The development of metal nanostructures on large-area Gallium Nitride (GaN) surfaces has the potential to enable new, low-cost technologies for III-N semiconductor layer nanostructuring. Self-assembled nanostructures are typically formed through the thermal activation of solid-state dewetting (SSD) in thin metal layers. However, such thermal processing can induce degradation of the metal-GaN material system. This comprehensive study investigated the thermal stability of thin metal films on GaN surfaces, focusing on their morphology and nanostructuring for high-temperature processing. The research expands and systematizes the understanding of the thin metal layers on GaN surface interactions at high temperatures by categorizing metals based on their behaviour: those that exhibit self-assembly, those that catalyze GaN decomposition, and those that remain thermally stable. Depending on the annealing temperature and metal type, varying degrees of GaN layer decomposition were observed, ranging from partial surface modification to significant volumetric degradation of the material. A wide range of metals was investigated: Au, Ag, Pt, Ni, Ru, Mo, Ti, Cr, V, Nb. These materials were selected based on criteria such as high work function and chemical resistance. In this studies metal layers with a target thickness of 10 nm deposited by vacuum evaporation on 2.2 $\mathsf{\mu }$m thick GaN layers grown by metal organic vapor phase epitaxy were applied. The surface morphology and composition were analyzed using AFM, SEM, EDS, and Raman spectroscopy measurement techniques. Full article

This study provides new insight into the mechanisms governing solid state dewetting (SSD) in SiGe alloys and underscores the potential of this bottom-up technique for fabricating self-organized defect-free nanostructures for CMOS-compatible photonic and nanoimprint applications. In particular, we investigate the SSD of Si_1−xGe_x thin films grown by molecular beam epitaxy on silicon-on-insulator (SOI) substrates, focusing on and clarifying the interplay of dewetting dynamics, strain elastic relaxation, and SiGe/SOI interdiffusion. Samples were annealed at 820 °C, and their morphological and compositional evolution was tracked using atomic force microscopy (AFM), scanning electron microscopy (SEM), energy-dispersive X-ray spectroscopy (EDX), X-ray diffraction (XRD), and Raman spectroscopy, considering different annealing time steps. A sequential process typical of the SiGe alloy has been identified, involving void nucleation, short finger formation, and ruptures of the fingers to form nanoislands. XRD and Raman data reveal strain relaxation and significant Si-Ge interdiffusion over time, with the Ge content decreasing from 29% to 20% due to mixing with the underlying SOI layer. EDX mapping confirms a Ge concentration gradient within the islands, with higher Ge content near the top. Full article

Gold nanostructures (AuNSs) were used to fabricate surface-enhanced Raman spectroscopy (SERS) substrates. These AuNSs were produced using the solid-state dewetting method from thin films. The fragmentation process was studied at 300 °C, with durations of thermal treatment of 1, 3, 6, and 12 h. These SERS substrates were then employed to detect Rhodamine B (RhB) as the model analyte, simulating a contaminant in the water at a concentration of 5 ppm. The morphology of the AuNSs was examined using SEM, which revealed a spheroidal shape that began to coalesce at 12 h. The size of the AuNSs was estimated to range from 22 ± 7 to 24 ± 6 nm, depending on the annealing time. The localized surface plasmon resonance of the AuNSs was determined using absorption spectroscopy, showing a shift as the annealing time increased. The SERS signals of RhB adsorbed on the AuNS substrates were validated by performing a 10 × 10 point map scan over each sample surface (1, 3, 6, and 12 h), and a comparative analysis showed no significant differences in the positions of the bands; however, variations in intensity enhancement ranged from 5 to 123 times at 6 and 1 h, respectively. Full article

Pulse-magnetron-sputtered long-term superhydrophilic coatings have been synthesized to functionalize the surfaces of solid-state cooling devices, e.g., electrocaloric heat pumps, where not only a complete wetting of the surface by a fluid is intended, but also fast wetting and dewetting processes are required. The coatings consist of a (Ti,Si)O₂ outer layer that provides lasting hydrophilicity thanks to the mesoporous structure, followed by an intermediate WO₃ film that enables the reactivation of the wettability through visible light irradiation, and a W underlayer which can work as a top electrode of the electrocaloric components thanks to its suitable electrical and thermal conductivity properties. Process parameter optimization for each layer of the stack as well as the influence of the microstructure and composition on the wetting properties are presented. Finally, water contact angle measurements, surface energy evaluations, and a contact line dynamics assessment of evaporating drops on the coatings demonstrate that their enhanced wetting performance is attributed not only to their intrinsic hydrophilic nature but also to their porous microstructure, which promotes wicking and spreading at the nanometric scale. Full article

Biomaterial-centered infections of orthopedic implants remain a significant burden in the healthcare system due to sedentary lifestyles and an aging population. One approach to combat infections and improve implant osteointegration is functionalizing the implant surface with anti-infective and osteoinductive agents. In this framework, Au nanoparticles are produced on the surface of Ti-6Al-4V medical alloy by solid-state dewetting of 5 nm Au film and used as the substrate for the conjugation of a model antibiotic vancomycin via a mono-thiolated poly(ethylene glycol) linker. Produced Au nanoparticles on Ti-6Al-4V surface are equiaxed with a mean diameter 19.8 ± 7.2 nm, which is shown by high-resolution scanning electron microscopy and atomic force microscopy. The conjugation of the antibiotic vancomycin, 18.8 ± 1.3 nm-thick film, is confirmed by high resolution-scanning transmission electron microscopy and X-ray photoelectron spectroscopy. Overall, showing a link between the solid-state dewetting process and surface functionalization, we demonstrate a novel, simple, and versatile method for functionalization of implant surfaces. Full article

The efficiency of thin film photoelectric devices can be improved by redirecting incident electromagnetic radiation along their surface layers. Redirection can be achieved using antireflection coatings made of subwavelength dielectric particle arrays. In this study, we fabricate such coatings, consisting of Ge particles on quartz glass substrates via solid-state dewetting, transforming thin Ge films into compact particles. Using optically transparent substrates, we measure reflection and transmission spectra and determine absorption spectra, showing that substrates coated with Ge particles absorb much more strongly than substrates coated with continuous Ge films. The spectra obtained using objective lenses with different aperture angles indicate that scattered radiation is predominantly directed at glancing angles to the substrate surface. The lateral propagation of scattered radiation is the result of destructive interference, which suppresses both reflected and transmitted radiation. Full article

The fabrication technology of surface nanocomposites based on hexagonally ordered gold nanoparticle (AuNP) layers (quasi-arrays) and their possible application as surface-enhanced Raman spectroscopy (SERS) substrates are presented in this paper. The nanoparticle layers are prepared using a nanotextured template formed by porous anodic alumina (PAA) and combined with gold thin-film deposition and subsequent solid-state dewetting. Three types of hexagonal arrangements were prepared with different D/D₀ values (where D is the interparticle gap, and D₀ is the diameter of the ellipsoidal particles) on a large surface area (~cm² range), namely, 0.65 ± 0.12, 0.33 ± 0.10 and 0.21 ± 0.09. The transfer of the particle arrangements to transparent substrates was optimized through three generations, and the advantages and disadvantages of each transfer technology are discussed in detail. Such densely packed nanoparticle arrangements with high hot-spot density and tunable interparticle gaps are very beneficial for SERS applications, as demonstrated with two practical examples. The substrate-based enhancement factor of the nanocomposites was determined experimentally using a DNA monolayer and was found to be between 4 × 10⁴ and 2 × 10⁶ for the different particle arrangements. We also determined the sensing characteristics of a small dye molecule, rhodamine 6G (R6G). By optimizing the experimental conditions (e.g., optimizing the laser power and the refractive index of the measurement medium with an ethylene-glycol/water mixture), concentrations as low as 10⁻¹⁶ M could be detected at 633 nm excitation. Full article

In this work, the process of solid-state dewetting in FePd thin films and its influence on structural transformation and magnetic properties is presented. The morphology, structure and magnetic properties of the FePd system subjected to annealing at 600 °C for different times were studied. The analysis showed a strong correlation between the dewetting process and various physical phenomena. In particular, the transition between the A1 phase and L1₀ phase is strongly influenced by and inextricably connected with solid-state dewetting. Major changes were observed when the film lost its continuity, including a fast growth of the L1₀ phase, changes in the magnetization reversal behavior or the induction of magnetic spring-like behavior. Full article

In this work, dewetting process has been investigated in shape-memory Heuslers. To this aim, series of high-temperature annealing (1100–1150 K) have been performed at high vacuum (time is varied in the range of 55–165 min) in Ni-Mn-Ga epitaxial thin films grown on MgO(001). The process kinetics have been followed by studying the evolution of morphology and composition. In particular, we report the initiation of the dewetting process by the formation of symmetric holes in the films. The holes propagate and integrate, leaving micrometric and submicron islands of the material, increasing the average roughness of the films by a factor of up to around 30. The dewetting process is accompanied by severe Ga and Mn sublimation, and Ni-Ga segregation, which significantly modify the magnetic properties of the films measured at each stage. The annealed samples show a relatively weak magnetic signal at room temperature with respect to the pristine sample. Full article

A reliable, scalable, and inexpensive technology for the fabrication of ordered arrays of metal nanoparticles with large areal coverage on various substrates is presented. The nanoparticle arrays were formed on aluminum substrates using a two-step anodization process. By varying the anodization potential, the pore diameter, inter-pore spacing, and pore ordering in the anodic aluminum oxide (AAO) template were tuned. Following a chemical etch, the height of the pores in the AAO membrane were reduced to create a dimpled membrane surface. Periodic arrays of metal nanoparticles were subsequently created by evaporating metal on to the dimpled surface, allowing for individual nanoparticles to form within the dimples by a solid state de-wetting process induced by annealing. The ordered nanoparticle array could then be transferred to a substrate of choice using a polymer lift-off method. Following optimization of the experimental parameters, it was possible to obtain cm${}^2$ coverage of metal nanoparticles, like gold and indium, on silicon, quartz and sapphire substrates, with average sizes in the range of 50–90 nm. The de-wetting process was investigated for a specific geometry of the dimpled surface and the results explained for two different film thicknesses. Using a simple model, the experimental results were interpreted and supported by numerical estimations. Full article

Cu nanoparticles were produced by using solid-state dewetting (dry) of a 1.3 nm Cu layer or laser ablation of a Cu solid target (wet) in acetone and methanol. The morphology and chemical composition of the nanoparticles were investigated as a function of the synthesis methods and their key parameters of the annealing temperature (200–500 °C) and the liquid environment during the ablation. Cu nanoparticles were then embedded in transparent conductive oxide (TCO) films as aluminum-doped zinc oxide (AZO) or zirconium-doped indium oxide (IZrO); the TCO_bott/Cu nanoparticle/TCO_top structures were synthesized with all combinations of AZO and IZrO as the top and bottom layers. The goal was to achieve a plasmonic and conductive structure for photovoltaic applications via a comparison of the involved methods and all fabricated structures. In particular, solid-state dewetting produced faceted or spherical (depending on the annealing temperature) nanoparticles with an average size below 150 nm while laser ablation produced spherical nanoparticles below 250 nm. Dry and wet plasmonic conductive structures as a function of the TCOs employed and the temperature of annealing could reach a sheet resistance of 86 Ω/sq. The energy band-gap E_gap, absorbance, transmittance, and reflectance of the plasmonic conductive structures were investigated in the UV–vis–NIR range. They showed a dependence on the sequence of the top and bottom TCO, with best transmittances of 89.4% for the dry plasmonic conductive structure and 84.7% for the wet plasmonic conductive structure. The latter showed a higher diffused transmittance of between 10–20% in the visible range. Full article

The microstructure of a sub-micrometric gold crystal during nanoindentation is visualized by in situ multi-wavelength Bragg coherent X-ray diffraction imaging. The gold crystal is indented using a custom-built atomic force microscope. A band of deformation attributed to a shear band oriented along the (221) lattice plane is nucleated at the lower left corner of the crystal and propagates towards the crystal center with increasing applied mechanical load. After complete unloading, an almost strain-free and defect-free crystal is left behind, demonstrating a pseudo-elastic behavior that can only be studied by in situ imaging while it is invisible to ex situ examinations. The recovery is probably associated with reversible dislocations nucleation/annihilation at the side surface of the particle and at the particle-substrate interface, a behavior that has been predicted by atomistic simulations. The full recovery of the particle upon unloading sheds new light on extraordinary mechanical properties of metal nanoparticles obtained by solid-state dewetting. Full article

β-Ga₂O₃ nanostructures, including nanowires (NWs), nanosheets (NSHs), and nanorods (NRs), were synthesized using thermally dewetted Au nanoparticles as catalyst in a chemical vapor deposition process. The morphology of the as-grown β-Ga₂O₃ nanostructures depends strongly on the growth temperature and time. Successful growth of β-Ga₂O₃ NWs with lengths of 7–25 μm, NSHs, and NRs was achieved. It has been demonstrated that the vapor–liquid–solid mechanism governs the NW growth, and the vapor–solid mechanism occurs in the growth of NSHs and NRs. The X-ray diffraction analysis showed that the as-grown nanostructures were highly pure single-phase β-Ga₂O₃. The bandgap of the β-Ga₂O₃ nanostructures was determined to lie in the range of 4.68–4.74 eV. Characteristic Raman peaks were observed with a small blue and red shift, both of 1–3 cm⁻¹, as compared with those from the bulk, indicating the presence of internal strain and defects in the as-grown β-Ga₂O₃ nanostructures. Strong photoluminescence emission in the UV-blue spectral region was obtained in the β-Ga₂O₃ nanostructures, regardless of their morphology. The UV (374–377 nm) emission is due to the intrinsic radiative recombination of self-trapped excitons present at the band edge. The strong blue (404–490 nm) emissions, consisting of five bands, are attributed to the presence of the complex defect states in the donor (V_O) and acceptor (V_Ga or V_Ga–O). These β-Ga₂O₃ nanostructures are expected to have potential applications in optoelectronic devices such as tunable UV–Vis photodetectors. Full article

Metal-based nanoparticles with antimicrobial activity are gaining a lot of attention in recent years due to the increased antibiotics resistance. The development and the pathogenesis of oral diseases are usually associated with the formation of bacteria biofilms on the surfaces; therefore, it is crucial to investigate the materials and their properties that would reduce bacterial attachment and biofilm formation. This work provides a systematic investigation of the physical-chemical properties and the antibacterial activity of TiO₂ thin films decorated by Ag and Au nanoparticles (NP) against Veillonella parvula and Neisseria sicca species associated with oral diseases. TiO₂ thin films were formed using reactive magnetron sputtering by obtaining as-deposited amorphous and crystalline TiO₂ thin films after annealing. Au and Ag NP were formed using a two-step process: magnetron sputtering of thin metal films and solid-state dewetting. The surface properties and crystallographic nature of TiO₂/NP structures were investigated by SEM, XPS, XRD, and optical microscopy. It was found that the higher thickness of Au and Ag thin films results in the formation of the enlarged NPs and increased distance between them, influencing the antibacterial activity of the formed structures. TiO₂ surface with AgNP exhibited higher antibacterial efficiency than Au nanostructured titania surfaces and effectively reduced the concentration of the bacteria. The process of the observation and identification of the presence of bacteria using the deep learning technique was realized. Full article

Silver nanoparticles (NPs) on glass substrates were obtained by a solid-state thermal dewetting (SSD) process using vacuum-evaporated-silver precursor layers. An exhaustive investigation of the morphological, structural, and surface chemistry properties by systematically controlling the precursor film thickness, annealing temperature, and time was conducted. Thin silver films with thicknesses of 40 and 80 nm were deposited and annealed in air by applying a combined heat-up+constant temperature–time program. Temperatures from 300 to 500 °C and times from 0 to 50 min were assayed. SSD promoted the morphological modification of the films, leading to the Ag NPs having a discrete structure. The size, shape, surface density, and inter-nanoparticle distance of the nanoparticles depended on the initial film thickness, annealing temperature, and time, exhibiting a cubic silver structure with a (111) preferred crystallographic orientation. The prepared NPs were found to be highly enriched in the Ag{111}/Ag{110}/Ag{100} equilibrium facets. SSD not only promotes NP formation but also promotes the partial oxidation from Ag to AgO at the surface level. AgO was detected on the surface around the nanoparticles synthesized at 500 °C. Overall, a broad framework has been established that connects process factors to distinguish resultant Ag NP features in order to develop unique silver nanoparticles for specific applications. Full article
