Search Results (16)

Search Parameters:
Keywords = resistive–capacitive voltage divider

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 2923 KiB
Article
Programmable Gain Amplifier with Programmable Bandwidth for Ultrasound Imaging Application
by István Kovács, Paul Coste and Marius Neag
Electronics 2025, 14(6), 1186; https://doi.org/10.3390/electronics14061186 - 18 Mar 2025
Viewed by 677
Abstract
This paper presents a low-power, fully differential, programmable gain amplifier (PGA) for ultrasound receiver analog front-ends (AFE). It consists of a programmable attenuator implemented by a capacitive voltage divider and a closed-loop amplifier based on a differential difference amplifier (DDA). A suitable sizing [...] Read more.
This paper presents a low-power, fully differential, programmable gain amplifier (PGA) for ultrasound receiver analog front-ends (AFE). It consists of a programmable attenuator implemented by a capacitive voltage divider and a closed-loop amplifier based on a differential difference amplifier (DDA). A suitable sizing strategy provides orthogonal control over gain and bandwidth. The PGA was designed using a standard 180 nm CMOS process. The gain value can be set between −18 dB and +20 dB in 2 dB steps; the bandwidth can be programmed independently of gain, to values from 5 MHz to 20 MHz, in 5 MHz steps; it draws 600 µA from a 1.8 V supply line. It achieves a differential output swing of 0.8 V peak-to-peak differential with no more than 1.7% total harmonic distortion (THD) and an input-referred noise density of 22 nV/√Hz at 10 MHz, measured at the gain of 20 dB. The PGA exhibits high input impedance and low output resistance for easy integration within the AFE signal chain. The digitally controlled gain and bandwidth make this PGA suitable for ultrasound imaging applications requiring precise time gain compensation and adjustable frequency response and/or additional anti-aliasing filtering. Full article
Show Figures

Figure 1

14 pages, 3597 KiB
Article
TCAD Simulation Study of Electrical Performance of a Novel High-Purity Germanium Drift Detector
by Mingyang Wang, Zheng Li, Bo Xiong and Yongguang Xiao
Micromachines 2025, 16(2), 229; https://doi.org/10.3390/mi16020229 - 17 Feb 2025
Cited by 2 | Viewed by 737
Abstract
High-purity germanium (HPGe) detectors occupy a prominent position in fields such as radiation detection and aerospace because of their excellent energy resolution and wide detection range. To achieve a broader detection range, conventional HPGe detectors often need to be expanded to cubic-centimeter-scale volumes. [...] Read more.
High-purity germanium (HPGe) detectors occupy a prominent position in fields such as radiation detection and aerospace because of their excellent energy resolution and wide detection range. To achieve a broader detection range, conventional HPGe detectors often need to be expanded to cubic-centimeter-scale volumes. However, this increase in volume leads to a large detector area, which in turn increases the detector capacitance, affecting the detector’s noise level and performance. To address this issue, this study proposes a novel high-purity germanium drift detector (HPGeDD). The design features a small-area central collecting cathode surrounded by concentric anode rings, with a resistive chain interposed between the anode rings to achieve self-dividing voltage. This design ensures that the detector’s capacitance is only related to the area of the central collecting cathode, independent of the overall active area, thus achieving a balance between a small capacitance and large active area. Electrical performance simulations of the novel detector were conducted using the semiconductor simulation software Sentaurus TCAD (P-2019.03). The results show a smooth electric potential distribution within the detector, forming a lateral electric field, as well as a lateral hole drift channel precisely directed toward the collecting cathode. Furthermore, simulations of heavy ion incidence were performed to investigate the detector’s carrier collection characteristics. The simulation results demonstrate that the HPGeDD exhibits advantages such as fast signal response and short collection time. The design proposal presented in this study offers a new solution to the problem of excessive capacitance in conventional HPGe detectors, expands their application scope, and provides theoretical guidance for subsequent improvements, optimizations, and practical manufacturing. Full article
(This article belongs to the Special Issue Photonic and Optoelectronic Devices and Systems, Third Edition)
Show Figures

Figure 1

14 pages, 3048 KiB
Article
Intelligent Insulation Testing and Optimization Based on Machine Learning
by Sichen Liu, Guowen Zhao and Huixin Zhang
Electronics 2025, 14(1), 109; https://doi.org/10.3390/electronics14010109 - 30 Dec 2024
Viewed by 851
Abstract
To address the demand for high-precision insulation testing in modern complex cable networks, this study proposes and implements an intelligent insulation testing system based on FPGA technology. The system integrates decision tree (DT) models to enable efficient anomaly detection and process optimization. Utilizing [...] Read more.
To address the demand for high-precision insulation testing in modern complex cable networks, this study proposes and implements an intelligent insulation testing system based on FPGA technology. The system integrates decision tree (DT) models to enable efficient anomaly detection and process optimization. Utilizing the voltage-divider principle for insulation testing, the system extracts features such as maximum values, minimum values, and entropy to construct an explainable classification model capable of accurately monitoring different types of currents (leakage, absorption, and capacitive currents) during their decay processes. An adaptive post-processing filtering method is introduced to enhance classification accuracy and optimize testing efficiency by minimizing redundant range switching. Experimental results demonstrate that the proposed system achieves exceptional recognition accuracy and process stability across a wide range of resistances, significantly advancing the intelligence of insulation testing while improving measurement efficiency by 54.71%. This innovative solution provides a robust approach for high-demand electrical performance assessments. Full article
Show Figures

Figure 1

17 pages, 6898 KiB
Article
Research on Ultra-Fast Transient Overvoltage Characteristics of Electric Locomotive
by Yike Guo, Fuqiang Tian, Hongqi Liu and Yufeng Yin
Appl. Sci. 2024, 14(20), 9561; https://doi.org/10.3390/app14209561 - 19 Oct 2024
Cited by 3 | Viewed by 1489
Abstract
Operating overvoltage occurs when the pantograph or main breaker of an electric locomotive is operated, which is prone to causing insulation failure of high-voltage equipment. The HXD1 electric locomotive is taken as the research object in this paper to explore the [...] Read more.
Operating overvoltage occurs when the pantograph or main breaker of an electric locomotive is operated, which is prone to causing insulation failure of high-voltage equipment. The HXD1 electric locomotive is taken as the research object in this paper to explore the characteristics and influencing factors of operating overvoltage. Under pantograph lifting, main breaker closing, main breaker opening, and pantograph dropping, operating overvoltage waveform in the high-voltage system is recorded by a high-speed oscilloscope and resistance–capacitance voltage divider to analyze the overvoltage characteristics and distribution law. Tested data show that the amplitude of operating overvoltage is in the range of 80 to 330 kV with ultra-high steepness, which is similar to the Very Fast Transient Overvoltage (VFTO) in power systems. The maximum overvoltage during the entire test occurred during the main breaker closing and its amplitude is 328.60 kV with a steepness of 4.21 × 104 kV/μs. The max overvoltage of the other operations (pantograph lifting, main breaker opening, and pantograph dropping) are 280.60 kV, 194.73 kV, and 305.56 kV with ultra-high steepness. High-amplitude overvoltage is predominantly located at the pantograph, while the low-amplitude sort is mainly observed around other high-voltage equipment. The result indicates that operating overvoltage belongs to ultra-fast transient overvoltage and its amplitude and steepness are higher than existing research. Full article
Show Figures

Figure 1

13 pages, 2247 KiB
Article
Calibration Method of a Wideband AC Resistance Voltage Divider Based on an Equivalent Model
by Bo Li, Yanping He, Lei Wang, Min Cao, Zhihong Fu and Huiyuan Zhang
Sensors 2023, 23(16), 7181; https://doi.org/10.3390/s23167181 - 15 Aug 2023
Cited by 3 | Viewed by 1953
Abstract
Aiming at the problem of large measurement error and phase shift in resistance voltage dividers under high-frequency conditions in the field of power measurement, such as power harmonics, an error correction method is proposed for an alternating current (AC) resistance voltage divider based [...] Read more.
Aiming at the problem of large measurement error and phase shift in resistance voltage dividers under high-frequency conditions in the field of power measurement, such as power harmonics, an error correction method is proposed for an alternating current (AC) resistance voltage divider based on the equivalence principle. Firstly, the frequency error model of the AC resistance voltage divider precision is established, and the angle difference of the continuous spectrum ratio difference from 50 Hz to 100 kHz is corrected by determining the shielding structure and the resistance parameters and fine-tuning the shielding potential correction method to reduce the capacities error of the AC resistance voltage divider design precision. At the same time, the performance parameters such as the direction and magnitude of the shielding potential compensation capacitive error are investigated. Finally, the precision voltage divider (the maximum voltage applied is 480 V) calibration experiments verify that the important characteristic judgment factor of the voltage divider is independent of the frequency and the equivalent capacitance value, which effectively solves the phase correction problem of harmonic power measurement. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

13 pages, 12206 KiB
Article
Design, Implementation, and Characterization of a Compact Lock-in Add-on for Low-Frequency Impedance Measurements
by Sara Pettinato, Armando Piccardi, Maria Cristina Rossi and Stefano Salvatori
Electronics 2023, 12(16), 3406; https://doi.org/10.3390/electronics12163406 - 10 Aug 2023
Cited by 1 | Viewed by 2304
Abstract
Impedance measurements are crucial in a variety of applications, from the characterization of lithium batteries, microbial fuel cells, and biosensors to the study of polymers and material degradation, where strict requirements have to be met in terms of frequency bandwidth and current level. [...] Read more.
Impedance measurements are crucial in a variety of applications, from the characterization of lithium batteries, microbial fuel cells, and biosensors to the study of polymers and material degradation, where strict requirements have to be met in terms of frequency bandwidth and current level. Here, we present a cost-effective compact solution for ultra-low-frequency impedance measurements, operating in a wide range, from 1 mHz to 250 kHz. Coupled to a lock-in amplifier, the designed circuit is based on a Howland current pump cascaded by a precision current divider in order to set the conversion factor at 100 nA/V, 1 μA/V, or 100 μA/V. Therefore, it is possible to generate very low-current signals to measure resistive impedances up to 100 MΩ. In addition, a feedback network is inserted to null the voltage drift induced by leakage currents and offset voltages, thus allowing the measurement of low-capacitance loads, experimentally tested down to 10 nF. Remarkably, the feedback network allows to perform measurements also in the presence of high voltage bias of the load and experimental results performed up to 60 V demonstrate the excellent stability of the designed system, thus a high voltage compliance. The proposed circuit is particularly interesting for the conditioning of both resistive and capacitive sensors and it is likely to be an effective solution for the implementation of a portable instrument for measuring signals from biosensors. Full article
Show Figures

Graphical abstract

13 pages, 2777 KiB
Communication
First Review of Conductive Electrets for Low-Power Electronics
by D. D. L. Chung
J. Low Power Electron. Appl. 2023, 13(2), 25; https://doi.org/10.3390/jlpea13020025 - 6 Apr 2023
Cited by 1 | Viewed by 2739
Abstract
This is the first review of conductive electrets (unpoled carbons and metals), which provide a new avenue for low-power electronics. The electret provides low DC voltage (μV) while allowing low DC current (μA) to pass through. Ohm’s Law is obeyed. The voltage scales [...] Read more.
This is the first review of conductive electrets (unpoled carbons and metals), which provide a new avenue for low-power electronics. The electret provides low DC voltage (μV) while allowing low DC current (μA) to pass through. Ohm’s Law is obeyed. The voltage scales with the inter-electrode distance. Series connection of multiple electret components provides a series voltage that equals the sum of the voltages of the components if there is no bending at the connection between the components. Otherwise, the series voltage is below the sum. Bending within the component also diminishes the voltage because of the polarization continuity decrease. The electret originates from the interaction of a tiny fraction of the carriers with the atoms. This interaction results in the charge in the electret. Dividing the electret charge by the electret voltage V’ provides the electret-based capacitance C’, which is higher than the permittivity-based capacitance (conventional) by a large number of orders of magnitude. The C’ governs the electret energy (1/2 CV2) and electret discharge time constant (RC’, where R = resistance), as shown for metals. The discharge time is promoted by a larger inter-electrode distance. The electret discharges occur upon short-circuiting and charge back upon subsequent opencircuiting. The discharge or charge of the electret amounts to the discharge or charge of C’. Full article
Show Figures

Figure 1

14 pages, 5772 KiB
Article
A Novel 4H-SiC Double Trench MOSFET with Built-In MOS Channel Diode for Improved Switching Performance
by Jaeyeop Na and Kwangsoo Kim
Electronics 2023, 12(1), 92; https://doi.org/10.3390/electronics12010092 - 26 Dec 2022
Cited by 6 | Viewed by 4130
Abstract
This study proposed a novel 4H-SiC double trench metal-oxide-semiconductor field-effect-transistor (DTMCD-MOSFET) structure with a built-in MOS channel diode. Further, its characteristics were analyzed using TCAD simulation. The DTMCD-MOSFET comprised active and dummy gates that were divided horizontally; the channel diode operated through the [...] Read more.
This study proposed a novel 4H-SiC double trench metal-oxide-semiconductor field-effect-transistor (DTMCD-MOSFET) structure with a built-in MOS channel diode. Further, its characteristics were analyzed using TCAD simulation. The DTMCD-MOSFET comprised active and dummy gates that were divided horizontally; the channel diode operated through the dummy gate and the p-base and N+ source regions at the bottom of the dummy gate. Because the bult-in channel diode was positioned at the bottom, the DTMCD-MOSEFT minimized static deterioration. Despite having a 5.2% higher specific on-resistance (Ron-sp) than a double-trench MOSFET (DT-MOSFET), the DTMCD-MOSFET exhibited a significantly superior body diode and switching properties. In comparison to the DT-MOSFET, its turn-on voltage (VF) and reverse recovery charge (Qrr) were decreased by 27.2 and 30.2%, respectively, and the parasitic gate-drain capacitance (Crss) was improved by 89.4%. Thus, compared with the DT-MOSFET, the total switching energy loss (Etot) was reduced by 41.4%. Full article
(This article belongs to the Special Issue Wide Bandgap Semiconductor: From Epilayer to Devices)
Show Figures

Figure 1

25 pages, 9842 KiB
Article
Resistive High-Voltage Probe with Frequency Compensation by Planar Compensation Electrode Integrated in Printed Circuit Board Design
by Jonas Winkelholz, Moritz Hitzemann, Alexander Nitschke, Anne Zygmanowski and Stefan Zimmermann
Electronics 2022, 11(21), 3446; https://doi.org/10.3390/electronics11213446 - 25 Oct 2022
Cited by 8 | Viewed by 5009
Abstract
Resistive voltage dividers tend to have a highly non-linear transfer function as parasitic and stray capacitances exert an increasing influence with increasing frequency. The non-linear transfer function depends on the topology and resistors used and consists of a low-pass filter with an additional [...] Read more.
Resistive voltage dividers tend to have a highly non-linear transfer function as parasitic and stray capacitances exert an increasing influence with increasing frequency. The non-linear transfer function depends on the topology and resistors used and consists of a low-pass filter with an additional high-pass component in the GHz range. Due to the non-linear transfer function the measured signal differs from the original input signal. Here, we present an improved resistive voltage divider with additional compensation capacities to extend the linear bandwidth. With this new concept, the linear bandwidth is improved from 115 kHz to 88 MHz, while maintaining a DC input impedance of 10 MΩ. For high-voltage insulation and easy manufacturing, surface mounted resistors on a printed circuit board with a compensation electrode on the adjacent side are used. The performance of this resistive voltage divider is demonstrated by measuring a series of high-voltage pulses with an amplitude of 2.5 kVpeak-peak. The measured pulse rise time is about 16 ns, corresponding to an average slew-rate of 150 V/ns. Finally, the developed resistive voltage divider is successfully used to measure fast high-voltage transients required for advanced ion mobility spectrometers with integrated collision induced fragmentation. Full article
(This article belongs to the Topic High Voltage Engineering)
Show Figures

Figure 1

14 pages, 5072 KiB
Article
Development of Broadband Resistive–Capacitive Parallel–Connection Voltage Divider for Transient Voltage Monitoring
by Shijun Xie, Zhou Mu, Weidong Ding, Zhenbo Wan, Shaochun Su, Chenmeng Zhang, Yu Zhang, Yalong Xia and Donghui Luo
Energies 2022, 15(2), 451; https://doi.org/10.3390/en15020451 - 10 Jan 2022
Cited by 10 | Viewed by 2487
Abstract
The on-site measurement of transient voltages is of great significance in analyzing the fault cause of power systems and optimizing the insulation coordination of power equipment. Conventional voltage transformers normally have a narrow bandwidth and are unable to accurately measure various transient voltages [...] Read more.
The on-site measurement of transient voltages is of great significance in analyzing the fault cause of power systems and optimizing the insulation coordination of power equipment. Conventional voltage transformers normally have a narrow bandwidth and are unable to accurately measure various transient voltages in power systems. In this paper, a wideband parallel resistive–capacitive voltage divider is developed, which can be used for online monitoring of transient voltages in a 220 kV power grid. The structures of the high-voltage and low-voltage arms were designed. The internal electric field distribution of the high-voltage arm was analyzed. The influence factors and improvement techniques of the upper frequency limit were studied. The parameters of the elements of the divider were determined. The voltage withstand performances and scale factors under lightning impulses and AC and DC voltages, the temperature stabilities of scale factors and the step response and bandwidth of the developed voltage divider were tested. The results show that the deviations of the scale factors under various voltage waveforms and different temperatures ranging from −20 to 40 °C are within 3%. The withstand voltage meets the relevant requirements specified in IEC60071-1-2011. The step response 10~90% rise time is approximately 29 ns, and the 3 dB bandwidth covers the range of DC to 10 MHz. Full article
Show Figures

Figure 1

12 pages, 2793 KiB
Article
Method to Evaluate the Resistance–Capacitance Voltage Divider and Uncertainty Analysis
by Yi Luo, Bin Guo, Bin Qian, Lijuan Xu, Fan Zhang, Fusheng Li and Xingxing Feng
Energies 2021, 14(22), 7744; https://doi.org/10.3390/en14227744 - 18 Nov 2021
Cited by 1 | Viewed by 2676
Abstract
The resistance and capacitance parameters of a resistance–capacitance divider may change due to factors such as long-term operation, internal insulation flashover, and dielectric breakdown, which will affect the measurement characteristics of the resistance–capacitance divider. Since it is difficult to separate the voltage divider, [...] Read more.
The resistance and capacitance parameters of a resistance–capacitance divider may change due to factors such as long-term operation, internal insulation flashover, and dielectric breakdown, which will affect the measurement characteristics of the resistance–capacitance divider. Since it is difficult to separate the voltage divider, and because improper disassembly will damage the insulation of the equipment, measuring the resistance and capacitance parameters of a voltage divider non-destructively has always been a problem. In this paper, an indirect method for evaluating the resistance and capacitance parameters is proposed, and the uncertainty of measurement of this method is determined. Simulation and actual test results show that this method can be used to estimate the resistance–capacitance parameters and has a good level of measurement accuracy. Besides, through the uncertainty analysis, it is concluded that the proposed method can overcome measurement errors within a certain range and has high practicability. Finally, a very practical application scenario of the proposed method is given, showing that the proposed method has good economic significance. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Graphical abstract

21 pages, 11706 KiB
Article
Novel Stable Capacitive Electrocardiogram Measurement System
by Chi-Chun Chen, Shu-Yu Lin and Wen-Ying Chang
Sensors 2021, 21(11), 3668; https://doi.org/10.3390/s21113668 - 25 May 2021
Cited by 11 | Viewed by 5296
Abstract
This study presents a noncontact electrocardiogram (ECG) measurement system to replace conventional ECG electrode pads during ECG measurement. The proposed noncontact electrode design comprises a surface guard ring, the optimal input resistance, a ground guard ring, and an optimal voltage divider feedback. The [...] Read more.
This study presents a noncontact electrocardiogram (ECG) measurement system to replace conventional ECG electrode pads during ECG measurement. The proposed noncontact electrode design comprises a surface guard ring, the optimal input resistance, a ground guard ring, and an optimal voltage divider feedback. The surface and ground guard rings are used to reduce environmental noise. The optimal input resistor mitigates distortion caused by the input bias current, and the optimal voltage divider feedback increases the gain. Simulated gain analysis was subsequently performed to determine the most suitable parameters for the design, and the system was combined with a capacitive driven right leg circuit to reduce common-mode interference. The present study simulated actual environments in which interference is present in capacitive ECG signal measurement. Both in the case of environmental interference and motion artifact interference, relative to capacitive ECG electrodes, the proposed electrodes measured ECG signals with greater stability. In terms of R–R intervals, the measured ECG signals exhibited a 98.6% similarity to ECGs measured using contact ECG systems. The proposed noncontact ECG measurement system based on capacitive sensing is applicable for use in everyday life. Full article
(This article belongs to the Special Issue Advances in ECG Sensing and Monitoring)
Show Figures

Figure 1

21 pages, 8289 KiB
Article
Series Arc Fault Detection Method Based on Category Recognition and Artificial Neural Network
by Xiangyu Han, Dingkang Li, Lizong Huang, Hanqing Huang, Jin Yang, Yilei Zhang, Xuewei Wu and Qiwei Lu
Electronics 2020, 9(9), 1367; https://doi.org/10.3390/electronics9091367 - 23 Aug 2020
Cited by 31 | Viewed by 4463
Abstract
The influence of a series arc on line current is different with different loads, which makes it difficult to accurately extract arc fault characteristics suitable for all loads according to line current signal. To improve the accuracy of arc fault detection, a series [...] Read more.
The influence of a series arc on line current is different with different loads, which makes it difficult to accurately extract arc fault characteristics suitable for all loads according to line current signal. To improve the accuracy of arc fault detection, a series arc fault detection method based on category recognition and an artificial neural network is proposed on the basis of analyzing the current characteristics of arc faults under different loads. According to the waveform of current and voltage, the load is divided into three types: Resistive category (Re), resistive-inductive category (RI), and rectifying circuit with a capacitive filter category (RCCF). Based on the wavelet transform, the characteristics of line current in the time domain and frequency domain when the series arc occurs under different types of loads are analyzed, and then the time and frequency indicators are taken as the inputs of the artificial neural network to establish three-layer neural networks corresponding to three types of loads to realize the detection of the series arc fault of lines under different categories of loads. To avoid the neural network falling into a local optimum, the initial weight and threshold of the neural network are optimized by a genetic algorithm, which further improves the accuracy of the neural network in arc identification. The experimental results show that the proposed arc detection method has the advantages of high recognition rate and a simple neural network model. Full article
(This article belongs to the Section Power Electronics)
Show Figures

Figure 1

16 pages, 6125 KiB
Article
Analysis and Mitigation of Stray Capacitance Effects in Resistive High-Voltage Dividers
by Jordi-Roger Riba, Francesca Capelli and Manuel Moreno-Eguilaz
Energies 2019, 12(12), 2278; https://doi.org/10.3390/en12122278 - 14 Jun 2019
Cited by 11 | Viewed by 5003
Abstract
This work analyzes the effects of the parasitic or stray distributed capacitance to ground in high-voltage environments and assesses the effectiveness of different corrective actions to minimize such effects. To this end, the stray capacitance of a 130 kV RMS high-voltage resistive divider [...] Read more.
This work analyzes the effects of the parasitic or stray distributed capacitance to ground in high-voltage environments and assesses the effectiveness of different corrective actions to minimize such effects. To this end, the stray capacitance of a 130 kV RMS high-voltage resistive divider is studied because it can severely influence the behavior of such devices when operating under alternating current or transient conditions. The stray capacitance is calculated by means of three-dimensional finite element analysis (FEA) simulations. Different laboratory experiments under direct current (DC) and alternating current (AC) supply are conducted to corroborate the theoretical findings, and different possibilities to mitigate stray capacitance effects are analyzed and discussed. The effects of the capacitance are important in applications, such as large electrical machines including transformers, motors, and generators or in high-voltage applications involving voltage dividers, conductors or insulator strings, among others. The paper also proves the usefulness of FEA simulations in predicting the stray capacitance, since they can deal with a wide range of configurations and allow determining the effectiveness of different corrective configurations. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1

16 pages, 2728 KiB
Article
Research on Electronic Voltage Transformer for Big Data Background
by Zhen-Hua Li, Yao Wang, Zheng-Tian Wu and Zhen-Xing Li
Symmetry 2018, 10(7), 234; https://doi.org/10.3390/sym10070234 - 21 Jun 2018
Cited by 29 | Viewed by 4199
Abstract
A new type of electronic voltage transformer is proposed in this study for big data background. By using the conventional inverted SF_6 transformer insulation structure, a coaxial capacitor sensor was constructed by designing a middle coaxial electrode between the high-voltage electrode and the [...] Read more.
A new type of electronic voltage transformer is proposed in this study for big data background. By using the conventional inverted SF_6 transformer insulation structure, a coaxial capacitor sensor was constructed by designing a middle coaxial electrode between the high-voltage electrode and the ground electrode. The measurement of the voltage signal could be obtained by detecting the capacitance current i of the SF_6 coaxial capacitor. To improve the accuracy of the integrator, a high-precision digital integrator based on the Romberg algorithm is proposed in this study. This can not only guarantee the accuracy of computation, but also reduce the consumption time; in addition, the sampling point can be reused. By adopting the double shielding effect of the high-voltage shell and the grounding metal shield, the ability and stability of the coaxial capacitor divide could be effectively improved to resist the interference of stray electric fields. The factors that affect the coaxial capacitor were studied, such as position, temperature, and pressure, which will influence the value of the coaxial capacitor. Tests were carried out to verify the performance. The results showed that the voltage transformer based on the SF_6 coaxial capacitor satisfies the requirements of the 0.2 accuracy class. This study can promote the use of new high-performance products for data transmission in the era of big data and specific test analyses. Full article
(This article belongs to the Special Issue Emerging Approaches and Advances in Big Data)
Show Figures

Figure 1
