A novel non-contact piezoelectric motor modulated by electromagnetic force is proposed in this work. The motor consists of a driving system and a transmission system. The transmission system includes a driving torque modulation mechanism and a keeping torque modulation mechanism. The calculation model of the magnetic forces of the motor is deduced, based on which the calculated equations of the magnetic driving torque, the magnetic keeping torque, the total torque, and the torque fluctuation applied to the rotor are presented. The transfer functions of the motor torque and its proportional-integral (PI) control are also given. Compensation control is used to remove the torque fluctuation. Via the derived equations, the effects of the system parameters on the system gain and time constant are investigated. Moreover, the step responses of the motor torque and the effects of the system parameters on them are analyzed, as are the step responses of the closed-loop control system with a PI controller. Furthermore, the torque fluctuation of the rotor is investigated, and its compensation signals are determined. Finally, the compensation control of the torque fluctuation is realized by adding feedback compensation signals. Full article

Aiming at the deterioration in Noise, Vibration and Harshness (NVH) performance caused by broadband torsional vibration in the integrated electric drive system (IEDS) of electric vehicles, most existing studies independently focus on electromagnetic excitation suppression or torsional vibration control of mechanical transmissions. Few researchers consider the coupling characteristics between the electromagnetic nonlinearity of motors and the nonlinearity of gear transmissions, making it difficult to realize the coordinated suppression of high- and low-frequency torsional vibration. In this paper, a seven-degree-of-freedom electromechanical coupling dynamic model is firstly established, which incorporates the electromagnetic torque ripple of the motor, the time-varying meshing stiffness of gears, meshing errors, and gear backlash nonlinearity. Through modal analysis and Campbell diagram solution, the natural characteristics and critical speed range of the system are clarified, and the generation mechanism of full-frequency band torsional vibration as well as the high–low frequency coupling characteristics are systematically revealed. On this basis, a coordinated active control strategy based on PD pole placement and harmonic current injection (PD-HCI) is proposed. The PD pole placement controller is adopted to suppress the low-frequency torsional vibration (0–20 Hz) of the transmission system, and the 5th/7th harmonic current injection is used to counteract the high-frequency torque ripple (above 200 Hz) of the motor, thereby achieving the coordinated suppression of broadband torsional vibration. The Matlab/Simulink R2023a simulation results show that the proposed control strategy reduces the torque fluctuation rate from 3.11% to 1.96%, the speed fluctuation rate from 0.10% to 0.03%, and the total harmonic distortion (THD) of stator current from 8.69% to 1.77% under steady-state operating conditions. Under transient operating conditions with sudden load changes, the stabilization time of fluctuations in speed and half-shaft torque is shortened by more than 80%, the impact amplitude is significantly reduced, and there is no loss in the vehicle’s dynamic response and speed tracking performance. Experimental results show that the coefficients of determination R2 of vehicle speed, motor speed, acceleration and torque are 0.9990, 0.9982, 0.9997 and 0.9997, respectively, which verifies the reliability of the established model. Full article

High-end vertical five-axis machining centers commonly adopt dual-motor direct-drive configurations for their cradle-type A-axis to improve dynamic performance; however, this approach introduces control challenges in balancing counteracting torque and synchronization accuracy due to high-rigidity coupling. To address this issue, this study presents a novel error compensation control strategy based on a synchronous state observer. First, a system dynamic model incorporating dual-axis coupling effects is developed to systematically investigate the coupling mechanism between synchronization error and counteracting torque. Based on this model, a synchronous state observer is designed, which achieves real-time reconstruction and feedforward compensation of synchronization disturbances induced by factors such as transmission parameter mismatches and inter-axis torque imbalance, thereby enabling coordinated control of high-precision position synchronization and torque balance. The effectiveness of the proposed method is verified through simulation and experiments conducted on a VMC630 vertical five-axis machining center. Results show that under various speed and acceleration conditions, the maximum position synchronization error remained below $6.3\mathrm{e}-4$${}^{\circ }$, with comparable convergence performance; the current deviation between the dual motors was constrained to within $\pm 0.25$$\mathrm{A}$, demonstrating effective mitigation of counteracting torque. In machining tests of S-shaped specimens, all measured contour deviations fell within the $\pm 0.060$$\mathrm{m}$$\mathrm{m}$ tolerance range, and the specimens exhibited excellent contour consistency and surface quality. These results validate the proposed strategy’s status as an engineering-viable solution for precision motion control in high-rigidity coupled dual-motor systems. Full article

The conventional robotic position control is gradually being replaced by force control, which is commonly used in humanoid robot applications that require force interaction with the environment, force transmission, or contact. A high-back-drive-efficiency actuator with a high-torque-density permanent magnet motor connecting the low-ratio planetary reducer is widely applied in interactive robotic systems without a torque/force sensor. This paper proposes a high-torque-density permanent magnet motor with an external rotor structure, which can realize torque enhancement by the increased air-gap diameter and better space utilization by the internal planetary reducer, i.e., the reducer inside the stator. First, the motor topologies with different slot/pole number combinations are introduced. Then, the optimization of a slot/pole number combination is elaborated for the maximum torque and torque mass density. In addition, the influence of the slot/pole number combination on the torque characteristic and overload capability is investigated by the finite element (FE) method. The experimental results of the prototype motor are provided to verify the analysis. Full article

Background: The quad-helix (QH), a conventional appliance, and clear aligners (CA), which have been increasingly used, are both used for maxillary expansion. However, their biomechanical behavior during dentoalveolar expansion has not been directly compared. This study evaluates their biomechanical responses using finite element analysis (FEA). Methods: Three-dimensional finite element models of a CA with attachments and buccal root torque and a QH appliance were constructed. Clinically relevant loading conditions were applied based on reported activation protocols. A 5 mm activation (1.4 N) was applied to QH, and a 0.4 mm deformation (0.7 N) to CA. Tooth displacement and stress distribution were evaluated at cusp tips, root apices, and bifurcation areas of canines, premolars and molars. Results: In both models, displacement was greater at the crown level and decreased toward the root, indicating a predominantly tipping pattern. Maximum buccal displacement was observed at the first molar in the quad-helix model (1.054 × 10⁻⁴ mm), whereas in the clear aligner model, the highest value was at the second molar (5.498 × 10⁻⁵ mm). The quad-helix demonstrated a more localized expansion pattern, primarily affecting the first molar and premolars, while clear aligners exhibited a more distributed posterior response. Stress concentrations were more localized in the QH model and more uniformly distributed in the CA model. Conclusions: Dentoalveolar expansion is influenced not only by movement magnitude but also by the pattern of force distribution. Differences in posterior force transmission between CA and QH were associated with distinct biomechanical response patterns under the simulated loading conditions evaluated in the present study. Full article

In a planetary gear system, the planet phasing depends on the number of teeth in the sun and the ring and the number of planets. When the tooth numbers are both multiples of the number of planets, all planets mesh at the same relative position—which is called synchronous configuration—and the input torque is shared evenly among them. Otherwise, the configuration is asynchronous, or sequentially phased, and the torque sharing is uneven. This directly influences the instantaneous load sharing between the external planet–sun and internal planet–ring meshes, consequently altering both load-induced tooth deflections and the resulting transmission error. The profile relief, frequently used to avoid the mesh-in impact, influences the teeth contact along the interval of relief, which also affects the load distribution, mesh stiffness, and transmission error. Since the transmission error is a source of dynamic load, noise, and vibrations, its peak-to-peak amplitude should be controlled, and the geometry of the profile modification provides an efficient tool. In this paper, the transmission error of spur planetary gears is studied with an analytical model previously developed, based on the minimum elastic potential energy. The study also assesses the influence of the depth and length of the tip relief and compares the behavior of synchronous and asynchronous configurations. As a result of this analysis, it has been found that the variation in the amplitude of transmission error is significantly lower in sequentially phased configurations and reaches the minimum variation for the adjusted depth of relief and medium length of relief. Furthermore, an odd number of teeth on the planets results in a higher mesh stiffness than an even number, which induces a slightly lower peak-to-peak transmission error. Full article

The electromechanical transmission (EMT) systems of hybrid special vehicles are highly susceptible to severe transient torsional resonance under frequent start-stop operating conditions. Traditional entire-frequency domain H_∞ active vibration reduction strategies are often limited by insufficient gain, failing to achieve ultimate suppression within the core resonance frequency band. To address this issue, this paper proposes a finite-frequency H_∞ active torsional vibration suppression strategy based on a motor dual-loop control architecture. This strategy achieves a profound physical decoupling between torsional vibration suppression and steady-state driving tasks. Furthermore, by introducing the Generalized Kalman–Yakubovich–Popov (GKYP) lemma and Linear Matrix Inequalities (LMIs) into the secondary loop, the control degrees of freedom are precisely concentrated on the 8–30 Hz frequency band, where the transient resonance energy is highly localized. This thoroughly eliminates the conservatism inherent in entire-frequency designs. To mitigate the instability risks caused by unmeasurable states and actuator response lags in practical engineering applications, a robust controller integrating input time-delay compensation and dynamic output feedback is subsequently constructed. Numerical case studies and hardware-in-the-loop (HIL) test results based on a specific EMT configuration demonstrate that the proposed strategy effectively overcomes the instability induced by system delays. It achieves an outstanding resonance peak attenuation of up to 93% and strictly constrains output shaft torque fluctuations within a safe threshold of 50 N·m. Ultimately, this study provides an efficient and robust closed-loop engineering solution for the transient vibration management of high-power electromechanical transmission systems and the enhancement of overall vehicle NVH performance. Full article

The use of prosthetic devices can significantly improve the quality of life of individuals with limb amputations. However, existing prosthetic hands face multiple engineering and manufacturing challenges, making them economically inaccessible to a large portion of the population. This study focuses on the design and analysis of a cost-effective prosthetic hand capable of performing five fundamental grasp types: tripod, cylindrical, spherical, lateral, and pinch. The development process began with a biomechanical analysis of the human hand, followed by the derivation of a kinematic model. To ensure anthropomorphic fidelity, finger trajectories were synthesized using a computer vision-based algorithm that captured natural human motion. These trajectories were then mapped to the prosthetic control system. Experimental validation was conducted through rigorous goniometric analysis of the prototype’s execution. The results demonstrated the system’s effectiveness in replicating functional grasps, with a Root Mean Square Error (RMSE) within acceptable thresholds for assistive tasks. While the prototype achieved high motion correspondence, higher deviations were observed in distal joints due to mechanical transmission resistance and spring-return torque requirements. This work provides a scalable framework for tendon-driven prostheses, balancing advanced trajectory synthesis with a robust and accessible mechanical architecture. Full article

Gravity energy storage systems (GESS) have emerged as a promising long-duration energy storage technology capable of supporting large-scale renewable integration and enhancing grid resilience. However, the modeling framework for the hoisting electromechanical subsystem in wire-rope-based GESS remains underdeveloped, thereby limiting the accurate characterization of its transient grid-connected behavior, dynamic operating response, and cross-domain coupling effects. Existing studies commonly simplify wire ropes and related transmission components as rigid bodies or low-dimensional mechanical elements, failing to adequately account for their flexibility and the resulting high-dimensional nonlinear dynamics. Although related studies in mine hoisting and elevator systems have addressed mechanical vibration phenomena, they primarily focus on mechanical-side effects, such as shock loading and guide-structure response, whereas the mechanism by which flexible mechanical vibrations propagate through electromechanical coupling and influence electrical dynamic performance remains inadequately understood. To address this gap, this study establishes a distributed-parameter model for the wire-rope hoisting mechanism based on Hamilton’s principle and solves the corresponding vibration governing equations using the Galerkin method to capture nonlinear multi-modal dynamics. An electromechanical coupling model is then developed to elucidate how rope-vibration-induced tension fluctuations propagate through the drive chain, resulting in torque ripple, electrical interharmonics, and low-frequency grid-side oscillations. A Bessel-function-based analytical representation is further introduced to explain the formation of interharmonic clusters and beat-frequency phenomena under converter modulation. An experimental prototype is constructed to validate the proposed modeling framework. The measured vibration spectra, beat-frequency characteristics, and torque ripple align closely with analytical predictions, confirming the model’s capability to capture key propagation paths from rope vibration to electromechanical oscillation and grid-side dynamic response. The results provide a solid theoretical foundation for vibration mitigation, dynamic analysis, and control design of hoisting electromechanical subsystems in gravity energy storage applications. Full article

The conventional microstepping driving method suffers from significant periodic speed oscillations under ultra-low-speed conditions, which fail to meet the stringent demand for smooth operation of ultrasonic motors in semiconductor packaging. Most existing theories and simulations of ultrasonic motors adopt a macroscopic mechanical perspective; after extensive linearization and idealization, they can only provide preliminary mechanism analysis and fail to achieve precise quantitative computation. Moreover, they neglect critical factors such as the microstructure of contact surfaces, preload distribution, and vibration mode transmission, making it difficult to reflect the true characteristics of the motor—including strong nonlinearity, multiphysics coupling, and complex interface behavior—resulting in considerable discrepancies between theory and experiment. In this paper, a macro-micro multi-scale finite element model of a traveling-wave ultrasonic motor is established using ADINA and HyperMesh, fully accounting for the strong nonlinearity and multiphysics coupling effects. Based on the ultrasonic friction reduction theory and the beat traveling wave mechanism, the stator deformation, interface zoning characteristics, and torque output of the superimposed pulse driving method and the microstepping driving method are systematically compared. The simulated stator mode shapes are validated by laser scanning vibrometry experiments, and multiple speed tests ranging from 200 to 320 arcsec/s are conducted. Simulation results show that at a target speed of 900 arcsec/s, the superimposed pulse driving method reduces the speed fluctuation rate from 228% to 32%. Experimental results confirm that the speed fluctuation rate of the superimposed pulse driving method is consistently much lower than that of the microstepping driving method across the entire tested speed range. This study reveals the low-speed smooth operation mechanism of the superimposed pulse driving method, characterized by single-peak dominance and smooth alternation between the driving and braking zones, thereby fundamentally overcoming the inherent shortcomings of the traditional microstepping driving method. The proposed model can effectively replace costly direct interface measurements, providing a new method and reference for ultra-low-speed precision control of ultrasonic motors and for investigating the driving mechanisms of similar motors. Full article

Flat leather belts were the first to be used in drive and transport technology and were later replaced by plastic belts. Recently, there has been a return to hybrid designs, where belts are constructed as a “sandwich” with a technical leather outer layer and a polyamide or TPU inner core. This study analyses the thermal behavior of a modern leather belt transmission as a function of braking torque at different rotational speeds of the active pulley. A linear temperature response was observed, with temperature differences between the passive and active belts of 4 °C at 500 rpm (R² = 0.93), 5.4 °C at 1000 rpm (R² = 0.96), and 4 °C at 1500 rpm (R² = 0.98). Due to the specific structure of the outer layer, non-contact surface measurement methods were applied. Surface topography analysis showed only minor changes in average roughness, with Sq = 37.8 µm (new belt) and 37.9 µm (used belt) and Sa decreasing from 26.5 µm to 25.1 µm. However, clear morphological changes were observed: Ssk decreased from 2.63 to 2.00, Sku from 14.3 to 8.19, Sp from 449 µm to 308 µm, and Sz from 557 µm to 400 µm, indicating reduced peak sharpness after wear. Profile parameters increased after operation, with Ra rising from 18.6 µm to 21.9 µm, Rq from 26.7 µm to 30.7 µm, and Rz from 116 µm to 143 µm. Microscopy confirmed wear-related smoothing and fragmentation of surface asperities. The results demonstrate that the applied methods are effective for evaluating thermal response and wear mechanisms in modern leather composite belts. Full article

When a fault occurs in the power grid to which the Virtual Synchronous Generator (VSG) is connected, it leads to overcurrent phenomena, which threatens the safety of the inverter and easily results in device damage. Although existing direct current limiting unit (CLU) control strategies can restrict the fault current, the input active power command far exceeds the power output, causing the virtual rotor to continuously accelerate. This leads to power angle divergence and a subsequent loss of synchronization. To address the conflict between direct current-limiting control and system transient stability, this paper proposes a control strategy based on the Particle Swarm Optimization (PSO) algorithm to modify the active power command, building upon existing direct current-limiting VSG control. During grid faults, the output current is constrained to its maximum value, leading to a reduction in the system’s output power. By leveraging the PSO algorithm, the proposed strategy decreases the active power command to minimize the power mismatch between the command and the output. This maximizes the system’s transient stability by minimizing the rotor acceleration torque and effectively suppressing excessive power angle deviation. Meanwhile, the active power command reduction is introduced as a penalty term to maximize the active power output capability during the fault period. Simulation results demonstrate that, compared to VSG with only direct current-limiting control, the proposed strategy significantly enhances the transient stability and transmission efficiency of the VSG under long-term fault conditions across various grid voltage sag scenarios. Furthermore, it ensures a seamless transition from the fault state to normal operation during short-term faults. Full article

Herringbone gear pairs are critical in high-speed aerospace transmissions, where windage power loss significantly impacts efficiency and thermal management. This study proposes a prediction method that decomposes the total windage loss into five components based on structural features: the tooth, end, circumferential, and relief groove surface losses for both gears, and the meshing extrusion loss. Theoretical models for each component are established to form a complete prediction method using fluid–structure interaction principles. CFD simulations analyze the velocity, pressure, and energy fields around the gear pair, with windage loss integrated via fluid torque on gear surfaces. Results indicate that windage loss escalates rapidly and becomes non-negligible when the driving gear speed exceeds 7000 rpm. The prediction model demonstrates strong agreement with CFD simulations, with a maximum relative error of 13.6%. Analysis reveals that the driving gear contributes the largest share of the total gear pair loss, with meshing extrusion accounting for 20.1–23.6%. For a single herringbone gear, the tooth surface is the primary source of loss (~83%), followed by the end surface (~8%), while relief groove and circumferential losses remain below 10%. This research provides a validated theoretical foundation for optimizing efficiency and thermal control in high-speed aerospace gear systems. Full article

Near-bit multi-parameter MWD (measurement while drilling) is a key technology for achieving precise and efficient directional drilling in underground and tunnel engineering. The near-bit multi-parameter MWD method was studied, and a “center + side wall” distributed measurement scheme was proposed, based on an analysis of special application scenarios in underground and tunnel engineering. The transmission characteristics of Bluetooth wireless signals in water were investigated. An analysis of the underwater Bluetooth signal link was conducted. When the transmission distance is 100 mm, the received signal strength is −17.5 dBm, and the link margin is 69.5 dB. Wireless Bluetooth was used to transmit the near-bit data. A Bluetooth wireless communication simulation model was established using ANSYS software, and the influence of transmission power, transmission medium, and transmission distance on the Bluetooth signal strength was analyzed. The results indicate that: (1) the received signal strength increases with transmission power, and appropriately increasing the transmission power can improve the effect of Bluetooth wireless communication and extend the communication distance. (2) When the transmission medium is water, the received signal is unstable, and the echo loss curve shows a high and low oscillation form, presenting a frequency shift feature; when the transmission medium is air, the received signal is relatively stable, and the echo loss curve shows a parabolic form. The echo loss of Bluetooth wireless signal in water transmission is significantly higher than that in air transmission, indicating that the Bluetooth signal attenuates more rapidly when transmitted in water. (3) When the transmission distance increases near the optimal transmission frequency of 2.4 GHz, the echo loss increases accordingly, and the received signal strength of the wireless receiving module gradually decreases. The theoretical analysis, simulation, and indoor test results are in good agreement. The reasonable Bluetooth transmission power is 1 mW, and the transmission distance is 100 mm. After completing the overall scheme design and simulation analysis optimization, the structure, circuit, and program development were carried out, and the near-bit multi-parameter MWD device was developed. A laboratory water supply test was conducted, and the power supply, collection, and wireless transmission were all normal. A drilling test was carried out at an underground engineering of a coal mine in Wuhai City, achieving a drilling depth of 2328 m. A continuous and stable collection of various parameters such as WOB (weight on bit), torque, rotation speed, vibration, and gamma was carried out. A wireless transmission channel for near-bit data was established across the screw drilling tool. It can provide key technical support for the research and development of near-bit MWD in underground and tunnel engineering. Full article

Contactless transmission of mechanical power, which is characteristic of coaxial magnetic gears (CMGs), offers significant advantages over conventional mechanical gears, in particular, reduced maintenance frequency and inherent overload protection. At the same time, there is a lack of design methodologies for this type of gear based on the analysis and systematization of experience gained from already implemented designs. This paper presents a method for determining the maximum magnetic torques of CMGs on the basis of an equivalent magnetic-circuit model. The error associated with the proposed methodology does not exceed ±15%, which enables the influence of geometric parameters and the magnetic properties of materials on the key performance indicators of the gear to be assessed already at the preliminary design stage. A mathematical model of CMG dynamics was also developed, based on a quasi-stationary two-dimensional approximation of the magnetic field, accounting for the geometry of the magnetic circuit, the spatial distribution of the magnetic vector potential, and magnetic-circuit saturation. The proposed mathematical model was verified using the results of physical experiments. The discrepancy between the calculated and experimental values of the torque on the low-speed shaft in the steady state does not exceed 5.5%. Based on the optimization procedure, the dependence of the maximum linear torque density on the outer diameter of the CMG, the number of poles of the high-speed rotor, and the transmission ratio was determined. It was shown that, as the number of poles increases, the linear torque density also increases and, for example, for diameters of approximately 800 mm, it may exceed 100 N·m/m. Full article
