Vehicle-to-home (V2H) technology enables electric vehicles (EVs) to supply power to residential loads, offering enhanced energy self-sufficiency and backup capabilities. Accurate voltage regulation is essential in such systems, especially under nonlinear and time-varying load conditions. The control method for three-phase four-wire (3P4W) converters plays a vital role in addressing these challenges. In the control configuration of such systems, the non-ideal proportional-resonant (PR) controller stands out due to its ability to reject periodic disturbances. However, the comprehensive study on the discretization of this controller for digital implementation in 3P4W systems has not been available in the literature to date. This paper presents a comparative study of several discretization methods for non-ideal PR controllers. The continuous-time complete transfer function of the integral term of non-ideal PR controllers is discretized using techniques such as Forward Euler, Backward Euler, Tustin, Zero-Order Hold, and Impulse Invariance. Additionally, the discretization methods based on two discrete integrators for the non-ideal PR controller, such as Forward Euler and Backward Euler, Backward Euler and Backward Euler plus computational delay, and Tustin and Tustin, are also evaluated. In the MATLAB/Simulink platform, through evaluating the performance of the non-ideal PR controllers, which are discretized using the above discretization methods, in controlling the output voltage of the 3P4W converter in the V2H application under nonlinear load scenarios, including substantial and sudden changes in load, the discretization method Backward Euler and Backward Euler plus delay is recommended. Full article

This paper explores the challenges of detecting wiring anomalies in three-phase, four-wire energy metering devices, especially when large amounts of reactive power compensation are involved. Traditional methods, such as the hexagon phasor diagram technique, perform well under standard loads, but struggle to adapt to new situations, such as over- or under-compensation. To overcome these limitations, this paper proposes a hybrid approach that combines mechanism-based knowledge with data-driven technologies, including backpropagation neural networks (BPNNs). This method improves the accuracy and efficiency of anomaly detection and can better adapt to a dynamic power environment. The result is improved universality of anomaly detection, which helps to achieve safer, more accurate, and more efficient smart grid operation in complex situations. Full article

In Wire Arc Additive Manufacturing (WAAM), solidification grain morphology in titanium alloy tends to be columnar rather than equiaxed due to heat dissipation and repeated thermal cycles. This study demonstrates improved microstructure and anisotropic properties in Ti-6Al-4V specimens fabricated by WAAM and treated with hammer peening, resulting in a transition from columnar grains to fine equiaxed grains (~300 μm) in both single-pass and four-bead WAAM walls. The anisotropic elongation decreased by approximately 7%, and tensile strength along the building direction decreased by ~50 MPa for a single-pass wall. Additionally, small and large equiaxed prior-β grains appeared alternately due to the combined effect of hammer peening and welding deposition. The region can be categorized into three parts (MAX, MED, MIN) based on the degree of plastic strain characterized by KAM mapping of EBSD data. In current WAAM parameters, the ratio of strong (~1.5 mm) deformation field (MAX) is about 50% within one deposition layer (MAX+MIN), suggesting a new approach for producing equiaxed prior-β grains. We expect that this method will be applicable for transforming the prior-β grains from columnar to equiaxed. Furthermore, the distribution of plastic strain and phase transformation mechanisms offers innovative approaches to optimize the hammer peening process, with potential applications to optimize the process for more complex components in the aerospace and power plant industries. Full article

This study proposes a receiving-end voltage compensation method employing a phase-specific reactive power control strategy with a neutral-point-clamped (NPC) inverter in a three-phase four-wire distribution system. The principle of the proposed receiving end voltage compensation method is explained. Further, the proposed control strategy can solve the problems of the three-phase, four-wire distribution system, which are an increase in the neutral-line current and the unbalanced voltage. Computer simulation is performed to confirm the validity of the proposed method. The simulation results indicate the receiving-end voltages can be compensated using the proposed method. Full article

The primary objective of this paper focuses on developing a control approach to improve the operational performance of a three-level neutral point clamped (3LNPC) shunt active power filter (SAPF) within a grid-tied PV system configuration. Indeed, this developed control approach, based on the used 3LNPC-SAPF topology, aims to ensure the seamless integration of a photovoltaic system into the three-phase four-wire grid while effectively mitigating grid harmonics, grid current unbalance, ensuring grid unit power factor by compensating the load reactive power, and allowing power sharing with the grid in case of an excess of generated power from the PV system, leading to overall high power quality at the grid side. This developed approach is based initially on the application of the four-wire instantaneous p-q theory for the identification of the reference currents that have to be injected by the 3LNPC-SAPF in the grid point of common coupling (PCC). Whereas, the 3LNPC is controlled based on using the finite control set model predictive control (FCS-MPC), which can be accomplished by determining the convenient set of switch states leading to the voltage vector, which is the most suitable to ensure the minimization of the selected cost function. Furthermore, the used topology requires a constant DC-link voltage and balanced split-capacitor voltages at the input side of the 3LNPN. Hence, the cost function is adjusted by the addition of another term with a selected weighting factor related to these voltages to ensure their precise control following the required reference values. However, due to the random changes in solar irradiance and, furthermore, to ensure efficient operation of the proposed topology, the PV system is connected to the 3LNPN-SAPF via a DC/DC boost converter to ensure the stability of the 3LNPN input voltage within the reference value, which is achieved in this paper based on the use of the maximum power point tracking (MPPT) technique. For the validation of the proposed control technique and the functionality of the used topology, a set of simulations has been presented and investigated in this paper following different irradiance profile scenarios such as a constant irradiance profile and a variables irradiance profile where the main aim is to prove the effectiveness and flexibility of the proposed approach under variable irradiance conditions. The obtained results based on the simulations carried out in this study demonstrate that the proposed control approach with the used topology under different loads such as linear, non-linear, and unbalanced can effectively reduce the harmonics, eliminating the unbalance in the currents and compensating for the reactive component contained in the grid side. The obtained results prove also that the proposed control ensures a consistent flow of power based on the sharing principle between the grid and the PV system as well as enabling the efficient satisfaction of the load demand. It can be said that the proposal presented in this paper has been proven to have many dominant features such as the ability to accurately estimate the power sharing between the grid and the PV system for ensuring the harmonics elimination, the reactive power compensation, and the elimination of the neutral current based on the zero-sequence component compensation, even under variable irradiance conditions. This feature makes the used topology and the developed control a valuable tool for power quality improvement and grid stability enhancement with low cost and under clean energy. Full article

In this paper, we aim to address the limited capacity of compensation devices by enhancing their utilization rate by applying the currents’ physical component (CPC) theory for reactive power optimization in three-phase four-wire systems. When reactive currents cannot be fully compensated for, we propose using CPC theory to generate reference currents for the compensation devices. Weight coefficients associated with different reactive current components are introduced, enabling flexible combinations of these independent current components. The maximum output amplitude of the three-phase current from the compensation device serves as a constraint condition, allowing for the calculation of reference currents under various compensation targets. Additionally, a reactive current optimization compensation scheme focusing on loss reduction is selected. The simulated annealing–particle swarm optimization (SA-PSO) hybrid algorithm is employed to solve the optimization mathematical model. The discussed calculations, current waveforms, and voltage waveforms are generated using the constructed mathematical model and then used for a theoretical explanation. The simulation verifies the feasibility of the proposed method. Full article

Budeanu’s power theory, in its fundamental version, describes single-phase sinusoidal and nonsinusoidal systems. Over time, this elementary description has been extended to three-phase three-wire and four-wire systems, regardless of power conditions. Initially, three-phase systems were considered as three independent single-phase systems. A distinct approach was introduced by Czarnecki in his power theory (Currents’ Physical Components—CPC). The energy description and reference of the equivalent parameters of the load are comprehensive in the context of three-phase systems; Czarnecki treats such systems as a whole. This paper introduces a mathematical model to expand the basic Budeanu theory for three-phase four-wire (3-p 4-w) systems powered by symmetrical and nonsinusoidal voltage sources. The proposed approach is based on mutual elements between the fundamental Budeanu theory and the CPC theory, treating the 3-p 4-w system as a whole. In the extended Budeanu theory model, equations for the Budeanu reactive current and the Budeanu complemented reactive current are derived. The article also demonstrates their orthogonality concerning the remaining components, indicating that each of the seven components can exist independently of the others. Furthermore, in the extended Budeanu theory, it is possible to identify which equivalent parameters of the load are responsible for the individual currents (powers) and which components are associated with the total distortion power proposed by Budeanu in 1927. All of the calculations were performed in Matlab/Simulink 2023b software. Full article

This article presents a new modulation technique called three-dimensional sigma–delta (3D-$\Sigma \Delta$) modulation for high-frequency three-leg four-wire voltage source converters (VSCs) that use wide-bandgap (WBG) semiconductors. These WBG devices allow for the use of high switching frequencies with a greater efficiency than silicon devices. The proposed 3D-$\Sigma \Delta$ technique enables operation at a variable switching frequency, resulting in a significant reduction in switching losses compared to classical pulse-width modulation (PWM) techniques. Moreover, the 3D-$\Sigma \Delta$ technique uses a fast-processing 3D quantiser that simplifies implementation and considerably reduces computational costs. The behaviour of the 3D-$\Sigma \Delta$ modulation is analysed using MATLAB/Simulink and PLECS. The experimental results performed on an active power filter that uses silicon carbide (SiC) MOSFETs demonstrate an improvement in converter efficiency compared to the conventional SPWM technique. Additionally, the experimental results show how 3D-$\Sigma \Delta$ allows for the compensation of harmonics and homopolar currents, thereby balancing the electrical grid currents. The experiments also show that the proposed 3D-$\Sigma \Delta$ modulation outperforms an SPWM technique in terms of power quality, since the former achieves a larger reduction in the harmonic content of the power grid. In conclusion, the proposed modulation technique is an attractive option for improving the performance of four-wire converters in active power filter applications. Full article

Energy-feed power electronic loads can precisely control the phase and magnitude of the power supply output current, achieving the emulation of loads. Moreover, they can feed energy back to the grid for energy regeneration, demonstrating significant research value. This article proposes an energy-fed power electronic load topology and control method that can realize the static and dynamic simulation of linear and non-linear loads and take into account the simulation needs of single-phase, three-phase three-wire, and three-phase four-wire loads. The main circuit uses a two-stage back-to-back AC/DC/AC structure: the front side is a three-phase four-wire split capacitor PWM rectifier bridge, which is used to simulate loads under various operating conditions; the back side is a three-phase three-wire PWM inverter bridge, which realizes the energy feeding back to the grid and reduces the waste of energy; and the intermediate side uses a split capacitor to equalize the voltage and achieve voltage stabilization. The topology is analyzed under the simulation demands of three-phase balanced, three-phase unbalanced, single-phase and non-linear loads. Finally, a MATLAB(R2022a)/Simulink simulation platform is built for a power electronic load with a rated capacity of 200 kVA. The simulation results verify the effectiveness, feasibility, and advancement of the power electronic load proposed in this article. Full article

This article presents the concept of a mathematical description of a three-phase, four-wire asymmetrical electric circuit in decomposition into Voltages’ Physical Components (VPC), associated with distinctive physical phenomena in the load. This is an alternative method of mathematical description to the Currents’ Physical Components (CPC) still being developed since the end of the last century. According to previous studies, the improvement of the power factor in three-phase systems is possible by observing several components. Compensation for the scattered power is possible only by using a reactive compensator connected in series with the load. Thanks to the presented analytical method, it is possible to design compensators connected in series with the load. The VPC power theory opens the possibility of improving the power factor in three-phase networks for loads with asymmetry between phases. Due to the unfavorable impact of high currents on the compensator branches, the method proposed in the article can improve the energy quality in local low-power grids. However, the possibility of its practical use in high-power industrial networks is questionable. Full article

In this paper, a solution is proposed to the problem of the unequal phase imbalance of output voltage caused by a three-phase, four-wire, split capacitor inverter when the load is unbalanced. First, the triple-loop control strategy was used to solve the unequal amplitude problem. This method used the feedforward + feedback composite control strategy on the inductor current inner-loop and voltage mid-loop to decrease the disturbance of the power and load. And the Root Mean Square (RMS) of voltage on the outer-loop completed the control of amplitude for the three-phase voltage. Second, to solve the imbalanced phase problem, the imbalance operation mechanism of the three-phase four-wire inverter was analyzed. It is known from the analysis that the phase imbalance is related to the DC-side splitting capacitance. The function relations between the DC-side capacitance and phase angle between each phase was simulated by MATLAB. But, it was too complicated to calculate the magnitude of the capacitance value through the functional relationship. In order to simplify the design of the DC-side splitting capacitor, the relations among the imbalanced current, the voltage fluctuations of the DC-side capacitor and the harmonics of load voltage were analyzed. In addition, by following the requirement of the national standard about the harmonics of load voltage, a DC-side capacitor design was mentioned to decrease the influence of imbalanced phase. Finally, simulation and experimental results show that the three-phase load voltage is stable, the THD value is less than 3%, and three-phase voltage unbalance is less than 2%, thus verifying the effectiveness of the proposed DC-side split capacitor design and control strategy. Full article

Electrical Power quality in distribution systems is crucial to both utility and consumers simultaneously. The main issue that affects the quality factor of electrical distribution systems is phase load imbalance. Phase imbalance is a major issue in distribution networks in Pakistan, India, the United States, China, and other nations and regions. The distribution system in Pakistan is normally a three-phase, four-wire system, whereas our residential and commercial loads are often single-phase, resulting in an unbalanced system. These unbalanced circumstances in the system result in single-phasing, overloading, and overheating situations, and the return of current to neutral, as well as increased power system investment and operational expenses. In this paper, several methodologies for phase balance are being studied. After researching several techniques of phase balancing and building on that methodology, a simulation prototype is developed, and different unbalanced situations are studied. To analyze unbalanced conditions in practical mode, a hardware prototype is developed on the basis of simulation. Examined some unbalanced loads on the simulation prototype and then on the hardware prototype and achieved the best possible load balancing on phases. Full article

Three-phase four-wire voltage inverters are commonly used in energy complexes based on distributed generation sources (solar panels, wind power plants, hydrogen fuel cells) and accumulator batteries. They allow to power loads, including single-phase ones, which require neutral point connection. In these cases, phase voltage formed by spatial pulse-width modulation (PWM) methods considerably differs from sinusoidal waves and has high total harmonic distortions of voltage and current curves. This article is devoted to research into the authors’ control method of a three-phase four-wire inverter, allowing for the rectification of the form of phase voltage supplying the load when applying the most common PWM (SVPWM, DPWMMIN, DPWMMAX, GDPWM) methods. The description of the method and its research results by simulation modeling and test bench are presented in the article. The simulation modeling was carried out by the developed Simulink-model of the three-phase four-wire inverter and its control system. The modeling results showed that the method application ensures sinusoidal voltage form when applying any PWM method. At this, THD_U was reduced from 21.56% to 4.39%, while THD_I was reduced from 21.16% to 1.69%. Experimental tests were carried out by a test bench featuring an uninterruptible power supply source. The authors researched the inverter operation as a component of the test bench under the control of the proposed method to form neutral point voltage. The experimental test results coincided with the simulation modeling results. Full article

As the penetration of renewable energy increases year by year, the risk of high-frequency oscillation instability increases when a three-phase, four-wire split capacitor inverter (TFSCI) is connected to the grid with complementary capacitors in weak grids. Compared to the three-phase, three-wire inverter, the TFSCI has an additional zero-sequence current loop. To improve the accuracy of the modeling and stability analysis, the effect of the zero-sequence loop needs to be considered in the impedance-based stability analysis. Therefore, a correlation model considering multi-perturbation variables is first established, based on which the inverter positive, negative, and zero sequence admittance models are derived, solving the difficult problem of impedance modeling under small perturbations. Secondly, an admittance remodeling strategy based on a negative third-order differential element and a second-order generalized integrator (SOGI) damping controller is proposed, which can improve the stability of positive, negative, and zero-sequence systems simultaneously. Finally, the effectiveness of the oscillation suppression strategy is verified by simulation and experiment. Full article

Single-loop current sensorless control allows for abolishing of the instantaneous current measurement in the control system using only a single control loop with voltage feedback to stabilise the DC-bus voltage. This approach eliminates current sensors in the control circuit, benefiting from saving space on the printed circuit board and minimising power dissipation in the current measurement circuitry. This paper focuses on the single-loop current sensorless control applied to bidirectional three-phase four-wire three-level NPC MLC by simulation analysis and demonstrates the performance of the proposed current control algorithm in the rectifier and inverter modes and the step response with power direction change and grid-voltage change. In capacitor voltage balancing, an additional controller is applied, which is capable of compensating for the voltage asymmetry caused by adding a 2.5 kOhm resistor in parallel to one of the DC-bus capacitors. Our results demonstrate good performance of the proposed control method both in the inverter and rectifier modes, showing stable current shape in the low power and full power modes with acceptable harmonics content, meeting the requirements of the IEC 61000-3-2 standard for Class A devices. The analysis showed that the proposed control approach is suitable for industrial application. Full article
