Adjoint-based optimization methods, that were previously in the realm of computational fluid dynamics (CFD) research, are now available in commercial software. This work explores the use of adjoint-based optimization to maximize mixing and combustion efficiencies for a supersonic combustor. To this end, a two-dimensional combustor was considered with parallel hydrogen injection. Simulations were carried out based on the steady Reynolds-Averaged Navier–Stokes equations and optimization was performed using a simplified passive scalar field instead of the full reactive flow problem. The optimization of a triangle-shaped mixing element is considered in addition to a case allowing the entire bottom of the combustor to deform. The relatively small mixing element could not boost efficiency significantly. By comparison, the optimization of the combustor wall resulted in both mixing and combustion efficiency gains accompanied by total pressure loss penalty. The optimization achieved higher efficiency compared to the baseline by extending the total volume of the reaction zone. The presented proof-of-concept results are relevant for the design of hypersonic vehicle propulsion systems, such as scramjets. Full article

Scramjet operation requires a comprehensive understanding of the internal flowfield, encompassing fuel–air mixing and combustion. This study investigates transient flow and flame development within a HIFiRE-2 scramjet engine combustor, which features two opposing cavities and dual sets of fuel injectors—the upstream (primary) and downstream (secondary) injectors. These cavities function as flameholders, creating circulating flows with elevated temperatures and pressures. Shock waves form both ahead of fuel plumes and at the diverging and converging sections of the flowpath. Special attention is given to the interactions among these shock waves and the shear layers along the supersonic core flow as the system progresses towards a quasi-steady state. Driven by increased backpressure, bow shocks and disturbances induced by the normal, secondary fuel injection and the inclined, primary fuel injection move upstream, amplifying the cavity pressure. These shocks generate adverse pressure gradients, causing near-wall flow separation adjacent to both injector sets, which enhances the penetration and dispersion of fuel plumes. Once a quasi-steady state is achieved, a feedback loop is established between dynamic wave motions and combustion processes, resulting in sustained entrainment of reactive mixtures into the cavities. This mechanism facilitates stable combustion in the cavities and near-wall separation zones. Full article

The solid-fuel scramjet has become a potential power device for hypersonic missiles in the future and has important military application prospects due to its advantages in gas flow regulation, flame stability, and blended combustion efficiency. This paper summarizes the research progress of three types of solid-fuel scramjet, including a large number of landmark numerical and experimental results. At the same time, the research progress of supersonic steady combustion and combustion enhancement technology, thermal protection technology, and the improvement of solid-fuel and combustion performance are reviewed. On this basis, the key technologies of the solid solid-fueled scramjet are summarized, and several internal scientific problems are summarized, such as the combustion organization strategy of the wide velocity domain solid rocket scramjet, efficient combustion chamber loading and thermal bulking technology, combustion instability, etc. Finally, some suggestions for the future development of the solid-fuel scramjet are put forward. Full article

Two-staged fuel injection configuration for scramjet combustors has been shown to be effective in distributing heat release in the combustor for preventing the unstart transition of the engine by suppressing peak pressure while increasing the pressure thrust. In this study, the effect of fuel species on combustion characteristics in a two-staged fueled scramjet combustor was investigated. Wall pressure measurements in a two-staged fueled scramjet combustor were conducted in a combustion wind tunnel facility with fuels having different reactivity, such as H₂ and CH₄. Reynolds-Averaged Navier–Stokes/Large Eddy Simulation (RANS/LES) hybrid simulations were performed to verify the interaction characteristics between the primary and secondary combustion zones for different fuels. The experimental results confirmed that pressure peaks at injections were clearly separated in the hydrogen case, while these interacted with each other in the methane case with a lower reactivity than H₂. The RANS/LES Hybrid analysis predicted this effect of fuel reactivity on the pressure distribution, namely, the heat release delay of the first stage fuel caused the interaction with the second stage fuel heat release. The results indicate that the need to design the staged fueled combustor, i.e., the injection stage interval accordingly to the reactivity of the fuel. Full article

This study investigates the operational characteristics of the Rotating Detonation Engine (RDE), with a focus on fuel injector design. Inspired by the similarity between the fuel injection structure of RDE and the Jet in Supersonic Crossflow (JISC) of a scramjet, experimental research on fuel injectors with jet penetration was conducted. Five injectors were designed, each with a fixed fuel injection area or injection hole diameter. Experiments determined practical injection areas, and an empirical correlation was used to calculate jet penetration heights. Under conditions of a total mass flow rate of 105 ± 5 g/s and an equivalence ratio of 1.05 ± 0.1, combustion modes were analyzed. Initial detonation occurrence was assessed through pressure history, with a detailed analysis via image post-processing. The results indicated that the injector D4N15, with the highest jet penetration height, exhibited deflagration, while D4N23 showed chaotic propagation. The injector D2N60 demonstrated relatively unstable behavior in sustained detonation cases. Thrust comparisons revealed that D4N30, with wider hole spacing and higher jet penetration height, exhibited approximately 12.5% higher specific impulse compared to D1N240. These outcomes confirm the significant impact of jet penetration height and hole spacing on detonation propagation and engine performance. Full article

A micro-pulse detonation engine (μPDE) was designed and installed to a direct-connect scramjet combustor of Pusan National University (PNU-DCSC). The active excitation on the scramjet combustor was experimentally studied using the μPDE operating at frequencies of 10–20 Hz. A vitiation air heater (VAH) was used to supply high-enthalpy vitiated air to the isolator and the scramjet combustor at a Mach number of 2.0, with a total temperature of 1600 K and a total pressure of 1.68 MPa. The exit of μPDE was located at the center of the cavity of the scramjet combustor. Active excitation was performed at equivalence ratios of 0.111 and 0.163, and characteristics were analyzed through Schlieren recording and bottom wall pressure measurement. As a result, when the detonation emitted from the μPDE entered the scramjet combustor, it instantly formed a shock train and moved forward within the scramjet combustor. The flame instantaneously changed from the cavity shear layer flame to the cavity flame. Through bottom wall pressure measurement, it was also observed that active excitation resulted in a significant pressure increase near the cavity compared to when active excitation was not performed. This revealed combustion characteristics, indicating improved combustion efficiency from the pressure increase in the scramjet combustor. Full article

This work primarily focuses on a three-dimensional model of flame propagation and stable combustion in a scramjet chamber. The one-equation LES turbulence model is adopted to close the sub-grid-scale turbulent viscosity terms. The finite-rate combustion model, along with the Jachimowski detailed hydrogen reaction mechanism with eight components and nineteen steps, is used to analyze the flame propagation characteristics of hydrogen combustion in the scramjet combustion chamber. Initially, based on the combustion chamber model, the effect of different injection locations and equivalence ratios on flame kernel formation and the flame propagation process is analyzed. The relationship between different fuel injection conditions and the oxygen consumption rate of the combustion chamber, as well as the total pressure recovery coefficient changes, is investigated. The research focuses on changes in equivalence ratios and injection hole distributions, with injection holes arranged upstream, downstream, and inside of the cavity. The result indicated that when the injection holes were arranged downstream of the cavity, there was a phenomenon of flame backflow into the cavity, which was related to the size of the injection pressure. For this work, the pressure causing flame backflow was approximately 2 MPa. When the injection hole was arranged inside the cavity, the relative distance difference between the injection hole and the upper wall of the cavity led to the formation of two reaction zones in the combustion chamber. When the injection hole was arranged upstream of the cavity, different injection equivalence ratios affected the final stable position and structure of the flame. Therefore, the injection position, injection pressure, and injection equivalence ratio all had a certain impact on the flame kernel formation and flame propagation process. Full article

This study focuses on the three-dimensional flow and combustion characteristics of a cavitied scramjet engine with multi-position injection. A single-equation large eddy simulation (LES) turbulence model is employed, with a detailed reaction mechanism for hydrogen combustion, as described by Jachimowski. The combustion characteristics of hydrogen in the scramjet combustion chamber are analyzed. Based on the combustion chamber model, the influence of different equivalence ratios, injection timing, injection positions, and injection pressures on the flame formation and propagation process are compared. The results indicate that within a certain range, an increase in the equivalence ratio enhances the combustion intensity and chamber pressure. In the case of multi-position injection, the order of injection from different nozzles has little effect on the final flame stabilization mode and pressure distribution. The opposite-side distribution of nozzles can effectively improve the fuel efficiency and the internal pressure. Furthermore, when the nozzles are closely placed in the opposite-side distribution, the combustion efficiency increases, although this leads to a higher total pressure loss. In scenarios where the fuel injection duration is short, an increase in the injection pressure at the upstream nozzles of the cavity results in a higher local equivalence ratio, as well as reduced fuel mixing and ignition time. Full article

Scramjet based on solid propellant has become a potential choice for the development of future hypersonic vehicles. In this paper, a boron-containing solid rocket scramjet based on the central strut injection was proposed, and the ground direct-connect experiment with the equivalence ratios of 0.43 to 2.4 under the flight condition of Mach 6, 25 km was carried out. The pressure and flow rate over time were measured in the experiment. The results show that the engine can realize stable supersonic mode or subsonic mode combustion by changing the gas flow rate. The engine can effectively increase the combustor pressure, reduce the unstable combustion time, and advance the strong combustion position by increasing the gas flow rate. The engine achieved high combustion efficiency when the equivalence ratio was about 1, with a maximum of 88.28%. A numerical simulation analysis was also carried out in this paper. Compared to the experimental results, the pressure error obtained by numerical simulation was less than 4%, and the typical position error was less than 3%, suggesting that the simulation model can be used to predict the behavior of scramjet. Full article

This paper presents a summary of and introduction to research on high-altitude and subatmospheric combustion concerning turbine and scramjet engines. The investigation includes theoretical analysis, experimental studies, and numerical simulations. The analysis encompasses the flow field structure, fuel atomization, and combustion performance. Subsequently, recent research on the combustion performance of liquid fuels, solid fuels, and gaseous fuels under high-altitude and low-pressure plateau environments is reviewed. This includes an evaluation of flame height, flame temperature, combustion rate, fire spread rate, and heat radiation flux. Additionally, combustion performance prediction models for high-altitude environments based on experimental and theoretical analysis have been introduced. Lastly, issues in subatmospheric combustion in the aerospace and plateau fire fields are presented based on the current research. Full article

Pressure and flame surface oscillations are common in supersonic combustion instability. Understanding the characteristics, generation, maintenance, and interaction mechanisms of these oscillations is crucial. An experimental setup with an alcohol heater was used to study injection positions and fuel quantities in a dual-cavity scramjet combustion chamber. High-frequency pressure sensors and high-speed equipment were employed in this research. The most significant pressure oscillation occurred at a global equivalence ratio of 1.2 with a frequency of 300 Hz and an amplitude of 43%. Mean oscillation was not affected by changes in equivalence ratio. Increased amplitude was linked to stronger flow instability, indicating that flow instability induced by unstable heat release plays a significant role in supersonic combustion instability. Full article

In order to study the infrared radiation characteristics of an air-breathing hypersonic vehicle powered by a scramjet, it is necessary to solve the internal and external flow field of the air-breathing hypersonic vehicle. Owing to the complexity and difficulty of solving the three-dimensional flow and heat-transfer process in a scramjet combustor, a quasi-one-dimensional calculation method was established. Utilizing zooming technology, a combination of quasi-one-dimensional simulation within the combustion chamber and three-dimensional numerical simulation elsewhere on the vehicle was employed to obtain the flow field. The accuracy of the zooming method in determining flow, heat transfer, and infrared radiation was verified through comparison with experimental data. The results show that under the flight condition of Ma = 6, the gas temperature and wall heat flux in the scramjet combustor first increased and then decreased along the flow direction. The Mach number of the plume was smaller than that of the free flow, while the velocity of the plume was slightly larger. In the wavelength range of 3–5 μm, as the azimuth angle increased, the integrated radiation intensity of the air-breathing hypersonic vehicle demonstrated a characteristic pear-shaped distribution. Full article

A scramjet engine consisting of several components is a highly coupled system that urgently needs a universal performance metric. Exergy is considered as a potential universal currency to assess the performance of scramjet engines. In this paper, a control-volume-based exergy method for the Reynolds-averaged Navier–Stokes solution of truncated and corrected Busemann inlets was proposed. An exergy postprocessing code was developed to achieve this method. Qualitative and quantitative analyses of exergies in the Busemann inlets were performed. A complete understanding of the evolution process of anergy and the location where anergy occurs in the inlet at various operation conditions was also obtained. The results show that the exergy destroyed in the Busemann inlet can be decomposed into shock wave anergy, viscous anergy and thermal anergy. Shock wave anergy accounts for less than 4% of the total exergy destroyed while thermal anergy and viscous anergy, in a roughly equivalent magnitude, contribute to almost all the remaining. The vast majority of inflow exergy is converted into boundary pressure work and thermal exergy. Some of the thermal exergy excluded by the computation of the total pressure recovery coefficient belongs to the available energy, as this partial energy will be further converted into useful work in combustion chambers. Full article

An approach based on the OpenFOAM library has been developed to solve a high-speed, multicomponent mixture of a reacting, compressible flow. This work presents comprehensive validation of the newly developed solver, called compressibleCentralReactingFoam, with different supersonic flows, including shocks, expansion waves, and turbulence–combustion interaction. The comparisons of the simulation results with experimental and computational data confirm the fidelity of this solver for problems involving multicomponent high-speed reactive flows. The gas dynamics of turbulence–chemistry interaction are modeled using a partially stirred reactor formulation and provide promising results to better understand the complex physics involved in supersonic combustors. A time-scale analysis based on local Damköhler numbers reveals different regimes of turbulent combustion. In the core of the jet flow, the Damköhler number is relatively high, indicating that the reaction time scale is smaller than the turbulent mixing time scale. This means that the combustion is controlled by turbulent mixing. In the shear layer, where the heat release rate and the scalar dissipation rate have the highest value, the flame is stabilized due to finite rate chemistry with small Damköhler numbers and a limited fraction of fine structure. This solver allows three-dimensional gas dynamic simulation of high-speed multicomponent reactive flows relevant to practical combustion applications. Full article

In the combustion chamber of scramjets, fuel jets interact with supersonic airflow in the form of a liquid jet in crossflow (LJIC). It is difficult to achieve adequate jet–crossflow mixing and the efficient combustion of fuel in an instant. Large eddy simulation (LES), the coupled level-set and volume of fluid (CLSVOF) method, and an adaptive mesh refinement (AMR) framework are used to simulate supersonic LJICs in this article. This way, LJIC atomization characteristics and mechanisms can be further explored and analyzed in detail. It is found that the surface waves of the liquid column exist in a two-dimensional form, including vertical and spanwise directions. Column breakup occurs when all the spanwise surface waves between adjacent vertical surface waves break up. Bow shock waves, composed of multiple connected arcuate shock waves, are dynamic and will change with the evolution of the liquid column. The vortex ring movement of supersonic LJICs, whose trends in the vertical and spanwise directions are different, is relatively complex, which is due to the complex and time-dependent shape of liquid columns. Full article
