Seismic responses of Nuclear Island (NI) structures have great significance in the foundation adaptability analysis and the seismic design of equipment. However, with the increasing complexity of nuclear power site conditions, establishing a reasonable and effective soil–pile–structure dynamic interaction model has become the key technical problem that needs to be solved. In this study, a pseudo three-dimensional soil–pile–structure dynamic interaction model considering soil nonlinearity and heterogeneity is developed for seismic response analysis of NI structures. Specifically, the nonlinearity of the near-field soil is described via the equivalent linear method, the radiation damping effect of half space is simulated through viscous boundary, and the displacement/stress conditions at lateral boundaries of the heterogeneous site are derived from free-field response analysis. Meanwhile, an equivalent stiffness–mass principle is established to simplify NI superstructures, while pile group effects are incorporated via a node-coupling scheme within the finite-element framework. Two validation examples are presented to demonstrate the accuracy and efficiency of the proposed model. Finally, seismic response analysis of two typical NI structure of reactor types (CPR1000 and AP1000) based on the actual complex site conditions in China is also presented to study the effect of radiation damping, soil conditions, and pile foundation. Key findings demonstrate the necessity of integrating SSI effects and nonlinear characteristics of non-rock foundations. While the rock-socketed pile exhibits superior performance compared to the CFG pile alternative; this advantage is offset by higher costs and construction complexity. The research findings can serve as a valuable reference for the foundation adaptability analysis and optimizing the design of equipment under the similar complex condition of the soil site. Full article

In coastal regions with thick, soft soil deposits, bridge pile foundations are susceptible to lateral displacements induced by the construction of adjacent seawalls. This study employs a three-dimensional nonlinear finite element framework to investigate the lateral deformation mechanisms of rock-socketed bridge piles under seawall surcharge loading in soft soils, considering the effects of both immediate construction and long-term consolidation. A parametric analysis is performed to evaluate the effectiveness of deep cement mixing (DCM) piles in mitigating pile displacements, focusing on key design parameters, including DCM pile length, area replacement ratio, and elastic modulus. The results reveal that horizontal pile displacements peak at the pile head post-construction (25 days: 25 mm) and progressively decrease during consolidation, shifting the critical displacement zone to mid-pile depths (20 years: 12 mm). Bending moment analysis identifies persistent positive moments at the rock-socketed interface. Increasing pile stiffness marginally reduces displacements (a < 1 mm reduction for a 22% diameter increase), while expanding the seawall–pile distance to 110 m decreases displacements by 72–84%. DCM pile implementation significantly mitigates short-term (48% reduction) and long-term (54% reduction) displacements, with optimal thresholds at a 30% area replacement ratio and a 40.5 MPa elastic modulus. This study provides critical insights into time-dependent soil–pile interaction mechanisms and practical guidelines for optimizing coastal infrastructure design to minimize surcharge-induced impacts on adjacent pile foundations. Full article

With the rapid development of the national economy, the construction of super high-rise buildings, long-span bridges, high-speed railways, and transmission towers has become increasingly common. It is also more frequent to build structures on karst foundations, which imposes higher demands on foundation engineering, especially pile foundations. To study the influence of the roughness factor (RF) on the bearing characteristics of rock-socketed pile, model pile load tests were conducted with different RF values (0.0, 0.1, 0.2, and 0.3) to reveal the failure modes of the test pile, analyze the characteristics of the load–displacement curves and the axial force and resistance exertion law of the pile, and discuss the influence of the RF on the ultimate bearing capacity of the test pile. Based on the load transfer law of test piles, a load transfer model considering the relative pile–soil displacement and the shear dilatancy effect of pile–rock is established to analyze its load transfer characteristics. The results show that the failure mode of the test pile is splitting failure. The load–displacement curves are upward concave and slowly varying. The pile side resistance and the pile tip resistance mainly bear the load on the pile top. As the load on the pile top increases, the pile tip resistance gradually comes into play, and when the ultimate load is reached, the pile tip resistance bears 72.12% to 79.22% of the upper load. The pile side resistance is mainly borne by the rock-socketed section, and the pile side resistance increases sharply after entering the rock layer, but it decreases slightly with increasing depth, and the peak point is located in the range of 1.25D below the soil–rock interface. Increasing the roughness of the pile can greatly improve the ultimate bearing capacity. In this study, the ultimate bearing capacity of the test pile shows a trend of increasing and then decreasing with the gradual increase in RF from 0.0 to 0.3, and the optimal RF is 0.2. The load transfer model of pile–soil relative displacement and pile–rock shear dilatancy effect, as well as the pile tip load calculation model, were established. The calculation results were compared with the test results and engineering measured data, respectively, and they are in good agreement. Full article

In order to study the horizontal bearing characteristics of large-diameter rock-socketed rigid pile and flexible pile, two lateral loading tests in which the pile lengths are 5.2 m and 11.07 m were carried out. Unidirectional multi-cyclic loading was applied to the piles during the tests, with the maximum load reaching 3500 kN. The measured results are compared with the calculated results of Zhang’s method, m-method and the rigid pile method in the design codes. It is indicated that if the characteristic values of the horizontal bearing capacity of the large-diameter rock-socketed rigid pile and flexible pile are determined by the same horizontal displacement of the pile head, some risk will be brought to the design of the rigid pile. Compared with the rigid pile method, the m-method is more suitable for calculating the rotation angle of the pile head. In terms of the maximum bending moment of the large-diameter rock-socketed flexible pile under the critical load, the calculated result of Zhang’s method is less than the measured result, while the calculated result of the m-method is the largest. However, for the rigid pile, both Zhang’s method and m-method underestimate the maximum bending moment of the pile body. In summary, when a large-diameter rock-socketed pile is designed, reasonable calculation method and failure discrimination standard should be chosen according to the actual conditions. Full article

Rock-socketed piles are commonly used in pile foundations for large buildings because of their excellent load-bearing characteristics. The roughness of the pile–rock interface affects the load transfer and the ultimate side resistance of the pile. In this work, a laser radar system is developed to measure the surface roughness of a dry bored pile and the shape of the borehole, and a three-dimensional model of the borehole is reconstructed based on the laser point cloud. The 3D surface model was used to extract the vertical contour lines in different directions and thus calculate the roughness of the pile. A numerical simulation of the real measured 3D model using FLAC3D is presented. A borehole of a real rock-socketed pile was measured and simulated. The results show that, although the working load is carried by both the side and base resistances, the former plays a major role. The slow-varying load-settlement curve indicates that the pile has a superior load–bearing capacity, and the maximum allowable settlement should be considered in the application. The simulations, using the actual piles tested, produced a more realistic load response and were able to predict the load-bearing performance of the piles more accurately. Furthermore, this approach offers a reference for the design of rock-socketed piles. Full article

In the waterway construction projects of the upper reaches of the Yangtze River, crushed mudstone particles are widely used to backfill the foundations of rock-socketed concrete-filled steel tube (RSCFST) piles, a structure widely adopted in port constructions. In these projects, the steel–mudstone interfaces experience complex loading conditions, and the surface profile tends to vary within certain ranges during construction and operation. The changes in boundary conditions and material profile significantly impact the bearing performance of these piles when subjected to cyclic loads, such as ship impacts, water level fluctuations, and wave-induced loads. Therefore, it is necessary to investigate the shear characteristics of the RSCFST pile–soil interface under cyclic vertical loading, particularly in relation to varying deformation levels in the steel casing’s outer profile. In this study, a series of cyclic direct shear tests are carried out to investigate the influential mechanisms of roughness on the cyclic behavior of RSCFST pile–soil interfaces. The impacts of roughness on shear stress, shear stiffness, damping ratio, normal stress, and particle breakage ratio are discussed separately and can be summarized as follows: (1) During the initial phase of cyclic shearing, increased roughness correlates with higher interfacial shear strength and anisotropy, but also exacerbates interfacial particle breakage. Consequently, the sample undergoes more significant shear contraction, leading to reduced interfacial shear strength and anisotropy in the later stages. (2) The damping ratio of the rough interface exhibits an initial increase followed by a decrease, while the smooth interface demonstrates the exact opposite trend. The variation in damping ratio characteristics corresponds to the transition from soil–structure to soil–soil interfacial shearing. (3) Shear contraction is more pronounced in rough interface samples compared to the smooth interface, indicating that particle breakage has a greater impact on soil shear contraction compared to densification. Full article

To study the bearing characteristics of rock-socketed single piles on the southeast coast of Fujian Province, we conducted similar material ratio tests and single pile model tests. Initially, based on the mechanical parameters of strongly weathered granite, 10 groups of similar material samples were prepared using iron concentrate powder, barite powder, and quartz sand as aggregates, with rosin and alcohol as the cementing agents and gypsum as the modulating agent. Through triaxial testing and range and variance analysis, it was determined that the binder concentration has the most significant impact on the material properties. Consequently, Specimen 1 was selected as the simulation material. In the model test, the strongly weathered granite stratum was simulated using the ratio of Specimen 1. A horizontal load was applied using a pulley weight system, and the displacement at the top of the pile was measured with a laser displacement meter, resulting in a horizontal load–displacement curve. The results indicated that the pile foundation remained in an elastic state until a displacement of 2.5 mm. Measurements of the horizontal displacement and bending moment of the pile revealed that the model pile behaves as a flexible pile; the bending moment initially increases along the pile length and then decreases, approaching zero at the pile’s bottom. The vertical load test analyzed the relationship between vertical load and settlement of the single pile, as well as its variation patterns. This study provides an experimental basis for the design of single pile foundations in weathered granite formations on the southeast coast of Fujian Province and aids in optimizing offshore wind power engineering practices. Full article

In recent years, offshore wind turbine technology has been widely developed, making a significant contribution to the advancement of renewable energy. Due to the predominant subsurface geological composition characterized by rocky formations in some marine areas, rock-socketed piles are commonly applied as offshore wind turbine foundations. Generally, rock-socketed piles need to be driven into rock layers that have not undergone significant weathering or erosion for optimal load-bearing capacity. This design is essential to ensure structural support for offshore wind turbines. However, during the long-term operation period of offshore wind turbines, the contact surface between the rock-socketed pile and the rock is prone to be detached under multiple dynamic loads. The generated channel makes seawater seep into the unweathered rock layer, resulting in the erosion of rock meso-structure and deterioration of mechanical properties. The reduced load-bearing capacity will adversely affect the operation of the offshore wind turbine. In this study, the meso-structural evolution of bedrock in pressurized seawater is investigated by X-ray CT imaging using tuff samples from the marine areas of an offshore wind farm in China. A cellular automata model is proposed to predict the long-term evolutionary process of tuff meso-structure. Results indicate that the porosity of the tuff sample in the pressurized seawater shows an upward trend over time. Based on the erosion rate of pores obtained from the CT scanning test, the proposed cellular automata model can predict the evolutionary process of tuff meso-structure and corresponding failure strength of the bedrock in the long term. Full article

Sidewall roughness is a key factor influencing the shaft resistance of rock-socketed piles. Owing to the difficulties in onsite measuring and the inconsistency in quantitatively characterizing the roughness degree of sidewalls, existing approaches for estimating the shaft resistance of rock-socketed piles often cannot take this factor into account. Based on the measured surface curves of the 68 sockets in No. 6# and 7# group piles of the Chishi Bridge on the Ru-Chen Expressway in China, sidewall roughness is described by introducing the roughness factor (RF) based on the Horvath and Monash models, respectively, while a statistical analysis of the sidewall roughness in rock-socketed sections is also conducted. In addition, an analytical solution to the shaft resistance of rock-socketed piles with consideration of sidewall roughness and the relative settlement of the pile–rocks interface (∆s), is proposed and further compared with the field load tests. The results showed that: the RF obtained by the Horvath model is bigger than that obtained by the Monash model; the larger RF is, the bigger the mobilized shaft resistance; the analytical solution generally overestimates the mobilized shaft resistance of rock-socketed piles under the same ∆s, and the deviation is less than 15% if ∆s is larger than 3.00 mm. The Horvath model is recommended to quantitatively characterize the roughness degree of sidewalls for its good operability in practice. Full article

Two centrifuge model tests were conducted, each with three large diameter steel tubular piles installed under similar conditions, i.e., diameter (Φ) = 2 m; thickness (t) = 25 mm; loading height from the rock surface (H_L) = 6.5 m, but different rock socketing depths (d_r), i.e., 2 m, 3 m, and 4 m, respectively, in prototype scale. Two additional 1 g model tests were conducted using the same model pile and ground. The results indicate that the pile lateral resistance increased with an increase in the rock socketing depth to diameter ratio (d_r/Φ) in both 1 g and 50 g models. However, the difference between the two gravitational acceleration levels became visible in the non-linear behaviour as the imposed displacement increased. Specifically, the 1 g models showed larger residual displacement and less stiffness in reloading than the 50 g models, particularly under cyclic loading. Two types of ultimate failure modes were observed, i.e., rock failure and pile structural failure with local buckling just above the rock surface. The latter failure mode was only attained in the pile with a d_r/Φ ratio of 2 in a 50 g models among the test conditions adopted in the models, but not in the 1 g model. Full article

Monopiles are commonly used in the construction of offshore wind turbines. However, implementing drive-drill-drive construction techniques in decomposed granite seabed may lead to borehole instability during the window period between drilling and pile driving, resulting in significant project losses. This study provides a comprehensive understanding and approach to address the causes of borehole instability in rock-socketed monopiles in decomposed granite seabed. Using the Pinghai Bay offshore wind farm project in Fujian, China as an example, the details of drive-drill-drive and reverse-circulation drilling techniques employed in monopile construction were introduced. An improved sampling method was utilized to obtain decomposed granite samples, and a series of in situ and laboratory tests were conducted to analyze the physical and mechanical properties of marine-decomposed granite. By examining three cases of monopile construction, the factors contributing to borehole instability during rock-socketed monopile construction in decomposed granite seabed were identified, and corresponding recommendations were proposed. The results indicated that construction technology and unfavorable geological characteristics of decomposed granite are the primary causes of borehole instability. Collapses occurred mainly in highly and moderately decomposed granite layers. Employing smaller boreholes can reduce the likelihood and impact of borehole instability. Full article

Rock-socketed pile is widely used in coastal wharf, Marine bridge, and Marine power engineering, and the end bearing function is considered more in the design process. However, the lateral friction resistance of rock-socketed piles is an important bearing part, and the load transfer mechanism of the pile–soft rock interface is an important research focus. In this paper, a comparative analysis was adopted in the test, and ten groups of test specimens were made, including five groups of natural and saturated mudstone specimens, respectively. The characteristics of interfacial load transfer were analyzed through the shear test of a pile–mudstone interface. A calculation model for the vertical bearing capacity of rock-socketed piles based on the softening of lateral friction resistance was established, and the effects of interface relative displacement, lateral positive pressure, pile length, and pile stiffness on the vertical bearing capacity of rock-socketed piles were analyzed. The results show that the shear strength of the pile–rock interface is lower than that of the mudstone interface, and the interfacial shear strength shows the characteristics of “first increasing, then decreasing, and finally flattening with the increase of shear displacement”. The vertical ultimate bearing capacity and residual bearing capacity under saturation were 89.49% and 89.73% of the natural state, respectively. With the increase of pile side pressure, the proportion of pile side friction resistance increased by 39.96%, and the pile side friction resistance was fully exerted. With the increase of pile length, the vertical ultimate bearing capacity of pile foundation increased, and the residual bearing capacity change value increased from 6.80% to 16.97%. However, the increase in pile stiffness had little effect on the vertical bearing capacity. The calculation model can provide a certain reference for the design and calculation of rock-socketed piles in soft rock areas. Full article

Rock-socketed concrete-filled steel tube piles (RSCFSTs), which have been widely used in harbors, bridges, and offshore wind turbines, were exposed to horizontal cyclic loading during service and suffered fatigue damage. For the RSCFSTs, longitudinal steel bars were welded to the inner wall of the steel tube to enhance the bonding strength of the steel tube and concrete core interface. It is essential to research the bearing performance of RSCFSTs like this, under horizontal cyclic loading. In this paper, cyclic loading tests of RSCFSTs under horizontal loading were carried out. The failure patterns of RSCFSTs during the destabilization process were generalized, and the lateral displacement development law of RSCFSTs was analyzed. The interfacial bonding characteristics between the steel tube and concrete core during the test were also discussed. Results showed that the horizontal bearing capacity of RSCFSTs decreases nonlinearly with the increase in the equal amplitude of load, and the development process of the lateral displacement-cycle number curve was divided into three phases: (I) rapid growth period, (II) fatigue growth period, and (III) sharp growth period. The larger the horizontal load was, the faster the lateral displacement entered the fatigue growth period. The duration of the rapid growth period and fatigue damage period accounts for about 90% of the total life of RSCFSTs. The stiffening form of the longitudinal steel bars welded to the inner wall of the steel tube can realize the synergistic force between the upper steel tube and the concrete core of RSCFSTs, which accounts for about 7/10 of the length of RSCFSTs. The depth of the steel tube, foundation stiffness, and bonding performance between the steel tube and the concrete core were the key factors that affected the horizontal bearing performance of RSCFSTs. Finally, some constructive suggestions are proposed for the design of RSCFSTs, including increasing steel tube embedded depth, adding a sniffer bar between the steel tube and concrete interface, etc. Full article

Karst landforms constitute one of the most harmful geological conditions, which have an adverse effect on the deep foundation structures of bridges. During earthquakes, the existence of karst caves can cause serious seismic damage to the bridge pile foundation. In order to investigate the seismic response of rock-socketed piles under vertical loads in complex karst cave conditions, finite element numerical simulation analyses were carried out, referring to the practical major bridge structure rock-socketed pile project in China. The peak strain distributions of rock-socketed pile foundation influenced by single-karst cave factors under the combined action of vertical loads and ground motions were investigated, and the influences of complex multi-caves were further explored. The results showed that the restraint effect of the bedrock near the pile would gradually decrease with the increase of the height of the karst cave and the decrease of the height of the karst cave roof; under the condition of a beaded karst cave, the constraint of bedrock between the karst caves makes the pile present the distribution characteristics of “multi-segment and multi-broken line”; under the condition of an underlying karst cave, the existence of the underlying karst cave would decrease the restraint of the bedrock at the bottom pile and increase the peak strain of the pile to a certain extent. This paper revealed the seismic response law of the rock-socketed pile under vertical loads within various complex karst cave conditions and developed reasonable reinforcement measures aiming at dangerous locations, providing important engineering guidance and a reference for the seismic design of rock-socketed pile foundation in complex karst areas. Full article

Rock–socketed pile under lateral loading is important in engineering practice. It is very significant to calculate the lateral bearing capacity of rock–socketed piles since few studies focus on this problem. The rock cohesion and instantaneous angle of friction, which have a high correlation with confining pressure, are obtained. Moreover, the strain wedge model is modified from three aspects: the assumption of nonlinear displacement; the stress level related to cohesion and friction angle; and the pile side resistance. Then, the modified strain wedge model is employed to deduce p–y criterion for rock–socketed pile considering Hoek–Brown failure criterion. The fourth-order partial differential equation constructed according to the p–y curve is solved by using the finite difference method. A numerical method with 2 m diameter rock-socketed pile is given to validate the rationality of the proposed method. It is shown that the proposed could predict the pile deformation well, and the responses are considered acceptable. Full article
