Search Results (513)

In this paper, composite structures were fabricated by incorporating silver nanowires (AgNWs) with various metal oxides via the sol–gel method. This approach enhanced the electrical performance of AgNW-based transparent electrodes while simultaneously improving their stability under damp heat conditions and modifying the local medium environment surrounding the AgNW meshes. The randomly distributed AgNW meshes fabricated via drop-coating were treated with plasma to remove surface organic residues and reduce the inter-nanowire contact resistance. Subsequently, a zinc oxide (ZnO) coating was applied to further decrease the sheet resistance (R_sheet) value. The pristine AgNW mesh exhibits an R_sheet of 17.4 ohm/sq and an optical transmittance of 93.06% at a wavelength of 550 nm. After treatment, the composite structure achieves a reduced R_sheet of 8.7 ohm/sq while maintaining a high optical transmittance of 92.20%. The use of AgNW meshes as window electrodes enhances electron injection efficiency and facilitates the coupling mechanism between localized surface plasmon resonances and excitons. Compared with conventional ITO transparent electrodes, the incorporation of the AgNW mesh leads to a 17-fold enhancement in ZnO emission intensity under identical injection current conditions. Moreover, the unique scattering characteristics of the AgNW and metal oxide composite structure effectively reduce photon reflection at the device interface, thereby broadening the angular distribution of emitted light in electroluminescent devices. Full article

Flexible, intelligent color-changing windows with excellent color-switching capability and fast response time rely significantly on conductive composite layers composed of electrochromic materials and flexible, transparent substrates. Herein, we developed a high-performance electrochromic film (CPC) with mechanical, humidity, and temperature insensitivity by coating sodium carboxymethyl cellulose (CMC)-dispersed PEDOT:PSS onto a CA film. In the CPC system, CMC not only effectively enhances interfacial bonding and compatibility between the hydrophobic CA film and the hydrophilic PEDOT:PSS but also enables uniform and stable deposition of PEDOT:PSS on the CA film. As a result, the designed CPC demonstrates a high optical modulation capability (the transmittance changes from 60.1% to 3%) and a response time of 2 s. In addition, the CPC features the advantages of mechanical-, humidity-, and temperature-insensitive electrochromic distinctions, where it outputs the stable coloring efficiency with 100-time bending treatment, various temperatures, and humidity in an all-day outdoor environment. The developed CPC electrochromic film offers new insights into promoting the structural simplification and sustainability of electrochromic materials. Full article

This study investigates pristine and doped ZnO thin films fabricated via the sol-gel technique, aiming to address efficiency challenges when used as transparent conductive oxide (TCO) layers in thin-film solar cells. ZnO was first doped with aluminum (Al), and subsequently with both Al and reduced graphene oxide (rGO), to evaluate the individual and combined effects of these dopants. The optimal pH value for the ZnO structure was initially determined, with the film produced at pH 9 exhibiting the most favorable characteristics. Al doping was then optimized at a ratio of Al/(Al + Zn) = 0.2, followed by optimization of the graphene content at 1.5 wt%. In this context, the structural, optical, and electrical properties of pristine ZnO, Al-doped ZnO (AZO), and Al and graphene co-doped ZnO (Gr:AZO) thin films were systematically investigated. These films were integrated as TCO layers into Cu₂SnS₃ (CTS)-based thin-film solar cells fabricated via physical vapor deposition (PVD). The cell architecture employed an 80 nm pristine ZnO window layer, while the doped ZnO films (300 nm) served as TCO layers. To assess the influence of the chemically deposited top layers, device performance was compared against a reference cell in which all layers were fabricated entirely using PVD. As expected, the reference cell exhibited superior performance compared to the cell whose AZO layer deposited chemically; however, the incorporation of both Al and graphene significantly enhanced the efficiency of the chemically modified cell, outperforming devices using only pristine or singly doped ZnO films. These results demonstrate the promising potential of co-doped solution-processed ZnO films as an alternative TCO layer in improving the performance of thin-film solar cell technologies. Full article

Transparent conductive oxides (TCOs), such as indium tin oxide (ITO), are essential for flexible electronics; however, conventional vacuum-based deposition is costly and thermally aggressive for polymers. This study investigated the surface functionalization of PET substrates with ITO thin film-based forced hydrolysis as a low-cost, reproducible alternative. $\mathrm{S}\mathrm{n}{\mathrm{O}}_2$ nanoparticles were synthesized by forced hydrolysis at 180 °C for 3 h and 6 h, yielding crystalline nanoparticles with a cassiterite phase and an average crystallite size of 20.34 nm. The process showed high reproducibility, enabling consistent structural properties without complex equipment or high-temperature treatments. The $\mathrm{S}\mathrm{n}{\mathrm{O}}_2$ sample obtained at 3 h was incorporated into commercial ${\mathrm{I}\mathrm{n}}_2{\mathrm{O}}_3$ to form a mixed In–Sn–O oxide, which was subsequently deposited onto PET substrates by spin coating onto UV-activated PET. The resulting 1.1 µm ITO films demonstrated good adhesion (4B according to ASTM D3359), a low resistivity of 1.27 × 10⁻⁶ Ω·m, and an average optical transmittance of 80% in the visible range. Although their resistivity is higher than vacuum-processed films, this route provides a superior balance of mechanical robustness, featuring a hardness of (H) of 3.8 GPa and an elastic modulus (E) of 110 GPa. These results highlight forced hydrolysis as a reproducible route for producing ITO/PET thin films. The thickness was strategically optimized to act as a structural buffer, preventing crack propagation during bending. Forced hydrolysis-driven PET sheet functionalization is an effective route for producing durable ITO/PET electrodes that are suitable for flexible sensors and solar cells. Full article

With the widespread diffusion of personal Internet of Things (IoT) devices, Electromagnetic Side-Channel Attacks (EM-SCAs), which exploit electromagnetic emissions to uncover critical data such as cryptographic keys, are becoming extremely common. Existing shielding approaches typically rely on bulky or opaque materials, which limit integration in modern IoT environments; this motivates the need for a transparent, lightweight, and easily integrable solution. Thus, to address this threat, we propose the use of electromagnetic metasurfaces with shielding capabilities, fabricated with an optically transparent conductive film. This film can be easily integrated into glass substrates, offering a novel and discrete shielding solution to traditional methods, which are typically based on opaque dielectric media. The paper presents two proof-of-concept case studies for shielding against EM-SCAs. The first one investigates the design and fabrication of a passive metasurface aimed at shielding emissions from chip processors in IoT devices. The metasurface is conceived to attenuate a specific frequency range, characteristic of the considered IoT processor, with a target attenuation of 30 dB. At the same time, the metasurface ensures that signals from 4G and 5G services are not affected, thus preserving normal wireless communication functioning. Conversely, the second case study introduces an active metasurface for dynamic shielding/transmission behavior, which can be modulated through diodes according to user requirements. This active metasurface is designed to block undesired electromagnetic emissions within the 150–465 MHz frequency range, which is a common band for screen gleaning security threats. The experimental results demonstrate an attenuation of approximately 10 dB across the frequency band when the shielding mode is activated, indicating a substantial reduction in signal transmission. Both the case studies highlight the potential of transparent metasurfaces for secure and dynamic electromagnetic shielding, suggesting their discrete integration in building windows or other environmental structural elements. Full article

As a core candidate material for indium-free transparent conductive oxides, tin dioxide (SnO₂) thin films are gradually replacing indium tin oxide (ITO) and becoming a research focus in the field of optoelectronic devices, thanks to their excellent physicochemical stability, wide bandgap characteristics, and abundant tin resource reserves. This review focuses on SnO₂ thin films. Firstly, it elaborates on the tetragonal rutile crystal structure characteristics of SnO₂ and the transparent conductive mechanism based on oxygen vacancies and doping elements to regulate free electron concentration, while clarifying the key parameters for evaluating their transparent conductive properties. Subsequently, it systematically summarizes the research progress in preparing SnO₂ transparent conductive thin films via physical methods and chemical methods in recent years. It compares the microstructure and transparent conductive properties of thin films prepared by different methods, and analyzes the regulatory laws of preparation processes, doping types, and film thickness on their optoelectronic properties. Furthermore, this work supplements the current application status of SnO₂ thin films in devices. Meanwhile, the core performance differences between indium-free tin-based thin film devices and ITO-based devices are compared. Finally, we have summarized the advantages and challenges of physical and chemical methods in the preparation of SnO₂ thin films. It also forecasts the application potential of interdisciplinary integration of physical–chemical methods and the development of new doping systems in the preparation of high-performance SnO₂ transparent conductive thin films. This review aims to provide theoretical guidance and technical references for the selection and process optimization of SnO₂ transparent conductive thin films in fields such as photovoltaic devices and flexible optoelectronic equipment. Full article

This article proposes a novel transparent conductive film structure to solve the problem of electrostatic accumulation in traditional nanoimprint lithography processes. This structure is formed by spin-coating a layer of silver nanowire (AgNWs) transparent conductive films on a graphic substrate, followed by coating a layer of polydimethylsiloxane (PDMS) on the surface of the film. After the PDMS is cured, it is peeled off from the substrate to form a free-standing elastic three-dimensional structured surface. These transparent conductive films are not only designed to mitigate static electricity generated during the nanoimprint lithography process, but also have excellent UV transparency, with a 325 nm UV transmittance of up to 90%. At the same time, it exhibits good conductivity with a sheet resistance of 20 Ω/sq. In addition, the films have excellent elasticity and can maintain stable conductivity during repeated stretching, providing a novel solution for flexible optoelectronic devices and nanoimprint technology. Full article

Transparent conductive materials (TCMs) are essential for optoelectrical devices ranging from smart windows and defogging films to soft sensors, display technologies, and flexible electronics. Materials, such as indium tin oxide (ITO) and silver nanowires (AgNWs), are commonly used and offer high optical transmittance and electrical conductivity, but suffer from brittleness, oxidation susceptibility, and require high-cost materials, greatly limiting their use. Carbon nanotube (CNT) networks provide a promising alternative, featuring mechanical compliance, chemical robustness, and scalable processing. This study reports an aqueous ink formulation composed of ultra-long mix-walled carbon nanotubes (UL-CNTs), compatible with the flow coating process, yielding uniform transparent conductive films (TCFs) on polyethylene terephthalate (PET), glass, and polycarbonate (PC). The resulting films exhibit tunable transmittance (85%–88% for single layers; ~57% for three layers at 550 nm) and sheet resistance of 7.5 kΩ/□ to 1.5 kΩ/□ accordingly. These TCFs maintain stable sheet resistance for over 5000 bending cycles and show excellent mechanical durability with negligible effects on heating performance. Post-deposition treatments, including nitric acid vapor doping or flash photonic heating (FPH), further reduce sheet resistance by up to 80% (7.5 kΩ/□ to 1.2 kΩ/□). X-ray photoelectron spectroscopy (XPS) results in reduced surface oxygen content after FPH. The photonic-treated heaters attain ~100 °C within 20 s at 100 V. This scalable, water-based process provides a pathway toward low-cost, flexible, and stretchable devices in a variety of fields, including printed electronics, optoelectronics, and thermal actuators. Full article

Transparent conductive films based on silver nanowire meshes have demonstrated significant potential as alternatives to conventional tin-doped indium oxide and fluorine-doped tin oxide thin films. However, these materials feature high junction resistance, poor damp heat (DH) stability, and weak mechanical adhesion to substrates, which are critical issues that must be addressed before any practical applications. In this paper, transparent conducting films composed of silver nanowire (AgNW) frameworks and amorphous indium zinc oxide (IZO) fillers were prepared by a spin-coating method. The AgNW-IZO composite films exhibited a higher conductivity and better DH stability and adhesion to substrates than that of their constituent parts alone. The lowest sheet resistance of the composite films was 3.3 ohm/sq with approximately 70% transparency in the visible spectrum. No degradation was observed after 8 months. The excellent DH stability and mechanical adhesion might facilitate applications of these AgNW-IZO composite films in optoelectronic devices. Furthermore, the composite electrode is shown to have potential as a transparent heater. Full article

With the discovery of amorphous oxide semiconductors, a new era of electronics opened. Indium gallium zinc oxide (IGZO) overcame the problems of amorphous and poly-silicon by reaching mobilities of ~10 cm²/Vs and demonstrating thin-film transistors (TFTs) are easy to manufacture on transparent and flexible substrates. However, mobilities over 30 cm²/Vs have been difficult to reach and other materials have been introduced. Recently, polycrystalline In₂O₃ has demonstrated breakthroughs in the field. In₂O₃ TFTs have attracted attention because of their high mobility of over 100 cm²/Vs, which has been achieved multiple times, and because of their use in scaled devices with channel lengths down to 10 nm for high integration in back-end-of-the-line (BEOL) applications and others. The present review focuses first on the material properties with the understanding of the bandgap value, the importance of the position of the charge neutrality level (CNL), the doping effect of various atoms (Zr, Ge, Mo, Ti, Sn, or H) on the carrier concentration, the optical properties, the effective mass, and the mobility. We introduce the effects of the non-parabolicity of the conduction band and how to assess them. We also introduce ways to evaluate the CNL position (usually at ~E_C + 0.4 eV). Then, we describe TFTs’ general properties and parameters, like the field effect mobility, the subthreshold swing, the measurements necessary to assess the TFT stability through positive and negative bias temperature stress, and the negative bias illumination stress (NBIS), to finally introduce In₂O₃ TFTs. Then, we will introduce vacuum and non-vacuum processes like spin-coating and liquid metal printing. We will introduce the various dopants and their applications, from mobility and crystal size improvements with H to NBIS improvements with lanthanides. We will also discuss the importance of device engineering, introducing how to choose the passivation layer, the source and drain, the gate insulator, the substrate, but also the possibility of advanced engineering by introducing the use of dual gate and 2 DEG devices on the mobility improvement. Finally, we will introduce the recent breakthroughs where In₂O₃ TFTs are integrated in neuromorphic applications and 3D integration. Full article

The development of non-invasive sensors for individualised plant monitoring has become essential in smart farming to increase crop production. However current approaches are focused on the measurement of soil parameters instead, which cannot provide direct information about plant health. Moreover, equipment used for the direct monitoring of plant health are costly with complex operation, hindering their use by the wider community of farmers. This work reports for the first time the development of a flexible and highly transparent sensor, based on thin conductive PEDOT:PSS/PDMS hybrid films directly deposited onto leaves. The films were fabricated by aerosol deposition and could operate under two different modes. The first mode is used for the determination of plant dryness and concentration of ions. The second mode is used as a triboelectric generator to generate up to 7.2 µW cm⁻² electrical power through the friction of the sensors with a leaf. The device was assembled using a low-cost (GBP < 70) microcontroller incorporating environmental sensors, and an intuitive interface was designed for operation. The final sensor could determine the ionic strength at the millimolar level by means of the impedance of electrodes. This performance allowed the study of differences in ionic content and water availability in tomato leaves during day–night cycles. The high stability of the sensors also allowed the long-term monitoring of plant health. Using this technology, a decrease in the leaf ionic strength due to the lack of electrolytes was observed after watering with deionised water for 2 days. Upon supplementation with fertiliser, the recorded ionic strength and leaf water content were similar to the original values prior to the use of DI water, demonstrating the applicability of the device in the early detection of stress factors that could decrease crop production. Full article

This scoping review evaluates the literature on options for planar solid oxide cell (SOC) performance optimization, with a focus on applied fabrication methods and design enhancements. Literature identification, selection, and charting followed PRISMA-ScR guidelines to ensure transparency, reproducibility, and comprehensive coverage, while also enabling the identification of research gaps beyond the scope of narrative reviews. We analyze the influence of fabrication methods on cell and component characteristics and evaluate optimization approaches identified in the literature. Subsequent discussion explores how design innovations intersect with fabrication choices. The surveyed literature reveals a broad spectrum of manufacturing methods, including conventional processes, thin-film deposition, infiltration, and additive manufacturing. Our critical assessment of scalability revealed that reduction in operating temperature, improving robustness, and electrochemical performance are the main optimization objectives for SOC designs. Regarding production cost, production scale-up, and process control, inkjet, electrophoretic deposition, and solution aerosol thermolysis appeared to be promising manufacturing methods for design enhancements. By combining the PRISMA-ScR evidence map with a synthesis focused on scalability and process control, this review provides practical insights and a strong foundation for future SOC research and scale-up, also for evolving the field of proton-conducting cells. Full article

Silver nanowire transparent conductive films (AgNW TCFs), as a promising new generation of transparent electrode materials poised to replace ITO, have long been plagued by inadequate optoelectronic performance. Herein, flash lamp sintering was used to facilitate rapid welding of TCFs, and the effects of process parameters and TCFs’ characteristics on the sintering outcomes were investigated. The leveraging of millisecond-scale intense light pulses of flash lamp sintering can achieve the rapid welding of AgNWs, thereby enhancing the optoelectronic performance of TCFs. The TCFs fabricated from 30 nm diameter AgNWs with an initial sheet resistance of 111 Ω/sq exhibited a reduced sheet resistance of 57 Ω/sq post-sintering, while maintaining a transmittance of 93.3%. The quality factor increased from 4.56 × 10⁻³ to 9.09 × 10⁻³ Ω⁻¹, and the surface roughness decreased from 6.12 to 5.19 nm after sintering. This work holds significant promise for advancing the continuous production of AgNW TCFs using flash lamp sintering technology, potentially paving the way for high-quality, low-cost, and rapid manufacturing of AgNW TCFs. Full article

Transparent conductive electrodes that combine flexibility with effective electromagnetic interference (EMI) shielding are important for next-gen flexible electronics and 5G/6G communication devices. Achieving high optical transparency, low sheet resistance, and broadband shielding performance remains a sophisticated task. This work demonstrates a solution: the synthesis and comprehensive characterization of flexible In₂O₃/Ag/In₂O₃ (IAI) structures on polyethylene terephthalate substrates. The optimized structure with a 13.2 ± 1.1 nm silver interlayer achieves an incredible combination of properties: high optical transmittance (82.59% at 500 nm), low sheet resistance (6.4 ± 0.8 Ω/sq), and insignificant optical haze (1.04%). Broadband EMI shielding measurements from 10 MHz to 1 THz reveal a uniform shielding effectiveness of 25–30 dB across band from radiowave to terahertz. The IAI structures also show outstanding mechanical resilience, maintaining their electrical and shielding performance under repeated bending. This unique set of attributes positions IAI thin films as a prospective material for transparent EMI shielding in advanced telecommunications and flexible optoelectronics. Full article

Underwater acoustics is the optimal method for long-distance information transmission in aquatic environments. Hydrophones, as the core component of sonar systems, have found widespread application across multiple fields. However, existing types of hydrophones exhibit limited detection capabilities under low-signal conditions. To enhance low-frequency long-range detection performance, the development of new hydrophones featuring low power consumption, low frequency, high sensitivity, and miniaturization has become a research priority, with breakthroughs sought in the principle of electroacoustic conversion. Therefore, this study designed a frustum-cone triboelectric hydrophone (FCTH) based on friction layer materials, utilizing an indium-tin oxide (ITO) flexible conductive film on a polyethylene terephthalate (PET) substrate and a Polytetrafluoroethylene (PTFE) film. The sensor consists of a waterproof, sound-transparent polyurethane flow guide, silicone oil, and a frustum-cone triboelectric sensing unit based on a coupled membrane–cavity structure. The frustum-cone triboelectric sensing unit, based on a thin-film-perforated-tube resonance structure, enables omnidirectional detection of low-frequency hydroacoustic signals. The miniaturized design significantly reduces the volume of the FCTH. The acoustic–electric conversion relationship of the FCTH was derived using acoustic theory, thin-film vibration theory, and Maxwell’s displacement current theory. Furthermore, the low-frequency response characteristics of the frustum-cone triboelectric sensing unit were analyzed. The FCTH achieves a wide-frequency response ranging from 50 Hz to 12,000 Hz, with omnidirectional sensitivity and a maximum sensitivity of −174.6 dB. The FCTH achieves a wide-frequency response capability of 50 Hz to 12,000 Hz, with omnidirectional sensitivity and a maximum sensitivity of −174.6 dB. Additionally, through acoustic signal acquisition experiments in air, indoor, and outdoor water environments, the FCTH has been validated to possess excellent underwater acoustic detection performance and application potential across multiple scenarios. Full article
