context, Urban Air Mobility (UAM) has emerged as a new transportation solution through the use of Vertical Take-Off and Landing (VTOL) aircraft, more precisely, configurations such as lift-plus-cruise tilt-rotors. During the conceptual design phase, propeller design methodologies commonly reported in the literature rely on vortex-based approaches or actuator disk theory. However, the accuracy of these methods strongly depends on the inflow angle and operating conditions. This paper introduces an analytical model to predict propeller thrust at a 90° inflow angle (edgewise flight), based on a correction of the thrust under axial flight conditions and the propeller geometry evaluated at 75% span. The approach relies on local velocity and angle of attack estimations derived from classical Blade Element Momentum Theory (BEMT) with an additional correction to account for stall effects at high angles of attack. This capability is particularly relevant for modeling lift-plus-cruise tilt-rotor configurations cruise phase during early design stages while maintaining minimal computational cost. The proposed model is validated against wind tunnel measurements for several propellers tested at different global pitch angles, varying from 0 m/s to 9.1 m/s of windspeed and 1300 to 6200 rpms, demonstrating the applicability of the developed formulation for blades with twist angles up to 16°. Full article

Accurate performance prediction for large offshore wind turbines requires a principled treatment of uncertainty in both the wind resource and the rotor design parameters. In the present work, we develop a surrogate-based, multi-level uncertainty quantification (UQ) framework coupling a physics-based Blade Element Momentum (BEM) solver with a spectral Polynomial Chaos Expansion (PCE) surrogate that replaces the expensive Monte Carlo loop and apply it to the IEA 15 MW offshore reference wind turbine. The framework is completed by Sobol variance-based global sensitivity analysis. The contribution is methodological rather than algorithmic: although each individual ingredient (PCE, Sobol, BEM, and Jensen) is well established, their joint deployment in a single, internally consistent, end-to-end probabilistic workflow that simultaneously delivers (i) aerodynamic–structural UQ with analytical Sobol ranking, (ii) a like-for-like cross-comparison of three reference turbines, (iii) a quantitative leading-edge icing degradation study, and (iv) a farm-level wake-steering optimization on the same IEA 15 MW reference rotor yields a unified probabilistic envelope from which manufacturing tolerances, cold-climate investment thresholds, and farm-layout/control trade-offs can be read off consistently. Five input parameters are treated as random variables: hub-height wind speed (Weibull, k = 2.2, c = 9.8 m/s), air density, blade chord length, twist angle, and rotor speed. A degree-4 sparse PCE is built by non-intrusive spectral projection using N = 5000 Sobol quasi-random realizations, which allows the Sobol indices to be recovered analytically from the expansion coefficients at essentially no extra cost. Three parallel engineering studies complement the core UQ analysis: (A) a head-to-head comparison of the NREL 5 MW, DTU 10 MW, and IEA 15 MW reference turbines; (B) a quantitative assessment of leading-edge ice accretion at four severity levels; and (C) a Jensen-based wake optimization for a 25-turbine offshore array with static wake steering. The main results are as follows: the turbine reaches C_p,max = 0.480 at λ_opt = 8.51, and an annual energy production (AEP) of 71,261 MWh/year (PCE: 70,840 ± 2,140 MWh/year, 95% CI). Wind speed emerges as the dominant driver of C_p variance (S₁ = 0.412), followed by blade twist (0.198) and chord (0.143). Severe icing (30 kg/m) reduces C_p by 18.2% and increases the blade-root Damage Equivalent Load (DEL) by 18.5%. For the array, the optimal spacing (s_x = 8D, s_y = 6D) gives a farm efficiency of 89.6% and 1296 GWh/year, and a 15° wake-steering offset adds a further +3.2% to farm AEP. Compared with plain Monte Carlo, the sparse PCE delivers the same statistics with about 36% fewer model evaluations and a relative error below 0.8%. Full article

A numerical study was conducted to investigate the effect of embedded piezoelectric actuators integrated into the skin of a model-scale BO105 rotor blade on its torsional behaviour. The analysis was performed for blades with different combinations of spar and skin materials, including UD GFRP and UD CFRP composites. Four finite element models of the helicopter blade were developed in ANSYS 16.0. The piezoelectric response of the MFC (Smart Material Corp., Sarasota, FL, USA) actuators was simulated using a thermal analogy approach. The effects of actuator placement, as well as the selection of spar and airfoil skin materials, on the torsion angle and structural characteristics of the blade were analysed. The largest torsional angle was obtained for rotor blade configurations equipped with MFC actuators and manufactured entirely from UD GFRP composites. The spar material did not affect the torsional angle. Full article

Vertical axis wind turbines (VAWTs) have regained attention for distributed, urban, and floating offshore applications, yet the literature remains fragmented across competing rotor concepts and modelling traditions. This review consolidates the principal archetypes—Savonius, H-Darrieus, troposkein Darrieus, helical Darrieus, and Savonius–Darrieus hybrids—through five governing parameters: drag-versus-lift-driven operating principle, tip speed ratio $\mathsf{\lambda }=\mathsf{\omega }\mathrm{R}/{\mathrm{V}}_{\infty }$ (0.6–1.2 for Savonius; 2.5–5.0 for Darrieus), solidity $\mathsf{\sigma }=\mathrm{N}\mathrm{c}/\mathrm{R}$ (0.1–0.4), chord-based Reynolds number ${\mathrm{R}}_{\mathrm{e}\_\mathrm{c}}$ (${10}^5–{10}^6$), and peak power coefficient ${\mathrm{C}}_{\mathrm{p}\_\mathrm{m}\mathrm{a}\mathrm{x}}$ (0.15–0.25 for Savonius; 0.35–0.45 for optimized H-Darrieus). Off-design performance is dominated by unsteady mechanisms that quasi-steady streamtube models cannot resolve—leading edge vortex shedding, dynamic stall hysteresis, blade–wake interaction, and flow-curvature-induced virtual camber—each examined for its contribution to the instantaneous torque ${\mathrm{C}}_{\mathrm{T}}\left(\mathsf{\theta }\right)$ and the cycle-averaged ${\mathrm{C}}_{\mathrm{p}}$. Turbulence closures are benchmarked against phase-locked PIV and torque measurements: $\mathrm{k}–\mathsf{\omega }\mathrm{S}\mathrm{S}\mathrm{T}$ URANS captures peak-region ${\mathrm{C}}_{\mathrm{p}}$ to within $\pm 5–10\%$ but over-predicts torque below ${\mathsf{\lambda }}_{\mathrm{o}\mathrm{p}\mathrm{t}}$; the $\mathsf{\gamma }–{\mathrm{R}}_{\mathrm{e}\_\mathsf{\theta }}$ transition SST model reduces this error to $\pm 3–5\%$; DES, DDES, and LES reach $\pm 2–3\%$ at one to two orders of magnitude higher cost. Best practice computational fluid dynamics (CFD) guidelines are consolidated: domain extents of 15D upstream, 10D downstream, and 20D lateral; rotating sub-domain ${\mathrm{D}}_{\mathrm{r}\mathrm{o}\mathrm{t}}$ $\approx 1.5\mathrm{D}$; ${\mathrm{y}}^{+}\le 1$; $\Delta \mathsf{\theta }\le 0.1°$; and 20–30 revolutions before sampling. Performance enhancement strategies (variable pitch, guide vanes, helical twist, and hybridization) are reviewed quantitatively, with reported ${\mathrm{C}}_{\mathrm{p}}$ gains of $5–30\%$. Four research priorities are identified: (i) transition-sensitive turbulence closures validated below ${\mathrm{R}}_{\mathrm{e}\_\mathrm{c}}$ = $5\times {10}^5$; (ii) coupled aero-hydro-servo-elastic models for floating offshore VAWTs; (iii) machine-learning-augmented turbulence modelling—including physics-informed neural networks (PINNs) and neural-network-corrected RANS closures—to improve unsteady flow prediction at sub-LES cost; and (iv) integrated aeroacoustic–aeroelastic frameworks for urban and building-integrated deployment. Full article

The performance bottleneck in high-rotational-speed turbomolecular pumps (TMPs), wherein a significant increase in rotational speed does not lead to a noticeable increase in pumping speed, can be attributed to a mismatch between the traditional straight blade structure (TSBS) and high rotational speeds. Therefore, based on the theory of molecular gas dynamics, a gas molecular transport model incorporating twisted stator blade rows (TSBRs) was established. Utilizing the Monte Carlo (MC) method, a simulation calculation program was developed and validated in previous research. Taking structural parameters of the first four stages of a TMP available in the laboratory as an example, research on the necessity of TSBRs in TMPs was conducted. Our research findings indicate that increasing the probability of collisions between gas molecules and the lower surface is beneficial to improve pumping speed. Gas molecules incident on stator blade rows are no longer evenly distributed, exhibiting a trend of being sparse in the middle and dense at the edges. The maximum pumping speed coefficient and maximum compression ratio of the four-stage combined blade rows with TSBRs increased by 71.86% and 15.14%, respectively. Our research findings confirm the necessity of incorporating TSBRs and also provide direction and theoretical guidance for the structural optimization of TMPs. Full article

A review of morphing actuation systems in relation to rotary-wing aerial platforms is presented. The research highlights an inadequate maturation of rotary actuation systems, characterised by a scarcity of (1) comprehensive full-scale experimental research relative to non-rotary (fixed-wing) systems, (2) techniques used for rotary actuation systems and (3) implementation of full-chord morphing systems, with existing research only utilising partial-chord actuation techniques. Additionally, another notable shortcoming is presented to be the lack of comprehensive proportional investigation in the proposed five-step development process for rotary actuation designs. A comprehensive critical review is offered, covering the following challenges of progressing through this development process for rotary actuation systems from conceptual design to production: (1) numerical and computational studies, (2) small-scale wind-tunnel testing, (3) full-scale wind-tunnel testing, (4) demonstrator, and ultimately (5) fabrication for industrial implementation. The review examines several existing rotary actuation systems, including (but not limited to) leading-edge, trailing-edge and Gurney flaps; active twist; chord extension; variable span and camber systems. Comparisons are made between rotary morphing actuation systems and their non-morphing counterparts, highlighting the distinct difficulties encountered by rotary-wing systems due to the more complex and challenging operational conditions found in rotorcraft. The review reveals that a significant portion of existing research on rotary-wing systems has focused only on early-stage development, including computational modelling and sub-scale wind-tunnel experiments, underscoring the necessity for more comprehensive full-scale testing and prototype evaluation given that only a small number of studies have progressed to full-scale wind-tunnel testing or actual prototype evaluation, with only one example identified as having been tested on a production helicopter. In addition, a comparative Technology Readiness Level (TRL) assessment is presented for both rotary-wing and fixed-wing morphing actuation systems, enabling a structured evaluation of relative technology maturity, experimental validation depth, and proximity to operational implementation. Building upon this assessment, a morphing Actuation Concept-Transfer Feasibility (ACTF) study is also provided, examining the potential for adapting mature fixed-wing morphing actuation technologies for application in rotary-wing environments, while identifying the key structural, aerodynamic, and operational constraints that currently limit direct technology transfer. This study addresses and proposes opportunities for a novel rotary actuation system design and concludes by suggesting the potential for future research on more effectual systems to include full-chord configuration over larger spanwise blade footprints with innovative actuation mechanisms that could be utilised and progressed through all development stages from numerical studies to full-scale fabrication. Full article

Gravitational water vortex power systems are one of the cost-effective systems of extracting low head hydro power. This study investigates numerically a gravitational water vortex power system five-blade turbine rotating in a cylindrical basin for three blade shapes (flat, curved, and vertical twist) and three diameters of the discharge orifice at the basin bottom. The numerical simulations adopted a scaled down model using the Froude number similarity and employed the Volume of Fluid, Moving Reference Frame, and SST $k-\omega$ turbulence model. The system performance was examined both qualitatively and quantitatively for five turbine rotation speeds over 40–120 revolution/minute (RPM). It was found that blade shape, orifice diameter, and turbine rotation speed have significant effects on system performance. For a specific blade shape and discharge orifice diameter combination, the generated torque and power increases almost linearly at a large rate when the turbine rotation speed is increased from 40 RPM to 80 RPM and then decreases, also essentially linearly, at a much smaller rate from 80 RPM to 120 RPM. The optimal rotation speed was found to be 80 RPM across the speeds considered for all cases. It was also shown that the system with an intermediate diameter ratio performs better for each blade shape and the system with the curved blades performs better than the other two blade shapes. The results further show that for the cases considered, the most favorable operating condition was achieved by using a combination of a five-bladed curved turbine, a medium discharge orifice diameter ($d_o/D\approx 0.16$) in a cylindrical basin, and a rotational speed of 80 RPM, yielding relatively the highest efficiency of up to 62%, which are very good outcomes for such low head hydropower systems. Full article

The marine centrifugal pump is one of the most energy-intensive pieces of equipment in ship auxiliary machinery, and the efficient design of its hydraulic components can effectively reduce the total energy consumption of the ship system. Aiming at the complex three-dimensional twisted blade profile structure of the marine centrifugal pump, this paper optimized the clonal selection algorithm and constructed an automatic hydraulic optimization design method for the high-efficiency centrifugal pump impeller. Considering the multi-condition operation characteristics of the marine centrifugal pump, a performance test platform for the marine centrifugal pump was built, and the actual operating conditions of the model pump were tested to obtain its performance characteristics under operating conditions. The numerical simulation method was employed to capture and analyze the internal flow field and flow characteristics of the model pump. Addressing the design challenges of the marine centrifugal pump impeller, which involve multiple parameters with significant interactions, a traditional clonal selection algorithm was enhanced using a Slime Mold Algorithm, and a hybrid Clonal Selection Algorithm integrated with Slime Mold and Tangent Flight mechanisms was established. Based on the MATLAB and ANSYS platforms, an automated hydraulic optimization design framework for the centrifugal pump impeller was established. Using the optimized clonal selection algorithm, with the operational efficiency of the model pump as the optimization objective and controlling ten key geometric parameters of the blade profile through Bézier curves, the blade profile optimization design was achieved. The pump hydraulic efficiency under the rated flow condition increased by 7%. The unsteady internal flow efficiency of the optimized marine centrifugal pump was significantly improved. The blade optimization alleviated flow separation phenomena on the tangential surface of the impeller and in partial regions of the volute, reduced the flow loss area, and significantly decreased overall flow losses. Full article

This study investigates an inlet design for a gravitational vortex turbine (GVT), drawing inspiration from the ancient Nazca puquios. The puquios are ingenious subterranean aqueducts constructed by the Nazca culture (c. 100 BC–800 AD) in southern Peru, featuring spiral ojos de agua (water eyes) used to access groundwater and stabilize flow.The primary objective was to enhance vortex stability and overall GVT efficiency under low-head, low-flow operating conditions. A parametric Nazca-type inlet feeding a conical basin was defined by two controlling factors: the number of turns (N) and the inclination angle ($\theta$). The optimal geometry was determined through a $3^2$ full factorial design, computational fluid dynamics (CFD) simulations, and response surface methodology (RSM), with vortex circulation $(\Gamma )$ serving as the optimization metric. The best-performing inlet configuration ($N=4$, $\theta ={13}^{\circ }$) yielded $\Gamma =1.3459$ m²/s. This circulation level is comparable to that reported for optimized conventional wrap-around inlets at similar flow rates, but uniquely produced a broader and more symmetric vortex structure. Subsequently, two four-bladed runners (one with twisted blades and one with curved cross-flow blades) were evaluated numerically and experimentally using a laboratory-scale prototype operated at a consistent flow rate ($Q\approx 0.00143$ m³/s). CFD predicted maximum efficiencies of $15.37\%$ and $17.07\%$ for the twisted and curved runners, respectively, while experimental tests achieved $8.70\%$ and $11.61\%$, demonstrating similar efficiency ($\eta$) versus angular velocity ($\omega )$ characteristics. These results indicate reduced hydraulic effectiveness of the Nazca-inspired geometry for the GVT, with experimental efficiencies below those reported in the literature. Full article

The concept of active blade twisting as a method for reducing helicopter noise and vibration during flight is presented. Active twisting is achieved through piezoelectric actuators embedded in the blade skin, which generate dynamic twist when subjected to an electric field. Such dynamic deformation can lower fuel consumption while also reducing noise and vibration levels. A methodology for determining the optimal geometric dimensions of the cross-section of a helicopter blade, taking into account design constraints, is proposed to achieve the maximum twist angle of the blade under the action of piezoelectric actuators. First, a three-dimensional numerical model of the BO 105 model-scale rotor blade is developed in the finite element software ANSYS 16.0. The effect of the rotor blade’s cross-sectional dimensions on the cross-sectional properties and twist angle is investigated. It is found that skin thickness, spar flange thickness, and spar flange length affect the twist angle, with skin thickness showing a significant effect. Based on these results, an optimisation strategy is formulated to identify the optimal blade cross-section configuration to achieve the maximum twist angle. It was established that with the optimised geometric parameters of the cross-section the maximum active twist reaches 5.2°, while the positions of the elastic axis and the centre of gravity exhibit only minor deviations from those of the reference model. The placement of the piezoelectric actuators has a significant influence on both the flapwise bending stiffness and the torsional stiffness of the blade. Full article

The horizontal-axis tidal turbine is a representative device for harnessing ocean tidal energy, and the structural optimization of its blades is crucial for enhancing the power capture efficiency. In this work, the twist and chord distributions of the blade are determined using an improved Blade Element Momentum (BEM) approach, in which tip and hub loss factors are employed to enhance the modeling accuracy, and these results are employed to construct a parametric model of the original rotor. Due to its simplified assumptions and inability to capture three-dimensional flow effects, computational fluid dynamics (CFD) simulations were carried out to evaluate the hydrodynamic performance and flow analysis of the designed rotor. Further, the orthogonal test method was used to optimize the hydraulic performance of the rotor. Three optimization parameters, namely hub diameter, airfoil type, and maximum airfoil thickness, were set with three levels. Based on the orthogonal design scheme, nine rotor configurations were generated, and their energy capture characteristics and flow fields were subsequently evaluated through numerical simulations. The analysis indicates that the choice of airfoil exerts the strongest impact on the rotor’s energy capture efficiency, while the influences of maximum airfoil thickness and hub diameter follow in descending order. Consequently, the optimized rotor adopts a NACA63-415 airfoil with a reduced maximum thickness of 0.9 T₀ and an intermediate hub diameter of 15%R, achieving a power coefficient of 0.445 at the design tip-speed ratio of 4, corresponding to a 3.08% improvement compared with the original design. Flow field analysis demonstrates that the optimized geometry promotes a more uniform spanwise pressure distribution and effectively suppresses flow separation, thereby enhancing the overall hydrodynamic efficiency. Full article

Robust condition monitoring of wind turbine blades is essential for reducing downtime and maintenance costs, particularly under variable operating conditions. While recent studies suggest that combining trend monitoring (TM) with change point detection (CPD) can improve diagnostic performance, it remains unclear whether such integration is beneficial for all fault types. This study experimentally evaluates the integration of TM and CPD using vibration data from a laboratory-scale wind turbine for two representative blade faults: leading-edge erosion and twist misalignment. For the erosion case, discrete wavelet transform (DWT) energy features exhibit a clear and persistent increase in mid-frequency content, with energy deviations of approximately 34–45% relative to the healthy state. However, Bayesian Online Change Point Detection (BOCPD) does not reveal distinct change points, indicating that CPD provides limited additional value for gradual, steady-state degradation. In contrast, for twist misalignment, the short-time Fast Fourier Transform (FFT) features reveal dynamic spectral redistribution, and CPD applied to spectral centroid trends produces a sharp, localized detection signature. These results demonstrate that integrating TM with CPD significantly enhances fault detectability for dynamic, instability-driven faults, while TM alone is sufficient for smooth, steady-state degradation. This study provides an evidence-based guideline for selectively integrating CPD into wind turbine blade condition monitoring systems based on fault physics. Full article

This paper presents a numerical study of fluid–structure interaction (FSI) applied to wind turbines, combining computational fluid dynamics (CFD) and finite element analysis (FEA). The study focuses on a 3D wind turbine blade inspired by the GE 1.5XLE model. The blade features a twisted geometry with S818, S825, and S826 aerodynamic profiles, and is made of an orthotropic composite material with variable thickness and an internal spar. The fluid domain is defined by two circular sections upstream and downstream, aligned along the Z-axis. Simulations are performed under a wind speed of 12 m/s and a rotational speed of −2.22 rad/s (Tip Speed Ratio (TSR) = 8), with air modeled as an incompressible fluid at ambient temperature. On the CFD side, a periodic and symmetric modeling approach is applied, reducing the fluid domain to one-third of the full configuration by simulating flow around a single blade and extrapolating results to the remaining ones. This method achieves a 47% reduction in computation time while maintaining high accuracy in aerodynamic results. On the FEA side, spar condensation is performed by creating a superelement using the substructuring method. This strategy reduces structural computation time by 45% while preserving reliable predictions of displacements, stresses, and natural frequencies. These results confirm the effectiveness of the proposed techniques for accurate and computationally efficient aeroelastic simulations. Full article

The Wind Wall is a symmetric multi-VAWT system designed for efficient wind energy harvesting using Ugrinsky-type blades that are arranged in a compact, geometrically balanced layout to improve flow uniformity and torque stability and reduce pulsating loads. This study uses CFD simulations to determine the optimal helix angle and turbine spacing by analyzing the aerodynamic moment coefficient ($C_m$), effective velocity ($V_e$), and corresponding pressure-induced torque trends for stationary turbine configurations and proposes a simplified correlation linking $V_e$, turbine diameter, and spacing. The results show that a helix angle of 20–30° and symmetric spacing yield the highest performance, with the optimal angle increasing the time-averaged $C_m$ by approximately 831% compared to the closest-packed case. These findings address the critical impact of improper spacing and sub-optimal twist angles in compact multi-turbine systems and provide the first combined CFD-based assessment of the helix angle and spacing for a symmetric Ugrinsky-blade Wind Wall, contributing a practical spacing–velocity relationship for future design and deployment. Full article

Aiming at the nonlinear high-frequency micro-vibration (HFMV) phenomenon that would cause hidden faults of blade fracture failure of a wind turbine, this study calibrated a new type of HFMV aerodynamic force, elaborated on the nonlinear aeroelastic behavior of a 2D airfoil-based structural nonlinear system driven by HFMV aerodynamic forces, and proposed a control plan based on flutter suppression. Based on structural reinforcement based on a nonlinear tuned vibration absorber (NTVA), the flutter wind speed was increased, and artificial structural damping was introduced to analyze the flutter wind speed. The control planning adopted a new unified pitch control system based on the “screw rod–translational slider (nut)” transmission, which was driven by the hydraulic system to drive the ball screw and further drive the slider translation, achieving pitch motion. The control method adopted an optimal trajectory control and the optimal proportional-derivative (PD) controller adjustment technology based on the differential evolution algorithm (DEA). It achieved analysis of flap-wise bending/twist displacement responses, analysis of pitch angle changing, and display of slider driving force. The robustness of the control algorithm was validated by the control results displayed at different wind speeds near the flutter wind speed. The robustness of engineering applications for controlling performance was also validated on the controller hardware-in-the-loop simulation platform through an “object linking and embedding (OLE)” technology based on process control. Finally, the driving performance and wear consumption in engineering applications were discussed. On the basis of ensuring the control effect, the control algorithm was improved, and the fractional-order optimal PD control was adopted, so that the system could stabilize at the “0” consumption state when achieving flutter suppression. Full article
