Search Results (34)

Active or semi-active vibration control systems require real-time vibration information from controlled structures as feedback. However, integrating vibration sensors into some controlled structures remains a challenge due to factors such as mass and signal lines. This issue is particularly prominent in attachment structures located far from the spacecraft, such as robotic arms and solar panels. This paper presents a miniaturized autonomous inertial sensor that can be easily attached to the controlled structure to acquire vibration data and wirelessly transmit the data. We also establish the relationship between cantilevered structural vibration and the inertial acceleration or angular velocity directly measured by the sensor. Consequently, the feedback information for the control system can be calculated by the processor in real-time. This autonomous inertial sensor consists of an inertial measurement unit (IMU) named BMI088 and a common wireless communication unit. An improved Extended Kalman Filter (EKF) algorithm is employed to enhance the quality of the sensing data in practical environments. The experimental results validated the theoretical model, indicating that the miniaturized inertial sensor effectively captures the bending vibration characteristics of the controlled structure. Full article

This paper presents the results of a computational experiment on the natural vibrations of a homogeneous rigidly fixed plate after a temperature shock. Unlike in many well-known studies, in this work, the plate is not stationary at the moment of thermal shock. This formulation has wide practical applications. For example, as a result of the unfolding of solar panels, free vibrations are excited. The purpose of this work was to analyze the effect of temperature shock on the characteristics of the plate’s own vibrations. Specifying the parameters of natural vibrations and considering temperature shock make it possible to model the vibration process more adequately. The simulation parameters simulate the conditions of the space environment. Therefore, the results of this study can be applied to the study of thermal vibrations in solar panels and other large elastic elements of spacecraft. Full article

Electric power supply (EPS) is the heart of any aerospace mission and plays an important role in improving the performance and service lifetime of spacecraft. It generates, converts, stores, and distributes power to different voltage levels. The EPS is composed of solar panels, a power conditioning unit (PCU), batteries, and a power distribution unit (PDU). This paper describes the design and analysis of an efficient power conditioning system for a CubeSat standard small satellite. For this purpose, the aim of this paper is to propose a two-input maximum power point tracker (MPPT)-based interleaved boost converter. The design copes with the fact that when a satellite revolves around the Earth, a single panel or at most two panels face solar radiation at different angles. In order to extract maximum power from the panels, the designed converter drives the solar panels at the maximum power point (MPP). A small signal model is drawn for the converter, and the closed-loop gain of the converter is analyzed using a Bode diagram. To improve the phase margin and gain, a PID compensator is designed and added to the closed loop of the converter. Finally, the performance of the proposed converter is validated by the simulation results. Full article

During the in-orbit operation of spacecraft, permanent magnet synchronous motors are commonly used as power sources in the drive mechanisms of solar panel arrays and the high-precision servo control systems based on satellites. Apart from the performance of the motors themselves and the software control algorithms, the accuracy of the entire control system is also influenced by angle sensors used to detect the rotor position of the motors. As a high-precision angular measuring instrument, the inductosyn possesses excellent environmental adaptability and long service life. Effectively utilizing the inductosyn can greatly enhance the performance of servo control systems. To address the complexity of the decoding process for dual-channel round inductosyn-to-digital converters, this paper proposes a design of the decoding circuit for dual-channel round inductosyn based on the parallel-synchronization decoding method of two AD2S1210 Resolver-to-Digital Converter (RDC) decoding chips. The decoding circuit amplifies the excitation signal outputted by the AD2S1210 for driving the round inductosyn, and processes the sine and cosine induction signals outputted by the round inductosyn through filtering, amplification, and other methods; by using analog circuitry, the output signals of the dual-channel round inductosyn are processed to meet the input requirements of the AD2S1210. Finally, through both the Multisim (circuit simulation software Version 14.1) simulation and physical experiments, it was verified that the decoding circuit designed in this paper could process the input/output signals of the dual-channel round inductosyn and AD2S1210, and successfully decoded the analog induction signal of the round inductosyn. This greatly simplifies the signal decoding process for the dual-channel round inductosyn. Full article

The problem of the effective control of a small spacecraft is very relevant for solving a number of target tasks. Such tasks include, for example, remote sensing of the Earth or the implementation of gravity-sensitive processes. Therefore, it is necessary to develop new technologies for controlling small spacecraft. These technologies must take into account a number of disturbing factors that have not been taken into account previously. Temperature shock is one such factor for small spacecraft with solar panels. Therefore, the goal of the work is to create a new technology for controlling a small spacecraft based on a mathematical model of the stressed/deformed state of a solar panel during a temperature shock. The main methods for solving the problem are mathematical methods for solving initial/boundary value problems, in particular, the initial/boundary value problem of the third kind. As a result, an approximate solution for the deformation of a solar panel during a temperature shock was obtained. This solution is more general than those obtained previously. In particular, it satisfies the symmetrical condition of the solar panel. This could not be achieved by the previous solutions. We also observe an improvement (as compared to the previous solutions) in the fulfillment of the boundary conditions for the whole duration of the temperature shock. Based on this, a new technology for controlling a small spacecraft was created and its effectiveness was demonstrated. Application of the developed technology will improve the performance of the target tasks such as remote sensing of the Earth or the implementation of gravity-sensitive processes. Full article

Thermally induced vibrations usually affect spacecraft equipped with light and slender appendages such as booms, antennas or solar panels. This phenomenon occurs when a thermal shock, resulting from the sudden cooling and warming phases at the entrance and exit from eclipses, triggers mechanical vibrations. The study proposed hereafter concerns the modeling and prediction of jitter of thermal origin in a long and thin plate with a sun-pointing attitude in geostationary orbit. The system’s temperature and dynamics are described by a set of equations expressing the two-way coupling between the thermal bending moment and the shape of the panel. The structure is discretized and reduced to a one-degree-of-freedom simplified model able to identify a mechanism of thermal pumping that could lead to instability. Finally, the results of the analysis are compared with those obtained with a more accurate FEM modelization. Full article

As the most common energy source of spacecraft, photovoltaic (PV) power generation has become one of the hottest research fields. During the on-orbit operation of spacecraft, the influence of various uncertain factors and the unbalanced inertial force will make the solar PV wing vibrate and degrade its performance. In this study, we investigated the influence of mechanical vibration on the output characteristics of PV array systems. Specifically, we focused on a three-segment solar panel commonly found on satellites, analyzing both its dynamic response and electrical output characteristics under mechanical vibration using numerical simulation software. The correctness of the simulation model was partly confirmed by experiments. The results showed that the maximum output power of the selected solar panel was reduced by 5.53% and its fill factor exhibited a decline from the original value of 0.8031 to 0.7587, provided that the external load applied on the panel increased to 10 N/m², i.e., the vibration frequency and the maximal deflection angle were 0.3754 Hz and 74.9871°, respectively. These findings highlight a significant decrease in the overall energy conversion efficiency of the solar panel when operating under vibration conditions. Full article

When spacecraft execute missions in space, their solar panels—crucial components—often need to be folded, unfolded, and adjusted at an angle. These operations can induce numerous detrimental nonlinear vibrations. This paper addresses the issues of nonlinear and thermal-coupled vibration control within the context of space-based flexible solar panel systems. Utilizing piezoelectric smart hybrid vibration control technology, this study focuses on a flexible plate augmented with an active constrained layer damping. The solar panel, under thermal field conditions, is modeled and simulated using the commercial finite element simulation software ABAQUS. The research examines variations in the modal frequencies and damping properties of the model in response to changes in the coverage location of the piezoelectric patches, their coverage rate, rotational angular velocity, and the thickness of the damping layer. Simulation results indicate that structural damping is more effective when the patches are closer to the rotation axis, the coverage area of the patches is larger, the rotational speed is lower, and the damping layer is thicker. Additionally, the effectiveness of vibration suppression is influenced by the interplay between the material shear modulus, loss factor, and specific working temperature ranges. The selection of appropriate parameters can significantly alter the system’s vibrational characteristics. This work provides necessary technical references for the analysis of thermally induced vibrations in flexible solar sails under complex space conditions. Full article

The Inverse Synthetic Aperture Radar (ISAR) has been proven to be an effective tool for space target sensing due to its capability of performing high-resolution imaging. Since the component information of the spacecraft is key to the identification of the target and diagnosis of its status, ISAR images with a clear and complete representation of the typical components are much desired. This requires a selection of the imaging time, during which a certain spacecraft component has a good projection on the ISAR image plane with the shape feature well conserved and a high resolution. In addition, a fully automated implementation with a high computational efficiency is also highly preferred for on-orbit operations so as to improve the intelligence level of the space-borne system. We propose a bicriterion-based automated optimal imaging time-selection method for the space-borne ISAR, which is seeking the slow time section of the data that result in the best image. A good image means a high azimuth resolution and the best presentation of the solar panels. One criterion is the Maximum Doppler Spread (MDS), which indicates the maximum Effective Rotational Velocity (ERV) leading to high image resolution, but it is influenced by the satellite attitude. of the spacecraft. The other is the Maximum Component Area (MCA), which is defined to indicate the completeness of the component considered. The radar echoes are processed sequentially by way of a sliding window. The interval with the co-maximization of the DS and CA is selected, and fine processing is performed further to obtain the best images. The results of the simulation experiments show that the proposed method can achieve spacecraft images with the solar panels presented the best. The computational complexity is low. Full article

Accurately estimating the pose of spacecraft is indispensable for space applications. However, such targets are generally non-cooperative, i.e., no markers are mounted on them, and they include no parts for operation. Therefore, the detection and measurement of a non-cooperative target is very challenging. Stereovision sensors are important solutions in the near field. In this paper, a rectangular natural feature recognition and pose measurement method for non-cooperative spacecraft is proposed. Solar panels of spacecraft were selected as detection objects, and their image features were captured via stereo vision. These rectangle features were then reconstructed in 3D Cartesian space through parallelogram fitting on the image planes of two cameras. The vertexes of rectangle features were detected and used to solve the pose of a non-cooperative target. An experimental system was built to validate the effectiveness of the algorithm. The experimental results show that the average position measurement error of the algorithm is about 10 mm and the average attitude measurement error is less than 1°. The results also show that the proposed method achieves high accuracy and efficiency. Full article

The diagnostics of environmentally induced damages in composite structures plays a critical role for ensuring the operational safety of space platforms. Recently, spacecraft have been equipped with lightweight and very large substructures, such as antennas and solar panels, to meet the performance demands of modern payloads and scientific instruments. Due to their large surface, these components are more susceptible to impacts from orbital debris compared to other satellite locations. However, the detection of debris-induced damages still proves challenging in large structures due to minimal alterations in the spacecraft global dynamics and calls for advanced structural health monitoring solutions. To address this issue, a data-driven methodology using Long Short-Term Memory (LSTM) networks is applied here to the case of damaged solar arrays. Finite element models of the solar panels are used to reproduce damage locations, which are selected based on the most critical risk areas in the structures. The modal parameters of the healthy and damaged arrays are extracted to build the governing equations of the flexible spacecraft. Standard attitude manoeuvres are simulated to generate two datasets, one including local accelerations and the other consisting of piezoelectric voltages, both measured in specific locations of the structure. The LSTM architecture is then trained by associating each sensed time series with the corresponding damage label. The performance of the deep learning approach is assessed, and a comparison is presented between the accuracy of the two distinct sets of sensors: accelerometers and piezoelectric patches. In both cases, the framework proved effective in promptly identifying the location of damaged elements within limited measured time samples. Full article

Piezoelectric actuators and sensors can be incorporated into aerospace structures to suppress unwanted flexible oscillations. These devices need to interact with various passive structures, including innovative materials such as thermoplastic composites, which offer several advantages over traditional options. This study explores the application of a piezoelectric-based vibration control system on a lightweight carbon-reinforced thermoplastic material. Numerical and experimental investigations are conducted to assess the mechanical properties and damping behavior of the composite. As a case study, an equivalent orthotropic shell laminate is developed to facilitate finite element modeling of two composite solar panel structures equipped to a spacecraft. Moreover, an electro-mechanical formulation is implemented to integrate smart actuators and sensors onto the composite hosting structure. Finally, the efficiency of the active vibration control system is assessed when significant vibration perturbations are caused on the panels by rigid–flexible dynamics coupling during agile attitude maneuvers. The results demonstrate the damping factor of the material can be noticeably improved, making the proposed system a promising technological solution for further aerospace applications. Full article

An analytical dynamic model is presented for a spacecraft with multiple large flexible structures. Based on the partial differential equations (PDEs) of the motion of the solar panel and deployable arm, the governing equations of the main-body and deployable antenna and the boundary conditions at each end point are used to obtain the frequency and mode shapes of the system. Then, the ordinary differential equations (ODEs) of the system can be obtained from the orthogonality relations and mode shape. The influence of the deployable antenna on the frequencies and mode shapes of the spacecraft is investigated. The frequency veering and mode interchanged phenomenon are observed with the variation of the diameter of the deployable antenna. Using the ODEs, the dynamic responses of the spacecraft are calculated to study the influence of the control torque on the attitude and position of the antenna in the attitude maneuver. Full article

The aim of this paper is to analyze the transfer performance of a spacecraft whose primary propulsion system is a diffractive solar sail with active, switchable panels. The spacecraft uses a propellantless thruster that converts the solar radiation pressure into propulsive acceleration by taking advantage of the diffractive property of an electro-optically controlled (binary) metamaterial. The proposed analysis considers a heliocentric mission scenario where the spacecraft is required to perform a two-dimensional transfer between two concentric and coplanar circular orbits. The sail attitude is assumed to be Sun-facing, that is, with its sail nominal plane perpendicular to the incoming sunlight. This is possible since, unlike a more conventional solar sail concept that uses metalized highly reflective thin films to reflect the photons, a diffractive sail is theoretically able to generate a component of the thrust vector along the sail nominal plane also in a Sun-facing configuration. The electro-optically controlled sail film is used to change the in-plane component of the thrust vector to accomplish the transfer by minimizing the total flight time without changing the sail attitude with respect to an orbital reference frame. This work extends the mathematical model recently proposed by the authors by including the potential offered by an active control of the diffractive sail film. The paper also thoroughly analyzes the diffractive sail-based spacecraft performance in a set of classical circle-to-circle heliocentric trajectories that model transfers from Earth to Mars, Venus and Jupiter. Full article

Nanosatellites have established their importance in low-Earth orbit (LEO), and it is common for student teams to build them for educational and technology demonstration purposes. The next challenge is the technology maturity for deep-space missions. The LEO serves as a relevant environment for maturing the spacecraft design. Here we present the ESTCube-2 mission, which will be launched onboard VEGA-C VV23. The satellite was developed as a technology demonstrator for the future deep-space mission by the Estonian Student Satellite Program. The ultimate vision of the program is to use the electric solar wind sail (E-sail) technology in an interplanetary environment to traverse the solar system using lightweight propulsion means. Additional experiments were added to demonstrate all necessary technologies to use the E-sail payload onboard ESTCube-3, the next nanospacecraft targeting the lunar orbit. The E-sail demonstration requires a high-angular velocity spin-up to deploy a tether, resulting in a need for a custom satellite bus. In addition, the satellite includes deep-space prototypes: deployable structures; compact avionics stack electronics (including side panels); star tracker; reaction wheels; and cold–gas propulsion. During the development, two additional payloads were added to the design of ESTCube-2, one for Earth observation of the Normalized Difference Vegetation Index and the other for corrosion testing in the space of thin-film materials. The ESTCube-2 satellite has been finished and tested in time for delivery to the launcher. Eventually, the project proved highly complex, making the team lower its ambitions and optimize the development of electronics, software, and mechanical structure. The ESTCube-2 team dealt with budgetary constraints, student management problems during a pandemic, and issues in the documentation approach. Beyond management techniques, the project required leadership that kept the team aware of the big picture and willing to finish a complex satellite platform. The paper discusses the ESTCube-2 design and its development, highlights the team’s main technical, management, and leadership issues, and presents suggestions for nanosatellite and nanospacecraft developers. Full article
