Torque motors are typically operated within a limited angular range and are widely used in high-precision control applications due to their ability to provide uniform torque throughout the operating region. In this paper, a new torque motor structure is proposed that enhances torque density while maintaining the inherent torque uniformity. The proposed motor employs an optimized stator pole geometry that enables the magnetic flux generated by both the armature and the permanent magnet to contribute more effectively to torque production. To clarify the torque generation mechanism, the flux distributions of the field and armature were analyzed and validated through finite element analysis. Key design parameters were then defined, and an optimal design was performed to maximize the average torque. The performance of the proposed structure was evaluated through a comparative analysis with a conventional torque motor, confirming its superiority. Finally, a prototype of the proposed torque motor was fabricated, and its torque performance was verified through load testing. Full article

This paper presents an analytically derived optimal control strategy for wound-rotor synchronous machines (WRSM) based on minimising the Joule losses in both the stator and rotor windings. The presented control strategy is analysed in terms of analytical derivation, machine current ratios, working regions and constraints. It is experimentally verified on a salient-pole wound-rotor synchronous machine with strongly non-linear equivalent circuit parameters. The verification was performed in two stages: first, considering constant equivalent circuit parameters while assessing strong non-linear behaviour of the machine leading to significant discrepancies in the resulting machine torque. In the second stage, after determination of non-linear machine parameters using measured flux maps, identical control methodology is analysed in terms of variations in ratios between machine currents. Using pre-calculated current ratios the same control methodology is extended for machines with strongly non-linear equivalent circuit parameters and verified in a real environment. The measurement confirms expected machine behaviour in all available control regions achievable by used synchronous motor as well as limits between these control regions. The results of the verification in a real environment show a discrepancy of approximately 5% in measured machine torque in comparison to expected value confirming the validity of the analytically derived approach and introduced modifications for machines with non-linear equivalent circuit parameters. Full article

This study presents an experimental framework for mapping the air-gap magnetic flux in electric machines operating under controlled eccentricity and tilt conditions. A six-degree-of-freedom industrial robotic arm positions the rotor, while the stator accommodates a dense single-axis Hall-sensor array. Synchronous data acquisition at 10 kHz captures magnetic-field dynamics during torque-producing excitation. A coordinate-transformation method synthesises virtual rotor poses from a limited set of physical measurements, eliminating the need for exhaustive mechanical scanning. The proposed approach generates pose-resolved RMS and THD maps, together with harmonic amplitude and phase signatures, thereby revealing localised asymmetries and phase-decoherence effects that are not predicted by idealised finite-element models. In a custom PMSM-like prototype, the local RMS value doubles (from 31 mT to 64 mT), while the THD increases by more than 25% across displacement and tilt grids. These findings provide quantitative experimental evidence of misalignment-induced magnetic-field symmetry breaking, supporting model validation and digital-twin calibration for traction, aerospace, and robotic applications. Full article

This study proposes an electromagnetic balance-based structural design and shim plate application to improve the response characteristics of an electromagnetic brake. Electromagnetic brakes typically experience response delay due to inductive effects and residual magnetic flux after power-off. To address this issue, the inner and outer thicknesses of the stator were parameterized to achieve balanced magnetic flux distribution, and a non-magnetic shim plate (SUS 304) was applied to reduce residual flux within the electromagnet. Finite element analysis (FEA) was conducted to evaluate the influence of structural parameters on the magnetic flux balance and attractive force. The optimized stator geometry provided a stable electromagnetic balance, and the shim plate effectively reduced the response delay and improved the overall response performance compared with the conventional design. These findings demonstrate that the proposed electromagnetic balance design combined with shim plate application is an effective approach to enhance the reliability and control responsiveness of electromagnetic brakes, with potential applicability to robotic and industrial actuator systems. Full article

Demand for brushless alternatives to the series universal motors and induction motors in domestic applications and automotive applications is increasing. Among the available candidates, single-phase flux-switching permanent magnet (SP-FSPM) machines have gained attention due to a simpler magnetic structure and control system. However, their torque density remains limited. Therefore, a SP doubly-fed FSPM (SP-DF-FSPM) machine is developed in this paper which features an additional set of armature windings on the rotor. By effectively utilizing the rotor slot area, the proposed SP-DF-FSPM machine enhances electrical loading and torque density while providing inherent fault-tolerant capability, a critical addition compared with conventional SP-FSPM machines. A comprehensive parameter-sensitivity analysis is conducted for a 10-stator-pole/10-rotor-tooth configuration to optimize key geometric parameters for the maximum torque and reliable self-starting operation. The electromagnetic performance of an optimized design is evaluated and compared against a conventional SP-FSPM machine. The results show that the SP-DF-FSPM machine can achieve a 24.75% higher torque output, improved efficiency, and enhanced power factors under the healthy condition. Moreover, the machine can deliver 63.5% and 36.0% torque when operating with only stator and rotor windings, respectively, demonstrating the fault-tolerant capability. Experimental validation via an SP-DF-FSPM prototype shows close agreement with simulation results. Full article

The predictive current control for the permanent magnet synchronous machine (PMSM) shows great potential in applications like flywheel energy storage, owing to its fast dynamic response and simple structure. However, under low carrier ratio conditions, conventional deadbeat predictive current control (DPCC) exhibits drawbacks such as significant current prediction error, inaccurate instruction voltage calculation, and severe torque and flux linkage coupling. This paper proposes an improved DPCC method suitable for both high and low carrier ratio operation of the PMSM. First, a modified stator voltage equation is established considering rotor flux orientation error. By treating the dq-coordinates as stationary and accounting for rotor rotation within the control period, a dynamic PMSM model is developed, effectively suppressing cross-axis coupling under low carrier ratios. Simultaneously, a multi-coordinate variable synchronization method is also introduced to eliminate prediction and voltage errors caused by cross-coordinate computation, enabling precise deadbeat control across all carrier ratios. The experimental results demonstrate that the proposed method enhances torque-flux decoupling, improves current prediction and tracking accuracy at low carrier ratios, and offers a reliable solution for dynamic control in flywheel energy storage systems. Full article

For an induction motor operating as a symmetric three-phase system, the performance of indirect field-oriented vector control relies heavily on the accuracy of the rotor time constant. Any inaccuracies result in severe torque errors and compromise dynamic performance because of the coupling between the flux and torque controls. Although conventional IFOC methods are intended to compensate for the rotor time constant error, they rely on induction machine parameters such as the mutual and leakage inductances. This paper proposes an online method for tuning the rotor time constant independent of other parameters. First, an active power model of three-phase symmetric induction motor is selected to estimate the stator resistance based on a model reference adaptive system, which requires only the rotor time constant. Additionally, high-frequency current injection and torque ripple estimation without phase delay or amplitude decay are introduced to compensate for the rotor time constant. When a high-frequency current is injected, the rotor time constant and stator resistance can be simultaneously tuned without depending on other parameters. A high-frequency current is injected only when a rotor time constant error is detected from the estimated stator resistance. This behavior is enabled by the correlation between the stator resistance and the rotor time constant. Simulation results using MATLAB/Simulink regarding the symmetric three-phase induction motor validate the proposed method. Full article

To improve the control accuracy and address the parameter disturbance issues of joint-driven permanent magnet synchronous motors in intelligent manufacturing, this paper proposes an improved deadbeat predictive current predictive control (DPCC) scheme that eliminates dead zones. This scheme establishes a multi-parameter identification model based on the error equation of the d-q axis predicted current, which improves the problem of not being able to identify all parameters caused by insufficient input signals. It also implements decoupling compensation for the coupling between the d-q axis inductance, stator resistance, and magnetic flux linkage. To meet the anticipated control objectives and account for external disturbances, a low-complexity specified performance tracking controller (LCSPC) based on output target error signals has been designed. This mitigates output delay issues arising from nonlinear components during motor operation. Finally, simulation analysis and experimental testing demonstrate that the proposed control scheme achieves high identification accuracy with minimal delay, thus meeting the transient control performance requirements for motors in intelligent manufacturing processes. Full article

This paper proposes a novel direct-drive rotary actuator based on a modular five-phase outer-rotor flux-switching permanent magnet (FSPM) machine to overcome the limitations of conventional actuators with gear reducers, such as mechanical complexity and low reliability. The research focused on a synergistic design of a lightweight, high-torque-density motor and a precise control strategy. The methodology involved a structured topology evolution to create a modular stator architecture, followed by finite element analysis-based electromagnetic optimization. To achieve precision control, a multi-vector model predictive current control (MPCC) scheme was developed. This optimization process contributed to a significant performance improvement, increasing the average torque to 13.33 Nm, reducing torque ripple from 9.81% to 2.36% and obtaining a maximum position error under 1 mil. The key result was experimentally validated using an 8 kg inertial load, confirming the actuator’s feasibility for industrial deployment. Full article

This paper presents the design and experimental validation of a 3D-printed BLDC motor featuring a hollow-shaft rotor and nickel-reinforced stator. The rotor employs neodymium magnets to reduce inertia while maintaining torque density, and the stator integrates thin nickel laminations to improve flux density. A custom controller with Hall sensors, BiSS-C encoder, and CAN interface enables closed-loop position control. Experiments demonstrate stable tracking with short settling time and negligible steady-state error, confirming feasibility for robotic and precision applications. Full article

Magnetically levitated artificial hearts impose stringent requirements on the blood-pump motor: zero friction, minimal heat generation and full biocompatibility. Traditional mechanical-bearing motors and permanent-magnet bearingless motors fail to satisfy all of these demands simultaneously. A bearingless switched reluctance motor (BSRM), whose rotor contains no permanent magnets, offers a simple structure, high thermal tolerance, and inherent fault-tolerance, making it an ideal drive for implantable circulatory support. This paper proposes an 18/15/6-pole dual-stator BSRM (DSBSRM) that spatially separates the torque and levitation flux paths, enabling independent, high-precision control of both functions. To suppress torque ripple induced by pulsatile blood flow, a variable-overlap TSF-PWM-DITC strategy is developed that optimizes commutation angles online. In addition, a grey-wolf-optimized fast non-singular terminal sliding-mode controller (NRLTSMC) is introduced to shorten rotor displacement–error convergence time and to enhance suspension robustness against hydraulic disturbances. Co-simulation results under typical artificial heart operating conditions show noticeable reductions in torque ripple and speed fluctuation, as well as smaller rotor radial positioning error, validating the proposed motor and control scheme as a high-performance, biocompatible, and reliable drive solution for next-generation magnetically levitated artificial hearts. Full article

In this study, a sensorless speed control method is proposed to enhance the speed control performance under load variations by utilizing a discrete-time flux observer in a V/f control environment. Due to their simple structure, low cost, and high reliability, induction motors are widely used in various fields, such as fans, pumps, and home appliances. Among the control methods for induction motors, V/f control operates as an open-loop system, without using speed sensors. It is mainly applied in industrial environments where fast dynamic performance is not required, due to its simple implementation and low cost. However, in cases of load variations or low-speed operation, it suffers from performance degradation and control limitations due to flux variations. To overcome these issues, this paper proposes a method that uses a discrete-time flux observer to estimate the stator flux. We calculate the rotor speed based on the estimated flux, and then improve V/f control performance by adding a compensation signal to the reference frequency, which signal is generated through a PI controller based on the difference between the estimated rotor speed and the reference speed. The proposed method is validated through MATLAB/Simulink-based simulations and experiments using a 5.5 kW induction motor M−G set, confirming that compared to conventional V/f control, the speed maintenance capability and overall robustness against load variations are enhanced. This study presents a practical solution to effectively improve the performance of existing V/f control systems without adding external sensors. Full article

This paper introduces a novel sensorless speed control strategy for squirrel-cage induction motors, which ensures robust operation in the presence of external disturbances by applying the state feedback technique. Based on the induction motor model, the speed controller is synthesized by defining a sliding variable that is driven to zero through the supertwisting control law, ensuring the stabilization of the tracking error. The time derivative of the error variable is estimated using a robust differentiator based on the sliding-mode twisting algorithm, thereby eliminating the need to estimate the load torque. A robust observer is employed to estimate the rotor speed and flux linkages simultaneously. The convergence of the estimated rotor flux linkages is enforced through a discontinuous first-order sliding-mode input, while the convergence of the rotor speed estimate is attained via a quasi-continuous super-twisting sliding-mode input. In the proposed model, the inductance parameters are determined from the magnetizing inductance and the leakage inductances of the stator and rotor. A procedure is also presented for adjusting the stator resistance and leakage inductances, taking into account the squirrel-cage rotor type and the skin effect in alternating current conduction. The performance of the sensorless speed control system under variations in load torque and reference speed is validated through experimental testing. The rotor speed estimation provided by the robust observer is accurate. The reference speed tracking control, evaluated using a 1600–1700 rpm pulse train phase-shifted by 4 s with respect to a 0–0.5 N·m pulse train, demonstrates high precision. Full article

Subject to magnetic saturation, temperature rise, and other factors, the electrical parameters of permanent magnet synchronous motors (PMSMs) in marine electric propulsion systems exhibit time-varying characteristics. Existing parameter identification algorithms fail to fully satisfy the requirements of high-performance PMSM control systems in terms of accuracy, response speed, and robustness. To address these limitations, this paper introduces multi-innovation theory and proposes a novel multi-innovation extended Kalman filter (MIEKF) for the identification of key electrical parameters of PMSMs, including stator resistance, d-axis inductance, q-axis inductance, and permanent magnet flux linkage. Firstly, the extended Kalman filter (EKF) algorithm is applied to linearize the nonlinear system, enhancing the EKF’s applicability for parameter identification in highly nonlinear PMSM systems. Subsequently, multi-innovation theory is incorporated into the EKF framework to construct the MIEKF algorithm, which utilizes historical state data through iterative updates to improve the identification accuracy and dynamic response speed. An MIEKF-based PMSM parameter identification model is then established to achieve online multi-parameter identification. Finally, a StarSim RCP MT1050-based experimental platform for online PMSM parameter identification is implemented to validate the effectiveness and superiority of the proposed MIEKF algorithm under three operational conditions: no-load, speed variation, and load variation. Experimental results demonstrate that (1) across three distinct operating conditions, compared to forget factor recursive least squares (FFRLS) and the EKF, the MIEKF exhibits smaller fluctuation amplitudes, shorter fluctuation durations, mean values closest to calibrated references, and minimal deviation rates and root mean square errors in identification results; (2) under the load increase condition, the EKF shows significantly increased deviation rates while the MIEKF maintains high identification accuracy and demonstrates enhanced anti-interference ability. This research has achieved a comprehensive improvement in parameter identification accuracy, dynamic response speed, convergence effect, and anti-interference performance, providing an electrical parameter identification method characterized by high accuracy, rapid dynamic response, and strong robustness for high-performance control of PMSMs in marine electric propulsion systems. Full article

The magnetic properties of electrical steel sheets, crucial for efficient electrical machine performance, deteriorate through manufacturing processes. This study investigates the impact of different manufacturing steps on magnetization behavior and specific core losses in M270-50A electrical steel, and their influence on the performance of a reluctance synchronous machine (RSM). Magnetic measurements were conducted on three material states: laser-cut strips, assembled stator cores, and press-fitted stator cores. These were integrated into finite element analysis (FEA) models, including an extended two-region stator model that separates yoke and tooth regions to reflect different manufacturing effects. Simulations examined torque characteristics and flux linkage under various loading conditions and were validated using a prototype machine. The findings of magnetic measurements indicate that manufacturing-induced stresses significantly increase magnetization demand and core losses—up to 650% and 53%, respectively. These effects lead to a 4.2% reduction in maximum air gap torque and notable changes in torque characteristic curves and d-axis flux linkage maps. Including realistic magnetic data yielded torque predictions closely aligned with experimental results and reduced discrepancy in core loss simulation by more than 50%. The study’s findings indicate that accounting for manufacturing influences in material characterization enhances modeling accuracy and enables optimized electrical machine designs and control strategies. Full article
