The lateral vibration of propulsion shafting is a critical factor affecting the acoustic stealth performance of underwater vehicles. As the main vibration isolation component in transmitting vibrational energy, the damping efficiency of the propulsion shafting support system (PSSS) holds particular significance. This study investigates the dynamic characteristics of the PSSS with the integral squeeze film damper (ISFD). A dynamic model of ISFD–PSSS is developed to systematically analyze the effects of shaft speed and external load on its dynamic behavior. Three test bearings (conventional, 1S, and 3S structure) are designed and manufactured to study the influence of damping structure layout scheme, damping fluid viscosity, unbalanced load, and shaft speed on the vibration reduction ability of ISFD–PSSS through axis orbit and vibration velocity. The results show that the damping effects of ISFD–PSSS are observed across all test conditions, presenting distinct nonlinear patterns. Suppression effectiveness is more pronounced in the vertical direction compared to the horizontal direction. The 3S structure bearing has better vibration reduction and structural stability than other schemes. The research results provide a reference for the vibration control method of rotating machinery. Full article

The dynamics of the vibrational mode of motion of the driving member of a nonideal system, a mixing–whipping device based on a simple slide-crank mechanism, was studied. The highly nonlinear differential equations of motion were solved numerically by the Runge–Kutta method. The interaction of the mixing–whipping device with the nonideal excitation source causes the rotational speed of the engine shaft and the rotation angle of the driving member to fluctuate, accomplishing a damped process. The parameters of the device and the nonideal energy source have an effect on the kinematic, vibrational and energy characteristics of the system. An increase in the engine’s torque, crank length, number and radius of piston holes, and piston mass, as well as a decrease in the fluid’s density, leads to a reduction in the oscillation range of the crank angle, amplitude and period of angular velocity oscillations of the engine shaft and the mixing–whipping force power. The effects of a nonideal energy source may be used in designing a mixing–whipping device based on a slider-crank mechanism to select effective system parameters and an energy-saving motor in accordance with the requirements of technological processes and products. Full article

This study aimed to investigate the dynamic characteristics of shafts joined by friction welding and to update their finite element models. The first five bending mode resonance frequencies, damping ratios, and mode shapes of SAE 304 steel beams, friction-welded at three different rotational speeds (1200, 1500, and 1800 rpm), were determined using the Experimental Modal Analysis method. This approach allowed for an examination of how the dynamic properties of friction-welded beams change at varying rotational speeds. A slight decrease in resonance frequency values was observed with the transition from lower to higher rotational speeds. The largest difference of 3.28% was observed in the first mode, and the smallest difference of 0.19% was observed in the second mode. Different trends in damping ratios were observed for different modes. In the first, second, and fourth modes, damping ratios tended to increase with increasing rotational speeds, while they tended to decrease in the third and fifth modes. The largest difference was calculated as 52.83% in the third vibration mode. However, no significant change in mode shapes was observed for different rotational speeds. Based on the examined Modal Assurance Criterion (MAC) results, cross-comparisons of the mode shapes obtained for all three different speeds yielded a minimum similarity of 93.8%, reaching up to 99.9%. For model updating, a Frequency Response Assurance Criterion (FRAC)-based method utilizing frequency response functions (FRFs) was employed. Initially, a numerical model of the welded shaft was created using MATLAB-R2015a, based on the Euler–Bernoulli beam theory. Since rotational coordinates were not used in the EMA analyses, static model reduction was performed on the numerical model to reduce the effect of rotational coordinates to translational coordinates. For model updating, experimentally obtained FRFs from EMA and FRFs from the numerical model were used. The equivalent modulus of elasticity and equivalent density of the friction weld region were used as updating parameters. Successful results were achieved by developing an algorithm that ensured the convergence of the numerical model’s FRFs and natural frequencies. Full article

The inter-shaft bearing is an important component of aero-engine rotor systems. It works between a high-pressure rotor and a low-pressure rotor. Effective fault diagnosis of it is significant for an aero-engine. The casing vibration signals can promptly and intuitively reflect changes in the operational health status of an aero-engine’s support system. However, affected by a complex vibration transmission path and vibration of the dual-rotor, the intrinsic vibration information of the inter-shaft bearing is faced with strong noise and a dual-frequency excitation problem. This excitation is caused by the wide span of vibration source frequency distribution that results from the quite different rotational speeds of the high-pressure rotor and low-pressure rotor. Consequently, most existing fault diagnosis methods cannot effectively extract inter-shaft bearing characteristic frequency information from the casing signal. To solve this problem, this paper proposed the denoised improved envelope spectrum (DIES) method. First, an improved envelope spectrum generated by a spectrum subtraction method is proposed. This method is applied to solve the multi-source interference with wide-band distribution problem under dual-frequency excitation. Then, an improved adaptive-thresholding approach is subsequently applied to the resultant subtracted spectrum, so as to eliminate the influence of random noise in the spectrum. An experiment on a public run-to-failure bearing dataset validates that the proposed method can effectively extract an incipient bearing fault characteristic frequency (FCF) from strong background noise. Furthermore, the experiment on the inter-shaft bearing of an aero-engine test platform validates the effectiveness and superiority of the proposed DIES method. The experimental results demonstrate that this proposed method can clearly extract fault-related information from dual-frequency excitation interference. Even amid strong background noise, it precisely reveals the inter-shaft bearing’s fault-related spectral components. Full article

To analyze the wear performance induced by rotor–stator rubbing in an aero-engine sealing structure under authentic operating conditions, a transonic rotor system with double bearing is constructed. This system incorporates the disk, shaft, blades, joint bolts, and auxiliary support structure. The system was evaluated in terms of its critical speed, vibration characteristics, component strength under operational conditions, and response characteristics in abnormal extreme scenarios. A ball screw-type feeding system is employed to achieve precise rotor–stator rubbing during rotation by controlling the coating feed. Additionally, a quartz lamp heating system is used to apply thermal loads to coating specimens, and the appropriate heat insulation and cooling measures are implemented. Furthermore, a high-frequency rubbing force test platform is developed to capture the key characteristics caused by rubbing. The test rig can conduct response tests of the system with rotor–stator rubbing and abrasion tests with tip speeds reaching 425 m/s, feed rates ranging from 2 to 2000 μm/s, and heating temperatures up to 1200 °C. Test debugging has confirmed these specifications and successfully executed rubbing tests, which demonstrate stability throughout the process and provide reliable rubbing force test results. This designed test rig and analysis methodology offers valuable insights for developing high-speed rotating machinery. Full article

Rotating machinery is essential in various industrial fields, and growing demands for high performance under harsh operating conditions have heightened interest in fault diagnosis and prognostic technologies. However, a major challenge in fault diagnosis research lies in the scarcity of data, primarily due to the inability to deliberately introduce faults into machines during actual operation. In this study, a physical model is proposed to realistically simulate the system behavior of a ship’s turbo-rotating machinery by coupling the torsional and lateral vibrations of the rotor. While previous studies employed simplified single-shaft models, the proposed model adopted gear mesh interactions to reflect the coupling behavior between shafts. Furthermore, the time-domain response of the system is analyzed through state-space transformation. The proposed model was applied to simulate imbalance and gear teeth damage conditions that may occur in marine turbo-rotating systems and the results were compared with those under normal operating conditions. The analysis confirmed that the model effectively reproduces fault-induced dynamic characteristics. By enabling rapid implementation of various fault conditions and efficient data acquisition data, the proposed model is expected to contribute to enhancing the reliability of fault diagnosis and prognostic research. Full article

Deep groove ball bearings are important mechanical elements in the automotive and process industries, particularly in electric motors. One of the primary reasons for their failure is lubricant degradation due to stray shaft current. Thus, the present work exhibited the failure of bearings under simulated lubricated conditions similar to those of real time bearings failing in presence of stray electric current. The test was conducted using a full bearing test rig with an applied radial load, 496 N, an alternating current, 10 A, and a rotation of 2000 rpm for 24 h. The bearings (6206 series) were greased using two commercially available ester-polyalphaolefin oil-based greases with viscosity 46–54 cSt (Grease 1) and 32–35 cSt (Grease 2, also contained aromatic oil). The optical microscopic images of the bearing raceways after the tribo test indicated the superior performance of Grease 1 compared to Grease 2, with lesser formation of white etching areas, micro-pitting, spot welds, and fluting on the surfaces of the bearings. Additionally, 80% less vibrations were recorded during the test with Grease 1, indicating a stable lubricating film of Grease 1 during the test as compared to Grease 2. Furthermore, a higher extent of Grease 2 degradation during the tribo test was also confirmed using Fourier transform infrared spectroscopy. Statistical analysis (t-test) indicated the significant variation of the vibrations produced during the test with electrified conditions. The present work indicated that the composition of the greases plays a significant role in controlling the bearing failures. Full article

Fans are essential electronic components for heat dissipation in electronic systems, with fan bearings being critical parts that determine fan performance and lifespan. This paper investigates the corrosion, wear, power consumption, temperature, and vibration characteristics of a newly designed and manufactured powder metallurgy bearing with herringbone oil grooves for fans under high-humidity and high-temperature conditions. Corrosion experiments on iron–copper powder metallurgy bearings show that a higher environmental temperature and humidity result in greater corrosion current and reduced corrosion resistance. Bearings operated under high humidity (85% RH) and a high temperature (80 °C) for 0, 3, and 8 days, respectively, revealed that wear and corrosion occur simultaneously. The longer the operating time, the more significant the wear and corrosion. After 3 and 8 days, the lubricating oil flow in the oil grooves decreased by 9.8% and 51.5%, respectively. When bearings subjected to varying degrees of corrosion were tested under the same standard operating conditions, it was found that the bearings corroded for 3 and 8 days, resulting in a significant increase in the number of wear debris particles, higher RMS vibration values, and a power consumption increase of 6.9% and 7.8%, respectively. The percentage of iron elements on the surface gradually decreased, with the copper elements being the primary wear particles during the wear process. However, due to the increased clearance between the rotating shaft and the bearing caused by wear, the fan temperature slightly decreased with increased surface wear. Full article

For complex mechanical transmission equipment, shaft bearings are usually enclosed together with the shaft in the internal space of the housing to maintain good sealing and reliability. However, it is difficult to monitor the status of the shaft bearing through external sensors on the housing, while internal sensors face challenges in energy supply and data transmission. Therefore, a piezoelectric transducer ring-based energy harvesting microelectromechanical system (PTR-EH-MEMS) is proposed for the condition monitoring of shaft bearings. Specifically, the piezoelectric transducer ring is designed to convert mechanical vibrations into electrical energy, which simultaneously acts as a self-powered monitoring sensor through energy harvesting. In addition, the MEMS is embedded for piezoelectric data processing and condition monitoring of the shaft bearings. To verify the proposed PTR-EH-MEMS, an experimental investigation is implemented under different conditions. The experimental results demonstrate that the system can achieve the maximum DC output of 0.8 V and the root mean square power of 43.979 μW within 128 s, which can effectively identify early-stage bearing faults frequency through a self-powered mode. By combining energy harvesting with condition monitoring capability, the PTR-EH-MEMS offers a compact and sustainable approach for predictive maintenance in rotating machinery, reducing the reliance on external power sources and enhancing the reliability of industrial systems. Full article

Traditional rotational speed measurement methods, such as invasive sensors and visual recognition technologies, are often constrained by physical wear and environmental limitations. This paper introduces a non-invasive rotational speed measurement approach based on vibration signal frequency spectrum analysis. The proposed method utilizes the Zoom-FFT algorithm to process vibration signals collected during pump operation, enabling the precise identification of the dominant frequency and its correlation with the pump shaft frequency for accurate speed calculation. The experimental results obtained from a centrifugal pump under varying operating conditions demonstrate the following: At a constant rotational speed, flow variations have a minimal impact on the measurement accuracy, with errors ≤0.04%. Under constant flow conditions, the speed calculation accuracy achieves an error rate of 0.27% across different speeds. Compared to traditional methods, the proposed approach exhibits superior reliability and accuracy. This non-invasive method minimizes physical wear and reduces dependency on environmental factors, offering an effective solution for mechanical equipment monitoring and fault diagnosis. Full article

Misalignment faults in drive systems occur when the motor and load are not properly aligned, leading to deviations in the centerlines of the coupled shafts. These faults can cause significant damage to bearings, shafts, and couplings, making early detection essential. Traditional diagnostic techniques rely on vibration monitoring, which provides insights into both mechanical and electromagnetic fault signatures. However, its main drawback is the need for external sensors, which may not be feasible in certain applications. Alternatively, motor current signature analysis (MCSA) has proven effective in detecting faults without requiring additional sensors. This study investigates misalignment faults in synchronous reluctance motors (SynRMs) by analyzing both vibration and current signals under different load conditions and operating speeds. Fast Fourier transform (FFT) is applied to extract characteristic frequency components linked to misalignment. Experimental results reveal that the amplitudes of rotational frequency harmonics ($1x{f}_r$, $2x{f}_r$, and $3x{f}_r$) increase in the presence of misalignment, with $1x{f}_r$ exhibiting the most stable progression. Additionally, acceleration-based vibration analysis proves to be a more reliable diagnostic tool compared to velocity measurements. These findings highlight the potential of combining current and vibration analysis to enhance misalignment detection in SynRMs, improving predictive maintenance strategies in industrial applications. Full article

This paper introduces a comprehensive and publicly accessible data set from an experimental study on an independent cart system powered by linear motors. The primary objective is to advance research in machine health monitoring, predictive maintenance, and stochastic modeling by providing the first data set of its kind. Vibration signals were collected using sensors placed along the track, alongside key system variables such as cart position, following error, speed, and set current. Experiments were conducted under a wide range of operating conditions, including different fault types, fault severities, cart speeds, and fault orientations, for both single-cart and multi-cart configurations. The data set captures the relationship between vibration signatures, system variables, and fault characteristics across diverse speed profiles. The data set includes inner race (IR) and outer race (OR) faults in both the top and bottom bearings, with fault severities of 0.25 mm, 0.5 mm, 1.0 mm, and 1.5 mm in width. Eight different types of experiments were performed, classified based on the number of carts used, the section of the guide rail traversed, and the type of movement exhibited. Each experiment was conducted at two distinct nominal speeds of 1000 mm/s and 2000 mm/s, with acquisition durations ranging from 30 s to 2 min. Many experiments included multiple realizations to ensure statistical reliability. Data were recorded at a sampling frequency of 50 kHz with a resolution of 24 bits. For single-cart experiments, 5 system variables were captured, while for three-cart experiments, 15 system variables were recorded along with nine vibration channels. The total data set is approximately 400 GB, offering an extensive resource for data-driven research. Independent cart systems present unique challenges such as non-synchronous operation, speed reversals, and modularity, with each cart containing multiple bearings. In industrial applications where hundreds of carts may operate simultaneously, monitoring a large number of bearings becomes highly complex, making fault identification and localization particularly difficult. Unlike conventional rotary systems, where bearings are fixed around a rotating shaft, independent cart systems involve bearings that both rotate and translate along the track. This fundamental difference makes existing data sets and methodologies inadequate, emphasizing the need for specialized research. By addressing this gap, this work provides a critical resource for benchmarking and developing novel algorithms for fault diagnosis, signal processing, and machine learning in industrial transport applications. The outcomes of this study lay the foundation for future research in the condition monitoring of linear motor-driven transport systems. Full article

This paper investigates how the torsional load affects two vibration-based unbalance fault indicators. This investigation is important for unbalance fault diagnosis in multiple constant load conditions, which are unavoidable for many rotating machines. Coupled flexural–torsional dynamics of an unbalanced disc–shaft system, as the representative of an induction motor, is investigated via a continuous shaft–beam model. Numerical investigations reveal that the fundamental rotating intensity of the transversal acceleration is independent of the torsional load. So, the novel speed-invariant version of this indicator, which is obtained by normalizing the fundamental rotating intensity by the fourth power of the rotational speed, is also load-independent. The comprehensive experimental trials confirm load-independency of the considered two unbalance fault indicators. The important novel outcome is that, by conducting numerical analysis and comprehensive experimental trials with a belt conveyor system under various constant loading conditions, the load-independency of the fundamental rotating harmonic intensity as well as novel speed-invariant unbalance feature are justified. Full article

This study explores the integration of wind power generation into urban infrastructure via a rooftop vertical-axis wind turbine. A rigorous experimental framework was established by installing a small-scale turbine on an urban building for performance assessment under controlled conditions. Simulated environmental conditions were created using a pedestal fan and blower to evaluate mechanical interactions between the components and electrical output efficiency of the turbine. Extensive numerical modeling was conducted to analyze turbine performance, by computational fluid dynamics using ANSYS FLUENT. The results reveal that the turbine operates efficiently even at low to moderate wind speeds (0.5–6 m/s), demonstrating its feasibility for urban deployment. Performance tests indicated that, as the shaft rotational speed increased from 55 rpm to 115 rpm, the output voltage, current and power varied nonlinearly in the ranges of 3–11.9 V, 20–130 mA and 0.05–2.7 W, respectively. Vibration measurement at specified turbine locations revealed nonlinear variation in displacement, velocity, acceleration and frequency without fixed patterns. Good agreement was observed between the experimental and numerical results. The numerical model yielded interesting profiles related to velocity and turbulence distributions, apart from torque, mechanical power and electrical voltage. Important conclusions were drawn from the entire work. Full article

This study aims to investigate the dynamic behavior of water-lubricated stern bearings during service. A transient rotor dynamics numerical model is developed to research the effects of operating conditions and critical structural parameters on the variation patterns of the dynamic characteristic coefficients and journal orbit of WLBs. The main stiffness and damping formulas for dimensionless bearings are fitted based on numerical results. Additionally, the accuracy of the model calculations is experimentally verified on a water-lubricated bearing test rig. The results demonstrate that the variation trends of the main stiffness and main damping coefficients in the horizontal and vertical directions of the bearings are proportional to the external load and inversely proportional to the rotational speed. Under eccentric excitation, the dynamic characteristic coefficients of the bearings change periodically with time as an approximately sinusoidal function. With the increase in the bearing length-to-diameter ratio or the decrease in the radial clearance-to-radius ratio, the main stiffness and the main damping coefficients in the horizontal direction increase, while the main stiffness coefficient in the vertical direction decreases. This study provides theoretical support for modeling the transient transverse vibration of a propulsion shaft system. Full article
