Phase noise constitutes a pivotal performance parameter in microwave systems, and the evolution of microwave signal sources presents new demands on phase noise analyzers (PNAs) regarding sensitivity and bandwidth. Traditional electronics-based PNAs encounter significant limitations in meeting these advanced requirements. This paper provides an overview of recent progress in photonics-based microwave PNA research. Microwave photonic (MWP) PNAs are categorized into two main types: phase-detection-based and frequency-discrimination-based architectures. MWP phase-detection-based PNAs utilize ultra-short-pulse lasers or optical–electrical oscillators as reference sources to achieve superior sensitivity. On the other hand, MWP frequency-discrimination-based PNAs are further subdivided into photonic-substitution-type PNA and MWP quadrature-frequency-discrimination-based PNA. These systems leverage innovative MWP technologies to enhance overall performance, offering broader bandwidth and higher sensitivity compared to conventional approaches. Finally, the paper addresses the current challenges faced in phase noise measurement technologies and suggests potential future research directions aimed at improving measurement capabilities. Full article

This manuscript aims to explore localized waves for the nonlinear partial differential equation referred to as the $(1+1)$-dimensional generalized Kundu–Eckhaus equation with an additional dispersion term that describes the propagation of the ultra-short femtosecond pulses in an optical fiber. This research delves deep into the characteristics, behaviors, and localized waves of the $(1+1)$-dimensional generalized Kundu–Eckhaus equation. We utilize the multivariate generalized exponential rational integral function method (MGERIFM) to derive localized waves, examining their properties, including propagation behaviors and interactions. Motivated by the generalized exponential rational integral function method, it proves to be a powerful tool for finding solutions involving the exponential, trigonometric, and hyperbolic functions. The solutions we found using the MGERIF method have important applications in different scientific domains, including nonlinear optics, plasma physics, fluid dynamics, mathematical physics, and condensed matter physics. We apply the three-dimensional (3D) and contour plots to illuminate the physical significance of the derived solution, exploring the various parameter choices. The proposed approaches are significant and applicable to various nonlinear evolutionary equations used to model nonlinear physical systems in the field of nonlinear sciences. Full article

This study reports a gate-tunable three-terminal optoelectronic synaptic device based on an Al/ZnO nanoparticles (NPs)/SiO₂/Si structure for neuromorphic in-sensor memory applications. The ZnO NP film, fabricated via spin coating, exhibited strong UV-induced excitatory post-synaptic current (EPSC) responses that were modulated by gate voltage through charge injection across the SiO₂ dielectric rather than by conventional field effect. Optical stimulation enabled short-term synaptic plasticity, with paired-pulse facilitation (PPF) values reaching 185% at a gate voltage of −5.0 V and decreasing to 180% at +5.0 V, confirming gate-dependent modulation of synaptic weight. Repeated stimulation enhanced learning efficiency and memory retention, as demonstrated by reduced pulse numbers for relearning and slower EPSC decay. Wickelgren’s power law analysis further revealed a decrease in the forgetting rate under negative gate bias, indicating improved long-term memory characteristics. A 3 × 3 synaptic device array visualized visual memory formation through EPSC-based color mapping, with darker intensities and slower fading observed under −5.0 V bias. These results highlight the critical role of gate-voltage-induced charge injection through the SiO₂ dielectric in controlling optical potentiation and electrical depression, establishing ZnO NP-based optoelectronic synaptic devices as promising platforms for energy-efficient, light-driven neuromorphic computing. Full article

This study introduces an innovative analytical solution to the time-fractional Cattaneo heat conduction equation, which models photothermal transport in metallic thin films subjected to short laser pulse irradiation. The model integrates the Caputo fractional derivative of order 0 < p ≤ 1, addressing non-Fourier heat conduction characterized by finite wave speed and memory effects. The equation is nondimensionalized through suitable scaling, incorporating essential elements such as a newly specified laser absorption coefficient and uniform initial and boundary conditions. A hybrid approach utilizing the finite Fourier cosine transform (FFCT) in spatial dimensions and the Laplace transform in temporal dimensions produces a closed-form solution, which is analytically inverted using the two-parameter Mittag–Leffler function. This function inherently emerges from fractional-order systems and generalizes traditional exponential relaxation, providing enhanced understanding of anomalous thermal dynamics. The resultant temperature distribution reflects the spatiotemporal progression of heat from a spatially Gaussian and temporally pulsed laser source. Parametric research indicates that elevating the fractional order and relaxation time amplifies temporal damping and diminishes thermal wave velocity. Dynamic profiles demonstrate the responsiveness of heat transfer to thermal and optical variables. The innovation resides in the meticulous analytical formulation utilizing a realistic laser source, the clear significance of the absorption parameter that enhances the temperature amplitude, the incorporation of the Mittag–Leffler function, and a comprehensive investigation of fractional photothermal effects in metallic nano-systems. This method offers a comprehensive framework for examining intricate thermal dynamics that exceed experimental capabilities, pertinent to ultrafast laser processing and nanoscale heat transfer. Full article

Glass-based microfluidic devices are essential for applications such as diagnostics and drug discovery, which utilize their optical clarity and chemical stability. This review systematically analyzes pulsed laser micromachining as a transformative technique for fabricating glass-based microfluidic devices, addressing the limitations of conventional methods. By examining three pulse regimes—long (≥nanosecond), short (picosecond), and ultrashort (femtosecond)—this study evaluates how laser parameters (fluence, scanning speed, pulse duration, repetition rate, wavelength) and glass properties influence ablation efficiency and quality. A higher fluence improves the material ablation efficiency across all the regimes but poses risks of thermal damage or plasma shielding in ultrashort pulses. Optimizing the scanning speed balances the depth and the surface quality, with slower speeds enhancing the channel depth but requiring heat accumulation mitigation. Shorter pulses (femtosecond regime) achieve greater precision (feature resolution) and minimal heat-affected zones through nonlinear absorption, while long pulses enable rapid deep-channel fabrication but with increased thermal stress. Elevating the repetition rate improves the material ablation rates but reduces the surface quality. The influence of wavelength on efficiency and quality varies across the three pulse regimes. Material selection is critical to outcomes and potential applications: fused silica demonstrates a superior surface quality due to low thermal expansion, while soda–lime glass provides cost-effective prototyping. The review emphasizes the advantages of laser micromachining and the benefits of a wide range of applications. Future directions should focus on optimizing the process parameters to improve the efficiency and quality of the produced devices at a lower cost to expand their uses in biomedical, environmental, and quantum applications. Full article

Bow-tie cavity configurations have gained significant attention due to their efficacy in facilitating stable resonator operation for applications requiring short pulse operation and high repetition rate pulses, offering versatility and reliability. While there is an extensive body of literature addressing the theoretical aspects and applications of this laser configuration, there exists a gap in practical insights and systematic approaches guidance pertaining to the development and precision alignment of this laser type. The paper achieves this by compiling a range of analytical and optimization techniques for the bow-tie cavity configuration and delineating the necessary steps for the optimization required for continuous wave operation. This ultimately leads to the attainment of the pulsed regime through the Kerr Lens Mode-locking technique, offering a detailed account of the development, optimization, and performance evaluation of a Ti:Sapphire femtosecond laser cavity, using dispersion-compensating mirrors to produce a low-energy pulse of 1 nJ, a high repetition rate of 1 GHz, and a short pulse duration of 61 fs. This work can be useful for researchers and engineers seeking to embark on the development of compact and high-performance femtosecond lasers for a spectrum of applications, encompassing biomedical imaging, laser-assisted surgery, spectroscopy, and optical frequency combs. Full article

The optimization of photoinjector brightness is crucial for achieving the highest performance at X-ray free-electron lasers. To this end, photocathode laser pulse shaping has been identified as a key technology for enhancing photon flux and lasing efficiency at short wavelengths. Supported by beam dynamics simulations, we identify transversely and longitudinally truncated Gaussian electron bunches as a beneficial bunch shape in terms of the projected emittance and 5D brightness. The realization of such pulses from chirped Gaussian pulses is studied for 514 nm and 257 nm wavelengths by inserting an amplitude mask in the symmetry plane of the pulse stretcher to achieve longitudinal shaping and an aperture for transverse beam shaping. Using this scheme, transversely and longitudinally truncated Gaussian pulses can be generated and later used for the production of up to 3 nC electron bunches in the photoinjector. The 3D pulse shape at a wavelength of 514 nm is characterized via imaging spectroscopy, and second-harmonic generation frequency-resolved optical gating (SHG FROG) measurements are also performed to analyze the shaping scheme’s efficacy. Furthermore, this pulse-shaping scheme is transferred to a UV stretcher, allowing for direct application of the shaped pulses to cesium telluride photocathodes. Full article

We report an ion-gel-gated amorphous indium gallium zinc oxide (a-IGZO) optoelectronic neuromorphic transistors capable of synaptic emulation in both photoelectric dual modes. The ion-gel dielectric in the coplanar-structured transistor, fabricated via ink-jet printing, exhibits excellent double-layer capacitance (>1 μF/cm²) and supports low-voltage operation through lateral gate coupling. The integration of ink-jet printing technology enables scalable and large-area fabrication, highlighting its industrial feasibility. Electrical stimulation-induced artificial synaptic behaviors were successfully demonstrated through ion migration in the gel matrix. Through a simple and controllable oxygen vacancy engineering process involving low-temperature oxygen-free growth and post-annealing process, a sufficient density of stable subgap states was generated in IGZO, extending its responsivity spectrum to the visible-red region and enabling wavelength-discriminative photoresponses to 450/532/638 nm visible light. Notably, the subgap states exhibited unique interaction dynamics with low-energy photons in optically triggered pulse responses. Critical synaptic functionalities—including short-term plasticity (STP), long-term plasticity (LTP), and paired-pulse facilitation (PPF)—were successfully simulated under both optical and electrical stimulations. The device achieves low energy consumption while maintaining compatibility with flexible substrates through low-temperature processing (≤150 °C). This study establishes a scalable platform for multimodal neuromorphic systems utilizing printed iontronic architectures. Full article

Quantum technologies are currently being explored for various applications, including computing, secure communication, and sensor technology. A critical aspect of achieving high-fidelity spin manipulations in quantum devices is the controlled optical initialization of electron spins. This paper introduces a low-cost programming scheme based on a 32-bit STM32F373 microcontroller, aimed at facilitating high-precision measurements of optically active solid-state spin centers within semiconductor crystals (SiC, hBN, and diamond) utilizing a multi-pulse sequence. The effective shaping of short optical pulses across semiconductor and solid-state lasers, covering the visible to near-infrared range (405–1064 nm), has been validated through photoinduced electron paramagnetic resonance (EPR) and electron nuclear double resonance (ENDOR) spectroscopies. The application of pulsed laser irradiation influences the EPR relaxation parameters associated with spin centers, which are crucial for advancements in quantum computing. The presented experimental approach facilitates the investigation of weak electron–nuclear interactions in crystals, a key factor in the development of quantum memory utilizing nuclear qubits. Full article

In high-capacity and short-reach applications, double-sideband self-coherent detection (DSB-SCD) has garnered significant attention due to its ability to recover optical fields of DSB signals without requiring a local oscillator. However, DSB-SCD is fundamentally constrained by the non-ideal receiver transfer function, necessitating a guard band between the carrier and signal. While the conventional twin-single-sideband (twin-SSB) modulation scheme addresses this requirement, it incurs substantial implementation complexity. In this paper, we propose a spectrum inversion-based double-sideband (SI-DSB) modulation scheme, where spectral inversion shifts the DSB signal to the high-frequency region, creating a guard band around the zero frequency. After photodetector detection, baseband signal recovery is achieved through subsequent spectral inversion. Compared with the twin-SSB modulation scheme, this approach significantly reduces DSP complexity. The simulation exploration two modulation formats of pulse–amplitude modulation and quadrature-amplitude modulation, demonstrating a comparable system performance between SI-DSB and twin-SSB modulation schemes. We also illustrate the parameter optimization process for the SI-DSB modulation scheme, including carrier-to-signal power ratio and guard band. Furthermore, validation with three FADD receivers further demonstrates the superior performance of the proposed SI-DSB modulation in DSB-SCD systems. Full article

Two-terminal optoelectronic synaptic devices based on ZnO nanoparticles (NPs) were fabricated to investigate the effects of thermal annealing control (200 °C–500 °C) in nitrogen and oxygen atmospheres on surface morphology, optical response, and synaptic functionality. Atomic force microscopy (AFM) analysis revealed improved grain growth and reduced surface roughness. At the same time, UV–visible spectroscopy and photoluminescence confirmed a blue shift in the absorption edge and enhanced near-band-edge emission, particularly in nitrogen-annealed devices due to increased oxygen vacancies. X-ray photoelectron spectroscopy (XPS) analysis of the O 1s spectra confirmed that oxygen vacancies were more pronounced in nitrogen-annealed devices than in oxygen-annealed ones at 500 °C. Optical resistive switching was observed, where 365 nm ultraviolet (UV) irradiation induced a transition from a high-resistance state (HRS) to a low-resistance state (LRS), attributed to electron–hole pair generation and oxygen desorption. The electrical reset process, achieved by applying −1.0 V to −5.0 V, restored the initial HRS, demonstrating stable switching behavior. Nitrogen-annealed devices with higher oxygen vacancies exhibited superior synaptic performance, including higher excitatory postsynaptic currents, stronger paired-pulse facilitation, and extended persistent photoconductivity (PPC) duration, enabling long-term memory retention. By systematically varying UV exposure time, intensity, pulse number, and frequency, ZnO NPs-based devices demonstrated the transition from short-term to long-term memory, mimicking biological synaptic behavior. Learning and forgetting simulations showed faster learning and slower decay in nitrogen-annealed devices, emphasizing their potential for next-generation neuromorphic computing and energy-efficient artificial synapses. Full article

Photoacoustic imaging (PAI) is an emerging modality that merges optical and ultrasound imaging to provide high-resolution and functional insights into biological tissues. This technique leverages the photoacoustic effect, where tissue absorbs pulsed laser light, generating acoustic waves that are captured to reconstruct images. While lasers have traditionally been the light source for PAI, their high cost and complexity drive interest towards alternative sources like light-emitting diodes (LEDs). This study evaluates the feasibility of using an avalanche oscillator to drive high-power LEDs in a basic photoacoustic imaging system. An avalanche oscillator, utilizing semiconductor avalanche breakdown to produce high-voltage pulses, powers LEDs to generate short, high-intensity light pulses. The system incorporates an LED array, an ultrasonic transducer, and an amplifier for signal detection. Key findings include the successful generation of short light pulses with sufficient intensity to excite materials and the system’s capability to produce detectable photoacoustic signals in both air and water environments. While LEDs demonstrate cost-effectiveness and portability advantages, challenges such as lower power and broader spectral bandwidth compared to lasers are noted. The results affirm that LED-based photoacoustic systems, though currently less advanced than laser-based systems, present a promising direction for affordable and portable imaging technologies. Full article

Ultrafast laser welding of transparent materials has been widely used in sensors, microfluidics, optics, etc. However, the existing ultrafast laser welding depths are limited by the short laser Rayleigh length, which makes it difficult to realize the joining of transparent materials in the millimeter depth range and becomes a new challenge. Based on temporal shaping, we realized Burst mode ultrafast laser output with different sub-pulse numbers and explored the effect of different Burst modes on the welding performance using high-speed shadow in situ imaging. The experimental results show that the Burst mode femtosecond laser (twelve sub-pulses with a total energy of 28.9 μJ) of 238 fs, 1035 nm and 1000 kHz can form a molten structure with a maximum depth of 5 mm inside the quartz, and the welding strength can be higher than 18.18 MPa. In this context, we analyzed the transient process of forming teardrop molten structures inside transparent materials using high-speed shadow in situ imaging detection and systematically analyzed the fracture behavior of the samples. In addition, we further reveal the Burst femtosecond laser welding mechanism of transparent materials comprehensively by exploring the difference in welding performance under the effect of Burst modes with different sub-pulse numbers. This paper is the first to realize molten structures in the range of up to 5 mm, which is expected to provide a new welding method for curved surfaces and large-size transparent materials, helping to improve the packaging strength of photoelectric devices and the window strength of aerospace materials. Full article

The acousto-optic Q-switch is exploited to develop a high-repetition-rate eye-safe Raman laser at 1526 nm. The Nd:YVO₄ and KGW crystals are employed as the fundamental laser and Stokes Raman gain materials, respectively. The influence of the gate-open time on the performance is systematically explored for the repetition rate between 80 and 150 kHz. The separate configuration is used to construct the resonant cavities for the fundamental and Stokes waves to achieve a pulse width that is as short as possible. Under the optimal alignment, the average output power can exceed 5.0 W at a pump power of 30 W for a repetition rate within 100–150 kHz with a gate-open time of 0.5 μs. In addition, the output peak power can be greater than 10 kW for a pulse repetition rate between 80 and 120 kHz. The optical-to-optical conversion efficiency is up to 16.7%, which is better than that obtained by the Nd:YVO₄/YVO₄ system. Full article

Microwave sources based on ultrastable lasers and optical frequency combs (OFCs) exhibit ultralow phase noise and ultrahigh-frequency stability, which are important for many applications. Herein, we present a microwave source that is phase-locked to an ultrastable continuous-wave laser, with a relative frequency instability of 7 × ${10}^{-16}$ at 1 s. An Er:fiber-based OFC and an optic-to-electronic converter with low residual noise are employed to confer optical frequency stability on the 9.6 GHz microwave signal. Instead of using the normal cascaded Mach–Zehnder interferometer method, we developed a microwave regeneration method for converting optical pulses into microwave signals to further suppress the additional noise in the optic-to-electronic conversion process. The microwave regeneration method employs an optical-to-microwave phase detector based on a fiber-based Sagnac loop to produce the error signal between a 9.6 GHz dielectric resonator oscillator (DRO) and the OFC. The 9.6 GHz microwave (48th harmonic of the comb’s repetition rate) signal with the frequency stability of the ultrastable laser was achieved using a DRO that was phase-locked to the optical comb. Preliminary evaluations showed that the frequency instability of the frequency synthesizer from the optical to the 9.6 GHz microwave signal was approximately 2 × ${10}^{-15}$ at 1 s, the phase noise was $-106$ dBc Hz⁻¹ at 1 Hz, and the timing noise was approximately 9 as Hz^−1/2 (phase noise approx. $-125$ dBc Hz⁻¹). The 9.6 GHz signal from the photonic microwave source exhibited a short-term relative frequency instability of 2.1 × ${10}^{-15}$ at 1 s, which is 1.5 times better than the previous results. Full article
