Bridges play a key and controlling role in transportation systems. Steel bridges are favored for their high strength, good seismic performance, and convenient construction. As important node connectors of steel bridges, high-strength bolts are extremely susceptible to damage such as corrosion and loosening. Therefore, accurate identification of bolt loosening is crucial. First, a new type of adhesive piezoelectric sensor is designed and prepared using PMN-PT piezoelectric single-crystal materials. The PMN-PT sensor and polyvinylidene fluoride (PVDF) sensor are subjected to steel plate fixed frequency load and swept frequency load tests to test the performance of the two sensors. Then, a steel plate component connected by high-strength bolts is designed. By applying exciter square wave load to the structure, the vibration response characteristics of the structure are analyzed to identify the loosening of the bolts. In addition, a piezoelectric smart washer sensor is designed to make up for the shortcomings of the adhesive piezoelectric sensor, and the effectiveness of the piezoelectric smart washer sensor is verified. Finally, a bolt loosening index is proposed to quantitatively evaluate the looseness of the bolt. The results show that the sensitivity of the PMN-PT sensor is 21 times that of the PVDF sensor. Compared with the peak stress change, the natural frequency change is used to identify the bolt loosening more effectively. Piezoelectric smart washer sensor and bolt loosening indicator can be used for bolt loosening identification. Full article

For relaxor ferroelectric single crystal (1 − x)Pb(Mg_1/3Nb_2/3)O₃ − xPbTiO₃ (PMN-PT), through reasonable component regulation and electric field polarization, an orthogonal mm² point group structure can be obtained, which has high piezoelectric constants and is, therefore, a desired substrate material for lateral-field-excited (LFE) bulk acoustic wave (BAW) devices. In this work, acoustic wave resonance characteristics of (zxt) 45° PMN-PT BAW devices with LFE are investigated. Firstly, Mindlin first-order plate theory is used to obtain vibration governing equations of orthorhombic crystals excited by a lateral electric field. By analyzing the electrically forced vibrations of the finite plate, the basic vibration characteristics, such as motional capacitance, resonant frequency, and mode shape are obtained, and influences of different electrode parameters on resonance characteristics of the device are investigated. In addition, the effects of the structure parameters on the mass sensitivity of the devices are analyzed and further verified by FEM simulations. The model presented in this study can be conveniently used to optimize the structural parameters of LFE bulk acoustic wave devices based on orthorhombic crystals, which is crucial to obtain good resonance characteristics. The results provide an important basis for the design of LFE bulk acoustic wave resonators and sensors by using PMN-PT orthorhombic crystals. Full article

Rare earth element (Sm)-doped potassium sodium niobate (KNN)-based ceramics are fabricated using spark plasma sintering method and their properties are investigated. The results show that all the samples crystallize in a typical perovskite structure with a single orthorhombic phase. With increasing the Sm doping, the ceramics gradually shift toward the relaxor ferroelectric state and the value of dielectric loss angle tangent (tanδ) is smaller than 0.05 for x ≤ 0.003 ceramic samples. Meanwhile, the optimized piezoelectric charge coefficient d₃₃ = 128 pC/N, and piezoelectric voltage coefficient g₃₃ = 18.9 × 10⁻³ Vm/N are obtained when x = 0.001. Compared with the undoped sample, the d₃₃ of x = 0.001 ceramics has been significantly enhanced by 28%. The positron annihilation lifetime results indicate that the main defect types in the ceramics are the A-site vacancies and defect dipoles. Based on the aforementioned results, the optimized piezoelectric performance and the lowest defect dipoles concentration in x = 0.001, may be attributed to the low internal oxygen vacancy concentration in it. This work may provide insights for the further study of KNN-based piezoelectric ceramics. Full article

[011] poled relaxor-PT single crystals provide superior piezoelectric constants and electromechanical coupling factors in the 32 crystal directions, and also exhibit high electrical stability under compressive stresses and temperature changes. In particular, Mn-doped Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ (Mn:PIN-PMN-PT) single crystals show a superior coercive field (E_C ≥ 8.0 kV/cm) and mechanical quality factor (Q_m ≥ 1030), making them suitable for high-power transducers. The high-power characteristics of [011] poled single crystals have been verified from a material perspective; thus, further investigation is required from a transducer perspective. In this study, the high-power characteristics of piezoelectric transducers based on [011] poled PIN-PMN-PT and [011] poled Mn:PIN-PMN-PT single crystals were investigated. To analyze the driving limits of the single crystals, the polarization–electric field (P–E) curves, as a function of the driving electric field, were measured. The results showed that [011] poled Mn:PIN-PMN-PT single crystals demonstrate lower energy loss and THD (Total Harmonic Distortion), directly relating to the driving efficiency and linearity of the transducer. Additionally, [011] poled Mn:PIN-PMN-PT crystals provide excellent stability under the compressive stress and temperature changes. To analyze the high-power characteristics of [011] poled single-crystal transducers, two types of barrel-stave transducers, based on [011] poled PIN-PMN-PT and [011] poled Mn:PIN-PMN-PT, were designed and fabricated. The changes in the impedance and transmitting voltage response with respect to the driving electric fields were measured, and the energy loss and THD of the transducers with respect to the driving electric fields were examined to assess the driving limit of the [011] poled single-crystal transducer. The high-power characteristic tests confirmed the stability of [011] poled Mn:PIN-PMN-PT single crystals and verified their potential for high-power transducer applications. Full article

In recent years, the development of environmentally friendly, lead-free ferroelectric films with prominent electrostrictive effects have been a key area of focus due to their potential applications in micro-actuators, sensors, and transducers for advanced microelectromechanical systems (MEMS). This work investigated the enhanced electrostrictive effect in lead-free sodium bismuth titanate-based relaxor ferroelectric films. The films, composed of (Bi_0.5Na_0.5)_0.8−xBa_xSr_0.2TiO₃ (BNBST, x = 0.02, 0.06, and 0.11), with thickness around 1 μm, were prepared using a sol-gel method on Pt/TiO₂/SiO₂/Si substrates. By varying the Ba²⁺ content, the crystal structure, morphology, and electrical properties, including dielectric, ferroelectric, strain, and electromechanical performance, were investigated. The films exhibited a single pseudocubic structure without preferred orientation. A remarkable strain response (S > 0.24%) was obtained in the films (x = 0.02, 0.06) with the coexistence of nonergodic and ergodic relaxor phases. Further, in the x = 0.11 thick films with an ergodic relaxor state, an ultrahigh electrostrictive coefficient Q of 0.32 m⁴/C² was achieved. These findings highlight the potential of BNBST films as high-performance, environmentally friendly electrostrictive films for advanced microelectromechanical systems (MEMS) and electronic devices. Full article

The versatile electrocaloric (EC) behaviors of the (1-x)Pb(Mg_1/3Nb_2/3)O₃-xPT (PMN-100xPT) single crystal are closely related to the multiple phase transitions under the multiple fields of electric field and temperature. In this work, the EC effect of <001>-oriented PMN-30PT single crystals with chemical composition at morphotropic phase boundary has been studied during the phase transformation process from the ferroelectric rhombohedral (R) phase to the tetragonal (T) phase. Two consecutive negative EC peaks have been achieved for the first time. Based on the projection of the EC effect in the electric field-temperature phase diagram, the relationship between the EC behaviors and the phase transitions is further established. It was found that the monoclinic (M) phase actually existed during the transformation from the R phase to the T phase, and the related R-M phase transition and M-T phase transition could both induce negative EC peaks. Under the electric field of E = 10 kV/cm, the first negative EC peaks induced by the R-M phase transition is at 57 °C with ΔT_max = −0.11 K. And the M-T phase transition can produce a higher negative EC peak, and its value can reach −0.22 K at 68 °C. Based on thermodynamic calculations, the relationship between the entropy change in different phase transitions and the EC behaviors has been further elucidated. The negative EC effect originates from the structural entropy increase in the electric field-induced phase transition process. This work not only advances the research on the electrical properties of relaxor ferroelectric single crystals but also provides a new insight into high-performance ferroelectric materials design. Full article

Relaxor ferroelectrics play a vital role as functional components in electromechanical devices. The observation of micro-scale domain structure evolution under electric bias in relaxor ferroelectrics has posed challenges due to their complex domain morphology characterized by small-sized domains. The present study aims to investigate the dielectric diffusion–relaxation characteristics, domain structure, and domain switching evolution under electric bias in high-performance single crystals of Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-33PbTiO₃. The findings reveal the presence of strip-like domain patterns that interlock irregular small-sized nanodomains in PIN-PMN-33PT single crystals. Furthermore, the sample undergoes three distinct stages under electric bias, including the nucleation of new domains, the gradual forward expansion of domains, and the lateral expansion of domains. These observations provide valuable insights for understanding and exploring domain engineering techniques in relaxor ferroelectrics. Full article

The relaxor ferroelectric single crystal (1−x)Pb(Mg_1/3Nb_2/3)O₃-xPbTiO₃ (PMN-PT) has high piezoelectric constants, and thus has a good application prospect in the field of highly sensitive piezoelectric sensors. In this paper, for relaxor ferroelectric single crystal PMN-PT, the bulk acoustic wave characteristics on pure- and pseudo-lateral-field-excitation (pure- and pseudo-LFE) modes are investigated. LFE piezoelectric coupling coefficients and acoustic wave phase velocities for PMN-PT crystals in different cuts and electric field directions are calculated. On this basis, the optimal cuts of pure-LFE and pseudo-LFE modes of relaxor ferroelectric single crystal PMN-PT are obtained, namely, (zxt)45° and (zxtl)90°/90°, respectively. Finally, finite element simulations are carried out to verify the cuts of pure-LFE and pseudo-LFE modes. The simulation results show that the PMN-PT acoustic wave devices in pure-LFE mode have good energy-trapping effects. For PMN-PT acoustic wave devices in pseudo-LFE mode, when the device is in air, no obvious energy-trapping emerges; when the water (as a virtual electrode) is added to the surface of the crystal plate, an obvious resonance peak and the energy-trapping effect appears. Therefore, the PMN-PT pure-LFE device is suitable for gas-phase detections. While the PMN-PT pseudo-LFE device is suitable for liquid-phase detections. The above results verify the correctness of the cuts of the two modes. The research results provide an important basis for the development of highly sensitive LFE piezoelectric sensors based on relaxor ferroelectric single crystal PMN-PT. Full article

Uniaxial ferroelectrics with tetragonal tungsten bronze structure are important functional materials with photorefractive, electrooptic, piezoelectric, and pyroelectric properties. Sr_xBa_1−xNb₂O₆ (SBN100x) with x > 50 is known as a typical uniaxial relaxor ferroelectric, while Ca_xBa_1−xNb₂O₆ (CBN100x) undergoes nearly normal ferroelectric phase transitions. Single crystals of CSBN100x = [x(CBN28) + (1 − x) (SBN61)] = xCa_0.28Ba_0.72Nb₂O₆ + (1 − x) Sr_0.61Ba_0.39Nb₂O₆ with nominal x = 0.00, 0.25, 0.50, 0.75, and 1.00 were studied to clarify the dynamical properties at the crossover from relaxor (x = 0) to normal (x = 1) ferroelectric behavior. The longitudinal acoustic (LA) and transverse acoustic (TA) modes and a central peak (CP) related to the relaxation process of polarization fluctuations along the polar c-axis were studied in uniaxial ferroelectric CSBN single crystals as a function of temperature via Brillouin scattering spectroscopy. A CBN28 (x = 1.00) crystal shows the sharp elastic anomaly of the LA mode in the gigahertz range toward Curie temperature, T_c. However, those of CSBN25 (x = 0.25) and SBN61 (x = 0.00) crystals show diffusive anomalies due to stronger random fields. The relaxation time determined from the width of a CP shows a critical slowing down in the vicinity of T_c. The elastic anomaly and slowing down of relaxation time of CSBN100x crystals become diffusive in the vicinity of T_c as the CBN28 content decreases. The origin of the crossover from relaxor to normal ferroelectric phase transitions is discussed in terms of the difference in the A1 and A2 sites’ occupancies. Full article

Numerous investigations on the development of the relaxor-PbTiO₃ ferroelectric crystals have been carried out since their extraordinary properties were revealed. Recent developments on these crystals have offered further advances in electromechanical applications. In this review, recent developments on relaxor-PbTiO₃ crystals and their practical applications are reviewed. The single crystal growth methods are first discussed. Two different strategies, poling and doping, for piezoelectric improvement are surveyed in the following section. After this, the anisotropic features of the single crystals are discussed. Application perspectives arising from the property improvements for electromechanical devices are finally reviewed. Full article

Lead-containing relaxor ferroelectrics show enormous piezoelectric capabilities relating to their heterogeneous structures. Time-resolved nanobeam X-ray diffraction reveals the time and position dependences of the local lattice strain on a relaxor ferroelectric single crystal mechanically vibrating and alternately switching, as well as its polarization under an alternating electric field. The complicated time and position dependences of the Bragg intensity distributions under an alternating electric field demonstrate that nanodomains with the various lattice constants and orientations exhibiting different electric field responses exist in the measured local area, as the translation symmetry breaks to the microscale. The dynamic motion of nanodomains in the heterogeneous structure, with widely distributed local lattice strain, enables enormous piezoelectric lattice strain and fatigue-free ferroelectric polarization switching. Full article

This study investigated the optical properties and the interband transition of a ternary [100]-oriented 6PSN-61PMN-33PT relaxor ferroelectric single crystal. Compared with the binary [100]-oriented PMN-32PT crystal, the [100]-oriented 6PSN-61PMN-33PT crystal exhibited excellent optical properties, including high transmittance, low refractive index, weak frequency dispersion, and low reflection and absorption coefficients. All these differences can be attributed to the structural changes of the 6PSN-61PMN-33PT crystal, such as its large lattice size and increased band gap. The crystal’s transmittance was significantly improved after alternating current electric field poling due to the increased domain size and the order domain structure. The largest transmittance for the 6PSN-61PMN-33PT crystal was up to 66%. Our experimental results indicate that the ternary 6PSN-61PMN-33PT ferroelectric single crystal has great application potential in the optical field. Full article

A relaxor-based ferroelectric single crystal with the nominal composition of xPb(Sm_0.5Nb_0.5)O₃-(0.7‒x) Pb(Mg_1/3Nb_1/3)O₃-0.3PbTiO₃ (x = 0.01, 0.02, and 0.03) was grown by the vertical Bridgman process. The electrical properties and the ferroelectric domains, as well as the luminescent characteristics of the single crystals, were investigated systematically. The piezoelectric coefficient d₃₃ of the single crystals are slightly higher than that of the undoped PMN-PT single crystal under direct current polarization, while the crystal wafers gain a much higher d₃₃ value upon being polarized with alternating current voltage. The single crystals possess a decreased phase transition temperature of around 60 °C and a decreased Curie temperature of 92~116 °C compared with the undoped PMN-PT single crystal. The crystal wafers polarized with alternating current voltage exhibited a desirable optical transmittance, which is associated with the domain structure changes inside the crystal medium. The domain density of the crystal wafers under alternating current polarization was significantly decreased compared with the direct current polarized crystal wafers. The luminescent spectra of the crystal wafers exhibit the typical emission peaks corresponding to the characteristic transition of Sm³⁺ ions in the crystal lattice. Full article

The evolution of the domain structures of [001]-oriented relaxor ferroelectric 0.93PbZn_1/3Nb_2/3O₃-0.07PbTiO₃ (PZN-7%PT) single crystals as a function of temperature was investigated in situ by using piezoresponse force microscopy (PFM). It was found that the local domain structure of PZN-7%PT single crystals at room temperature is rhombohedral with nanoscale twins. Temperature-dependent domain structures showed that the phase transition process is a collective process and that the sample underwent a sequence of rhombohedral (R) → monoclinic (Mc) → tetragonal (T) → cubic (C) phase transformations when the temperature increased from 25 °C to 170 °C. The results provide direct observation of the phase transition evolution of PZN-7%PT single crystals as a function of temperature, which is of great significance to fully understand the relationships between the domain structure and phase structure of PZN-7%PT single crystals. Full article

We report on the growth of stoichiometric, single-crystal YCrO₃ epitaxial thin films on (001) SrTiO₃ substrates using pulsed laser deposition. X-ray diffraction and atomic force microscopy reveal that the films grew in a layer-by-layer fashion with excellent crystallinity and atomically smooth surfaces. Magnetization measurements demonstrate that the material is ferromagnetic below 144 K. The temperature dependence of dielectric permittivity shows a characteristic relaxor-ferroelectric behavior at T_C = 375–408 K. A dielectric anomaly at the magnetic transition temperature indicates a close correlation between magnetic and electric order parameters in these multiferroic YCrO₃ films. These findings provide guidance to synthesize rare-earth, chromite-based multifunctional heterostructures and build a foundation for future studies on the understanding of magnetoelectric effects in similar material systems. Full article
