Search Results (18)

Search Parameters:
Keywords = spin-exchange optical pumping

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
15 pages, 1185 KiB
Article
Analysis and Suppression of Pump Beam Alignment Error in SERF Co-Magnetometer
by Qi Yuan, Wenfeng Fan, Haoying Pang, Xue Han, Zhuo Wang and Wei Quan
Photonics 2025, 12(6), 550; https://doi.org/10.3390/photonics12060550 - 29 May 2025
Viewed by 423
Abstract
The beam angle error of the pump light in a K-Rb-21Ne spin-exchange relaxation-free atomic co-magnetometer (SERFCM) significantly degrades the efficiency of optical pumping and the system’s ability to suppress magnetic field noise. In this work, a system response model that incorporates [...] Read more.
The beam angle error of the pump light in a K-Rb-21Ne spin-exchange relaxation-free atomic co-magnetometer (SERFCM) significantly degrades the efficiency of optical pumping and the system’s ability to suppress magnetic field noise. In this work, a system response model that incorporates the pump beam alignment error (PBAE) is established. The influence of PBAE on the scale factor, bandwidth, and magnetic noise response of the inertial output is analyzed. Theoretical results show that PBAE increases the internal magnetic field gradient, reduces the efficiency of nuclear spin hyperpolarization, and increases the nuclear spin relaxation rate, ultimately degrading the system’s scale factor, bandwidth, and magnetic noise suppression capability. Experimental results demonstrate that, compared to the original SERFCM with PBAE, aligning the pump laser using the proposed method improves the polarization strength of nuclear spins by approximately 10% and enhances magnetic noise suppression by 40%. Full article
(This article belongs to the Special Issue Quantum Enhanced Devices and Instruments for Sensing Applications)
Show Figures

Figure 1

12 pages, 690 KiB
Article
Bias Calibration of Optically Pumped Magnetometers Based on Variable Sensitivity
by Jieya Chen, Chaofeng Ye, Xingshen Hou, Yaqiong Niu and Limin Sun
Sensors 2025, 25(2), 433; https://doi.org/10.3390/s25020433 - 13 Jan 2025
Cited by 1 | Viewed by 1347
Abstract
Optically pumped magnetometers (OPMs) functioning in the spin-exchange relaxation-free (SERF) regime have emerged as attractive options for measuring weak magnetic fields, owing to their portability and remarkable sensitivity. The operation of SERF-OPM critically relies on the ambient magnetic field; thus, a magnetic field [...] Read more.
Optically pumped magnetometers (OPMs) functioning in the spin-exchange relaxation-free (SERF) regime have emerged as attractive options for measuring weak magnetic fields, owing to their portability and remarkable sensitivity. The operation of SERF-OPM critically relies on the ambient magnetic field; thus, a magnetic field compensation device is commonly employed to mitigate the ambient magnetic field to near zero. Nonetheless, the bias of the OPM may influence the compensation impact, a subject that remains unexamined. This paper introduced an innovative bias calibration technique for OPMs. The sensitivity of the OPM was altered by adjusting the cell temperature. The output of the OPM was then documented with varying sensitivity. It is assumed that the signal exhibits a linear correlation with the environmental magnetic field, and the statistical characteristics of the magnetic field are identical for both measurements, upon which the bias of the OPM is assessed. The bias was subsequently considered in the feedback magnetic field compensation mechanism. The results indicate that this technique might successfully reduce environmental magnetic fluctuations and enhance the sensitivity of the OPM. This technique measured the magnetic field produced by the human heart, confirming the viability of the ultra-weak biomagnetic field measurement approach. Full article
Show Figures

Figure 1

13 pages, 4538 KiB
Article
Measuring Transverse Relaxation with a Single-Beam 894 nm VCSEL for Cs-Xe NMR Gyroscope Miniaturization
by Qingyang Zhao, Ruochen Zhang and Hua Liu
Sensors 2024, 24(17), 5692; https://doi.org/10.3390/s24175692 - 1 Sep 2024
Cited by 3 | Viewed by 1416
Abstract
The spin-exchange-pumped nuclear magnetic resonance gyroscope (NMRG) is a pivotal tool in quantum navigation. The transverse relaxation of atoms critically impacts the NMRG’s performance parameters and is essential for judging normal operation. Conventional methods for measuring transverse relaxation typically use dual beams, which [...] Read more.
The spin-exchange-pumped nuclear magnetic resonance gyroscope (NMRG) is a pivotal tool in quantum navigation. The transverse relaxation of atoms critically impacts the NMRG’s performance parameters and is essential for judging normal operation. Conventional methods for measuring transverse relaxation typically use dual beams, which involves complex optical path and frequency stabilization systems, thereby complicating miniaturization and integration. This paper proposes a method to construct a 133Cs parametric resonance magnetometer using a single-beam vertical-cavity surface-emitting laser (VCSEL) to measure the transverse relaxation of 129Xe and 131Xe. Based on this method, the volume of the gyroscope probe is significantly reduced to 50 cm3. Experimental results demonstrate that the constructed Cs-Xe NMRG can achieve a transverse relaxation time (T2) of 8.1 s under static conditions. Within the cell temperature range of 70 °C to 110 °C, T2 decreases with increasing temperature, while the signal amplitude inversely increases. The research lays the foundation for continuous measurement operations of miniaturized NMRGs. Full article
(This article belongs to the Special Issue Atomic Magnetic Sensors)
Show Figures

Figure 1

16 pages, 987 KiB
Article
Theoretical Study on Performing Movement-Related MEG with 83Kr-Based Atomic Comagnetometer
by Yao Chen, Ruyang Guo, Jiyang Wang, Mingzhi Yu, Man Zhao and Libo Zhao
Photonics 2023, 10(12), 1302; https://doi.org/10.3390/photonics10121302 - 24 Nov 2023
Cited by 1 | Viewed by 1573
Abstract
A K–Rb–83Kr-based atomic comagnetometer for performing movement-related Magnetoencephalography (MEG) is theoretically studied in this paper. Parameters such as the spin-exchange rates, the spin-dephasing rates and the polarization of the nuclear spins are studied to configure the comagnetometer. The results show that [...] Read more.
A K–Rb–83Kr-based atomic comagnetometer for performing movement-related Magnetoencephalography (MEG) is theoretically studied in this paper. Parameters such as the spin-exchange rates, the spin-dephasing rates and the polarization of the nuclear spins are studied to configure the comagnetometer. The results show that the nuclear spin can generate a magnetic field of around 700 nT, at which the nuclear spin can compensate for a wide range of magnetic fields. In this paper, we also show the fabrication process for hybrid optical-pumping vapor cells, whereby alkali metals are mixed in a glove box that is then connected to the alkali vapor-cell fabrication system. Full article
(This article belongs to the Special Issue Optically Pumped Magnetometer and Its Application)
Show Figures

Figure 1

14 pages, 1661 KiB
Article
In-Situ Detection for Atomic Density in the K-Rb-21Ne Co-Magnetometer via an Optical Heterodyne Interferometry
by Sixun Liu, Zhuo Wang and Yueyang Zhai
Photonics 2023, 10(10), 1091; https://doi.org/10.3390/photonics10101091 - 28 Sep 2023
Cited by 5 | Viewed by 1360
Abstract
The low-frequency fluctuations of the atomic density within the cell can induce the longterm drift of the K-Rb-21Ne spin-exchange relaxation-free (SERF) co-magnetometer output, such that the accurate measurement of in situ atomic density is of great significance for improving the performance [...] Read more.
The low-frequency fluctuations of the atomic density within the cell can induce the longterm drift of the K-Rb-21Ne spin-exchange relaxation-free (SERF) co-magnetometer output, such that the accurate measurement of in situ atomic density is of great significance for improving the performance of co-magnetometer. In this paper, the complex refractive index model of the spin ensembles under the hybrid optical pumping condition is established first, according to which the relation between atomic density and its complex refractive index is revealed and an optical heterodyne-based scheme for atomic density detection is proposed. The dependence of the atomic density on the demodulated phase signal from the optical heterodyne-based scheme is provided by numerical simulations. After that, a dual acousto-optics frequency shifter (AOFS)-based optical heterodyne interferometry is constructed with a noise level below 1 mrad/Hz for frequencies > 1 Hz, and a compact SERF co-magnetometer is implemented as the testing medium, by which the atomic density detection with resolution of 0.40 K @ 473 K is reached and the experimental results agree well with theoretical simulations. Moreover, the detection scheme proposed in this paper has the properties of high detection sensitivity and immunity to laser power fluctuation, which are also proved experimentally. Full article
Show Figures

Figure 1

14 pages, 4065 KiB
Article
A 1083 nm Narrow-Linewidth DFB Semiconductor Laser for Quantum Magnetometry
by Mengying Wu, Haiyang Yu, Wenyu Wang, Shaojie Li, Yulian Cao and Jianguo Liu
Photonics 2023, 10(8), 934; https://doi.org/10.3390/photonics10080934 - 15 Aug 2023
Cited by 1 | Viewed by 2255 | Correction
Abstract
A 1083 nm laser, corresponding to a characteristic spectral line of 3He 23S1-23P, is the core light source for spin-exchange optical pumping-free technology, and thus has important developmental significance. In this paper, precise wavelength 1083.34 nm [...] Read more.
A 1083 nm laser, corresponding to a characteristic spectral line of 3He 23S1-23P, is the core light source for spin-exchange optical pumping-free technology, and thus has important developmental significance. In this paper, precise wavelength 1083.34 nm semiconductor lasers with 285 mW output power, −144.73 dBc/Hz RIN noise and 30.9952 kHz linewidth have been successfully achieved via reasonable chips design, high-quality epitaxial growth process and ultra-low reflectivity coating fabrication. All the results show the highest output power and ultra-narrow linewidth of the single-frequency 1083 nm DFB semiconductor laser achieved in this paper, which can fully satisfy the requirement of quantum magnetometers. Full article
Show Figures

Figure 1

16 pages, 2957 KiB
Article
Combined Polarization/Magnetic Modulation of a Transverse NMR Gyroscope
by Susan S. Sorensen and Thad G. Walker
Sensors 2023, 23(10), 4649; https://doi.org/10.3390/s23104649 - 11 May 2023
Cited by 5 | Viewed by 2131
Abstract
In this paper, we describe a new approach to the continuous operation of a transverse spin-exchange optically pumped NMR gyroscope that utilizes modulation of both the applied bias field and the optical pumping. We demonstrate the simultaneous, continuous excitation of 131Xe and [...] Read more.
In this paper, we describe a new approach to the continuous operation of a transverse spin-exchange optically pumped NMR gyroscope that utilizes modulation of both the applied bias field and the optical pumping. We demonstrate the simultaneous, continuous excitation of 131Xe and 129Xe using this hybrid modulation approach and the real-time demodulation of the Xe precession using a custom least-squares fitting algorithm. We present rotation rate measurements with this device, with a common field suppression factor of ∼1400, an angle random walk of 21 μHz/Hz, and a bias instability of ∼480 nHz after ∼1000 s. Full article
(This article belongs to the Special Issue Sensing Technologies for Precision Measurements)
Show Figures

Figure 1

11 pages, 6109 KiB
Communication
Nonzero-Order Resonances in Single-Beam Spin-Exchange Relaxation-Free Magnetometers
by Kun Wang, Kaixuan Zhang, Nuozhou Xu, Yifan Yan, Xiaoyu Li and Binquan Zhou
Photonics 2023, 10(4), 458; https://doi.org/10.3390/photonics10040458 - 15 Apr 2023
Cited by 2 | Viewed by 2238
Abstract
Zero-field optically pumped magnetometers operating in the spin-exchange relaxation-free (SERF) regime have been extensively studied, and usually depend on zeroth-order parametric resonance to measure the magnetic field. However, the studies conducted on this topic lack thorough analyses and in-depth discussion of nonzero-order magnetic [...] Read more.
Zero-field optically pumped magnetometers operating in the spin-exchange relaxation-free (SERF) regime have been extensively studied, and usually depend on zeroth-order parametric resonance to measure the magnetic field. However, the studies conducted on this topic lack thorough analyses and in-depth discussion of nonzero-order magnetic resonances in single-beam SERF magnetometers. In this paper, we analyzed the nonzero-order resonance, especially the first-order resonance, based on a single-beam SERF magnetometer, and discussed its various applications. A comprehensive theoretical analysis and experiments were conducted with respect to multiple functions, including nonzero finite magnetic field measurements, spin polarization measurement, and in situ coil constant calibration. The results showed that first-order resonance can be utilized for nonzerofinite magnetic field measurements, and the spin polarization of alkali-metal atoms can be determined by measuring the slowing-down factor using the resonance condition. Furthermore, acquiring the first-order resonance point at an equivalent zero pump light power through fitting offers an approach for quick and precise in situ coil constant calibration. This study contributes to the applications of SERF magnetometers in nonzero finite magnetic fields. Full article
(This article belongs to the Special Issue Optically Pumped Magnetometer and Its Application)
Show Figures

Figure 1

16 pages, 2051 KiB
Article
Automated Machine Learning Strategies for Multi-Parameter Optimisation of a Caesium-Based Portable Zero-Field Magnetometer
by Rach Dawson, Carolyn O’Dwyer, Edward Irwin, Marcin S. Mrozowski, Dominic Hunter, Stuart Ingleby, Erling Riis and Paul F. Griffin
Sensors 2023, 23(8), 4007; https://doi.org/10.3390/s23084007 - 15 Apr 2023
Cited by 7 | Viewed by 3157
Abstract
Machine learning (ML) is an effective tool to interrogate complex systems to find optimal parameters more efficiently than through manual methods. This efficiency is particularly important for systems with complex dynamics between multiple parameters and a subsequent high number of parameter configurations, where [...] Read more.
Machine learning (ML) is an effective tool to interrogate complex systems to find optimal parameters more efficiently than through manual methods. This efficiency is particularly important for systems with complex dynamics between multiple parameters and a subsequent high number of parameter configurations, where an exhaustive optimisation search would be impractical. Here we present a number of automated machine learning strategies utilised for optimisation of a single-beam caesium (Cs) spin exchange relaxation free (SERF) optically pumped magnetometer (OPM). The sensitivity of the OPM (T/Hz), is optimised through direct measurement of the noise floor, and indirectly through measurement of the on-resonance demodulated gradient (mV/nT) of the zero-field resonance. Both methods provide a viable strategy for the optimisation of sensitivity through effective control of the OPM’s operational parameters. Ultimately, this machine learning approach increased the optimal sensitivity from 500 fT/Hz to <109fT/Hz. The flexibility and efficiency of the ML approaches can be utilised to benchmark SERF OPM sensor hardware improvements, such as cell geometry, alkali species and sensor topologies. Full article
Show Figures

Figure 1

16 pages, 2822 KiB
Article
Precise Determination of Magnetic Gradient Relaxation of Coupled Atomic Spin Ensemble in Spin-Exchange Relaxation-Free Co-Magnetometer
by Xiujie Fang, Kai Wei, Wenfeng Fan, Siran Li, Qian Cao, Wei Quan, Yueyang Zhai and Zhisong Xiao
Photonics 2023, 10(4), 400; https://doi.org/10.3390/photonics10040400 - 3 Apr 2023
Cited by 2 | Viewed by 1939
Abstract
Inside a spin-exchange relaxation-free (SERF) co-magnetometer with a high-pressure buffer gas atomic cell, the magnetic field gradient causes the decoherence of atomic spins to produce magnetic-field gradient relaxation. This paper presents a new method for the accurate measurement of magnetic field gradient relaxation [...] Read more.
Inside a spin-exchange relaxation-free (SERF) co-magnetometer with a high-pressure buffer gas atomic cell, the magnetic field gradient causes the decoherence of atomic spins to produce magnetic-field gradient relaxation. This paper presents a new method for the accurate measurement of magnetic field gradient relaxation of alkali metal atoms and inert atoms of strongly coupled spin systems under triaxial magnetic field gradients in the K-Rb-21Ne co-magnetometer. The magnetic field gradient relaxation of alkali metal atoms is measured using a step magnetic field modulation method, and the magnetic field gradient relaxation of inert atoms is measured using a combined free induction decay and spin growth method. The method does not require the use of large background magnetic fields and RF fields to maintain the atoms in the SERF state, does not require additional optics, and is not affected by the pumping or detecting of optical power. A kinetic model that considers a large electron-equivalent magnetic field was designed and a gradient relaxation model was developed. The quadratic coefficients of the experimentally measured gradient relaxation curves fit the theoretical model well over the range of the applied magnetic field gradients, confirming the validity of the proposed method. Full article
(This article belongs to the Special Issue Optically Pumped Magnetometer and Its Application)
Show Figures

Figure 1

14 pages, 2320 KiB
Article
A Novel Measurement Method for Spin Polarization Three Axis Spatial Distribution in Spin-Exchange Relaxation Free Atomic Magnetometer
by Xiujie Fang, Jin Li, Yanning Ma, Kai Wei, Wenfeng Fan, Yueyang Zhai, Wei Quan and Zhisong Xiao
Photonics 2023, 10(3), 332; https://doi.org/10.3390/photonics10030332 - 20 Mar 2023
Cited by 1 | Viewed by 2643
Abstract
The measurement of atomic spin polarization distribution in spin-exchange relaxation free (SERF) magnetometer is an important topic for improving the sensitivity and consistency of multi-channel magnetic field measurement applications. A novel spin polarization spatial distribution measurement method is presented based on the transient [...] Read more.
The measurement of atomic spin polarization distribution in spin-exchange relaxation free (SERF) magnetometer is an important topic for improving the sensitivity and consistency of multi-channel magnetic field measurement applications. A novel spin polarization spatial distribution measurement method is presented based on the transient response of the magnetometer after modulating the pumped light with a chopper. Polarization is obtained by a slow-down factor based on the fast spin-exchange interaction effects. Longitudinal and transverse polarization distributions are measured simultaneously without interrupting the operation of the SERF status. Under different oscillating magnetic fields, the spin polarization is measured at the cell centroid. Residual magnetic field inside the magnetometer is obtained from the linear relationship between the precession frequency and the oscillating magnetic field. The one-dimensional polarization distributions in the x, y, and z axes are measured using a digital micromirror device with a resolution of 0.25 cm. The measurement results conform to the Lambert-Bier absorption law and the Gaussian distribution law. Furthermore, 7 × 7 two-dimensional spatial distribution measurements of polarization on the xy and yz planes are performed. Nonuniformity of 1.04 in the xy plane and 1.82 in the yz plane in the built magnetometer. Compared with other measurement methods, the distribution measurement method proposed is independent of optical depth and suitable for low polarization and high polarization applications. Based on the results of the proposed measurement method of spin polarization spatial distribution, further compensation can improve the application consistency of multi-channel magnetic field measurements and improve the sensitivity of single-channel differential measurements. Full article
(This article belongs to the Special Issue Optically Pumped Magnetometer and Its Application)
Show Figures

Figure 1

25 pages, 21000 KiB
Article
Investigating Rubidium Density and Temperature Distributions in a High-Throughput 129Xe-Rb Spin-Exchange Optical Pumping Polarizer
by James E. Ball, Jim M. Wild and Graham Norquay
Molecules 2023, 28(1), 11; https://doi.org/10.3390/molecules28010011 - 20 Dec 2022
Cited by 4 | Viewed by 3026
Abstract
Accurate knowledge of the rubidium (Rb) vapor density, [Rb], is necessary to correctly model the spin dynamics of 129Xe-Rb spin-exchange optical pumping (SEOP). Here we present a systematic evaluation of [Rb] within a high-throughput 129Xe-Rb hyperpolarizer [...] Read more.
Accurate knowledge of the rubidium (Rb) vapor density, [Rb], is necessary to correctly model the spin dynamics of 129Xe-Rb spin-exchange optical pumping (SEOP). Here we present a systematic evaluation of [Rb] within a high-throughput 129Xe-Rb hyperpolarizer during continuous-flow SEOP. Near-infrared (52S1/252P1/2 (D1)/52P3/2 (D2)) and violet (52S1/262P1/2/62P3/2) atomic absorption spectroscopy was used to measure [Rb] within 3.5 L cylindrical SEOP cells containing different spatial distributions and amounts of Rb metal. We were able to quantify deviation from the Beer-Lambert law at high optical depth for D2 and 62P3/2 absorption by comparison with measurements of the D1 and 62P1/2 absorption lines, respectively. D2 absorption deviates from the Beer-Lambert law at [Rb]D2>4×1017 m3 whilst 52S1/262P3/2 absorption deviates from the Beer-Lambert law at [Rb]6P3/2>(4.16±0.01)×1019 m3. The measured [Rb] was used to estimate a 129Xe-Rb spin exchange cross section of γ=(1.2±0.1)×1021 m3 s1, consistent with spin-exchange cross sections from the literature. Significant [Rb] heterogeneity was observed in a SEOP cell containing 1 g of Rb localized at the back of the cell. While [Rb] homogeneity was improved for a greater surface area of the Rb source distribution in the cell, or by using a Rb presaturator, the measured [Rb] was consistently lower than that predicted by saturation Rb vapor density curves. Efforts to optimize [Rb] and thermal management within spin polarizer systems are necessary to maximize potential future enhancements of this technology. Full article
Show Figures

Figure 1

18 pages, 5908 KiB
Article
Performance Analysis of Optically Pumped 4He Magnetometers vs. Conventional SQUIDs: From Adult to Infant Head Models
by Saeed Zahran, Mahdi Mahmoudzadeh, Fabrice Wallois, Nacim Betrouni, Philippe Derambure, Matthieu Le Prado, Agustin Palacios-Laloy and Etienne Labyt
Sensors 2022, 22(8), 3093; https://doi.org/10.3390/s22083093 - 18 Apr 2022
Cited by 19 | Viewed by 4336
Abstract
Optically pumped magnetometers (OPMs) are new, room-temperature alternatives to superconducting quantum interference devices (SQUIDs) for measuring the brain’s magnetic fields. The most used OPM in MagnetoEncephaloGraphy (MEG) are based on alkali atoms operating in the spin-exchange relaxation-free (SERF) regime. These sensors do not [...] Read more.
Optically pumped magnetometers (OPMs) are new, room-temperature alternatives to superconducting quantum interference devices (SQUIDs) for measuring the brain’s magnetic fields. The most used OPM in MagnetoEncephaloGraphy (MEG) are based on alkali atoms operating in the spin-exchange relaxation-free (SERF) regime. These sensors do not require cooling but have to be heated. Another kind of OPM, based on the parametric resonance of 4He atoms are operated at room temperature, suppressing the heat dissipation issue. They also have an advantageous bandwidth and dynamic range more suitable for MEG recordings. We quantitatively assessed the improvement (relative to a SQUID magnetometers array) in recording the magnetic field with a wearable 4He OPM-MEG system through data simulations. The OPM array and magnetoencephalography forward models were based on anatomical MRI data from an adult, a nine-year-old child, and 10 infants aged between one month and two years. Our simulations showed that a 4He OPMs array offers markedly better spatial specificity than a SQUID magnetometers array in various key performance areas (e.g., signal power, information content, and spatial resolution). Our results are also discussed regarding previous simulation results obtained for alkali OPM. Full article
Show Figures

Figure 1

24 pages, 2447 KiB
Article
Pilot Quality-Assurance Study of a Third-Generation Batch-Mode Clinical-Scale Automated Xenon-129 Hyperpolarizer
by Jonathan R. Birchall, Md Raduanul H. Chowdhury, Panayiotis Nikolaou, Yuri A. Chekmenev, Anton Shcherbakov, Michael J. Barlow, Boyd M. Goodson and Eduard Y. Chekmenev
Molecules 2022, 27(4), 1327; https://doi.org/10.3390/molecules27041327 - 16 Feb 2022
Cited by 10 | Viewed by 3322
Abstract
We present a pilot quality assurance (QA) study of a clinical-scale, automated, third-generation (GEN-3) 129Xe hyperpolarizer employing batch-mode spin-exchange optical pumping (SEOP) with high-Xe densities (50% natural abundance Xe and 50% N2 in ~2.6 atm total pressure sourced from Nova Gas [...] Read more.
We present a pilot quality assurance (QA) study of a clinical-scale, automated, third-generation (GEN-3) 129Xe hyperpolarizer employing batch-mode spin-exchange optical pumping (SEOP) with high-Xe densities (50% natural abundance Xe and 50% N2 in ~2.6 atm total pressure sourced from Nova Gas Technologies) and rapid temperature ramping enabled by an aluminum heating jacket surrounding the 0.5 L SEOP cell. 129Xe hyperpolarization was performed over the course of 700 gas loading cycles of the SEOP cell, simulating long-term hyperpolarized contrast agent production in a clinical lung imaging setting. High levels of 129Xe polarization (avg. %PXe = 51.0% with standard deviation σPXe = 3.0%) were recorded with fast 129Xe polarization build-up time constants (avg. Tb = 25.1 min with standard deviation σTb = 3.1 min) across the first 500 SEOP cell refills, using moderate temperatures of 75 °C. These results demonstrate a more than 2-fold increase in build-up rate relative to previously demonstrated results in a comparable QA study on a second-generation (GEN-2) 129Xe hyperpolarizer device, with only a minor reduction in maximum achievable %PXe and with greater consistency over a larger number of SEOP cell refill processes at a similar polarization lifetime duration (avg. T1 = 82.4 min, standard deviation σT1 = 10.8 min). Additionally, the effects of varying SEOP jacket temperatures, distribution of Rb metal, and preparation and operation of the fluid path are quantified in the context of device installation, performance optimization and maintenance to consistently produce high 129Xe polarization values, build-up rates (Tb as low as 6 min) and lifetimes over the course of a typical high-throughput 129Xe polarization SEOP cell life cycle. The results presented further demonstrate the significant potential for hyperpolarized 129Xe contrast agent in imaging and bio-sensing applications on a clinical scale. Full article
Show Figures

Figure 1

11 pages, 39292 KiB
Communication
Optimized Design of a Pump Laser System for a Spin Exchange Relaxation Free Inertial Measurement Device
by Jian Hao, Hong-Liang Ke, Zhai-Yue Yang and Bang-Cheng Han
Sensors 2021, 21(9), 2982; https://doi.org/10.3390/s21092982 - 23 Apr 2021
Cited by 1 | Viewed by 2376
Abstract
In order to improve the precision and beam quality of a pump laser for a spin exchange relaxation free inertial measurement device, we applied one scheme to achieve the square wave modulation and power stability control of the pump laser and another one [...] Read more.
In order to improve the precision and beam quality of a pump laser for a spin exchange relaxation free inertial measurement device, we applied one scheme to achieve the square wave modulation and power stability control of the pump laser and another one to obtain the uniform intensity distribution of the laser beam, in which the acousto-optic modulator (AOM) and proportion integration differentiation (PID) controller were used to achieve the former, and the freeform surface lens was designed and optimized to achieve the latter based on the TracePro software. In experiments, the first-order diffraction light beam coming through the AOM had a spot size of about 1.1 × 0.7 mm2, and a spherical vapor cell with a radius of 7 mm was placed behind the freeform surface lens. Results show that the uniformity of the reshaped intensity distribution is higher than 90% within the target area with a radius of 7 mm both in the simulation and the experiment, which ensure that the uniform laser beam covers the area of cell. On the other hand, the power stability of the pump laser is controlled to be less than 0.05%. Compared with traditional methods, the complicated calculation process in optical design is better solved, and a higher uniformity with slight energy loss is achieved. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1
