Reliable detection of the rotor winding faults in the doubly fed induction generator (DFIG) is crucial for the resilience of the variable speed energy systems. High-resistance connection (HRC) and inter-turn short circuit (ITSC) faults cause current distortions that are remarkably similar, and the rapid rotor side dynamics and the DFIG multimode operation ability also make fault diagnosis more difficult. This paper proposes a three-layer diagnostic framework named ZSC-CASI-CADI which leverages three-phase rotor currents in conjunction with rotor zero-sequence current (ZSC) for comprehensive rotor winding fault diagnosis. Fault detection is realized through ZSC magnitude and the Cosine Angle Spread Indicator (CASI) enables the strong discrimination between HRC and ITSC faults using the dispersion of rotor current phasors from the ZSC reference. Fault localization is achieved using the Current Angle Difference Indicator (CADI), which determines the faulty rotor phase through the angular deviations in rotor currents from the ZSC. The methodology is verified with extensive simulation results to demonstrate the accurate, real-time fault detection, discrimination, and localization of DFIG rotor winding faults under different load and rotor speed conditions including sub-synchronous and super-synchronous modes. The results show that the proposed framework provides a light and effective solution for rotor winding fault monitoring of the DFIG systems. Full article

The proliferation of photovoltaic energy in the electricity grid presents a significant challenge in terms of management, control, and optimization, especially due to its dependence on weather behavior and cloud passing. Even if there are a great number of articles centered on study cloud passing effects, such as voltage flickers, voltage fluctuations, or ramping events, the approaches are quite heterogeneous and lack a broader perspective. A key factor might be the limiting data sets, as wide power generation data sets often omit meteorological data and vice versa. This study uses an advanced monitoring system based on phasor measurement units (PMUs), developed by the authors. The monitoring system is installed at a photovoltaic plant and generates high-quality synchronous irradiance and power data, enabling the joint analysis of irradiance transients, solar power ramp rates, and voltage fluctuations. Therefore, the results of this article present a detailed analysis of the production parameters of photovoltaic plants, focusing on the effects of passing clouds on the photovoltaic plant’s power, current, and voltage. To that end, compression algorithms such as the Swinging Door Algorithm (SDA), commonly used to detect ramp events, were employed. It was found that SDA produces a similar ramp rate output with power and irradiance data, suggesting that both data sets may be complementary. In addition, voltage fluctuations attributable to passing clouds were analyzed. Full article

The ongoing decarbonisation of power systems is displacing synchronous generators (SGs) with converter-based plants, requiring a consistent assessment of grid-following inverters (GFLIs) and grid-forming inverters (GFMIs). Using an openly available four-bus root-mean-square (RMS) benchmark modelled in DIgSILENT PowerFactory, this work compares three generation configurations: (i) a single local SG connected at the point of common coupling; (ii) the same generator combined with a GFLI; and (iii) the generator combined with a GFMI. These configurations are evaluated under three disturbance scenarios: (1) a balanced load step, (2) an unbalanced double line-to-ground fault at low short-circuit ratio (SCR) with temporary islanding and single-shot auto-reclose, and (3) full islanding with under-frequency load shedding (UFLS), partial resynchronisation, and staged restoration. For the tested tuning ranges and within this RMS benchmark, the grid-forming configuration behaves as a low-impedance source at the point of common coupling in the phasor sense, yielding higher frequency nadirs during active-power disturbances and faster positive-sequence voltage recovery under weak and unbalanced conditions than the SG-only and SG+GFLI cases. During islanding, it supports selective UFLS, secure resynchronisation, and orderly load restoration. Rather than introducing new control theory, this work contributes a reproducible RMS benchmarking framework that integrates low-SCR operation, unbalance, and restoration sequences with a documented cross-technology tuning procedure. The findings indicate system-level improvements in frequency resilience and voltage recovery for the tested benchmark relative to the alternative configurations, while recognising that instantaneous device-level effects and broader generality will require electromagnetic-transient (EMT) or hybrid EMT/RMS validation in future work. Full article

To further enhance the deployment efficiency of synchronous phasor measurement units and rationally select deployment configuration schemes, an improved configuration method based on integer programming algorithms is proposed. Based on the existing deployment method of integer programming algorithm, on the one hand, the special conditions of end nodes and zero injection nodes are taken into consideration. By analyzing the corresponding node model matrix, special nodes are given priority processing, achieving the condition simplification of the algorithm model. On the other hand, the evaluation indicators for the construction of schemes with the same minimum deployment quantity in the solution set obtained from the iterative solution of the algorithm are further analyzed and compared, so as to screen out a more reasonable deployment method. After conducting simulation tests on the IEEE-14, IEEE-30, and NE-39 power node systems using the MATLAB platform, the depth-first search algorithm and the improved simulated annealing algorithm were compared with the improved method. Eventually, this method had fewer deployments in a similar number of deployments and less deployment time in a similar number of deployments. The results verified the superiority of this method in terms of time and deployment quantity for PMU deployment problems. Full article

In air-conditioning compressors operating under ultra-low temperature conditions, both the rotational speed and load torque are at high levels, demanding pump motors that offer high efficiency and high power at high speeds. Electrically excited synchronous motors (EESMs) satisfy these operational requirements by leveraging their inherent wide-speed field-weakening capability and superior high-speed performance characteristics. Current research on EESM primarily targets electric vehicle applications, with a high-efficiency design focused on medium and low speeds. Excitation design under constant-power–speed extension remains insufficiently explored. To address it, this paper proposes an EESM design methodology optimized for high-speed efficiency and constant-power excitation control. Key EESM parameters are determined through a dynamic phasor diagram, and design methods for turn number, split ratio, and other parameters are proposed to extend the high-efficiency region into the high-speed range. Additionally, a power output modulation strategy in the field-weakening region is introduced, enabling dynamic high-power regulation at high speed through excitation adjustment. Compared to similarly sized PMSMs, the proposed EESM exhibits consistently superior efficiency beyond 10,000 rpm, delivering 19% and 49% higher power output at 12,000 rpm and 14,000 rpm, respectively, relative to conventional pump-drive PMSMs. Experimental validation via a prototype confirms excellent high-speed efficiency and sustained constant-power performance, in alignment with the design targets. Full article

An intuitive method for estimating the inertia contribution from residual sources, such as induction motors and inverter-based power electronic facilities, in the Korea Electric Power Corporation (KEPCO) system is proposed. First, the method utilizes synchronized Phasor Measurement Units (PMUs) to obtain the measured system Rate of Change of Frequency (RoCoF) following an instantaneous power imbalance. Subsequently, the estimated system RoCoF for the same event is derived from simulations of the full dynamic model of the KEPCO system using Energy Management System (EMS) data. The estimated RoCoF accounts only for the inertia contribution from synchronous generators, as the dynamic model includes only these generators. The residual inertia of the entire power system is then estimated based on the ratio of the estimated RoCoF to the measured RoCoF, using the known inertia contribution from synchronous generators. The effectiveness of the proposed method is validated through dynamic simulations of the KEPCO system and demonstrated using real PMU and EMS data from actual disturbance events. The results illustrate that residual inertia was estimated at approximately 160 GW during daytime and around 67 GW during nighttime, indicating substantial variation in absolute terms. This finding highlights the importance of considering residual inertia contributions, particularly under varying load conditions. Full article

With the rapid development of renewable energy in China, thermal power units are facing decommissioning issues, while the power system is confronted with severe challenges such as reduced grid strength and insufficient voltage support. For power systems with multiple renewable energy stations, the short-circuit ratio at the connection points of renewable energy stations is an important indicator for measuring grid strength. Engineering requirements specify that the short-circuit ratio at these connection points should not be lower than 2.0. This study focuses on transforming retired thermal power units into synchronous condensers to improve the short-circuit ratio at renewable energy station connection points. This paper first studies the impact of thermal power unit operation, shutdown, and synchronous phasor operation on the short-circuit ratio, deriving the short-circuit ratio expressions for renewable energy stations under different states of thermal power units. It further analyzes the impact of different main transformer capacities and unit transformation capacities on the short-circuit ratio. Next, a multi-dimensional evaluation system is constructed, incorporating the change in short-circuit ratio at grid-connection points of multiple renewable energy stations ($\Delta MRSC{R}_{\mathrm{S}}$), the main transformer capacity within short-circuit ratio enhancement range ($S_{\mathrm{T}}$), the pre-retrofit short-circuit ratio level at grid-connection points of multiple renewable energy stations ($S_{\mathrm{G}}$), and the retrofitted unit capacity ($MRSC{R}_{\mathrm{S}}$) to comprehensively assess the transformed thermal power units. Finally, a case analysis conducted on the modified IEEE-39 bus system using the PSASP platform verifies that operating thermal power units as synchronous condensers can significantly enhance the short-circuit ratios of multiple renewable energy sites. Given that small-capacity thermal units are approaching retirement, there is a stronger preference for retrofitting these smaller units as synchronous condensers. The multi-dimensional evaluation method proposed in this study specifically identifies small-capacity thermal units as the most suitable candidates for such retrofitting. This approach provides theoretical support for implementing synchronous condenser operation in retired thermal power units and promotes the coordinated optimization of grid security and renewable energy integration. Full article

The rapid integration of renewable energy sources, such as photovoltaic power systems, has reduced the necessary for synchronous generators, which traditionally contributed to grid stability during disturbances. This shift has led to a decrease in reactive power reserves (RPRs), raising concerns about voltage stability. Real-time monitoring of voltage stability is crucial for transmission system operators to implement timely corrective actions. However, conventional methods, such as continuation power flow calculations, are computationally intensive and unsuitable for large-scale power systems. Machine learning techniques using data from phasor measurement units have been proposed to estimate voltage stability. However, these methods do not consider changes in generator operating conditions and fluctuating RPRs. As renewable energy generation increases, the operating conditions of generators vary, which leads to significant changes in system RPRs and voltage stability. In this paper, a voltage stability margin is proposed using regression trees with RPRs varying based on generator operation conditions. Simulations based on the IEEE 9-bus system demonstrate that the proposed approach provides an accurate and efficient voltage stability estimation. Full article

Phasor measurement units (PMUs) provide synchronized measurements to enhance power system monitoring, strategically placed to achieve full network observability with minimal cost. In this paper, the PMU placement problem for critical buses is addressed using integer linear programming, taking into account both PMU contingencies and the impact of zero-injection buses. The primary contribution is the development of a multi-stage approach to place PMUs on critical buses. Moreover, it is demonstrated that considering PMU contingencies inherently accounts for line contingencies. Furthermore, a new performance metric, the Bus Coverage Index (BCI), is proposed to evaluate the effectiveness of the placement strategy. This index overcomes the limitations of existing indices, such as the Sum of Redundancy Index (SORI) and Bus Observability Index (BOI). The results are tested on various IEEE benchmark systems under four different cases, showing significantly improved results in terms of network observability and minimized number of PMUs. In Case 1, SORI values improved significantly for the IEEE 7 and IEEE 118 bus systems, while in Case 2, enhancements were observed in the IEEE 30 and IEEE 118 systems. Case 3 demonstrated consistency in results across systems. Notably, in Case 4, the number of required PMUs was reduced in the IEEE 30, IEEE 57, IEEE 118, and New England 39 bus systems, with complete network observability. Full article

This paper presents a novel methodology to estimate the harmonic transfer impedances in electric power systems with multiple harmonic sources (HSs). The purpose is to determine the responsibility of each HS for the total harmonic distortion at a specific bus within the system, addressing a critical issue in the power quality field. To achieve this objective, it is necessary to estimate not only the individual HS, but also the transfer impedances between each source and the bus under analysis (BUA). Most methods for solving this problem are based on proper network modeling or restrict variations in harmonic sources to a single source at a time. The proposed methodology has overcome this limitation. For this, synchronized current and voltage phasors are measured at the BUA. Once the measurements are gathered, the Independent Component Analysis (ICA) method is applied to estimate the Norton equivalent. The harmonic transfer impedance (HTI) is then determined using the information provided by the ICA. To enhance the accuracy of HTI estimation, three procedures are employed for data mining the parameters provided by ICA over time to generate a well-conditioned system. Once the HTI is satisfactorily determined, the individual harmonic contributions (IHCs), i.e., the harmonic responsibility, can be estimated accurately. The effectiveness and performance of the method are demonstrated based on computational simulations using distribution and transmission systems. Additionally, the methodology is validated with real data collected from a Brazilian transmission system monitored by synchronized power quality measurement units. Simulated results show that the Total Vector Error (TVE) is less than 0.4%, and for the field data test, the TVE is less than 2%. Full article

The latest changes on the distribution network due to the presence of distributed energy resources (DERs) and electric vehicles make it necessary to monitor the grid using a real-time high-precision system. The present work centers on the development of an open-source software platform that allows for the joint management of, at least, power quality monitors (PQMs), phasor measurement units (PMUs), and smart meters (SMs), which are three of the most widespread devices on distribution networks. This framework could work remotely while allowing access to the measurements in a comfortable way for grid analysis, prediction, or control tasks. The platform must meet the requirements of synchronism and scalability needed when working with electrical monitoring devices while considering the large volumes of data that these devices generate. The framework has been experimentally validated in laboratory and field tests in two photovoltaic plants. Moreover, real-time Artificial Intelligence capabilities have been validated by implementing three Machine Learning classifiers (Neural Network, Decision Tree, and Random Forest) to distinguish between three different loads in real time. Full article

The active power-phase angle droop control avoids the frequency deviation problem caused by taking the frequency as the droop variable. However, the active power output of distributed generations (DGs) can only be allocated by adjusting the droop coefficient, and the reference value of active power output cannot be set arbitrarily. In this paper, a phase angle correction module attached to the active power-phase angle droop control is proposed. This correction module is based on the real-time data of the voltage and phase angle of the node at the generation end and the transmission end of the grid, and directly changes the phase angle reference value of the active power-phase angle droop control output. The correction can make the phase angle reference value reach the phase angle value corresponding to the active power reference value without changing the actual characteristics of the droop control, so as to adjust the active power output of the converter to reach the active power reference value. Finally, the feasibility of the correction method in different cases is verified by Matlab 23.2.0.2365128 (R2023b)/Simulink simulation. Full article

As renewable energy integration scales up, power systems increasingly depend on sources interfaced through power electronic converters, which lack rotating mass and substantially diminish system inertia. This reduction in inertia, coupled with the complex and diverse control strategies governing power electronics, presents significant challenges in accurately assessing the equivalent inertia levels within modern power systems. This paper introduces an online method for estimating the inertia time constant of power nodes, grounded in the node power flow equation, to address these challenges. The approach begins by deriving the rotor motion equation for synchronous generators and defining the inertia time constant of power nodes through an analysis of the power flow equations. Real-time frequency and voltage phasor data are collected from system nodes using phasor measurement units. The frequency state of the power equipment is then characterized using a divider formula, and the equivalent reactance between the power equipment and the node is further derived through the node power flow equation. This enables the real-time estimation of the equivalent inertia time constant for power nodes within the system. The effectiveness of the proposed method is demonstrated through simulations on the WSCC9 system, confirming its applicability for real-time system analysis. Full article

This paper proposes a correction technique for bad data and high-precision analysis based on micro-phasor measurement unit (μPMU) data for a stable and reliable smart substation. First, a high-precision wide-area monitoring system (WAMS) with 35 μPMUs installed at Korea’s Yeonggwang substation, which is connected to renewable energy sources (RESs), is introduced. Time-synchronized μPMU data are collected through the phasor data concentrator (PDC). A pre-processing program is implemented and utilized to integrate the raw data of each μPMU into a single comma-separated values (CSV) snapshot file based on the Timetag. After presenting the technique for identification and correction of event, duplicate, and spike bad data of μPMU, causal relationships are confirmed through the voltage and current fluctuations for a total of five states, such as T/L fault, tap-up, tap-down, generation, and generation shutdown. Additionally, the difference in active power between the T/L and the secondary side of the M.Tr is compared, and the fault ride through (FRT) regulations, when the fault in wind power generation (WP), etc., occurred, is analyzed. Finally, a statistical analysis, such as boxplot and kernel density, based on the instantaneous voltage fluctuation rate (IVFR) is conducted. As a result of the simulation evaluation, the proposed correction technique and precise analysis can accurately identify various phenomena in substations and reliably estimate causal relationships. Full article

The increase in renewable energy sources (RESs) in power systems is causing significant changes in their dynamic behavior. To ensure the safe operation of these systems, it is necessary to develop new methods for preserving transient stability that follow the new system dynamics. Fast-response devices such as flexible AC transmission systems (FACTSs) can improve the dynamic response of power systems. One of the most frequently used FACTS devices is the Static Var Compensator (SVC), which can improve a system’s transient stability with a proper control strategy. This paper presents a reactive power control strategy for an SVC using synchronized voltage phasor measurements and particle swarm optimization (PSO) to improve the transient stability of a multimachine power system. The PSO algorithm is based on the sensitivity analysis of bus voltage amplitudes and angles to the reactive power of the SVC. It determines the SVC reactive power required for damping active power oscillations of synchronous generators in fault conditions. The sensitivity coefficients can be determined in advance for the characteristic switching conditions of the influential part of the transmission network, and with the application of the PSO algorithm, enable quick and efficient finding of a satisfactory solution. This relatively simple and fast algorithm can be applied in real time. The proposed control strategy is tested on the IEEE 14-bus system using DIgSILENT PowerFactory. The simulation results show that an SVC with the proposed control strategy effectively minimizes the rotor angle oscillations of generators after large disturbances. Full article
