The study of the mechanical behavior of functionally graded material (FGM) sandwich plates under thermo-mechanical loading is of great significance for advanced structural design. This study systematically verifies the applicability of the shear strain functions proposed by Reddy and Touratier in the nonlinear bending analysis of porous FGM sandwich plates. Using the existing four-variable shear deformation theory framework, the governing equations are derived through the principle of minimum potential energy, and the Navier method is applied for a numerical solution. For the first time, the study systematically compared the effects of three different porosity distribution patterns on dimensionless deflection, and verified the reliability of the model by comparing it with literature data. The results demonstrate that the adopted shear strain functions can accurately predict the influence of key parameters, including layer thickness ratio, aspect ratio, side-to-thickness ratio, volume fraction index, and porosity, on the deflection performance of sandwich plates. This research provides an important verification basis for the theoretical analysis and engineering application of FGM sandwich plates, particularly offering quantitative evidence for assessing the influence of porosity effects on theoretical prediction accuracy. Full article

The vibration of porous Al–Al₂O₃ micro-cantilever sandwich beams in fluids was studied utilizing the modified couple stress theory and the scale distribution theory (MCST and SDT). Four types of porosity distributions were defined; the uniform distribution of pores was defined as U-type, while O-type, V-type and X-type represented non-uniform distributions of pores. The material properties of different porous sandwich beams were calculated. The properties of the micro-cantilever sandwich beams were adjusted to account for scale effects according to MCST. With the fluid driving force taken into consideration, the amplitude-frequency response, and resonant frequencies of the FGM sandwich beams in three different fluids were calculated using the Euler–Bernoulli beam theory. The computational studies showed that the presence of gradient factor p and the pores in the micro-cantilever sandwich beams affect the temperature field distribution and amplitude-frequency response in fluids. Increasing gradient factor p leads to a more obvious thermal concentration of the one-dimensional temperature field and migrates the resonance peaks to lower frequencies. In contrast to the uniform distribution type, the non-uniformly distributed pores also cause a decrease in the resonance frequency. Full article

This paper presents numerical investigations into the free vibration properties of a sandwich composite plate with two fiber-reinforced plastic (FRP) face sheets and a functionally graded carbon nanotube-reinforced composite (FG-CNTRC) core made of functionally graded carbon nanotube-reinforced composite resting on Winkler/Pasternak elastic foundation. The material properties of the FG-CNTRC core are gradient change along the thickness direction with four distinct carbon nanotubes reinforcement distribution patterns. The Hamilton energy concept is used to develop the equations of motion, which are based on the high-order shear deformation theory (HSDT). The Navier method is then used to obtain the free vibration solutions. By contrasting the acquired results with those using finite elements and with the previous literature, the accuracy of the present approach is confirmed. Moreover, the effects of the modulus of elasticity, the carbon nanotube (CNT) volume fractions, the CNT distribution patterns, the gradient index p, the geometric parameters and the dimensionless natural frequencies’ elastic basis characteristics are examined. The results show that the FG-CNTRC sandwich composite plate has higher dimensionless frequencies than the functionally graded material (FGM) plate or sandwich plate. And the volume fraction of carbon nanotubes and other geometric factors significantly affect the dimensionless frequency of the sandwich composite plate. Full article

This paper investigates the thermal mechanical bending response of symmetric functionally graded material (FGM) plates. This article proposes a thermodynamic analysis model of both the FGM plate and FGM sandwich plate, and the model only involves four control equations and four unknown variables. The control equation is based on the refined shear deformation theory and the principle of minimum potential energy. The Navier method is used to solve the control equation. According to the method, numerical examples are provided for the thermo-mechanical bending of the symmetric FGM plate and FGM sandwich plate under a simply supported boundary condition, and the accuracy of the model is verified. Finally, parameter analysis is conducted to investigate the effects of the volume fraction index, side-to-thickness ratio, thermal load, and changes in core thickness on the thermal mechanical bending behavior of the symmetric FGM plate and FGM sandwich plate in detail. It was found that the deflection of the FGM plate is greater than that of the FGM sandwich plate, while the normal stress of the FGM plate is smaller than that of the FGM sandwich plate. Moreover, the FGM plate and FGM sandwich plate are sensitive to nonlinear temperature changes. Full article

This paper investigates the bending of asymmetric functionally graded material (FGM) sandwich plates subjected to thermo-mechanical loads in thermal environments. In this paper, a thermo-mechanical analysis model for asymmetric FGM sandwich plates is proposed, which contains only four control equations and four unknown variables. The governing equation is obtained through refined shear theory and the principle of virtual work, and the Navier method is used to solve it. Numerical examples of simply supported FGM sandwich plates under thermo-mechanical loads are given to verify the accuracy of the model. Finally, detailed studies are conducted on the bending of asymmetric FGM sandwich plates under thermo-mechanical loads, exploring the effects of various parameter changes on their bending behavior, and providing strong guidance for the application of asymmetric FGM sandwich plates in industrial production practice. Full article

In this work, a coupled 3D thermo-elastic shell model is presented. The primary variables are the scalar sovra-temperature and the displacement vector. This model allows for the thermal stress analysis of one-layered and sandwich plates and shells embedding Functionally Graded Material (FGM) layers. The 3D equilibrium equations and the 3D Fourier heat conduction equation for spherical shells are put together into a set of four coupled equations. They automatically degenerate in those for simpler geometries thanks to proper considerations about the radii of curvature and the use of orthogonal mixed curvilinear coordinates $\alpha$, $\beta$, and z. The obtained partial differential governing the equations along the thickness direction are solved using the exponential matrix method. The closed form solution is possible assuming simply supported boundary conditions and proper harmonic forms for all the unknowns. The sovra-temperature amplitudes are directly imposed at the outer surfaces for each geometry in steady-state conditions. The effects of the thermal environment are related to the sovra-temperature profiles through the thickness. The static responses are evaluated in terms of displacements and stresses. After a proper and global preliminary validation, new cases are presented for different thickness ratios, geometries, and temperature values at the external surfaces. The considered FGM is metallic at the bottom and ceramic at the top. This FGM layer can be embedded in a sandwich configuration or in a one-layered configuration. This new fully coupled thermo-elastic model provides results that are coincident with the results proposed by the uncoupled thermo-elastic model that separately solves the 3D Fourier heat conduction equation. The differences are always less than 0.5% for each investigated displacement, temperature, and stress component. The differences between the present 3D full coupled model and the the advantages of this new model are clearly shown. Both the thickness layer and material layer effects are directly included in all the conducted coupled thermal stress analyses. Full article

Due to the high importance of viscoelastic materials in modern industrial applications, besides the intensive popularity of piezoelectric smart structures, analyzing their thermoelastic response in extreme temperature conditions inevitably becomes very important. Accordingly, this research explores the thermoviscoelastic response of sandwich plates made of a functionally-graded Boltzmann viscoelastic core and two surrounding piezoelectric face-layers subjected to electrothermal load in the platform of three-dimensional elasticity theory. The relaxation modulus of the FG viscoelastic layer across the thickness follows the power law model. the plate’s governing equations are expressed in the Laplace domain to handle mathematical complications corresponding to the sandwich plate with a viscoelastic core. Then, the state-space method, combined with Fourier expansion, is utilized to extract the plate response precisely. Finally, the obtained solution is converted to the time domain using the inverse Laplace technique. Verification of the present formulation is compared with those reported in the published papers. Finally, the influences of plate dimension, temperature gradient, and relaxation time constant on the bending response of the above-mentioned sandwich plate are examined. As an interesting finding, it is revealed that increasing the length-to-thickness ratio leads to a decrease in deflections and an increase in stresses. Full article

The present work aims at investigating the hygrothermal effect on the natural frequencies of functionally graded (FG) annular plates integrated with piezo-magneto-electro-elastic layers resting on a Pasternak elastic foundation. The formulation is based on a layer-wise (LW) theory, where the Hamiltonian principle is used to obtain the governing equation of the problem involving temperature- and moisture-dependent material properties. The differential quadrature method (DQM) is applied here as a numerical strategy to solve the governing equations for different boundary conditions. The material properties of FG annular plates are varied along the thickness based on a power law function. The accuracy of the proposed method is, first, validated for a limit-case example. A sensitivity study of the free vibration response is, thus, performed for different input parameters, such as temperature and moisture variations, elastic foundation, boundary conditions, electric and magnetic potential of piezo-magneto-electro-elastic layers and geometrical ratios, with useful insights from a design standpoint. Full article

This work studies the buckling and free vibration behavior of Shape Memory Alloy Hybrid Composite (SMAHC) sandwich beams under a thermal environment. The sandwich beams consist of layers reinforced with SMAs and a FGM core, and they are simply supported at both ends. The higher order theory is combined with the Minimum Potential Energy principle or Hamilton principle to derive the governing equations of the thermal buckling and thermal vibration problems, respectively. The material properties of the beam are assumed as temperature-independent (TID) or temperature-dependent (TD). In the last case, two different types of thermal distribution are considered, namely a uniform and a linear distribution. The results based on the proposed formulation are verified against the reference literature, with a very good matching. A parametric study checks for the influence of different effective parameters such as thickness-to-length ratios, volume fraction powers, initial strain, volume fraction of SMA wires, and temperature distribution on the overall mechanical response of the selected structural member, with useful insights from a design standpoint. Full article

The functionally graded (FG) sandwich plate has attained much attention in recent years due to its potential for exhibiting the merits of sandwich construction and FGM. Accordingly, intensive studies have focused on FG sandwich plates to investigate their mechanical behaviors. However, these mechanical behaviors are still in need of further investigation, particularly with respect to the major parameters. In this context, this paper intends to parametrically investigate the free-vibration behavior of the FG sandwich plate with a homogeneous core by developing a reliable and effective numerical method. This numerical method was based on hierarchical models, developed from the spectral model accuracy, and the 2-D natural element method (NEM). The hierarchical models were derived from the 3-D elasticity and the NEM was characterized by high smooth interpolation functions. From the verification experiments, the proposed method shows a good agreement with the reference and a uniform convergence to the 3-D elasticity. The free vibration characteristics of FG sandwich plates with a homogeneous core were investigated using the proposed numerical method. It was found that the calibrated fundamental frequency was significantly influenced by the type of material composing the core, the volume fraction index, the relative thickness and position of core layer, and the plate aspect ratio. Full article

Functionally graded materials (FGM) have received extensive attention in recent years due to their excellent mechanical properties. In this research, the theoretical process of calculating the propagation characteristics of Lamb waves in FGM sandwich plates is deduced by combining the FGM volume fraction curve and Legendre polynomial series expansion method. In this proposed method, the FGM plate does not have to be sliced into multiple layers. Numerical results are given in detail, and the Lamb wave dispersion curves are extracted. For comparison, the Lamb wave dispersion curve of the sliced layer model for the FGM sandwich plate is obtained by the global matrix method. Meanwhile, the FGM sandwich plate was subjected to finite element simulation, also based on the layered-plate model. The acoustic characteristics detection experiment was performed by simulation through a defocusing measurement. Thus, the Lamb wave dispersion curves were obtained by V(f, z) analysis. Finally, the influence of the change in the gradient function on the Lamb wave dispersion curves will be discussed. Full article

Flexoelectric and piezoelectric effects have attracted the attention of researchers, owing to their applications in sensing systems and actuators. In this paper, the vibration of functionally graded material (FGM) conical nanoshell is studied, taking into account both piezoelectricity and flexoelectricity. The nanoshell has a sandwich-type structure with a FGM core and two layers of piezoelectric materials on its top and bottom. With the combination of the first order shear deformation and Eringen’s nonlocal theories, the vibration equation of the nanoshell is developed. In order to study the governing equations and the frequency of vibrations of nanoshell, the generalized differential quadrature method is implemented. Based on the developed numerical solution procedure, the effect of different parameters, such as flexoelectricity, piezoelectricity, nonlocal term and Pasternak foundation, are shown on the vibrations of conical nanoshell. The presented analysis provides a better insight into the behavior of conical nanoshells, which are highly applicable in bio-sensing and optical devices. Full article

To examine the acousto-structural behavior of a sandwich cylindrical shell benefiting from hexagonal honeycomb structures in its core and functionally graded porous (FGP) layers on its outer and inner surfaces, a comprehensive study based on an analytical model which also considers the effect of an external flow is conducted. A homogenous orthotropic model is used for the honeycomb core while its corresponding material features are found from the modified Gibson’s equation. The distribution pattern of FGP parts is either even or logarithmic-uneven, and a special rule-of-mixture relation governs their properties. Based on the first-order shear deformation theory (FSDT), Hamilton’s principle is exploited to derive the final coupled vibro-acoustic equations, which are then solved analytically to allow us to calculate the amount of sound transmission loss (STL) through the whole structure. This acoustic property is further investigated in the frequency domain by changing a set of parameters, i.e., Mach number, wave approach angle, structure’s radius, volume fraction, index of functionally graded material (FGM), and different honeycomb properties. Overall, good agreement is observed between the result of the present study and previous findings. Full article

This paper presents an analytical solution for the thermomechanical buckling of functionally graded material (FGM) sandwich plates. The solution is obtained using a four-variable equivalent-single-layer (ESL) plate theory. Two types of sandwich plates are included: one with FGM facesheets and homogeneous core, and vice versa for the other. The governing equations are derived based on the principle of minimum total potential energy. For simply supported boundary conditions, these equations are solved via the Navier method. The results on critical buckling load and temperature increment of simply supported FGM sandwich plates are compared with the available solutions in the literature. Several results are presented considering various material and geometrical parameters as well as their effect on the thermomechanical buckling response of FGM sandwich plates. The relationship between the mechanical load and the temperature increment for uniform/linear temperature rise of FGM sandwich plates under combined mechanical and thermal loads is studied. Full article

Due to the widespread use of sandwich structures in many industries and the importance of understanding their mechanical behavior, this paper studies the thermomechanical buckling behavior of sandwich beams with a functionally graded material (FGM) middle layer and two composite external layers. Both composite skins are made of Poly(methyl methacrylate) (PMMA) reinforced by carbon-nano-tubes (CNTs). The properties of the FGM core are predicted through an exponential-law and power-law theory (E&P), whereas an Eshelby–Mori–Tanaka (EMT) formulation is applied to capture the mechanical properties of the external layers. Moreover, different high-order displacement fields are combined with a virtual displacement approach to derive the governing equations of the problem, here solved analytically based on a Navier-type approximation. A parametric study is performed to check for the impact of different core materials and CNT concentrations inside the PMMA on the overall response of beams resting on a Pasternak substrate and subjected to a hygrothermal loading. This means that the sensitivity analysis accounts for different displacement fields, hygrothermal environments, and FGM theories, as a novel aspect of the present work. Our results could be replicated in a computational sense, and could be useful for design purposes in aerospace industries to increase the tolerance of target productions, such as aircraft bodies. Full article
